HONDA PILOT 2012 2.G Owners Manual

µ
See pages f or important saf ety
inf ormation and warnings about how to properly position the seats and seat-backs.
Except LX models
On EX-L and Touring modelsExcept EX-L and Touring models
15 16
The controls f or the power
adjustable front seats are on the
outside edge of each seat bottom.
You can adjust the seats with the
ignition switch in any position. Make
all seat adjustments bef ore you start
driving.
The passenger seat has the same
adjustments as the driver

µ
See pages f or important saf ety
inf ormation and warnings about how to
properly position the seats and seat-backs.
Except EX-L and Touring models
15 16
Make all seat adjustments bef ore
you start driving.
Moves the seat forward
and backward. Moves the whole seat up
and f orward, or down
and backward. The front
of the seat also tilts up or
down at the same time.
Moves the f ront of the
seat up or down.
Raises or lowers the seat. Adjusts the seat-back
angle f orward or
backward.
Increases or decreases
the lumbar support.
(Driver

The height of your driver

CONT INUED
The head restraints adjust f or height.
You need both hands to adjust the
restraint.Donotattempttoadjustit
while driving. To raise it, pull upward.
To lower the restraint, push the
release button sideways, and push
the restraint down.
Your vehicle is equipped with head
restraints in all seating positions to
help protect you and your
passengers f rom the likelihood of
whiplash and other injuries.
They are most ef f ective when you
adjust them so the center of the back
of the occupant

To remove a head restraint f or
cleaning or repair, pull it up as f ar as
it will go. Push the release button,
then pull the restraint out of the seat-
back.
To lower the restraint, push short
side of the cap and pry up on long
side of the cap. Push the release
buttons sideways, and push the
restraint down. Push short side of the cap and pry up
on long side of the cap. Push the
release buttons, then pull the
restraint out of the seat-back.
Third Row Center Seat
Third Row Center Seat
Seats
Removing t he Head Rest raint
158
CUSHION
RELEASE BUTTON
LEGS
Second center and third row
LONG
SHORT
Main MenuTable of Contents

When reinstalling a head restraint,
put the legs back in place. Then
adjust it to the appropriate height
while pressing the release button.
When reinstalling a head restraint,
install the cap with the long side
toward the release button. Then
adjust it to the appropriate height
while pressing the release buttons.
Make sure the head restraint locks
in position when you reinstall it.The driver

For a head restraint system to work
properly:Do not hang any items on the head
restraints, or f rom the restraint
legs.
Do not place any object between
an occupant and the seat-back.
Install each restraint in its proper
location.
Only use genuine Honda
replacement head restraints. To adjust the second row seats f orward and backward, pull up on the
bar under the f ront edge of the seat
cushion. Move the seat to the
desired position and release the bar.
Trytomovetheseattomakesureit
is locked in position. To change the seat-back angle of the
seats in the second row, pull up on
the handle on the outside of the seat-
back, and push the seat-back.
Seats
Adjusting the Second Row Seats
160
HANDLE
Main MenuTable of Contents

The left and right halves can be
f olded separately.To unlatch the detachable anchor
bef ore f olding the seat-back, insert
the latch plate into the slot on the
side of the anchor buckle (see
page ) and allow the seat belt
to retract. Store the detachable
anchor and seat belt latch plates in
the retractor housing.
Lower the head restraints to their
lowest positions.
Pull up the handle on the outside
of the seat-back.
Fold the seat-back forward. Reverse this procedure to return the
seat to the upright position. Make
sure the seat is locked securely
bef ore driving.
Make sure that the folded seat-back
does not press against the f ront
passenger

Use the latch plate to release the
seat belt from the detachable
anchor (see page ).
Lower the head restraints to their
lowest positions.To f old the third row seat,
the second row seat-back must be
f olded down or in the f ull up right
position.
Unlock the seat-back by pulling
the handle. Push the seat-back
forward.
Make sure the outer shoulder belts
are positioned in each holding slot on
the side panel whenever the third
seat is f olded. Reverse this procedure to return the
seat to the upright position. Make
sure the seat is locked securely
bef ore driving. Reconnect the seat
belts to the detachable anchors.
Make sure all items in the cargo area
are secured. Loose items can f ly
f orward and cause injury if you have
to brake hard (See
on page ).
1. 2.
3.
163
506
Folding the T hird Row Seat
Carrying Cargo
Seats
162
NOTE:
HANDLE
Third seat
Main MenuTable of Contents

The seat belts in the second row
center seat and the third row seats
are equipped with detachable
anchors.
To unlatch the detachable anchor,
insert the latch plate into the slot on
the side of the anchor buckle. Store
the detachable anchor and seat belt
latch plates in the retractor housing.When the seats are returned to the
upright position, these detachable
anchors should be latched back
properly.
If any children are riding in the rear
seats, be sure that any unused seat
belts are either buckled, the lockable
retractor activated, and the belt fully
retracted, or in the case of any
unused detachable center belts,
stored in the roof slots so they are
out of reach. See page f or
additional information.
24
CONT INUED
Detachable Anchor
Seats
Inst rument s and Cont rols
163
LATCH PLATE
Using the seat belt with the
detachable anchor unlatched
increases the chance of serious
injury or death in a crash.
Before using the seat belt,
make sure the detachable
anchor is correctly latched.
