audio HONDA PILOT 2010 2.G Technology Reference Guide

Voice Command/HFL/Navigation
Using the Voice Command System
• Speak in a clear, natural voice.
• Reduce all background noise.
• Adjust the dashboard and sidevents away from the microphone in
the ceiling.
• Close the windows.
Voice Command
To reduce driver distraction, use voice commands for hands-free calling, \
navigation, audio, and climate
control functions. A full list of these commands is in the navigation system manual.
Voice Command Tips:
• Press and release the HFL or NAVI Talk button, wait for a
beep, then give a command.
• For a list of available HFL commands, press and release the HFL Talk button and say "Hands-free help."
• For a list of available navigation commands, press and release the NAVI Talk button and say "Voice command help."
HFL Talk button: Give HFL commands
or answer incoming calls.
HFL Back button: End a call, go back to
the previous command, or cancel an
operation. NAVI Talk button:
Give navigation, audio,
and climate control
commands.
NAVI Back button:
Cancel a command or
return to the previous
screen.
10 Pilot TRG_Base:Base 8/18/2009 9:30 AM Page 3 2010 Pilot

Commonly Used Voice Commands
Here are some examples of commonly used voice commands. Try some of these to familiarize yourself with
the voice command system.
Press and release the NAVI Talk button before you give a command.
Look for Restaurants in Your Location
Saya command like “Display Chinese restaurants” to
see restaurant icons appear on the map.
Adjust the Vehicle’s Climate Setting Make Audio Selections
Say
a command like “Radio 97.1 FM” or “CD play
track 5” to select that station or song.
Get Estimated Distance to Destination
After a destination is entered, say“How far to
destination?” to hear the remaining distance.
Say
a command like “Air conditioner on” and “Fan
speed 4” to adjust the setting to your liking.
10 Pilot TRG_3ab:ExtraPages.qxd 8/18/2009 9:37 AM Page e3 2010 Pilot

Commonly Used Voice Commands (continued)Navigation Commands
(Accepted on Map screen
after a destination is entered)
• How long/far to the destination?
• Display destination
• Display entire route
• Find nearest: - ATM
- gas station
- Mexican restaurant
- post office - bank
- Honda dealer
- airport
- hospital
Display Commands(Accepted on Map screen)
• Display (or hide):
- ATM
- gas station
- Mexican restaurant
- post office • Display north up/
heading up
• Zoom in/out
• Go home
• Display current location
• Display map
• Display menu
• Setup
• Information
• Display audio screen
• What time is it?
Press and release the NAVI Talk button before you give a command.
General Commands
(Accepted on most screens to change displays)
Find Place Commands(Accepted on Map screen)
10 Pilot TRG_3ab:ExtraPages.qxd 8/18/2009 9:37 AM Page f3 2010 Pilot

Voice Command/HFL/Navigation
Audio Commands(Accepted on most screens)
Commonly Used Voice Commands (continued)
Climate Control Commands
(Accepted on most screens)
• Brightness up/down
• Volume up/down/min/max/off • Interface dial
feedback on/off
• Guidance prompts min/max/normal
• Radio on
• Radio # FM/AM
• Radio preset
1/2/3/4/5/6
• XM channel # • XM preset 1/2/3/4/5/6
• CD play
• CD play track/disc #
• CD skip forward/back
• Auxiliary (AUX) play
Press and release the NAVI Talk button before you give a command.
Setup Commands
(Accepted on the Setup screen) • Air conditioner
on/off
• Rear defrost on/off
• Climate control recirculate/fresh air • Fan speed up/down
• Temperature #
degrees (# = 57–87)
• Temperature max hot/coldHelp Commands(Accepted on most screens)
• Help (list of available commands for currentscreen)
• Voice command help (list of all available navigation, audio, and climate control
commands)
10 Pilot TRG_Base:Base 8/18/2009 9:30 AM Page 4 2010 Pilot

Advanced AudioComponents
Playing an iPod®or USB Flash Memory Device (models with navigation)
2. Connect your USB connector to your flash
drive or iPod dock connector.
3. Push the CD/AUX button to begin playing.
USB Adapter Cable
USB Connector
Some of the same controls used to operate your in-dash CD player can als\
o operate some iPods or USB
flash memory devices.
Connecting and Beginning Play
1. Open the center console, and pull outthe
USB adapter cable.
10 Pilot TRG_Base:Base 8/18/2009 9:31 AM Page 5 2010 Pilot

2. Press the REAR CTRL OFF button to disable
rear audio controls.
3. Press the REAR SOURCE button to hear
what is currently playing in the rear.
Rear Entertainment System (RES) (if equipped)
With the rear entertainment system (RES) and wireless headphones, the rear passengers can enjoy a
different entertainment source than the front seat occupants.
Operating the RES from the Front Seat
1. Press the REAR PWR button. Rear
passengers will hear audio through the
wireless headphones.
4. After selecting an entertainment source for therear passengers, pressthe FRONT SOURCE
button to return to the front audio controls.
10 Pilot TRG_5ab_:ExtraPages.qxd 8/18/2009 9:37 AM Page a5 2010 Pilot

2. Press AM/FM, XM, CD, or DVD/AUX to make
a selection.
Operating the RES from the Rear Seat
1. Press the REAR PWR button from the front
audio panel, then pressthe PWR button on
the rear control panel to turn on the RES.
4. The rear control panel can be detached andused as a remote control. Pressthe
RELEASE button to remove it from the ceiling.
3. Use the (
) (
) (
) (
) buttons to navigate
the menu on the display. Press the ENT
button to select a function.
10 Pilot TRG_5ab_:ExtraPages.qxd 8/18/2009 9:39 AM Page b5 2010 Pilot

Advanced AudioComponents
Text Data Display Function (LX, EX, and EX-L)
For music CDs recorded with text data.
• Press the TITLE button to display the album, press it again to display the artist, and press once
more to display the track name.
• MP3 and WMA formats also show the folder when TITLE is pressed, and the file name when pressed again.
LX model shown
