HONDA RIDGELINE 2013 1.G Owners Manual

The vehicle’s f uses are contained in
threefuseboxes.The primary under-hood f use box is
on the passenger’s side. The
secondary f use box is next to the
brake f luid reservoir. To open them,
pushthetabsasshown.
The interior f use box is on the
driver’s lower lef t side. To remove
the f use box lid, put your f inger in
the notch on the lid, and pull it
outward slightly, then pull it toward
you and take it out of its hinges. If something electrical in your
vehicle stops working, check f or a
blown f use f irst. Determine f rom the
chart on pages and , or the
diagram on the f use box lid, which
f use or f uses control that device.
Check those f uses f irst, but check all
the f uses bef ore deciding that a
blown f use is the cause. Replace any
blown f uses, and check if the device
works.
379 380
Checking and Replacing Fuses
Fuses
376
UNDER-HOOD (SECONDARY)
UNDER-HOOD (PRIMARY)
INTERIOR
NOTCH
12/08/09 16:48:37 31SJC670_383
T aking Care of t he Unexpect ed

Check the smaller f uses in the
under-hood f use boxes and all the
fuses in the interior fuse box by
pulling out each one with the f use
puller provided in the primary
under-hood f use box.
Turn the ignition switch to the
LOCK (0) position. Make sure the
headlights and all other
accessories are of f .
Check each of the large f uses in
the primary under-hood f use box
by looking through the side
window at the wire inside.
Removing these f uses requires a
Phillips-head screwdriver.
R emove the cover f rom
the fusebox. 4.
3.
1.
2.
CONT INUED
Fuses
377
BLOWN
FUSE PULLER
BLOWN
FUSE
12/08/09 16:48:45 31SJC670_384
T aking Care of t he Unexpect ed

If the driver’s power window fuse is
removed, the AUTO function of the
driver’s window may be disabled.
To reset the AUTO function, see
page.
Look f or a blown wire inside the
fuse.If itisblown,replacethefuse
withoneof thesparefusesof the
same rating or lower. If the replacement fuse of the
same rating blows in a short time,
there is probably a serious
electrical problem in your vehicle.
Leave the blown fuse in that
circuit and have your vehicle
checked by a qualif ied technician.
If you cannot drive the vehicle
without f ixing the problem, and you
do not have a spare fuse, take a fuse
of the same rating or a lower rating
f rom one of the other circuits. Make
sureyoucandowithoutthatcircuit
temporarily (such as the accessory
power socket or radio).
If you replace the blown f use with a
spare f use that has a lower rating, it
might blow out again. This does not
indicate that anything is wrong.
Replace the f use with one of the
correct rating as soon as you can.
5. 6.
128
Fuses
378
BLOWN
Replacing a f use with one that has a
higher rating greatly increases the
chances of damaging the electrical
system. If you do not have a
replacement f use with the proper
rating f or the circuit, install one with
a lower rating.
12/08/09 16:48:51 31SJC670_385
T aking Care of t he Unexpect ed

ÎÎ Î
Î Î
Î
Î
Î
Î
µ
µ
µ´
Î
Î If equipped If equipped
1
2
3
4
5
6
7
8
9
10
11
12
1
2
3
4
5
6 Back Light
VSA FSR
VSA MTR
VTM-4
Front Accessory Sockets
Electric Brake 13
14
15
16
17
18
19
20
21
22
23
7
8
9
10
11
10 A
10 A
15 A
10 A
10 A
7.5 A 15 A
15 A
20 A
15 A
7.5 A
(7.5 A) 20 A
40 A
20 A
15 A
(20 A) (20 A)
(7.5 A) (20 A)7.5 A
(20 A) 20 A
20 A
40 A
15 A
40 A
20 A
30 A
30 A
40 A
40 A
120 A 60 A
50 A Horn, Stop
Defroster
Back Up, ACC
Hazard
Option 1
AC Inverter
Cooling Fan
Condenser Fan
Heater Motor
Seat
Battery
BIGIMain
Power Window
Spare Fuses
Small Lights
Stop/Turn Lights
Charge
TPMS
Moonroof
Left Headlight Low Beam
Not Used
Left Headlight High Beam
Small Lights
Right Headlight High Beam
Right Headlight Low Beam
Back Up
FI ECU (PCM)
DBW
Front Fog Lights
Heated Seats
MG Clutch
:
:
No.
No. Circuits Protected No.
No.
Amps.
Amps.
Amps.Amps. Circuits Protected
Circuits Protected
Circuits Protected
24 28
Fuse Locations
379
PRIMARY UNDER-HOOD FUSE BOX
SECONDARY UNDER-HOOD FUSE BOX
12/08/09 16:49:02 31SJC670_386
T aking Care of t he Unexpect ed

µ
µ
µ
ÎÎ
Î
Î
No. No.
No. Amps.
Amps. Amps.
Circuits Protected
Circuits Protected Circuits Protected
1
2
3
4
5
6
7
8
9
10
If equipped
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
1 7.5 A
7.5 A
15 A
10 A
15 A
20 A
10 A
7.5 A 20 A
10 A
7.5 A 30 A
(10 A)
(20 A)
(20 A) 15 A
15 A
7.5 A
7.5 A 10 A
7.5 A 20 A
20 A
20 A
20 A
20 A
7.5 A 10 A
7.5 A
7.5 A
(7.5 A) STS
Bed Lights
IG Coil
Daytime Running Light
LAF
Radio
Interior Lights
Back Up
Door Lock
Rear Accessory Socket
IG OPDS IG Wiper
Not Used
Driver’s Power Seat Lumbar
Driver’s Power Seat Sliding
Not Used
Driver’s Power Seat Reclining
Not Used
IG ACG
IG Fuel Pump
IG Washer
IG Meter
IG SRS
IGP
Left Rear Window
Right Rear Window
Passenger’s Window
Back Window
Driver’s Window
VBSOL2
IG HAC
IG VSA/ABS
ACC
Not Used
:
Fuse Locations
380
INTERIOR FUSE BOX UPPER AREA
INTERIOR FUSE BOX
Driver’s Side
12/08/09 16:49:11 31SJC670_387
T aking Care of t he Unexpect ed

CONT INUED
If your vehicle needs to be towed,
call a professional towing service or
organization. Never tow your
vehicle with just a rope or chain. It
is very dangerous.The operator will load
your vehicle on the back of a truck.
Any other method of towing will
damage the drive system. When you
contact the towing agency, inf orm
them a f lat-bed is required. If your vehicle gets stuck in sand,
mud, or snow, call a towing
service to pull it out (see the
previous column).
For very short distances, such as
f reeing the vehicle, you can use the
tie down hooks on the lower of the
f ront and rear bumpers.
Emergency Towing, If Your Vehicle Gets Stuck
The only way you can saf ely tow
your vehicle is with f lat-bed
equipment.
If Your Vehicle Gets Stuck
381
FRONT
REAR
TIE DOWN
HOOK TIE DOWN
HOOK
‘‘Rocking’’ your vehicle between
f orward and reverse gear or revving up
the engine and allowing the wheels to
spin f reely at high speeds can damage
the automatic transmission. Use a tow
service to prevent transmission damage.
Towing your vehicle with two tires on
the ground will damage parts of the
4WD system. It should be transported
on a f lat-bed truck or trailer.
12/08/09 16:49:20 31SJC670_388
T aking Care of t he Unexpect ed

If Your Vehicle Gets Stuck
382
To avoid damage to your vehicle, use
the tie down hooks f or straight, f lat
ground towing only. Do not tow at an
angle. These hooks should not be used
f or open-road towing.
12/08/09 16:49:23 31SJC670_389
T aking Care of t he Unexpect ed

µ
Thediagramsinthissectiongive
you the dimensions and capacities of
your vehicle and the locations of the
identif ication numbers. It also
includes inf ormation you should
know about your vehicle’s tires and
emissions control systems.
................
Identif ication Numbers . 384
................................
Specif ications .386
DOT Tire Quality Grading ......................
(U.S. Vehicles) .388
Unif orm Tire Quality ..................................
Grading .388
.................................
Treadwear .388
......................................
Traction .388
.............................
Temperature .389
.................................
Tire Labeling .390
Tire Pressure Monitoring System (TPMS) Required Federal ............................
Explanation .392
.......................
Emissions Controls .395
.....................
The Clean Air Act .395
Crankcase Emissions Control ....................................
System .395
Evaporative Emissions Control ....................................
System .395
Onboard Ref ueling Vapor ................................
Recovery .395
...
Exhaust Emissions Controls . 396
....................
PGM-FI System .396
Ignition Timing Control ................................
System .396 Exhaust Gas Recirculation
...................
(EGR) System . 396
Three Way Catalytic ...........................
Converter .396
....................
Replacement Parts . 396
..
Three Way Catalytic Converter . 397
........................
Emissions Testing .398
T echnical Inf ormation
383
12/08/09 16:49:27 31SJC670_390

Your vehicle has several identif ying
numbers in various places.
The vehicle identif ication number
(VIN) is the 17-digit number your
dealer uses to register your vehicle
f or warranty purposes. It is also
necessary f or licensing and insuring
your vehicle. The easiest place to
find the VIN is on a plate fastened to
the top of the dashboard. You can
seeitbylookingthroughthe
windshield on the driver’s side. It is
also on the certification label
attached to the driver’s doorjamb,
and is stamped on the engine
compartment bulkhead. The VIN is
also provided in bar code on the
certif ication label.
Identif ication Numbers
384
CERTIFICATION LABEL
VEHICLE IDENTIFICATION NUMBER (VIN)
12/08/09 16:49:31 31SJC670_391
Technical Inf ormation

The engine number is stamped into
the engine block. It is on the f ront.
The transmission number is on a
label on top of the transmission.
Identif ication Numbers
Technical Inf ormation
385
ENGINE NUMBERAUTOMATIC TRANSMISSION NUMBER
