HONDA RIDGELINE 2012 1.G Owners Manual

If you see steam and/or spray
coming f rom under the hood, turn
of f the engine. Wait until you see
no more signs of steam or spray,
then open the hood.
If you do not see steam or spray,
leave the engine running and
watch the temperature gauge. If
the high heat is due to overloading,
the engine should start to cool
down almost immediately. If it
does, wait until the temperature
gauge comes down to the midpoint,
then continue driving.
Saf ely pull to the side of the road.
Put the transmission in Park, and
set the parking brake. Turn of f all
the accessories, and turn on the
hazard warning lights.
The pointer of your vehicle

If the temperature gauge stays at
the red mark, turn of f the engine.
Look f or any obvious coolant leaks,
such as a split radiator hose.
Everything is still extremely hot,
so use caution. If you f ind a leak, it
must be repaired bef ore you
continue driving (seeon page ).
Put the radiator cap back on
tightly. Run the engine, and check
the temperature gauge. If it goes
back to the red mark, the engine
needs repair (seeon page ).
If the temperature stays normal,
check the coolant level in the
radiator reserve tank. If it has
gone down, add coolant to the
MAX mark. Put the cap back on
tightly.
If you do not f ind an obvious leak,
check the coolant level in the
radiator reserve tank. Add coolant
if the level is below the MIN mark.
If there was no coolant in the
reserve tank, you may need to add
coolant to the radiator. Let the
engine cool down until the pointer
reaches the middle of the tempera-
ture gauge, or lower, bef ore check-
ing the radiator.
Using gloves or a large heavy
cloth, turn the radiator cap
counterclockwise, without pushing
down, to the f irst stop. Af ter the
pressure releases, push down on
the cap, and turn it until it comes
off.Start the engine, and set the
temperature to maximum heat
(climate control to AUTO at
‘‘

Saf ely pull of f the road, and shut
of f the engine. Turn on the hazard
warning indicators.
Let the vehicle sit f or a minute.
Open the hood, and check the oil
level (see page ). An engine
very low on oil can lose pressure
during cornering and other driving
maneuvers.
If necessary, add oil to bring the
level back to the full mark on the
dipstick (see page ).
Start the engine, and watch the oil
pressure indicator. If it does not go
out within 10 seconds, turn of f the
engine. There is a mechanical
problem that needs to be repaired
bef ore you can continue driving
(see on page).
This indicator should never come on
when the engine is running. If it
starts f lashing or stays on, the oil
pressure has dropped very low or
lost pressure. Serious engine
damage is possible, and you should
take immediate action.
If the charging system indicator
comes on brightly when the engine
is running, the battery is not being
charged.
You will also see a ‘‘CHECK
CHARGING SYSTEM

If this indicator comes on
while driving, it means one
of the engine

Your vehicle has certain ‘‘readiness
codes

However, if the brake pedal does not
f eel normal, you should take
immediate action. A problem in one
part of the system

The vehicle

Check the smaller f uses in the
under-hood f use boxes and all the
fuses in the interior fuse box by
pulling out each one with the f use
puller provided in the primary
under-hood f use box.
Turn the ignition switch to the
LOCK (0) position. Make sure the
headlights and all other
accessories are of f .
Check each of the large f uses in
the primary under-hood f use box
by looking through the side
window at the wire inside.
Removing these f uses requires a
Phillips-head screwdriver.
Remove the cover f rom the f use
box. 4.
3.
1. 2.
CONT INUED
Fuses
T aking Care of the Unexpected
381
BLOWN
FUSE PULLER
BLOWN
FUSE
Main MenuTable of Contents

If the driver

ÎÎ Î
Î Î
Î
Î
Î
Î
µ
µ
µ´
Î
Î If equipped
If equipped
1 2 3 4 56 7 8 9
10 11 12
1 2 3 4 5 6 Back Light
VSA FSR
VSA MTR
VTM-4
Front Accessory Sockets
Electric Brake 131415 16 17 18 1920 21 22 23
7 8 9
1011
10 A
10 A
15 A
10 A
10 A
7.5 A 15 A
15 A
20 A
15 A
7.5 A
(7.5 A) 20 A
40 A
20 A
15 A
(20 A) (20 A)
(7.5 A)
(20 A)7.5 A
(20 A) 20 A
20 A
40 A
15 A
40 A
20 A
30 A
30 A
40 A
40 A
120 A
60 A
50 A Horn, Stop
Defroster
Back Up, ACC Hazard
Option 1
AC Inverter
Cooling Fan
Condenser Fan
Heater MotorSeat
Battery
BIGIMain
Power Window
Spare Fuses
Small Lights
Stop/Turn Lights
Charge
TPMS
Moonroof
Left Headlight Low Beam
Not Used
Left Headlight High Beam
Small Lights
Right Headlight High Beam
Right Headlight Low Beam
Back Up
FI ECU (PCM)
DBW
Front Fog Lights
Heated Seats
MG Clutch
:
:
No.
No. Circuits Protected No.No.
Amps.
Amps.
Amps.
Amps. Circuits Protected
Circuits Protected
Circuits Protected
24 28
Fuse Locations
T aking Care of the Unexpected
383
PRIMARY UNDER-HOOD FUSE BOX
SECONDARY UNDER-HOOD FUSE BOX
