Additional Informatio n Abou t You r SR S
Ho w th e SR S Indicato r
The purpose of the SRSlight is to alert you to a
potential problem with your Supplemental Restraint System.
When you turn the ignition ON (II), this indicator will light up briefly
then go out. This tells you that the system is working properly.
However, if the light comes on at any
other time, you should have the system checked by your dealer. For
If the SRS indicator light does not
come on after
turn the ignition
If the light
stays on after the
engine starts. If the light comes on or flashes on
and off while you drive.
If you see any of these indications,
your airbags may not deploy when
you need them. See your Honda dealer as soon as possible. SR
S Servic e
Your Supplemental Restraint System is virtually maintenance-free, and
there are no parts you can safely service. However, you must have
your car serviced if:
Your airbags ever inflate. The
airbags and the control unit must
be replaced. Do not try to remove or replace the airbags yourself.
This must be done by a Honda dealer or a knowledgeable body
The SRS indicator light alerts you
to a problem. Take your car to an
authorized Honda dealer as soon
as possible. If you ignore this
indication, the airbags might not
inflate when you need them (see
Drive r an d Passenge r Safet y
Ignoring the SRS indicator light
can result in serious injury or
death if the airbags do not inflate when needed.
Have your vehicle checked by a
dealer as soon as possible if
the SRS light alerts you to a potential problem.
Page 62 of 293
Fue l Gaug e
This shows how much fuel you have. It is most accurate when the car is on
level ground. It may show slightly more or less than the actual amount
when you are driving on curvy or hilly roads. The gauge stays at the same fuel
level reading after you turn off theignition. When you add fuel, the
gauge slowly changes to the new
reading after you turn the ignition switch back ON (II). Temperatur
e Gaug e
This shows the temperature of the engine's coolant. During normal
operation, the pointer should rise
from the bottom white mark to about the middle of the gauge. In severedriving conditions, such as very hot
weather or a long period of uphill driving, the pointer may rise to near
the upper white mark. If it reaches
the red (Hot) mark, pull safely to the side of the road. Turn to page 246 for
instructions and precautions on
checking the engine's cooling
Instrument s an d Control s
L GAUG E
P METE R
GAUG E MAINTENANC
REQUIRE D INDICATO R
R TRIP METE R
RESE T BUTTO N
Page 128 of 293
e Drivin g
Before you begin driving your Honda,
you should know what gasoline to use, and how to check the levels of
important fluids. You also need to
know how to properly store luggageor packages. The information in this
section will help you. If you plan to
add any accessories to your car,
please read the information in this
Break-in Period.............................. 126
Service Station Procedures .......... 127 Filling the Fuel Tank................. 127
Opening the Hood..................... 128
Oil Check................................ 130
Engine Coolant Check.......... 131
Fuel Economy................................ 132
Vehicle Condition...................... 132
Driving Habits............................ 132
Accessories and Modifications.... 133
Accessories................................. 133Modifications............................. 134
Additional Safety Precaution.... 134
Carrying Cargo.............................. 135
Load Limit.................................. 136
Carrying Items in the Passenger Compartment......................... 136
Carrying Cargo in the Trunk or
on a Roof Rack....................... 137
Before Drivin g
Page 133 of 293
e Statio n Procedure s
Check the engine oil level every time
you fill the car with fuel. Wait a few
minutes after turning the engine off
before you check the oil.
1. Remove the dipstick (orange handle). 2. Wipe the dipstick with a clean
cloth or paper towel. 3. Insert it all the way back in its tube.
Befor e Drivin g
Page 134 of 293
Statio n Procedure s
4. Remove the dipstick again and check the level. It should be
between the upper and lower
If it is near or below the lower mark, see Addin g Oi l on page 181.
Engine Coolant Check
Look at the coolant level in the
radiator reserve tank. Make sure it is
between the MAX and MIN lines. If
it is below the MIN line, see Addin g
Engin e Coolan t on page 185 for
information on adding the proper
Refer to Owne
r Maintenanc e
Check s on page 179 for information
on checking other items in your
Before Drivin g
R MAR K
LOWE R MAR K
RESERVE TAN K
Page 135 of 293
Fuel Econom y
The condition of your car and your
driving habits are the two most
important things that affect the fuel
mileage you get.
Vehicl e Conditio n
Always maintain your car according to the maintenance schedule. This
will keep it in top operating condition.
An important part of that mainte- nance is the Owne r Maintenanc e
Check s (see page 179). For
example, an underinflated tire
causes more "rolling resistance,"
which uses fuel. It also wears out faster, so check the tire pressure at
In winter, the build-up of snow on
your car's underside adds weight and rolling resistance. Frequent cleaning
helps your fuel mileage and reduces
the chance of corrosion. Drivin
g Habit s
You can improve fuel economy by driving moderately. Rapid acceler-
ation, abrupt cornering, and hard
braking use more fuel.
Always drive in the highest gear that allows the engine to run and acceler-
Depending on traffic conditions, try
to maintain a constant speed. Every
time you slow down and speed up,
your car uses extra fuel. Use the cruise control, when appropriate, toincrease fuel economy. A cold engine uses more fuel than a
warm engine. It is not necessary to "warm-up" a cold engine by letting it
idle for a long time. You can drive
away in about a minute, no matter
how cold it is outside. The engine
will warm up faster, and you get
better fuel economy. To cut down on the number of "cold starts," try to
combine several short trips into one.
The air conditioning puts an extra load on the engine which makes ituse more fuel. Turn off the A/C to
cut down on air conditioning use.Use the flow-through ventilation
when the outside air temperature is moderate.
Befor e Drivin g
Page 143 of 293
Preparing to Driv e
You should do the following checks
and adjustments every day before
you drive your car.
1. Make sure all windows, mirrors, and outside lights are clean and
unobstructed. Remove frost, snow,
2. Check that the hood and trunk are fully closed.
3. Visually check the tires. If a tire looks low, use a gauge to check its
4. Check that any items you may becarrying with you inside are stored
properly or fastened down
5. Check the adjustment of the seat (see page 80).
6. Check the adjustment of the inside and outside mirrors (see
7. Check the adjustment of the steering wheel (see page 66 ).
8. Make sure the doors are securely closed and locked.
9. Fasten your seat belt. Check that your passengers have fastenedtheir seat belts (see page 16 ).10. Turn the ignition switch ON (II). Check the indicator lights in the
11. Start the engine (see page 141).
12. Check the gauges and indicator lights in the instrument panel (see
Page 154 of 293
c Transmissio n
Shif t Loc k Releas e
This allows you to move the shift lever out of Park if the normal
method of pushing on the brake
pedal does not work. This procedure
also releases the Reverse Lockout.
1. Set the Parking brake.
2. Make sure the key is in the
ignition switch OFF (0) position.
To release the Reverse Lockout,
make sure the key is in the
ACCESSORY (I) position.
3. Put a cloth on the edge of the Shift Lock Release slot cover next to
the shift lever.
Use a small flat-tipped screwdriver
or small metal plate (neither are
included in the tool kit) to remove
the cover. Carefully pry off the
edge of the cover. 4. Insert a screwdriver in the shift
lock release slot.
5. Push down on the screwdriver and move the shift lever out of Park to
To release the Reverse Lockout, move the shift lever from Neutral
to Reverse, then Park. 6. Remove the screwdriver from the
shift lock release slot, then install
a new cover.
Depress the brake pedal and
restart the engine.
If you need to use the Shift Lock Release, it means your car is
developing a problem. Have the car
checked by your Honda dealer.
T LOC K
RELEAS E SLO T
Page 156 of 293
e Brakin g Syste m
Your Honda is equipped with disc brakes at all four wheels. A powerassist helps reduce the effort needed
on the brake pedal. The ABS helps
you retain steering control when
braking very hard.
Put your foot on the brake pedal only
when you intend to brake. Resting
your foot on the pedal keeps the
brakes applied lightly, causing them
to build up heat. Heat build-up can
reduce how well your brakes work. It also keeps your brake lights on all
the time, confusing drivers behind
Constant application of the brakes
when going down a long hill builds up heat and reduces their effective-
ness. Use the engine to assist the
brakes by downshifting to a lower
gear and taking your foot off the accelerator pedal.
Check your brakes after driving
through deep water. Apply the
brakes moderately to see if they feel normal. If not, apply them gently and
frequently until they do. Since a
longer distance is needed to stop
with wet brakes, be extra cautious and alert in your driving. Brak
e Wea r Indicator s
All four brakes have audible brake wear indicators.
When the brake pads need replacing,
you will hear a distinctive metallic "screeching" sound when you apply
the brakes. If you do not have the
brake pads replaced, they will begin screeching all the time.
Your brakes may sometimes squeal or squeak when you apply them
lightly. Do not confuse this with the
brake wear indicators. They make a
very audible "screeching."
Page 160 of 293
e Torqu e Transfe r Syste m
Type SH only
Your Honda is equipped wit
Active Torque Transfer System (ATTS). Under certain driving
conditions, the ATTS enhances the car's cornering performance by
transferring some torque between
the inside and outside front wheels during a turn.
Based on steering wheel turn angle,
lateral acceleration, and engine
power, the ATTS regulates the driving force to each drive wheel
through an electronically-controlled
hydraulic system and two sets of clutches and gears.
Important Safety Information
Th e ATT S canno t preven t
skiddin g if yo u ente r a corne r to o
fast . It has almost no effect on
braking and vehicle speed.
It is still your responsibility to drive
at reasonable speeds and to leave a
sufficient margin of safety.
The Active Torque Transfer System (ATTS) is self-checking. If a problem
is detected in the system, the ATTS
indicator on the instrument panel
If this happens, take the car to your Honda dealer to have it checked.
With the indicator on, your car will corner normally, but you will not
have active torque transfer.
S INDICATO R
