Fuses

All the electrical circuits in your
car have fuses to protect them
from a short circuit or overload.
These fuses are located in two fuse

boxes.

The underhood fuse box is locatedin the engine compartment next to
the battery. To open, push the tab

as shown.
The interior fuse box is underneath
the dashboard on the driver's side.
To open, turn the knob as shown.

CONTINUED
Taking Care of the Unexpected

UNDERHOOD

TAB

KNOB

INTERIORProCarManuals.comMain Menu Table of Contents s t

Fuses

Checking and Replacing
Fuses
If something electrical in your car
stops working, the first thing you
should check for is a blown fuse.
Determine from the chart on the
fuse box cover or inside the fuse
box which fuse or fuses control
that component. Check those fuses
first, but check all the fuses before deciding that is not the cause.
Replace any blown fuses and check
the component's operation.
1. Turn the ignition switch to LOCK (0). Make sure the head-
lights and all other accessories
are
off.

2. Remove the cover from the fuse box. 3. Check each of the large fuses in
the underhood fuse box by
looking through the top at the
wire inside. Removing these
fuses requires a phillips-head
screwdriver. 4. Check the smaller fuses in the
underhood fuse box and all the
fuses in the interior fuse box bypulling out each fuse with the
fuse puller provided in the interior fuse box.

Taking Care of the Unexpected
BLOWN
FUSE PULLERProCarManuals.comMain Menu Table of Contents s t

Index

5-Speed Transmission,
Shifting the ............................... 111

Flashers, Hazard
Warning ........... 56
Flat Tire, Changing a..................
185
Fluids Automatic Transmission.......
. 144
Brake.......................................... 146
Clutch......................................... 147
Manual Transmission.............. 145
Power Steering......................... 148
Windshield Washer..................
155
FM Stereo
Radio

Reception.............................. 75, 84

Folding Rear Seat.......................... 55
Foreign Countries, Driving in...... 99
Four-way Flashers......................... 56
Four Wheel Steering (4WS)
Description................................ 210

Indicator Light........................... 35

Operation...................................
118

Front End ,
Towing by Emergency

Wrecker..................................... 202

Fuel................................................... 9
8

Fille
r Door and Cap..................
100

Filter........................................... 150

Gauge............................................ 3
8
Octan
e Requirement................. 98

Oxygenated................................. 98

Tank, Filling the ...................... 100

Fuses, Checking the .................... 200

Gas Mileage, Improving.............. 104

Gasohol............................................ 98

Gasoline............................................ 98
Filter...........................................
150

Gauge............................................ 3 8

Octan
e Requirement................. 98
Tank, Filling the ......................
100
Gas Statio n
Procedures...............
100

Gauges

Engine Coolan
t Temperature.. 38

Fuel............................................... 38

Gearshift Lever Positions Automatic Transmission........
112

5-speed Transmission............. .

111

Glass Cleaning.............................
.

180

Glove Box........................................
.
62
Halogen Headlight Bulbs............ 164

Hazard Warning Flashers ............ 56

Headlights
Daytime Running Lights.......... 40

High Beam Indicator................. 35

High Beams, Turning on.......... 40
Low Beams, Turning on........... 40

Reminder Chime........................ 40

Replacing Halogen Bulbs ....... 164

Turning on.................................. 40

Heating and Cooling...................... 68

High Altitude, Starting at...........
110

High-Low Bea m
Switch ............... 40
Hood, Opening the........................
101

Horn.................................................. 4 7

Ho
t Coolant, Warning about......
139

Hydraulic Clutch.........................
.

147

Hydroplaning................................. 119

Identification Number
,

Vehicle......................................
.
204

If You
r
Car Has to be Towed ....
202
