2007 HUMMER H2 Owner ManualM
1

Vehicle Damage Warnings
Also, in this manual you will nd these notices:
Notice:These mean there is something
that could damage your vehicle.
A notice tells about something that can damage
the vehicle. Many times, this damage would not be
covered by your vehicle’s warranty, and it could
be costly. But the notice will tell what to do to help
avoid the damage.
When you read other manuals, you might see
CAUTION and NOTICE warnings in different colors
or in different words.
There are also warning labels on the vehicle.
They use the same words, CAUTION or NOTICE.
Vehicle Symbols
The vehicle has components and labels that use
symbols instead of text. Symbols are shown along
with the text describing the operation or information
relating to a specic component, control, message,
gage, or indicator.
If you need help guring out a specic name of a
component, gage, or indicator, reference the
following topics:
Seats and Restraint Systems in Section 1
Features and Controls in Section 2
Instrument Panel Overview in Section 3
Climate Controls in Section 3
Warning Lights, Gages, and Indicators in
Section 3
Audio System(s) in Section 3
Engine Compartment Overview in Section 5
5

Liftgate (SUV)
{CAUTION:
It can be dangerous to drive with
the liftgate open because carbon
monoxide (CO) gas can come into your
vehicle. You can not see or smell CO.
It can cause unconsciousness and even
death. If you must drive with the liftgate
open or if electrical wiring or other cable
connections must pass through the seal
between the body and the liftgate:
Make sure all other windows are shut.
Turn the fan on your heating or
cooling system to its highest speed
and select the control setting that will
force outside air into your vehicle.
SeeDual Automatic Climate Control
System on page 197.
If you have air outlets on or under the
instrument panel, open them all the
way. SeeEngine Exhaust on page 137.To lock and unlock the liftgate, use any of the
power door lock switches or the remote keyless
entry (RKE) transmitter.
To open the liftgate, do the following:
1. Move the spare tire carrier out of the way.
See “Opening the Spare Tire Carrier” under
Tailgate/Spare Tire Carrier on page 108.
2. Pull the handle located in the center of
the door.
To close the liftgate, do the following:
1. Pull the liftgate down until it latches.
2. Move the spare tire carrier back into place.
See “Closing the Spare Tire Carrier” under
Tailgate/Spare Tire Carrier on page 108.
104

Midgate®(SUT)
{CAUTION:
It can be dangerous to drive with the
cargo area covered and the tailgate and
the Midgate
®open because carbon
monoxide (CO) gas can come into your
vehicle. You can not see or smell CO.
It can cause unconsciousness and even
death. If you must drive with the cargo
covers on and the tailgate and Midgate
®
CAUTION: (Continued)
CAUTION: (Continued)
open or if electrical wiring or other cable
connections must pass through the seal
between the body and the Midgate
®:
Make sure all windows are shut.
Turn the fan on your heating or
cooling system to its highest speed
on the setting that brings in outside
air. This will force outside air into your
vehicle. SeeDual Automatic Climate
Control System on page 197.
If you have air outlets on or under the
instrument panel, open them all the
way. SeeEngine Exhaust on page 137.
The Midgate
®allows you to extend the length of
your vehicle’s cargo area into the cab.
105

Running the Engine While Parked
It is better not to park with the engine running. But if
you ever have to, here are some things to know.
{CAUTION:
Idling the engine with the climate control
system off could allow dangerous exhaust
into your vehicle. See the earlier caution
underEngine Exhaust on page 137.
Also, idling in a closed-in place can let
deadly carbon monoxide (CO) into your
vehicle even if the climate control fan is at
the highest setting. One place this can
happen is a garage. Exhaust — with
CO — can come in easily. NEVER park in
a garage with the engine running.
Another closed-in place can be a blizzard.
SeeWinter Driving on page 353.
{CAUTION:
It can be dangerous to get out of your
vehicle if the shift lever is not fully in
PARK (P) with the parking brake rmly
set. Your vehicle can roll. Do not leave
your vehicle when the engine is running
unless you have to. If you have left the
engine running, the vehicle can move
suddenly. You or others could be injured.
To be sure your vehicle will not move,
even when you are on fairly level ground,
always set your parking brake and move
the shift lever to PARK (P).
138

Outside Convex Mirror
{CAUTION:
A convex mirror can make things (like
other vehicles) look farther away than
they really are. If you cut too sharply into
the right lane, you could hit a vehicle on
your right. Check your inside mirror or
glance over your shoulder before
changing lanes.
The passenger’s side mirror is convex. A convex
mirror’s surface is curved so more can be
seen from the driver’s seat. It makes things in the
mirror appear farther away than they really are.
Outside Heated Mirrors
If the vehicle has
heated mirrors, the
button to turn this
function on or off is
located on the climate
control panel.
Press this button to warm the driver’s and
passenger’s outside rearview mirrors to help clear
them of ice, snow, and condensation.
With a rear window defogger, the heated mirrors
will come on when this button is pressed. See
“Rear Window Defogger” underDual Automatic
Climate Control System on page 197for more
information.
143

Instrument Panel Overview........................ 174
Hazard Warning Flashers.......................... 176
Other Warning Devices............................. 177
Horn.......................................................... 177
Tilt Wheel.................................................. 177
Turn Signal/Multifunction Lever.................. 178
Turn and Lane-Change Signals................. 178
Headlamp High/Low-Beam Changer.......... 179
Flash-to-Pass............................................ 180
Windshield Wipers..................................... 180
Windshield Washer.................................... 181
Rear Window Wiper/Washer (SUV)........... 182
Cruise Control........................................... 183
Exterior Lamps.......................................... 186
Headlamps on Reminder........................... 188
Daytime Running Lamps (DRL)................. 188
Automatic Headlamp System..................... 189
Off-Road Lamps........................................ 190
Instrument Panel Brightness...................... 191
Dome Lamps............................................. 191
Dome Lamp Override................................ 191Entry/Exit Lighting...................................... 191
Reading Lamps......................................... 192
Battery Run-Down Protection..................... 192
Rear Vision Camera.................................. 192
Accessory Power Outlet(s)........................ 196
Ashtray(s) and Cigarette Lighter................ 197
Climate Controls......................................... 197
Dual Automatic Climate Control System....... 197
Outlet Adjustment...................................... 203
Warning Lights, Gages, and Indicators........ 204
Instrument Panel Cluster........................... 205
Speedometer and Odometer...................... 206
Trip Odometer........................................... 206
Tachometer............................................... 206
Safety Belt Reminder Light........................ 206
Airbag Readiness Light............................. 207
Airbag Off Light......................................... 208
Charging System Light.............................. 209
Voltmeter Gage......................................... 210
Brake System Warning Light..................... 211
Anti-Lock Brake System Warning Light...... 212
Section 3 Instrument Panel
171

S. Cigarette Lighter or Accessory Power Outlet
(If Equipped). SeeAshtray(s) and Cigarette
Lighter on page 197orAccessory Power
Outlet(s) on page 196.
T. Shift Lever. SeeAutomatic Transmission
Operation on page 124.
U. Accessory Power Outlets. SeeAccessory
Power Outlet(s) on page 196.
V. OnStar Buttons. SeeOnStar
®System on
page 144.
W. Rear Window Defogger Button. See “Rear
Window Defogger” underDual Automatic
Climate Control System on page 197.
X. Climate Control System. SeeDual Automatic
Climate Control System on page 197.
Hazard Warning Flashers
The hazard warning ashers warn others. They
also let police know you have a problem. Your front
and rear turn signal lamps will ash on and off.
The hazard warning
asher button is located
on top of the steering
column.
The hazard warning ashers work no matter what
ignition position the key is in, and even if the
key is not in the ignition.
Press the button to make the front and rear turn
signal lamps ash on and off. Press the button
again to turn the ashers off.
When the hazard warning ashers are on, your
turn signals will not work.
176

Ashtray(s) and Cigarette Lighter
If your vehicle has an ashtray, it is removable and
ts into the front cupholder. Pull up on the
ashtray door to open it.
Notice:If you put papers, pins, or other
ammable items in the ashtray, hot cigarettes
or other smoking materials could ignite
them and possibly damage your vehicle. Never
put ammable items in the ashtray.
To remove the ashtray, pull it out from the
console. To reinstall the ashtray, slide it back to
the original position.
To use the cigarette lighter, if equipped, push it in
all the way, and let go. When it’s ready, it will
pop back out by itself.
Notice:Holding a cigarette lighter in while it
is heating will not allow the lighter to back
away from the heating element when it is hot.
Damage from overheating may occur to the
lighter or heating element, or a fuse could be
blown. Do not hold a cigarette lighter in
while it is heating.
Climate Controls
Dual Automatic Climate Control
System
With this system, you can control the heating,
cooling and ventilation in your vehicle.
You can select different climate control settings for
the driver and passengers.
197

9(Off):Press this button to turn off the entire
climate control system. Outside air will still
enter the vehicle, and will be directed to the oor.
This direction can be changed by pressing the
mode button. The temperature can also be
adjusted using either temperature knob. Press the
up or down arrows on the fan switch, the defrost
button, the AUTO button, or the air conditioning
button to turn the system on when it is off.
Manual Operation
You may manually adjust the air delivery mode or
fan speed.
w9x(Fan):The switch with the fan symbol
allows you to manually adjust the fan speed. Press
the up arrow to increase fan speed and the
down arrow to decrease fan speed.
Pressing this button when the system is off will
turn the system on.
C(Mode):Press this button to manually
change the direction of the airow in your vehicle;
repeatedly press the button until the desired
mode appears on the display.If you press the mode button to select an air
delivery mode, the display will change to show you
the selected air mode delivery. The display will then
show the current status of the system. When the
system is turned off, the display will go blank after
displaying the current status of the system.
H(Panel):This setting will deliver air to the
instrument panel outlets.
)(Bi-Level):This setting will deliver warmer air
to the oor and cooler air to the instrument
panel outlets.
6(Floor):This setting will deliver air to the
oor outlets.
-(Defog):See “Defogging and Defrosting” later
in this section.
@(Recirculation):Press this button to limit the
amount of outside air entering your vehicle. The
light on the recirculation button will glow. This is
helpful when you are trying to limit odors entering
your vehicle and for maximum air conditioning
performance in hot weather. Press this button again
to allow outside air to enter the vehicle. The light on
the recirculation button will go off.
200
