Your vehicle is equipped with dual-
stage, multiple-threshold f ront
airbags (SRS). During a f rontal crash
severe enough to cause one or both
f ront airbags to deploy, the airbags
can inf late at dif f erent rates,
depending on the severity of the
crash, whether or not the seat belts
are latched, and/or other factors.
Front airbags are designed to
supplement the seat belts to help
reduce the likelihood of head and
chest injuries in f rontal crashes.
After a crash, you may see what
looks like smoke. This is actually
powder from the airbag’s surface.
Although the powder is not
harmful, people with respiratory
problems may experience some
temporary discomfort. If
this occurs, get out of the vehicle
as soon as it is safe to do so. The total time for inflation and
def lation is less than a second, so
f ast that most occupants are not
aware that the airbags deployed until
they see them lying in their laps.
Af ter inf lating, the f ront airbags
immediately def late, so they won’t
interf ere with the driver’s visibility,
or the ability to steer or operate
other controls.
Additional Inf ormation About Your Airbags
Dual-Stage, Multiple-T hreshold Front A irbags (SRS)
26
12/08/09 16:02:28 31SJC670_033
Driver and Passenger Saf ety
Page 32 of 422
CONT INUED
Your f ront airbags are also advanced
airbags. The main purpose of this
feature is to help prevent airbag-
caused injuries to short drivers and
children or small-statured adults who
ride in f ront.The driver’s advanced front airbag
system includes a seat position
sensor under the seat. If the seat is
too f ar f orward, the airbag will
inf late with less f orce, regardless of
the severity of the impact.The passenger’s advanced f ront
airbag system has weight sensors
under the seat. Although Honda
does not encourage carrying an
inf ant or small child in f ront, if the
sensors detect the weight of an
inf ant or small child (up to about 65
lbs or 29 kg), the system will
automatically turn the passenger’s
front airbag off.
If there is a problem with the sensor,
the SRS indicator will come on, and
the airbag will inf late in the normal
manner regardless of the driver’s
seating position.
Failure to f ollow these instructions
could damage the sensors or prevent
them f rom working properly. For both advanced airbags to work
properly:
Occupants must sit upright and
wear their seat belts properly.
Do not spill any liquids on or
under the seats, cover the sensors,
or put any objects or metal items
under the f ront seats.
Objects placed or pushed under
the f ront passenger’s seat may
cause the sensor to malf unction,
increasing the risk of injury in a
crash.
Additional Inf ormation About Your Airbags
Advanced Airbags
27
DRIVER’S SEAT POSITION SENSOR PASSENGER’S SEAT WEIGHT SENSOR
12/08/09 16:02:37 31SJC670_034
Driver and Passenger Saf ety
Page 33 of 422
Hanging heavy items on the f ront
passenger seat, or placing heavy
items in the seat-back pocket. Moving the f ront seat f orcibly
back against cargo on the seat or
f loor behind it. A rear passenger pushing or
pulling on the back of the f ront
passenger’s seat.
When the passenger airbag gets
turned of f by the weight sensors, a
‘‘passenger airbag of f ’’ indicator in
the center of the dashboard comes
on (see page ). Be aware that objects placed on the
passenger’s seat can also cause the
airbag to be turned off.
If you ever have a moderate to
severe side impact, sensors will
detect rapid acceleration and signal
the control unit to instantly inf late
either the driver’s or the passenger’s
side airbag.
To ensure that the passenger’s
advanced front airbag system will
work properly,
This includes: If the weight sensors detect there is
no passenger in the f ront seat, the
airbag is automatically turned off.
However, the passenger airbag of f
indicator in this situation will not
come on.
Also,makesurethefloormatbehind
the f ront passenger’s seat is hooked
to the floor mat anchor (see page). If it is not, the mat may
interf ere with the proper operation
of the sensors and operation of the
seat. Back seat passengers should not
wedge objects or intentionally
f orce their f eet under the f ront
passenger seat.
31
342
Additional Inf ormation About Your Airbags
How Your Side A irbags Work
do not do anyt hing
t hat would increase or decrease t he weight on the f ront passenger’s seat.
28
12/08/09 16:02:46 31SJC670_035
Driver and Passenger Saf ety
Page 34 of 422
To get the best protection f rom the
side airbags, front seat occupants
should wear their seat belts and sit
upright and well back in their seats.Your vehicle has a side airbag cutoff
system designed primarily
to protect a child riding in the front
passenger’s seat.
If the side airbag of f indicator comes
on (see page ), have the
passenger sit upright. Once the
passenger is out of the airbag’s
deployment path, the system will
turn the airbag back on, and the
indicator will go out.
There will be some delay between
the moment the passenger moves
into or out of the airbag deployment
pathandwhentheindicatorcomes
on or goes of f .
A f ront seat passenger should not
use a cushion or another object as a
backrest. It may prevent the cutof f
system f rom working properly.
Although Honda does not
encourage children to ride in front,
if the position sensors detect a
child has leaned into the side
airbag’s deployment path, the
airbag will shut off.
Objects placed on the f ront
passenger seat can also cause the
side airbag to be shut of f . Thesideairbagmayalsoshutoff if a
short adult leans sideways, or a
larger adult slouches and leans
sideways into the airbag’s
deployment path.
Only one airbag will deploy during a
side impact. If the impact is on the
passenger’s side, the passenger’s
side airbag will deploy even if there
is no passenger.
31
Additional Inf ormation About Your Airbags
Side A irbag Cut of f Syst em
29
12/08/09 16:02:53 31SJC670_036
Driver and Passenger Saf ety
Page 35 of 422
A rollover sensor monitors the
degree and rate your vehicle may
roll over and automatically deploy
the side curtain airbags and activate
the front seat belt tensioners (see
page).
In a rollover toward the front
passenger’s side of the vehicle, both
side curtain airbags will inflate and
the front seat belt tensioners will
activate even if there are no
occupants on that side of the vehicle.
To get the best protection f rom the
side curtain airbags, occupants
should wear their seat belts and sit
upright and well back in their seats. When you turn the ignition switch to
the ON (II) position, this indicator
comes on f or several seconds then
goes of f . This tells you the system is
working properly.
If the indicator comes on at any
other time, or does not come on at all,
you should have the system checked
by your dealer. For example:
If the SRS indicator does not come
on after you turn the ignition
switch to the ON (II) position.
If the indicator comes on or
flashesonandoff whileyoudrive. If the indicator stays on after the
engine starts.
The SRS indicator alerts you to a
potential problem with your airbag
system components.
In a moderate to severe side
impact, sensors will detect
rapid acceleration and signal the
control unit to instantly inflate the
side curtain airbag. 22
Additional Inf ormation About Your Airbags
How Your Side Curtain
Airbags Work
How the SRS
Indicator WorksIn a Rollover
In a Side Impact
30
SIDE CURTAIN AIRBAG
12/08/09 16:03:03 31SJC670_037
Driver and Passenger Saf ety
Page 36 of 422
CONT INUED
This indicator alerts you that the
passenger’s f ront airbag has been
shut of f because weight sensors
detect about 65 lbs (29 kg) or less
(the weight of an inf ant or small
child) on the f ront passenger’s seat.
It does there is a problem
with the airbag.
You will also see a ‘‘CHECK
AIRBAG SYSTEM’’ message on the
multi-information display (see
page
). This indicator alerts you that the
passenger’s side airbag has been
automatically shut off. It does
mean there is a problem with your
side airbags.
When you turn the ignition switch to
the ON (II) position, the indicator
should come on for several seconds
and then go off (see page ). If it
doesn’t come on, stays on, or
comes on while driving without a
passenger in the front seat, have
the system checked.
You will also see a ‘‘PASSENGER
SIDE AIRBAG OFF’’ message on the
multi-information display (see
page
).
If you see any of these indications,
the airbag system components
may not work properly
when you need them.
90
9064
On models with navigation system
On models with navigation system
Additional Inf ormation About Your Airbags
How the Passenger Airbag Of f
Indicator Works
How the Side
Airbag Of f
Indicator Works
not mean
not
31
Canada
PASSENGER AIRBAG OFF INDICATOR
U.S.
U.S. Canada
Ignoring the SRS indicator can
result in serious injury or death
if the airbag systems or
tensioners do not work properly.
Have your vehicle checked by a
dealer as soon as possible if
the SRS indicator alerts you to
a possible problem.
12/08/09 16:03:13 31SJC670_038
Driver and Passenger Saf ety
Page 37 of 422
Your airbag systems are virtually
maintenance f ree, and there are no
parts you can saf ely service.
However, you must have your
vehicle serviced if:Any airbag
that has deployed must be
replaced along with the control
unit and other related parts. Any
seat belt tensioner that activates
must also be replaced.
Be aware that objects placed on the
f ront seat can cause the indicator to
come on.
If no weight is detected on the f ront
seat, the airbag will be automatically
shut of f . However, the indicator will
not come on.
The passenger airbag of f indicator
maycomeonandoff repeatedlyif
the total weight on the seat is near
the airbag cutof f threshold.
If an adult or teenage passenger is
riding in f ront, move the seat as f ar
to the rear as possible, and have the
passenger sit upright and wear the
seat belt properly. If the indicator comes on with no
f ront seat passenger and no objects
on the seat, or with an adult riding
there, something may be interf ering
with the weight sensors. Look f or
and remove:
Any items under the f ront
passenger’s seat.
Any object(s) touching the rear of
the seat-back.
If no obstructions are f ound, have
your vehicle checked by a dealer as
soon as possible. Any object(s) hanging on the seat
or in the seat-back pocket.
We recommend against the use
of salvaged airbag system
components, including the
airbag, tensioners, sensors,
and control unit.
Do not try to remove or replace
anyairbagbyyourself.Thismust
be done by an authorized dealer or
a knowledgeable body shop.
Additional Inf ormation About Your Airbags
Airbag Service
An airbag ever inf lates.
32
12/08/09 16:03:23 31SJC670_039
Driver and Passenger Saf ety
Page 38 of 422
Together, airbags and
seat belts provide the best
protection.
Tampering could cause
the airbags to deploy, possibly
causing very serious injury.
If water or
another liquid soaks into a seat-
back, it can prevent the side
airbag cutoff system from
working properly. This could make the
driver’s seat position sensor or the
f ront passenger’s weight sensors
inef f ective. If it is necessary to
remove or modif y a f ront seat to
accommodate a person with
disabilities, f irst contact Honda
Automobile Customer Service at
(800) 999-1009 in the US, or
Honda Customer Relations at
Even if your
airbags do not inflate, your dealer
should inspect the driver’s seat
position sensor, the f ront
passenger’s weight sensors, the
f ront seat belt tensioners, and all
seat belts and their anchors worn
during a crash to make sure they
are operating properly. Take your vehicle to an
authorized dealer as soon as
possible. If you ignore this
indication, your airbags may not
operate properly.
Additional Inf ormation About Your Airbags
Additional Saf ety Precautions
Donotattempttodeactivateyour
airbags.
Do not t amper wit h airbagcomponent s or wiring f or anyreason.
Do not expose the f ront passenger’sseat-back to liquid. Do not remove or modif y a f ront
seat without consulting yourdealer.
If your vehicle has a moderat e t o severe impact .
T he SRS indicat or alert s you t o a
problem.
33
12/08/09 16:03:29 31SJC670_040
Driver and Passenger Saf ety
1-888-9-HONDA-9 in Canada.
Page 39 of 422
µ
µµ
If you have children, or ever
need to drive with a child in your
vehicle, be sure to read this
section. It begins with important
general guidelines, then presents
special information for infants,
small children, and larger children.To reduce the number of child
deaths and injuries, every state,
Canadian province and territory
requires that inf ants and children be
properlyrestrainedwhentheyridein
a vehicle.
(see pages ). (see pages ).
Children depend on adults to protect
them. However, despite their best
intentions, many adults do not know
how to protect child
passengers. Each year, many children are injured
or killed in vehicle crashes because
they are either unrestrained or
not properly restrained. In fact,
traffic collisions are the number
one cause of death of children age
12 and under.
39 50 51 54
properly
Protecting Children General Guidelines
All Children Must Be Restrained
Inf ant s and small children must be
rest rained in an approved child seatt hat is properly secured t o t hevehicle Larger children must be restrained
wit h a lap/shoulder belt and ride ona boost er seat unt il t he seat belt f it st hem properly
34
Children who are unrestrained
or improperly restrained can be
seriously injured or killed in a
crash.
Any child too small for a seat
belt should be properly
restrained in a child seat. A
larger child should be properly
restrained with a seat belt and
use a booster seat if necessary.
12/08/09 16:03:36 31SJC670_041
Driver and Passenger Saf ety
Page 40 of 422
µ
Front airbags have been designed to
help protect adults in a moderate to
severe f rontal collision. To do this,
the passenger’s f ront airbag is quite
large, and it can inflate with enough
f orce to cause very serious injuries.If the vehicle seat is
too far forward, or the child’s head is
thrown f orward during a collision, an
inflating front airbag can strike the
child with enough f orce to kill or
very seriously injure a small child.
Whenever possible,
larger children should sit in the back
seat, on a booster seat if needed, and
be properly restrained with a seat
belt (see page f or important
inf ormation about protecting larger
children).
Even though your vehicle has an
advanced front airbag system that
automatically turns the passenger’s
f ront airbag of f under certain
circumstances (see page ), please
f ollow these guidelines:
If
the airbag inflates, it can hit the back
of the child seat with enough force
to kill or very seriously injure an
inf ant.
According to crash statistics,
children of all ages and sizes are
saf er when they are restrained in a
back seat.
The National Highway Traffic Safety
Administration and Transport
Canada recommend that all children
aged 12 and under be properly
restrained in a back seat. Some
states have laws restricting where
children may ride.
Children who ride in the back are
less likely to be injured by striking
interior vehicle parts during a
collision or hard braking. Also,
children cannot be injured by an
inflating front airbag when they ride
in the back.
51
31
CONT INUED
Protecting Children General Guidelines
Small Children
Placing a f orward-f acing child seat inthe f ront seat of a vehicle equippedwit h a passenger’s f ront airbag canbe hazardous.
Larger ChildrenChildren who have outgrown childseat s are also at risk of being injuredor killed by an inf lat ing passenger’sfront airbag.
Never put a rear-f acing child seat in the f ront seat of a vehicle equippedwit h a passenger’s f ront airbag.
Inf ant sAll Children Should Sit
in a Back Seat
The Passenger’s Front Airbag
Can Pose Serious Risks
35
12/08/09 16:03:46 31SJC670_042
Driver and Passenger Saf ety
