Page 25 of 219
1
FEATURES OF YOUR HYUNDAI
13
B080E01O-AATLumbar Support Control
(Driver's Seat only) (If Installed)To adjust the lumbar support, turn the handle
on the outboard or left side of the seat. To
increase the amount of lumbar support, pull
the lever forward. To decrease it, push the
lever toward the rear.
1. Minimum support
2. Maximum supprot
HLC2029B080F01S-AAT
Seat Cushion Height Adjustment
(Driver's Seat only) (If Installed)To raise or lower the front part of the seat
cushion, turn the front knob forward or rearward.
To raise or lower the rear part of the seat
cushion, turn the rear knob forward or rear-
ward.
Clockwise raises the seat, counterclockwise
lowers the seat.
HLC2028B080G01A-GAT
Adjusting Armrest Angle
(Driver's side only)The armrest will be raised or lowered manu-
ally.
To raise the armrest, pull it up.
To lower it, press the armrest down.
B080G02A-1
(1)
(2)
Page 31 of 219
1
FEATURES OF YOUR HYUNDAI
19
To fasten your seat belt, pull it out of the
retractor and insert the metal tab into the
buckle. There will be an audible "click" when
the tab locks into the buckle.
The seat belt automatically adjusts to the
proper length only after the lap belt is adjusted
manually so that it fits snugly around your hips.
If you lean forward in a slow, easy motion, the
belt will extend and let you move around. If
there is a sudden stop or impact, however, the
belt will lock into position. It will also lock if you
try to lean forward too quickly.
B190A01A-AATSEAT BELTS-Front Passenger and
Outboard Rear Seat 3-Point System
with Combination Locking Retractor :
To Fasten Your BeltCombination retractor type seat belts are in-
stalled in the rear seat outboard positions to
help accommodate the installation of child re-
straint systems. Hyundai strongly recommends
that children always be seated in the rear seat.
NEVER place any infant restraint system in
the front seat of the vehicle.
This type of seat belt combines the features
of both an emergency locking retractor seat
belt and an automatic locking retractor seat
belt. To fasten your seat belt, pull it out of the
retractor and insert the metal tab into the
buckle. There will be an audible "click" when
the tab locks into the buckle. When not secur-
ing a child restraint, the seat belt operates in
the same way as the driver's seat belt (Emer-
gency Locking Retractor Type). It automati-
!
B180A01A-AATSEAT BELT-Driver's 3-Point System
with Emergency Locking Retractor
To Fasten Your Belt
WARNING:
o The height adjuster must be in the
locked position when the vehicle is
moving.
o The misadjustment of height of the shoul-
der belt could reduce the effectiveness of
the seat belt in a crash.
B180A01L
it down while pressing the height adjuster
button.
Release the button to lock the anchor into
position. Try sliding the height adjuster to
make sure that it has locked into the position.
NOTE:If the driver's seat belt is not fastened when
the ignition key is in the "ON" position, the
seat belt warning light will flash and the warn-
ing chime will sound for approximately six
seconds.
Page 178 of 219
6
DO-IT-YOURSELF MAINTENANCE
23
G240A01A-AATPOWER STEERING HOSESIt is suggested that you check the power steer-
ing hose connections for fluid leakage at those
intervals specified in the vehicle maintenance
schedule in Section 5.
The power steering hoses should be replaced if
there is severe surface cracking, pulling, scuff-
ing or worn spots. Deterioration of the hose
could cause premature failure.Recommended FluidUse PSF-3 type fluidNOTE:Do not start the engine when the power
steering oil reservoir is empty.
HEADLIGHT AIMING ADJUSTMENT
G250A01A-AATFOR MORE INFORMATION ABOUT
YOUR HYUNDAIIf you desire additional information about main-
taining and servicing your Hyundai, you may
purchase a factory Shop Manual at your Hyundai
dealer's parts department. This is the same
manual used by dealership technicians and while
it is highly technical it can be useful in obtaining
a better understanding of your car and how it
works.
G290A04A-AATBefore performing aiming adjustment, make sure
of the following.
1. Keep all tires inflated to the correct pressure.
2. Place the vehicle on level ground and press
the front bumper & rear bumper down sever-
al times. Place vehicle at a distance of 118
in. (3m) from the test wall.
3. See that the vehicle is unloaded (except for
full levels of coolant, engine oil and fuel, and
spare tire, jack, and tools). Have the driver or
equivalent weight placed in driver's seat.
4. Clean the headlight lenses and turn on the
headlights (Low beam).
5. Open the hood.
G290A01A-1
Vertical
Aiming
Page 215 of 219
10
INDEX
3
D
Defrosting/Defogging.......................................................................1-72
Door
Central door lock .......................................................................... 1-6
Door locks.................................................................................... 1-4
Locking, unlocking front door with a key ................................... 1-4
Drink Holder.....................................................................................1-53
Drive Belts........................................................................................6-19
Driving
Economical driving......................................................................2-12
Smooth cornering.......................................................................2-13
Winter driving..............................................................................2-13
Dual-Stage Supplemental Restraint (AIRBAG) System ................1-30
E
Emission Control Systems................................................................ 7-1
Engine
Before starting the engine ............................................................ 2-3
Compartment (For 1.6 DOHC) ................................................... 6-2
Coolant.......................................................................................... 6-6
Coolant temperature gauge .......................................................1-42
If the engine overheats ................................................................ 3-4
Number.......................................................................................... 8-2
Oil .................................................................................................. 6-4
Starting.......................................................................................... 2-4
Engine Exhaust Can Be Dangerous ................................................ 2-2F
Fan Speed Control (Blower Control)..............................................1-66
Fog Light
Front............................................................................................1-51
Front Seats
Adjustable front seats ................................................................1-11
Adjustable headrests..................................................................1-12
Adjusting seatback angle ...........................................................1-11
Adjusting seatback forward and rearward...............................1-11
Lumbar support control ..............................................................1-13
Seat cushion height adjustment................................................1-13
Seat pocket.................................................................................1-55
Fuel
Capacity........................................................................................ 9-2
Gauge..........................................................................................1-42
Recommendations........................................................................ 1-2
Fuel Filler Lid
Remote release..........................................................................1-60
Fuses ......................................................................................................
6-19
G
General Checks................................................................................ 6-3
Glove box.........................................................................................1-55
H
Hazard Warning System .................................................................1-50
