Rearview Camera/Parking Sensors
Rearview Camera and Monitor (EX-L and Touring models)
2. The rear view is shown in the display area.
The display shows a view behind the vehicle.
To Turn the Camera On
1. Shift into Reverse (R).
To Turn the Display Off
All models: Shift out of Reverse.
EX-L models: Press the monitor on/off button
while in Reverse with your foot on the brake.
Press again to turn back on.
EX-L models Touring models
10 Pilot TRG_Base:Base 8/18/2009 9:31 AM Page 7 2010 Pilot

Rearview Camera/Parking Sensors
Parking Sensor System (Touring models)
Warns you of the proximity between your vehicle and nearby surrounding ob\
jects when parking or in Reverse.
To Turn the System On and Off
Press the parking sensor button. A
light appears when the system is on.
Corner Sensors Rear Center Sensors
Corner Sensor Indicator Rear Center Sensor Indicator Within about 24 in. (60 cm) Within about 40 in. (1 m)
How It Works
When the system senses an object, an indicator appears in the
MID and a beep sounds. As you get closer to an object, the
beep rate increases.
