Page 203 of 293
Battery
, Wipe r Blade s
If your car's battery is disconnected
or goes dead, the audio system willdisable itself. The next time you turn on the radio you will see
in the frequency display. Use the Preset buttons to enter the five-digit
code (see page 123 ).
Charging the battery with the cables
connected can seriously damage your
car's electronic controls. Detach the
battery cables before connecting the
battery to a charger.
Wipe
r Blade s
Check the condition of the wiper
blades at least every six months. Look for signs of cracking in the
rubber, or areas that are getting
hard. Replace the blades if you find these signs, or they leave streaksand unwiped areas when used.
Maintenanc e
The battery gives off explosive
hydrogen gas during normal
operation.
A spark or flame can cause the battery to explode with enough
force to kill or seriously hurt you.
Wear protective clothing and a
face shield, or have a skilled mechanic do the battery
maintenance.
NOTIC
E
Page 205 of 293
Wipe
r Blades , Ai r Conditionin g Syste m
4. Examine the new wiper blades. If they have no plastic or metal rein-
forcement along the back edge,
remove the metal reinforcement strips from the old wiper blade and
install them in the slots along the edge of the new blade. 5. Slide the new wiper blade into the
holder until the tabs lock.
6. Slide the wiper blade assembly onto the wiper arm. Make sure it
locks in place.
7. Lower the wiper arm down against the windshield.Lower the passenger's side first,
then the driver's side. Ai
r Conditionin g Syste m
Your car's air conditioning is a sealed system. Any major maintenance,
such as recharging, should be done
by a qualified mechanic. You can do a couple of things to make sure theair conditioning works efficiently.
Maintenanc e
BLAD
E
REINFORCEMEN T
AI
R CONDITIONIN G CONDENSE R
Page 238 of 293
Takin
g Car e o f th e Unexpecte d
This section covers the more- common problems that motorists
experience with their vehicles. It
gives you information about how to safely evaluate the problem and what
to do to correct it. If the problem has stranded you on the side of the road,
you may be able to get going again. If not, you will also find instructions
on getting your car towed. Compact Spare Tire....................... 236
Changing a Flat Tire ..................... 237
If Your Engine Won't Start........... 242
Nothing Happens or theStarter Motor OperatesVery Slowly............................. 243
The Starter Operates Normally................................. 244
Jump Starting................................. 244 If Your Engine Overheats............. 246Low Oil Pressure Indicator.......... 248
Charging System Indicator........... 249
Malfunction Indicator Lamp ........ 250
Brake System Indicator................ 251
Closing the Moonroof................... 252
Fuses...............................................253
Checking and Replacing........... 254
Emergency Towing....................... 258
Takin g Car e o f th e Unexpecte d
Page 252 of 293
Chargin
g Syste m Indicato r
This indicator should come on when the ignition switch is ON (II), and go
out after the engine starts. If it
comes on brightly when the engine
is running, it indicates that the
charging system has stopped charging the battery. Immediately turn off all electrical
accessories: radio, heater, A/C, rear
clefogger, cruise control, etc. Try not
to use other electrically-operated controls such as the power windows.
Keep the engine running and take
extra care not to stall it. Starting the
engine will discharge the battery
rapidly. By eliminating as much of the
electrical load as possible, you can
drive several miles (kilometers)
before the battery is too discharged
to keep the engine running. Drive to a service station or garage where
you can get technical assistance.
Takin g Car e o f th e Unexpecte d
CHARGIN
G SYSTE M INDICATO R
Page 285 of 293
Inde
x
Battery Charging SystemIndicator............................ 55, 249
Jump Starting............................. 244 Maintenance............................... 198
Specifications............................. 265
Before Driving............................... 125
Belts, Seat........................................... 8
Beverage Holder.............................. 91
Body Repair.................................... 233
Brakes
Anti-lock System (ABS)............ 154
Break-in, New Linings .............. 126
Fluid............................................ 193
Light, Burned-out....................... 219
Parking..........................................89
System Indicator.......................... 55
Wear Indicators......................... 153
Brakes, ABS Operation.................................... 154
System Indicator.................. 56, 156
Braking System.............................. 153
Break-in, New Car......................... 126
Brightness Control, Instruments... 63 Brights, Headlights......................... 62
Bulb Replacement
Back-up Lights........................... 219
Brake Lights............................... 219
Ceiling Lights............................. 223
Courtesy Lights......................... 223
Front Parking Lights................. 216
Front Side Marker Lights......... 217
Headlights.................................. 214
High-mount Brake Light.......... 221
License Plate Light.................... 222
Rear Side Marker Lights.......... 219
Specifications............................. 265
Trunk Light................................ 224
Turn Signal Lights..................... 218
Bulbs, Halogen............................... 214
Cables, Jump Starting With.......... 244
Capacities Chart............................. 264
Carbon Monoxide Hazard.............. 49
Cargo, Loading............................... 135
Cassette Player
Care............................................. 122
Operation.................................... 119
CAUTION, Explanation of ............... ii
CD Changer.................................... 114
CD Player........................................ 112
Certification Label......................... 262
Chains............................................. 210
Change Oil How to......................................... 183
When to....................................... 172
Changing a Flat Tire..................... 237
Changing Engine Coolant............. 187
Charging System Indicator .... 55, 249
Checking Automatic Transmission
Fluid........................................ 191
Battery Condition...................... 198
Brake Fluid................................. 193 Clutch Fluid................................ 194
Drive Belts.................................. 204
Engine Coolant........................... 131
Engine Oil................................... 130
Fuses...........................................254
Manual Transmission Fluid ..... 192
Power Steering Fluid................. 194
Checklist, Before Driving............. 140
Child Safety...................................... 21
Cleaner, Air.................................... 195
Page 286 of 293
Inde
x
Cleaning
Aluminum Wheels..................... 229
Carpeting.................................... 230
Exterior....................................... 228
Fabric.......................................... 230
Interior........................................ 230
Seat Belts.................................... 23
1
Vinyl............................................ 230
Windows..................................... 231
Clock, Settin
g the ............................ 90
Clutch Fluid.................................... 194
Coin Box........................................... 93
CO in the Exhaust......................... 270
Cold Weather, Starting in.............
141
Compact Spare............................... 236
Consumer Information*................
274
Controls, Instruments and.............. 51
Coolant
Adding......................................... 185
Checking.....................................
131
Proper Solution.......................... 185
Replacing.................................... 187
Temperatur
e Gauge.................... 59
Corrosion Protection..................... 232
Courtesy Lights............................... 95 Crankcase Emission Control
System.........................................270
Cruise Control Operation............... 67
Customer Relations Office........... 274
DANGER, Explanation of.................
ii
Dashboard........................................ 52
Daytime Running Lights................
. 62
Dead Battery, What to Do............ 244
Defects, Reporting Safety............. 278 Defog and Defrost......................... 104
Defogger, Rear Window................. 65
DEXRON ®
III Automatic
Transmission Fluid.................... 19
1
Dimensions..................................... 264
Dimming the Headlights................
62
Dipstick Automatic Transmission........... 19
1
Engine Oil...................................130
Directional Signals...........................
63
Disabled, Towing Your Car If...... 258
Disc Brake Wear Indicators......... 153
Disposal of Used Oil...................... 184 Doors
Locking and Unlocking............... 7
4
Power Door Locks....................... 7
4
DOT Tire Quality Grading...........
266
Downshifting, 5-speed Manual
Transmission.............................. 14 2
Driv
e Belts...................................... 204
Driving............................................ 139
Economy..................................... 132
In Bad Weather.......................... 158
In Foreign Countries................. 269
Economy, Fuel............................... 132
Emergencies on the Road............. 235 Batteiy, Jump Starting.............. 244
Brake System Indicator............ 251Changing a Flat Tire................. 237
Charging System Indicator ...... 249
Checking the Fuses................... 254
Low Oil Pressure Indicator...... 248
Malfunction Indicator Lamp .... 250
Manually Closing Moonroof .... 252
Overheated Engine................... 246
CONTINUED
