2008 Ridgeline Online Reference Owner's Manual
Contents

Owner's Identification Form

Introduction .......................................................................................................................................................... i A Few Words About Safety .............................................................................................................................. iii Important Handling Information .................................................................................................................... iv
Your Vehicle at a Glance (main controls) .................................................................................................... 3
Driver and Passenger Safety (seat belts, SRS, and child protection) .................................................... 5
Instruments and Controls
(indicators, gauges, dashboard, and steering column)
............................................ 57
Features (climate control
, audio, steering wheel, security, cruise control and Homelink)
...................................... 123
Before Driving (fuel, vehicle break- in, and cargo loading) ..................................................................... 179
Driving (engine and transmission operation) ................................................................................................ 197
Maintenance (minder, fluid checking, minor services, and vehicle storage)........................................... 237
Taking Care of the Unexpected (flat tire, dead battery, overheating, fuses) ...................................... 275
Technical Information (vehicle specifications, tires, and emissions controls) ....................................... 301
Warranty and Customer Relations (U. S. and Canada only) (warranty and contact information) ... 317
Authorized Manuals (U. S. only) (how to order) ......................................................................................... 321
Index ............................................................................................................................... ........................................ I

Service Information Summary ( fluid capacities and tire pressures)
1 00X31-SJC-6202

How to operate the heating and air
conditioning system, the audio
system, and other convenience
f eatures.
A convenient ref erence to the
sections in this manual.
A quick ref erence to the main
controls in your vehicle.
Explains the purpose of each
instrument panel indicator and gauge,
and how to use the controls on the
dashboard and steering column.The proper way to start the engine,
shif t the transmission, and park; plus
what you need to know if you’re
planning to tow a trailer.
ID numbers, dimensions, capacities,
and technical information.
How to order manuals and other
technical literature.
A summary of the inf ormation you
need when you pull up to the f uel
pump.
The maintenance minder shows you
when you need to take your vehicle
to the dealer for maintenance service.
There is also a list of things to check
and instructions on how to check
them.
A summary of the warranties
covering your new vehicle, and how
to contact us for any reason. Refer to
your warranty manual f or detailed
inf ormation.
This section covers several problems
motorists sometimes experience,
and details how to handle them.
Important inf ormation about the
proper use and care of your vehicle’s
seat belts, an overview of the
supplemental restraint system, and
valuable inf ormation on how to
protect children with child restraints. What gasoline to use, how to break-
in your new vehicle, and how to load
luggage and other cargo.
Contents
Your Vehicle at a Glance
Driver and Passenger Saf ety
Instruments and Controls
Features Bef ore Driving
Driving
Maintenance
T echnical Inf ormation
Warranty and Customer
Relations
(U.S. and Canada only)
Authorized Manuals
(U.S. only)
Index
Service Inf ormation Summary
T aking Care of the Unexpected
Overview of Contents
2
\f—\f—y
\fy
(\fy\f\f\fy
2008 Ridgeline

µµµ
µ µ
µ µ
µ
µ
The f ollowing f actors can lower your
vehicle’s f uel economy:
Aggressive driving (hard
acceleration and braking)
Excessive idling, accelerating and
braking in stop-and-go traf f ic
Cold engine operation (engines
aremoreefficientwhenwarmed
up)
Driving with a heavy load or the
air conditioner running
Improperly inf lated tires
A properly maintained vehicle
maximizes f uel economy. Poor
maintenance can signif icantly reduce
f uel economy. Always maintain your
vehicle according to the maintenance
messages displayed on the
inf ormation display (see on page ).
For example: An under-inf lated tire increases
‘‘rolling resistance,’’ which reduces
f uel economy.
It puts a heavier
load on the engine, increasing f uel
consumption. In
particular, a build-up of snow or
mud on your vehicle’s underside
adds weight and rolling resistance.
Frequent cleaning helps your f uel
economy.
Rapid
acceleration, abrupt cornering,
and hard braking increase fuel
consumption. Aerodynamic drag has a big ef f ect
on f uel mileage at speeds above 45
mph (75 km/h). Reduce your
speed and you reduce the drag.
Trailers, car top carriers, roof
racks and bike racks are also big
contributors to increased drag.
If your vehicle has a
manual transmission, you can
boost your f uel economy by up
shif ting as early as possible. Idling
results in 0 miles per gallon.
Combine several short trips into
one. A warmed-up engine is more
f uel ef f icient than a cold one. The A/C
puts an extra load on the engine
which makes it use more f uel. Use
the f resh-air ventilation when
possible.
245
Fuel Economy Factors
Improving Fuel Economy
Owner’s
Maintenance Checks Use the recommended viscosity
motor oil, displaying the A PI
Certif ication Seal (see page
).
Maintain proper tire inf lation
A void carrying excess weight in
your vehicle
K eep your vehicle clean
Drive moderately Observe the speed limit
Always drive in the highest gear
possible
Avoid excessive idling
Plan and combine trips
Minimize the use of the air
conditioning system
248
Fuel Economy
Vehicle Maint enance
Drive Ef f icient ly
186
\f—\f—y
\fy
(\fy\f

y
2008 Ridgeline

µTo shif t f rom second to
first, pull the shift lever towards you,
then shif t to the lower gear. This
position locks the transmission in
f irst gear. By upshif ting and
downshif ting through 1, 2, and D,
you can operate the transmission
much like a manual transmission
without a clutch pedal.
If you shif t into f irst position when
the vehicle speed is above 28 mph
(45 km/h), the transmission shif ts
into second gear first to avoid
sudden engine braking. If you exceed the maximum speed
f or the gear you are in, the engine
speed will enter into the tachometer’s
red zone. If this occurs, you may f eel
the engine cut in and out. This is
caused by a limiter in the engine’s
computer controls. The engine will
run normally when you reduce the
rpm below the red zone.
This allows you to move the shif t
lever out of Park if the normal
method of pushing on the brake
pedal and pulling the shif t lever does
not work.
Set the parking brake.
Make sure the ignition switch is in
the LOCK (0) position.
Putaclothonthenotchof the
shif t lock release slot cover. Using
a small f lat-tipped screwdriver or a
metal f ingernail f ile, caref ully pry
on the notch of the cover to
remove it.
1.
2.
3.
CONT INUED
First (1) Engine Speed Limiter Shift Lock Release
Automatic Transmission
Driving
205
\f—\f—y
\fy
(\fy\f
\fy
2008 Ridgeline

This section explains why it is
important to keep your vehicle well
maintained and how to f ollow basic
maintenance saf ety precautions.
If you have the skills and tools to
perf orm more complex maintenance
tasks on your vehicle, you may want
to purchase the service manual. See
page f or inf ormation on how to
obtain a copy, or see your dealer.
This section also includes
instructions on how to read the
maintenance minder messages on
the information display, and
instructions f or simple maintenance
tasks you may want to take care of
yourself .......................
Maintenance Saf ety .238
....................
Maintenance Minder .239
..............................
Fluid Locations .247
........................
Adding Engine Oil .248
Changing the Engine Oil and
...........................................
Filter .249
..............................
Engine Coolant .251
....................
Windshield Washers .252
....
Automatic Transmission Fluid .253
.................
Rear Dif f erential Fluid .254
.............
Transf er Assembly Fluid .255
....................................
Brake Fluid .255
....................
Power Steering Fluid .256
....................................
Timing Belt .256
.............................................
Lights .257
................
Cleaning the Seat Belts .263
.....................................
Floor Mats .263
..................
Dust and Pollen Filter .264
.................................
Wiper Blades .264
...........................................
Wheels .266
...............................................
Tires .266
...................
Checking the Battery .272
.............................
Vehicle Storage .274
321
Maintenance
Maint enance
237
\f—\f—y

y
(\fy\fy
2008 Ridgeline

Î
Î
.....................................
Tachometer .70
Tailgate, Dual-Action
.................................
Indicator .64,95
.....................................
Operation .93
......
Taillights, Changing Bulbs in .259
.
Taking Care of the Unexpected .275
Technical Descriptions
....
DOT Tire Quality Grading .306
.....
Emissions Control Systems .312
Three Way Catalytic
...............................
Converter .314
.......................
Temperature Gauge .72
...................
Tensioners, Seat Belts .19
............................
Thef t Protection .166
.................................................
Seats .99
..............
Adjusting the Seat .99,101
.............
Folding the Rear Seats .104
........................
Head Restraints .103
........................................
Heater .105
............................
Security System .168
...............................
Serial Number .302
...........................
Service Intervals .246
......
Service Manual, Purchasing .321
.........
Service Station Procedures .181
Shif ting the Automatic
.............................
Transmission .201
...
Shif t Lever Position Indicators .201
........................
Shif t Lock Release .205
....................................
Side Airbags .26
......................
Side Curtain Airbags .28
Side Marker (Parking)
...
Lights, Bulb Replacement in .258
...............................
Signaling Turns .76
.....................................
Snow Tires .271
................
Sound System .135,144,150
Spare Tire
..............................
Inf lating .267,276
....................
Specif ications .271,305
....................
Specif ications Charts .304
................................
Speed Control .169 ...................................
Speedometer .70
..........
SRS, Additional Inf ormation .21
...
Additional Safety Precautions .31
......
Airbag System Components .21
.............................
Airbag Service .30
How the Passenger Airbag Of f
......................
Indicator Works .29
How the Side Airbag Of f ......................
Indicator Works .29
..
How the SRS Indicator Works .28
How Your Front Airbags
.........................................
Work .23
...
How Your Side Airbags Work .26
How Your Side Curtain Airbags
.........................................
Work .28
.............................
SRS Indicator .28,62
....
START (Ignition Key Position) .82
.......................
Starting the Engine .200
................
With a Dead Battery .286
..............
State Emissions Testing .315
........
Steam Coming f rom Engine .288
Steering Wheel
..................................
Adjustment .79
.............
Anti-theft Column Lock .82
...
Stereo Sound System .135,144,150
....................
Storing Your Vehicle .274 ................................
Stuck Vehicle .299
........................................
Sun Visor .119
........................
Sunglasses Holder .117
Supplemental Restraint System
(SRS) ......................................
Servicing .30
.........................
SRS Indicator .28,62
...................
System Components .21
..................................
Synthetic Oil .249
Index
T
VIII
