HUMMER H3 2008 Manual Online

Doors and Locks
Door Locks
{CAUTION:
Unlocked doors can be dangerous.
Passengers, especially children, can easily
open the doors and fall out of a moving
vehicle. When a door is locked, the handle
will not open it. You increase the chance
of being thrown out of the vehicle in a
crash if the doors are not locked. So, wear
safety belts properly and lock the doors
whenever you drive.
Young children who get into unlocked
vehicles may be unable to get out. A child
can be overcome by extreme heat and can
suffer permanent injuries or even death
from heat stroke. Always lock your vehicle
whenever you leave it.
Outsiders can easily enter through an
unlocked door when you slow down or
stop your vehicle. Locking your doors can
help prevent this from happening.There are several ways to lock and unlock your vehicle.
From the outside, use the key in the driver’s door or
use the remote keyless entry transmitter.
From the inside, use the manual lock levers or power
door lock switch.
2-7

Power Door Locks
The power door lock
switches are located on
the driver’s and the
front passenger’s doors.
Press L (lock) to lock all the doors at once.
To unlock all the doors, press U (unlock).
Programmable Automatic
Door Locks
If your vehicle has an automatic transmission, it is
programmed from the factory to lock the doors
automatically when the shift lever is moved out of
PARK (P). All the doors will unlock when the shift lever
is moved back into PARK (P).
If your vehicle has a manual transmission, it is
programmed from the factory to lock the doors
automatically when the vehicle speed is greater than
15 mph (24 km/h). The doors will unlock when the key is
removed from the ignition.
To personalize the automatic door locks, see “Automatic
Door Locks” underDIC Operation and Displays on
page 3-40. Driver’s side shown
2-8

Rear Door Security Locks
With this feature, you can lock the rear doors so they
cannot be opened from the inside.
The rear door security lock
is located on the inside
edge of each rear door.
To engage the security locks, do the following:
1. Open one of the rear doors.
2. Using your ignition key, turn the lock toward the
front of the vehicle.
3. Close the door.
4. Repeat these steps on the other rear door.If you want to open a rear door when the security lock
is on, unlock the door and open the door from the
outside.
To disengage the security locks, do the following:
1. Open one of the rear doors.
2. Using your ignition key, turn the lock to the vertical
position.
3. Close the door.
4. Repeat these steps on the other rear door.
Lockout Protection
This feature protects you from locking your key in the
vehicle when the key is in the ignition and a door
is open.
If the power door lock switch is pressed when a door is
open and the key is in the ignition, all of the doors
will lock and then the driver’s door will unlock. A chime
will sound to indicate that the key has been left in
the ignition.
2-9

Swing-gate
To lock or unlock the swing-gate, use the power door
lock switch or the remote keyless entry transmitter.
{CAUTION:
Make sure the swing-gate is completely closed.
Driving with the swing-gate open could injure
pedestrians or damage the vehicle.
To open the swing-gate, pull the door handle.
Pull the swing-gate rearward slightly and it will
automatically open.
2-10

Windows
{CAUTION:
Leaving children, helpless adults, or pets in a
vehicle with the windows closed is dangerous.
They can be overcome by the extreme heat
and suffer permanent injuries or even death
from heat stroke. Never leave a child, a
helpless adult, or a pet alone in a vehicle,
especially with the windows closed in warm
or hot weather.
2-11

Power Windows
{CAUTION:
Leaving children, helpless adults, or pets in a
vehicle with the windows closed is dangerous.
They can be overcome from extreme heat in
warm or hot weather and suffer permanent
injuries or even death from heat stroke.
Leaving children in a vehicle with the ignition
key is dangerous for many reasons, children
or others could be badly injured or even killed.
They could operate the power windows or
other controls or even make the vehicle move.
The windows will function with the keys in the
ignition and they could be seriously injured
or killed if caught in the path of a closing
window. Do not leave keys in a vehicle with
children.
When there are children in the rear seat use
the window lockout button to prevent
unintentional operation of the windows.The power window controls are located on each door.
The driver’s door has switches for the passenger
windows as well. Your power windows will work when
the ignition is in ACC (Accessory) or ON, or when
Retained Accessory Power (RAP) is active. See
Retained Accessory Power (RAP) on page 2-20.
Pull up the front edge of the control to raise the window.
Press the front edge of the control down to lower the
window.
2-12

Express-Down Window
The driver’s window has an express-down feature that
allows you to lower the window without holding the
switch. Press the front edge of the switch past the
rst position to activate the express-down mode.
The express-down mode can be canceled at any
time by pulling up on the switch. To open the window
partway, press the front of the switch to the rst position
until the window is at the desired level.
Window Lockout
o
(Window Lockout):The window lockout button is
located forward of the window switches. This feature
disables the passenger’s window switches when
the button is pressed. Press the button again to turn the
lockout off. A red band on the side of the button can
be seen when the windows are not locked out.
Sun Visors
To block glare, pull the visor down. It can also be
detached from the center mount and moved to the side
to block glare from that direction. There are extenders
that can be pulled out for further coverage.
Visor Vanity Mirror
Your vehicle has a vanity mirror located on the driver’s
and passenger’s visor.
Illuminated Visor Vanity Mirror
Your vehicle may have an illuminated vanity mirror on
both visors. Lift the cover on the mirror and the lights will
automatically come on.
2-13

Theft-Deterrent Systems
Vehicle theft is big business, especially in some cities.
Although your vehicle has a number of theft-deterrent
features, we know that nothing we put on it can make it
impossible to steal.
Content Theft-Deterrent
Your vehicle has a
content theft-deterrent
alarm system.
To activate the content theft-deterrent system:
1. Close all the doors.
2. Lock the doors with the remote keyless entry
transmitter. The security light, located on the
instrument panel cluster, will ash.
If the lock button on the remote keyless entry transmitter
is pressed, but a door is open, the doors will lock,
the lights may ash and the horn may sound. Close
the open door and the alarm system will arm.If a locked door is not opened using the remote keyless
entry transmitter, or by OnStar
®, the alarm will go off.
First, a pre-alarm will sound the horn at reduced
intensity for 10 seconds. Then, the front turn signal
lamps will ash for two minutes, and the horn will sound
for two minutes. The alarm will then turn off to save
battery power.
Starting the engine with the correct key will shut off the
pre-alarm or alarm at any time.
Remember, the theft-deterrent system will not activate
if you lock the doors with the key, the manual door lock,
or power door lock switch. The system can only be
activated using the remote keyless entry transmitter, or
by OnStar
®. SeeOnStar®System on page 2-48for
additional information. You should also remember that
you can start your vehicle with the correct key if the
alarm has been set off.
Here is how to avoid setting off the alarm by accident:
If you do not want to arm the theft-deterrent
system, the vehicle should be locked with the
manual door lock lever, the power door lock switch,
or the key, after the doors are closed.
If the content theft-deterrent system is armed,
unlock the doors by pressing the unlock button
on the remote keyless entry transmitter or by
OnStar
®. Unlocking a door any other way will
activate the alarm.
2-14

If you set off the alarm by accident, you can turn it off
by pressing unlock on the remote keyless entry
transmitter, starting the vehicle with the correct key, or
by having OnStar
®unlock the doors. The alarm will
not stop if you try to unlock a door any other way.
Testing the Alarm
To test the alarm:
1. From inside the vehicle, activate the system by
locking the doors with the remote keyless entry
transmitter.
2. Unlock the door with the manual door lock and
open the door. This should set off the pre-alarm.
Wait 10 seconds for the full alarm to activate.
3. To turn the alarm off, press the unlock button
on the remote keyless entry transmitter or start
the engine.
If the alarm does not sound when it should but the
lights ash, check to see if the horn works. The horn
fuse may be blown. To replace the fuse, seeFuses
and Circuit Breakers on page 5-102.
If the alarm does not sound or the front turn signal
lamps do not ash, see your dealer/retailer for service.
Passlock®(U. S. Only)
Your vehicle has the Passlock®theft-deterrent system.
Passlock®is a passive theft-deterrent system.
Passlock®enables fuel if the ignition lock cylinder is
turned with a valid key. If an incorrect key is used or the
ignition lock cylinder is tampered with, the fuel system
is disabled and the vehicle will not start.
During normal operation, the security light will turn off
approximately ve seconds after the engine is started.
SeeSecurity Light on page 3-39.
If the engine stalls and the security light ashes, wait
about 10 minutes until the light stops ashing before
trying to restart the engine. Remember to release
the key from START as soon as the engine starts.
If the engine does not start after three tries, the vehicle
needs service.
If the engine is running and the security light comes on,
you will be able to restart the engine if you turn the engine
off. However, your Passlock
®system is not working
properly and must be serviced by your dealer/retailer.
Your vehicle is not protected by Passlock
®at this time.
See your dealer/retailer for service.
In an emergency, call the Roadside Assistance Center.
SeeRoadside Assistance Program on page 7-6.
Do not leave the key or device that disarms or
deactivates the theft deterrent system in the vehicle.
2-15

PASS-Key®III+
The PASS-Key®III+ system operates on a radio
frequency subject to Federal Communications
Commission (FCC) Rules and with Industry Canada.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received,
including interference that may cause undesired
operation.
This device complies with RSS-210 of Industry Canada.
Operation is subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference received,
including interference that may cause undesired
operation of the device.
Changes or modications to this system by other than
an authorized service facility could void authorization to
use this equipment.
PASS-Key
®III+ uses a radio frequency transponder in
the key that matches a decoder in your vehicle.
PASS-Key®III+ Operation
(Canada Only)
Your vehicle has a passive theft-deterrent system.
The system is automatically armed when the key
is removed from the ignition.
The system is automatically disarmed when the key is
turned to ON/RUN.
You do not have to manually arm or disarm the system.
The security light will come on if there is a problem
with arming or disarming the theft-deterrent system.
The key uses a transponder that matches an immobilizer
control unit in your vehicle. Only the correct key will
start the vehicle. If the key is ever damaged, you may
not be able to start your vehicle.
When trying to start the vehicle, if the engine does not
start and the security light comes on, there may be
a problem with your theft-deterrent system. Turn
the ignition off and try again.
If the engine still does not start, and the key appears
to be undamaged, try another ignition key. At this
time, you may also want to check the fuse.
SeeFuses and Circuit Breakers on page 5-102.
2-16
