engine overheat HONDA RIDGELINE 2011 1.G Owners Manual

(f luid capacities and tire pressures)
(seat belts, SRS, and child protection)
(main controls)
(indicators, gauges, multi-inf ormation display, dashboard, and steering column)
(fuel, vehicle break-in, and cargo loading)
(engine and transmission operation)
(vehicle specif ications, tires, and emissions controls) (warranty and contact inf ormation)
(how to order)
(f lat tire, jump starting, overheating, and f uses)
(
)
(minder, f luid checking, minor services, and vehicle storage)
climate control, audio, steering wheel, security, cruise control, HomeLink, and other convenience items
Contents
................................................................................................................................................
Index .I
..................................................
Service Inf ormation Summary . last page
............................................................
Driver and Passenger Saf ety .5
...............................................................................................
Your Vehicle at a Glance .3
.......
Instruments and Controls .59
.......................................................................
Bef ore Driving .247
.........................................................................................
Driving .267
..............................................
T echnical Inf ormation .385
..................
Warranty and Customer Relations (U.S. and Canada only) . 403
..................................................................................
A uthorized Manuals (U.S. only) .407
........................................
T aking Care of the Unexpected .359
..............
Features .145
.................................................
Maintenance .311INDEX
1Owner
Main Menu
2011 Ridgeline Online Reference Owner's Manual

µTo shif t to second,
pull the shif t lever towards you, then
shif t to the lower gear. This position
locks the transmission in second
gear. It does not downshif t to f irst
gear when you come to a stop.
Use second gear: For more power when climbing.
To increase engine braking when
going down steep hills.
For starting out on a slippery
surf ace or in deep snow.
To help reduce wheel spin.
When driving downhill with a
trailer.
This will increase the
automatic transmission f luid
temperature and may cause
overheating.
Shif ting out of the D position will
cancel D3, and cause the D3
indicator to go out. Selecting the D
position again will resume D3, and
the indicator will come on.
Turning the ignition switch to the
LOCK (0) position turns D3 of f . To
use D3 when you restart the engine,
select the D position, and press the
D3 switch again.
TheD3indicatoralsocomesonfora
f ew seconds when you turn the
ignition switch to the ON (II)
position.
When D3 is on, the transmission
selects only the f irst three gears.
Use D3 f or engine braking when
going down a steep hill.
Automatic Transmission
Second (2)When t owing a t railer on level roads
under normal driving condit ions, donot use D3.
274
D3 INDICATOR
Main MenuTable of Contents

When the low tire pressure indicator
is on, one or more of your tires is
signif icantly underinf lated. You
should stop and check your tires as
soon as possible, and inf late them to
the proper pressure as indicated on
the vehicle’s tire inf ormation placard.
If you think you can saf ely drive a
short distance to a service station,
proceed slowly, and inf late the tire to
the recommended pressure shown
on the driver’s doorjamb.
If the tire is f lat, or if the tire
pressure is too low to continue
driving, replace the tire with the
compact spare tire (see page ).
If you cannot make the low tire
pressure indicator go out af ter
inf lating the tires to the specif ied
values, have your dealer check the
system as soon as possible.Driving on a signif icantly under
inf lated tire causes the tire to
overheat and can lead to tire failure.
Underinf lation also reduces f uel
efficiency and tire tread life, and may
af f ect the vehicle’s handling and
stopping ability.
Becausetirepressurevariesby
temperature and other conditions,
the low tire pressure indicator may
come on unexpectedly.
Each tire has its own pressure
sensor (not including the spare tire).
If the air pressure of a tire becomes
signif icantly low, the sensor in that
tire immediately sends a signal that
causes the low tire pressure
indicator and the appropriate tire on
thetirepressuremonitortocomeon.
Your vehicle is equipped with a tire
pressure monitoring system (TPMS)
that turns on every time you start the
engine and monitors the pressure in
your tires while driving.
360
On models without navigation system
Tire Pressure Monitoring System (TPMS)
Low Tire Pressure
Indicator
278
Main MenuTable of Contents

CONT INUED
If you think you can saf ely drive a
short distance to a service station,
proceed slowly to the station, then
inflate the tire to the recommended
pressure.
If the tire is f lat, or if the tire
pressure is too low to continue
driving, replace the tire with the
compact spare tire (see page ).
Driving on a signif icantly under-
inf lated tire causes the tire to
overheat and can lead to tire failure.
Under-inf lation also reduces f uel
efficiency and tire tread life, and may
af f ect the vehicle’s handling and
stopping ability.
Becausetirepressurevariesby
temperature and other conditions,
the low tire pressure/TPMS
indicator may come on unexpectedly.
When the low tire pressure/TPMS
indicator is on, one or more of your
tires is signif icantly underinf lated.
Youshouldstopandcheckyourtires
as soon as possible, and inflate them
to the proper pressure as indicated
on the vehicle’s tire inf ormation
placard.
It is possible that the pressures
shown on the multi-inf ormation
display and the pressures you
manually measure are slightly
dif f erent.
If the dif f erence is signif icant or you
cannot make the low tire pressure/
TPMS indicator and message on the
multi-inf ormation display go out af ter
inf lating the tires to the specif ied
values, have your dealer check the
system as soon as possible.
Each tire has its own pressure
sensor. If the air pressure of a tire
becomes signif icantly low, the
sensor in that tire immediately sends
a signal that causes the low tire
pressure/TPMS indicator in the
instrument panel to come on. If this
happens, you will see which tire is
losing pressure on the multi-
inf ormation display along with a
‘‘CHECK TIRE PRESSURE’’
message.
Your vehicle is equipped with a tire
pressure monitoring system (TPMS)
that turns on every time you start the
engine and monitors the pressure in
your tires while driving.
361On models with navigation systemLow Tire Pressure/
TPMS Indicator
Tire Pressure Monitoring System (TPMS)
Driving
281
Main MenuTable of Contents

Drive slower than normal in all
driving situations, and obey posted
speed limits f or vehicles with trailers.
When towing a f ixed-sided trailer
(e.g., camper), do not exceed 55 mph
(88 km/h). At higher speeds, the
trailer may sway or affect vehicle
handling.
When towing a trailer on level roads
under normal driving conditions, do
not use D3. This will increase the
automatic transmission fluid
temperature and may cause
overheating.With heavy cargo on the pickup bed,
your vehicle has a higher center of
gravity. Drive slowly and cautiously,
and allow more time and distance f or
braking. Loading heavy cargo could
af f ect your vehicle’s handling and
perf ormance.
Maketurnsmoreslowlyandwider
than normal. The trailer tracks a
smaller arc than your vehicle, and it
canhitorrunoversomethingthe
vehicle misses.
Allow more time and distance f or
braking. Do not brake or turn
suddenly as this could cause the
trailer to jackknif e or turn over.
When driving down hills, reduce
your speed, and use D3. Do not
‘‘ride’’ the brakes.
If youmuststopwhenfacinguphill,
use the f oot brake or parking brake.
Do not try to hold the vehicle in
place by pressing on the accelerator,
as this can cause the automatic
transmission to overheat.
When climbing hills, closely watch
your temperature gauge. If it nears
the red (Hot) mark, turn the air
conditioning of f , reduce speed and, if
necessary, pull to the side of the
road to let the engine cool.
If the automatic transmission f luid
temperature increases and exceeds
the specif ied limit, the A/T
temperature indicator comes on (see
page ).
You will also see an ‘‘A/T TEMP
HIGH’’ message on the multi-
inf ormation display (see page ). 69
91
On models with navigation system
T owing Speeds and Gears
Making T urns and BrakingDriving on Hills
Towing a Trailer
Remember, it
takes longer to slow down and
stop when towing a trailer.
304
Main MenuTable of Contents

This section covers the more
common problems that motorists
experience with their vehicles. It
gives you inf ormation about how to
safely evaluate the problem and what
to do to correct it. If the problem has
stranded you on the side of the road,
you may be able to get going again.
If not, you will also f ind instructions
on getting your vehicle towed.......................
Compact Spare Tire . 360
....................
Changing a Flat Tire . 361
.............
If the Engine Won’t Start . 369
................................
Jump Starting . 370
..............
If the Engine Overheats . 372
.........
Low Oil Pressure Indicator . 374
..........
Charging System Indicator . 374
.......
Malf unction Indicator Lamp . 375
...............
Brake System Indicator . 376
..............................................
Fuses . 378
..............................
Fuse Locations . 381
......................
Emergency Towing . 383
..........
If Your Vehicle Gets Stuck . 383
Taking Care of the Unexpected
T aking Care of t he Unexpect ed
359
Main Menu

If you see steam and/or spray
coming f rom under the hood, turn
of f the engine. Wait until you see
no more signs of steam or spray,
then open the hood.
If you do not see steam or spray,
leave the engine running and
watch the temperature gauge. If
the high heat is due to overloading,
the engine should start to cool
down almost immediately. If it
does, wait until the temperature
gauge comes down to the midpoint,
then continue driving.
Saf ely pull to the side of the road.
Put the transmission in Park, and
set the parking brake. Turn of f all
the accessories, and turn on the
hazard warning lights.
The pointer of your vehicle’s
temperature gauge should stay in
the midrange under most conditions.
If it climbs to the red mark, you
should determine the reason (hot
day, driving up a steep hill, etc.).
If the vehicle overheats, you should
take immediate action. The only
indication may be the temperature
gauge climbing to or above the red
mark. Or you may see steam or
spray coming f rom under the hood. 1.
2.
3.
If theEngineOverheats
372
Steam and spray from an
overheated engine can
seriously scald you.
Do not open the hood if steam
is coming out.
Driving with the temperature gauge
pointer at the red mark can cause
serious damage to the engine.
Main MenuTable of Contents

If the temperature gauge stays at
the red mark, turn of f the engine.
Look f or any obvious coolant leaks,
such as a split radiator hose.
Everything is still extremely hot,
so use caution. If you f ind a leak, it
must be repaired bef ore you
continue driving (seeon page ).
Put the radiator cap back on
tightly. Run the engine, and check
the temperature gauge. If it goes
back to the red mark, the engine
needs repair (seeon page ).
If the temperature stays normal,
check the coolant level in the
radiator reserve tank. If it has
gone down, add coolant to the
MAX mark. Put the cap back on
tightly.
If you do not f ind an obvious leak,
check the coolant level in the
radiator reserve tank. Add coolant
if the level is below the MIN mark.
If there was no coolant in the
reserve tank, you may need to add
coolant to the radiator. Let the
engine cool down until the pointer
reaches the middle of the tempera-
ture gauge, or lower, bef ore check-
ing the radiator.
Using gloves or a large heavy
cloth, turn the radiator cap
counterclockwise, without pushing
down, to the f irst stop. Af ter the
pressure releases, push down on
the cap, and turn it until it comes
off.Start the engine, and set the
temperature to maximum heat
(climate control to AUTO at
‘‘ ’’). Add coolant to the
radiator up to the base of the f iller
neck. If you do not have the
proper coolant mixture available,
you can add plain water.
Remember to have the cooling
system drained and ref illed with
the proper mixture as soon as you
can.
4. 5.
6. 7. 8.9.
10. 11.
383
383
Emergency
Towing
Emergency
Towing
If theEngineOverheats
T aking Care of t he Unexpect ed
373
Removing the radiator cap
while the engine is hot can
cause the coolant to spray out,
seriously scalding you.
Always let the engine and
radiator cool down before
removing the radiator cap.
Main MenuTable of Contents

ÎÎ
CONT INUED
..............................
Economy, Fuel . 254
..................................
Emergencies . 359
.............
Battery, Jump Starting . 370
...........
Brake System Indicator . 376
................
Changing a Flat Tire . 361
.....
Charging System Indicator . 374
..................
Checking the Fuses . 378
.........
Hazard Warning Flashers . 99
.....
Low Oil Pressure Indicator . 374
...
Malf unction Indicator Lamp . 375
..................
Overheated Engine . 372
............................
Stuck Vehicle . 383
.......................................
Towing . 383
.........................
Emergency Brake . 132
.......................
Emissions Controls . 397
........................
Emissions Testing . 400 Engine
....
Coolant Temperature Gauge . 76
Malf unction Indicator
................................
Lamp . 63, 375
.................
Oil Lif e Display . 313, 317
........
Oil Pressure Indicator . 63, 374
..............
Oil, What Kind to Use . 326
...............................
Overheating . 372
............................
Specif ications . 389
............................
Speed Limiter . 275
.......................................
Starting . 270
.................
Engine, if it won’t start . 369
Evaporative Emissions Control
........................................
System . 397
...............................
Exhaust Fumes . 55
Exhaust Gas Recirculation
........................................
System . 398
Expectant Mothers, Use of Seat
........................................
Belts by . 18
..........................
Fan, Interior . 147, 154
.........................................
Features . 145
...............
DANGER, Explanation of . iii
...................................
Dashboard . 3, 60
................
Daytime Running Lights . 97
.................................
Dead Battery . 370
.........
Def ects, Reporting Saf ety . 406
......
Def rosting the Windows . 150, 155
................
Dif f erential Fluid, Rear . 333
....................................
Dimensions . 388
...............
Dimming the Headlights . 95
Dipstick
..........
Automatic Transmission . 331
..................................
Engine Oil . 253
..........................
Directional Signals . 95
........
Disc Brake Wear Indicators . 288
.....................
Disposal of Used Oil . 328
.
Door and Tailgate Open Monitor . 11
Doors
Locking and ..............
Unlocking . 103, 104, 107
..................
Lockout Prevention . 103
....................
Power Door Locks . 103
........
DOT Tire Quality Grading . 390
...........
Driver and Passenger Safety . 5 ...........................................
Driving . 267
....................................
Economy . 254
...................................................
D3 . 273
Dual-Action Tailgate
...............................
Indicator . 11, 115
...................................
Operation . 113
..................
Dust and Pollen Filter . 345
Index
E
F
D
INDEX
III
Main Menu

Î
CONT INUED
...
Octane Requirement, Gasoline . 248
.........................................
Odometer . 76
....................
Of f -Highway Driving . 306
...................
Of f -Road Precautions . 307
Oil
........................
Change, How to . 327
......................
Change, When to . 313
......................
Checking Engine . 253
...........................................
Filter . 328
..............
Pressure Indicator . 63, 374
Selecting Proper Viscosity
......................................
Chart . 326
.........
ON (Ignition Key Position) . 102
............................
Outside Mirrors . 134
....................
Overheating, Engine . 372
....
Owner’s Maintenance Checks . 323
.........................
Oxygenated Fuels . 248
..............
Panel Brightness Control . 98
........................
Park Gear Position . 272
...........................................
Parking . 286
...............................
Parking Brake . 132 .................................
Parking Lights . 95
..
Parking Over Things that Burn . 287
.............................
PGM-FI System . 398
Pickup Bed
.........................
Carrying Cargo . 259
.........................................
Lights . 144
..............
Power Seat Adjustments . 121
...............
Power Socket Locations . 139
.........
Pregnancy, Using Seat Belts . 18
.........
Protecting Adults and Teens . 11
...
Additional Safety Precautions . 19
.....
Advice f or Pregnant Women . 18
........................
Protecting Children . 34
.....................
General Guidelines . 34
.......................
Protecting Inf ants . 39
.......
Protecting Larger Children . 51
.........
Protecting Small Children . 40
Using Child Seats with
.....................................
Tethers . 48
.............................
Using LATCH . 43
...................
Radiator Overheating . 372
Radio/CD Sound
.......................
System . 159, 167, 173 .................
Rear Dif f erential Fluid . 333
..
Rear Lights, Bulb Replacement . 340
...........................
Rearview Mirror . 133
..
Rearview Mirror with Compass . 213
....................
Rear (Back) Window . 129
.....
Reclining the Seat-Backs . 120, 121
................
Remote Audio Controls . 203
.....................
Remote Transmitter . 110
Replacement Inf ormation
................
Engine Oil and Filter . 327
..........................................
Fuses . 378
................................
Light Bulbs . 336
........................................
Minder . 324
................................
Timing Belt . 336
...........................................
Tires . 361
.............................
Wiper Blades . 346
Replacing Seat Belts Af ter a ............................................
Crash . 22
..........
Reporting Saf ety Def ects . 406
...
Reserve Tank, Engine Coolant . 253
..................
Reverse Gear Position . 272
................................
Rotation, Tire . 351
Index
INDEX
P
R
O
VII
Main Menu
