Fuse
s

All the electrical circuits in your car have fuses to protect them from ashort circuit or overload. These
fuses are located in two fuse boxes.
The under-hood fuse box is locatedin the back of the engine compart-ment on the passenger's side. Toopen it, push the tab as shown. The interior fuse box is underneath
the dashboard on the driver's side.
To open it, turn the knob as shown.
Takin g Car e o f th e Unexpecte d
UNDER-HOO
D
TA
B

INTERIO R

KNOB

Fuse
s

Checkin g an d Replacin g Fuse s

If something electrical in your car stops working, the first thing you
should check for is a blown fuse.
Determine from the chart on pages 256 and 257 , or the diagram o n the
fuse box lid, which fus
e or fuses
control that component. Check those
fuses first, but check all the fuses before deciding that a blown fuse is
not the cause. Replace any blown
fuses and check the component's
operation.

1. Turn the ignition switch to LOCK (0). Make sure the headlights and
all other accessories are off.
2. Remove the cover from the fuse box.
FUS
E

3. Check each of the large fuses in the under-hood fuse box by
looking through the top at the wire
inside. Removing these fusesrequires a Phillips-head screw-
driver.
4. Check the smaller fuses in the
under-hood fuse box and all the
fuses in the interior fuse box by
pulling out each fuse with the fuse
puller provided in the interior fuse
box.
Takin g Car e o f th e Unexpecte d
BLOW
N
FUS
E PULLE R

Inde
x

Cleaning
Aluminum Wheels..................... 229
Carpeting.................................... 230
Exterior....................................... 228
Fabric.......................................... 230
Interior........................................ 230
Seat Belts.................................... 23
1

Vinyl............................................ 230
Windows..................................... 231

Clock, Settin
g the ............................ 90

Clutch Fluid.................................... 194
Coin Box........................................... 93
CO in the Exhaust......................... 270
Cold Weather, Starting in.............

141

Compact Spare............................... 236
Consumer Information*................
274
Controls, Instruments and.............. 51

Coolant
Adding......................................... 185

Checking.....................................

131

Proper Solution.......................... 185
Replacing.................................... 187
Temperatur
e Gauge.................... 59
Corrosion Protection..................... 232
Courtesy Lights............................... 95 Crankcase Emission Control

System.........................................270

Cruise Control Operation............... 67
Customer Relations Office........... 274
DANGER, Explanation of.................

ii

Dashboard........................................ 52
Daytime Running Lights................
. 62
Dead Battery, What to Do............ 244
Defects, Reporting Safety............. 278 Defog and Defrost......................... 104
Defogger, Rear Window................. 65
DEXRON ®
III Automatic
Transmission Fluid.................... 19

1

Dimensions..................................... 264
Dimming the Headlights................
62
Dipstick Automatic Transmission........... 19

1

Engine Oil...................................130
Directional Signals...........................
63
Disabled, Towing Your Car If...... 258
Disc Brake Wear Indicators......... 153
Disposal of Used Oil...................... 184 Doors
Locking and Unlocking............... 7

4

Power Door Locks....................... 7
4

DOT Tire Quality Grading...........
266

Downshifting, 5-speed Manual
Transmission.............................. 14 2

Driv
e Belts...................................... 204

Driving............................................ 139

Economy..................................... 132
In Bad Weather.......................... 158
In Foreign Countries................. 269

Economy, Fuel............................... 132

Emergencies on the Road............. 235 Batteiy, Jump Starting.............. 244
Brake System Indicator............ 251Changing a Flat Tire................. 237
Charging System Indicator ...... 249
Checking the Fuses................... 254
Low Oil Pressure Indicator...... 248
Malfunction Indicator Lamp .... 250
Manually Closing Moonroof .... 252

Overheated Engine................... 246

CONTINUED

Inde
x

Emergency Brake............................ 89
Emergency Flashers....................... 65
Emergency Towing....................... 258
Emission Controls......................... 270
Engine Coolant Temperature Gauge ..... 59

Malfunction Indicator
Lamp................................. 55, 250
Oil Pressure Indicator......... 55, 248
Oil, What Kind to Use............... 181
Overheating................................ 246

Specifications............................. 264

Ethanol in Gasoline ....................... 268
Evaporative Emission Controls.... 270
Exhaust Fumes................................ 49
Expectant Mothers, Use of Seat Belts by......................................... 19
Exterior. Cleaning the................... 228
Fabric, Cleaning............................. 230

Fan, Interior...................................... 98

Features, Comfort and
Convenience.................................
97

Filling the Fuel Tank.....................
127

Filters
Air................................................ 195

Oil................................................ 183

First
Gear, Shifting........................ 150
5-speed Manual Transmission Checking Fluid Level................ 192

Shifting the................................. 142

Flashers, Hazard Warning.............. 65

Flat Tire, Changing a.................... 237

Fluids Automatic Transmission........... 191
Brake........................................... 193

Clutch.......................................... 194

Manual Transmission............... 192

Power Steering........................... 194

Windshield Washer................... 190
FM Stereo Radio
Reception.................................... 110

Folding Rear Seat............................ 84
Foreign Countries, Driving in...... 269
Four-way Flashers........................... 65

Front End, Towing by
Emergency Wrecker................. 258

Fuel.................................................. 126
Fill Door and Cap....................... 127
Gauge............................................ 59
Octane Requirement................. 126

Oxygenated................................ 268

Reserve Indicator......................... 57

Tank, Filling the......................... 127

Fuses, Checking the...................... 254
Gas Mileage. Improving................ 132

Gasohol........................................... 268

Gasoline.......................................... 126
Fuel Reserve Indicator................ 57

Gauge............................................ 59

Octane Requirement................. 126

Tank, Filling the......................... 127

Gas Station Procedures................. 127

Gauges
Engine Coolant Temperature .... 59

Fuel................................................ 59

Gearshift Lever Positions Automatic Transmission........... 144
5-speed Manual Transmission.......................... 142
Glass Cleaning............................... 231
Glove Box......................................... 79
