2000 Prelude Online Reference Owner's Manual
Use these links (and links throughout this manual) to navigate through\
this reference.
For a printed owner's manual, click on authorized manuals or go to www.h\
elminc.com.
Contents

Owner's Identification Form
Introduction ........................................................................\
................................................................. i
A Few Words About Safet y........................................................................\
.........................................ii
Your Vehicle at a Glance........................................................................\
............................................ .2
Driver and Passenger Safety ........................................................................\
......................................5
Proper use and care of your vehicle's seat belts, and Supplemental Restr\
aint System.
Instruments and Controls........................................................................\
........................................ .51
Instrument panel indicator and gauge, and how to use dashboard and steering colu\
mn controls.
Comfort and Convenience Features ........................................................................\
........................ 97
How to operate the climate control system, the audio system, and other c\
onvenience features.
Before Driving........................................................................\
..........................................................125
What gasoline to use, how to break-in your new vehicle, and how to load luggage and other cargo.
Driving ........................................................................\
..................................................................... .139
The proper way to start the engine, shift the transmission, and park, pl\
us towing a trailer.
Maintenance........................................................................\
.............................................................167
The Maintenance Schedule shows you when you need to take yo ur vehicle to the dealer.
Appearance Care........................................................................\
..................................................... .227
Tips on cleaning and protecting your vehicle. Things to look for if your\
vehicle ever needs body repairs.
Taking Care of the Unexpected........................................................................\
..............................235
This section covers several problems motorists sometimes experience, a nd how to handle them.
Technical Information........................................................................\
............................................ .261
ID numbers, dimensions, capacities, and technical information.
Warranty and Customer Relations (U.S. and Canada)................................................................273
A summary of the warranties covering your new Acura, and how to contact \
us.
Authorized Manuals (U.S. only)........................................................................\
..............................279
How to order manuals and other technical literature.
Index........................................................................\
........................................................................\
...... I
Service Information Summary
A summary of information you need when you pull up to the fuel pump.

Drive
r an d Passenge r Safet y

This section gives you important information about how to protect
yourself and your passengers. It shows you how to use seat belts
properly. It explains your Supple- mental Restraint System. And it tells
you how to properly restrain infants and children in your car.
Important Safety Precautions .......... 6
Your Car's Safety Features ..............
7

Seat Belts........................................
8

Airbags............................................
9

Seats & Seat-Backs......................
1 0

Head Restraints...........................
10

Door Locks...................................
11

Pre-Drive Safety Checklist......... 11

Protectin
g Adults............................. 12

1. Close and Lock the Doors......

12

2. Adjust the Front Seats..........
.. 13

3. Adjust the

Seat-Backs.............

14

4. Adjust the Head Restraints...
. 15

5. Fasten and Position the Seat
Belts...................................... 16

6. Adjust the
Steering Wheel.....

17

7. Maintain a Proper Sitting

Position................................
. 18
Advice for Pregnant Women...... 19 Additional Safety Precautions.... 19
Protecting Children.........................

21

All Children Must Be
Restrained................................

21

Children Should Sit in the
Back

Seat............................................

22

The Passenger's Airbag Poses Serious
Risks to Children.......

22

If You Must Drive wit

h Several
Children....................................

24

If a Child Requires Close
Attention...................................
24

Additional Safety Precaution...... 24

General Guidelines for Using
Child Seats................................25

Protecting Infants........................ 29

Protecting Small Children.......... 33 Protecting Larger Children........ 36

Using Child Seats with Tethers......................................40
Additional Information About Your
Seat Belts.................................. 42

Seat Belt System Components... 42

Lap/Shoulder Belt....................... 42

Seat Belt Maintenance................ 44

Additional Information About Your
SRS............................................45

SRS Components......................... 45 How Your Airbags Work............ 45
How the SRS Indicator Light
Works........................................47

SRS Service................................... 47
Additional Safety Precautions.... 48
Carbon Monoxide Hazard.............. 49
Safety Labels.................................... 50
Driver an d Passenge r Safet y

Additional Informatio n Abou t You r SR S

Ho w th e SR S Indicato r
Ligh
t
Work s
The purpose of the SRSlight is to alert you to a
potential problem with your Supplemental Restraint System.
When you turn the ignition ON (II), this indicator will light up briefly
then go out. This tells you that the system is working properly.
However, if the light comes on at any
other time, you should have the system checked by your dealer. For

example:
If the SRS indicator light does not
come on after

you
turn the ignition
ON

(II).
If the light
stays on after the
engine starts. If the light comes on or flashes on
and off while you drive.
If you see any of these indications,
your airbags may not deploy when
you need them. See your Honda dealer as soon as possible. SR
S Servic e
Your Supplemental Restraint System is virtually maintenance-free, and
there are no parts you can safely service. However, you must have
your car serviced if:
Your airbags ever inflate. The

airbags and the control unit must
be replaced. Do not try to remove or replace the airbags yourself.
This must be done by a Honda dealer or a knowledgeable body

shop.
The SRS indicator light alerts you

to a problem. Take your car to an
authorized Honda dealer as soon
as possible. If you ignore this
indication, the airbags might not
inflate when you need them (see
page 45).
Drive r an d Passenge r Safet y

SRS

Ignoring the SRS indicator light
can result in serious injury or
death if the airbags do not inflate when needed.
Have your vehicle checked by a
dealer as soon as possible if
the SRS light alerts you to a potential problem.

Break-i
n Period , Gasolin e

Break-i n Perio d

Help assure your car's future
reliability and performance by paying
extra attention to how you drive
during the first 600 miles (1,000 km).
During this period: Avoid full-throttle starts and rapid

acceleration.

Avoid hard braking. New brakes need to be broken-in by moderate
use for the first 200 miles (300

km).

You shoul
d follow these
same re-
commendations with an overhauled
or exchanged engine, or when the

brakes are relined.
Gasolin
e

Your Honda is designed to operate on premium unleaded gasoline with a
pump octane number of 91 or higher.
If you are unable to find premium
unleaded gasoline, you may substi-
tute an unleaded regular gasoline.
The engine will compensate for the lower octane, but you may notice aslight decrease in power as a result.
We recommend gasolines containing detergent additives that help prevent
fuel system and engine deposits.
Using gasoline containing lead willdamage your car's emissions In Canada, some gasolines contain
an octane-enhancing additive called
MMT. If you use such gasolines,
your emission control system performance may deteriorate andthe Malfunction Indicator Lamp on
your instrument panel may turn on. If this happens, contact yourauthorized Honda dealer for service.
Befor e Drivin g

Service Statio n Procedure s
5. Screw the fuel fill cap back on,
tighten it until it clicks severaltimes. If you do not properly
tighten the cap, the Malfunction
Indicator Lamp may come on (see
page 250).
6. Push the fuel fill door closed until it latches. Openin
g th e Hoo d
1. Shift to Park or Neutral and set the parking brake. Pull the hoodrelease handle located under the
lower left corner of the dashboard.
The hood will pop up slightly. 2. Standing in front of the car, put
your fingers under the front edgeof the hood to the right of center.
Slide your hand to the left until
you feel the hood latch handle. Push this handle up until it
releases the hood. Lift the hood.
Befor e Drivin g HOOD
RELEAS E HANDL E
LATCH

Chargin
g Syste m Indicato r

This indicator should come on when the ignition switch is ON (II), and go
out after the engine starts. If it
comes on brightly when the engine
is running, it indicates that the
charging system has stopped charging the battery. Immediately turn off all electrical
accessories: radio, heater, A/C, rear
clefogger, cruise control, etc. Try not
to use other electrically-operated controls such as the power windows.
Keep the engine running and take
extra care not to stall it. Starting the
engine will discharge the battery
rapidly. By eliminating as much of the
electrical load as possible, you can
drive several miles (kilometers)
before the battery is too discharged
to keep the engine running. Drive to a service station or garage where
you can get technical assistance.
Takin g Car e o f th e Unexpecte d
CHARGIN
G SYSTE M INDICATO R

Brak
e Syste m Indicato r

The Brake System indicator light comes on when you turn the ignitionON (II). If the parking brake is not
set, it goes off after you start the
engine. If the parking brake is set, it
goes off when you fully release the
parking brake with the engine running.
If it comes on at any other time, it
indicates a problem with the car's
brake system. In most cases, the
problem is a low fluid level in the brake fluid reservoir. Press lightly on
the brake pedal to see if it feels
normal. If it does, check the brake
fluid level the next time you stop at a service station (see page 193 ). If the
fluid level is low, take the car to your dealer and have the brake system
inspected for leaks or worn brake

pads.

However, if the brake pedal does not
feel normal, you should take
immediate action. Because of the
brake system's dual-circuit design, a
problem in one part of the system
will still give you braking at two wheels. You will feel the brake pedal
go down much farther before the car
begins to slow down, and you will
have to press harder on the pedal.
The distance needed to stop will be much longer.
Slow down by shifting to a lower
gear, and pull to the side of the road
when it is safe. Because of the longer distance needed to stop, it is
hazardous to drive the car. Youshould have it towed, and repaired as
soon as possible. (See Emergenc y
Towin g on page 258.)
If you must drive the car a short distance in this condition, drive
slowly and cautiously.
Takin g Car e o f th e Unexpecte d

BRAK
E SYSTE M INDICATO R

Inde
x

Protecting Adults............................. 12 Additional Safety Precautions.... 19
Advice for Pregnant Women...... 19
Protecting Children......................... 21 Protecting Infants........................ 29
Protecting Larger Children........ 37
Protecting Small Children.......... 33
Using Child Seats with Tethers...................................... 40
Radiator Overheating.................... 246 Radio/CD Sound System.............. 106
Rear End Towing........................... 258
Rear Lights, Bulb Replacement... 219

Rear Seat Access ............................. 81

Rear Seat, Folding........................... 84

Rear View Mirror............................. 88
Rear Window Defogger.................. 65
Reclining the Seat Backs................ 80
Recommended Shift Speeds ........ 143
Reminder Lights.............................. 53
Remote Transmitter........................ 75
Replacement Information Air Cleaner Element.................. 195
Coolant........................................ 187

Engine Oil and Filter................. 183

Fuses...........................................254

Light Bulbs................................. 214

Schedule..................................... 170

Spark Plugs................................. 196

Timing Belt................................. 204

Tires............................................ 208
Wiper Blades.............................. 200

Replacing Seat Belts After a
Crash.............................................44

Reserve Tank, Engine Coolant.... 131

Restraint, Child................................ 21

Reverse Gear Position................... 146

Rotation, Tire................................. 208

Safety Belts......................................... 8
Safety Features.................................. 7
Airbags............................................ 9Door Locks................................... 1
1

Head Restraints........................... 10
Seat Belts........................................
8
Seats & Seat-Backs...................... 10

Safety Labels, Location of.............. 50
Safety Messages................................

ii

Seat Belt, Additional Information..
4
2
Lap/Shoulder Belt....................... 42
Seat Belt Maintenance................ 44
Seat Belt System Components... 42
Seat Belts............................................8
Cleaning...................................... 231
Maintenance................................. 44
Reminder Light and Beeper....... 54
System Components.................... 42
Tether Attachment Points.......... 40
Use During Pregnancy................ 19
Seat Heaters..................................... 83
Seats, Adjusting the......................... 80
Sequential SportShift Mode ......... 147
Serial Number................................ 262
Service Intervals............................ 172

Service Manual* ............................ 279
Service Station Procedures .......... 127
Setting the Clock............................. 90
Shifting The Automatic Transmission .. 144
The 5-speed Manual
Transmission.......................... 142
Shift Lever Position Indicator...... 144
CONTINUED

Inde
x

Shift Lock Release......................... 151

Side Marker Lights, Bulb
Replacement in.......................... 217

Signaling Turns................................
63

Snow Tires...................................... 210

Solvent-type Cleaners....................
228

Sound System................................. 106

Spare Tire Inflating....................................... 236

Specifications............................. 265

Spark Plugs, Replacing................. 196

Specifications Charts ...........

264, 265

Speed Control................................... 67

Speedometer....................................
58

SRS, Additional Information........... 45 Additional Safety Precautions.... 48How the SRS Indicator Light
Works........................................ 47

HowYour Airbags Work............ 45

SRS Components......................... 45

SRS Service................................... 4

7

SRS Indicator.............................. 47, 55
START
(Ignition Key Position)..... 73

Starting the Engine........................ 141

In Cold Weather at HighAltitude................................... 141 With a Dead Battery................. 244
Steam Coming from Engine......... 246
Steering Wheel Adjustment................................... 66

Anti-theft Column Lock.............. 73

Stereo Sound System.................... 106

Storing Your Car............................ 225
Supplemental Restraint System..... 45
Servicing....................................... 47

SRS Indicator......................... 47, 55

Synthetic Oil................................... 182

Tachometer...................................... 58

Taillights, Changing Bulbs in....... 219
Taking Care of the
Unexpected................................ 235

Tape Player..................................... 119

Technical Descriptions

Emission Control Systems........ 270

Three Way Catalytic
Converter................................ 272
Temperature Gauge........................ 59

Tether Attachment Points.............. 40

Three Way Catalytic Converter... 272
Time, Setting the............................. 90

Timing Belt..................................... 204

Tire Chains..................................... 210
Tire, How to Change a Flat.......... 237
Tires................................................ 205
Air Pressure............................... 205Checking Wear.......................... 206

Compact Spare........................... 236

DOT Tire Quality Grading....... 266
Inflation....................................... 205

Inspection................................... 206

Maintenance............................... 207

Replacing.................................... 208
Rotating....................................... 208

Snow............................................ 210

Specifications............................. 265

Tire Chains................................. 210
Winter Driving........................... 209

Tools,Tire Changing.................... 237

Towing
ATrailer...................................... 160

Emergency................................. 258
