Hyundai Accent 2009 Owner's Manual - RHD (UK. Australia)

1FEATURES OF YOUR HYUNDAI
90HEATING AND VENTILA- TION
B670B01A-AAT Fan Speed Control (Blower Control) This is used to turn the blower fan on or off and to select the fan speed. This blower fan speed, and therefore the volume of air delivered from thesystem, may be controlled manually by setting the blower control between the "1" and "4" positions.
B670A02A-DAT
(If Installed)
1. Temperature control
2. Air conditioning switch
3. Air intake control switch
4. Air flow control
5. Fan speed control
B670A01MC-D
OMC025083
B670C03A-AAT Air Intake Control Switch
This is used to select fresh outside air or recirculating inside air.
Fresh

Recirculation
With the "
" mode selected, air en-
ters the vehicle from outside and is heated or cooled according to the otherfunctions selected. With the "
" mode selected, air from
within the passenger compartment is drawn through the heating system and heated or cooled according to the other functions selected.
B670C02MC

1
FEATURES OF YOUR HYUNDAI
91
B670D02MCR
NOTE: It should be noted that prolonged operation of the heating system in "
" mode will give rise to misting
of the windshield and side windows and the air within the passenger com- partment will become stale. In addi-tion prolonged use of the air condi- tioning with the "
" mode selected
may result in the air within the pas- senger compartment becoming ex- cessively dry.
Face-Level
Selecting the "Face" mode will causeair to be discharged through the face level vents.
B670D02MC-DAT Air Flow Control This is used to direct the flow of air. Air can be directed to the floor, instrument panel outlets, or windshield. Five sym-bols are used to represent Face, Bi- Level, Floor, Floor-Demist and Demist air position.
B670D01MC-D

1FEATURES OF YOUR HYUNDAI
92
Bi-Level
Air is discharged through the face vents and the floor vents. Floor-Level
Air is discharged through the floor vents,windshield demister nozzle, side demister nozzle and side ventilator. Floor-Demist Level
Air is discharged through the wind-shield demister nozzle, the floor vents, side demister nozzle and side ventila-tor.
B670D03MCRB670D04MCRB670D05MCR

1
FEATURES OF YOUR HYUNDAI
93HEATING CONTROLS
For normal heating operation, set the air intake control to the fresh air (
)
position and the air flow control to the floor (
) position.
For faster heating, the air intake control should be set in the recirculate (
)
position. If the windows fog up, set the air flow control to the demist (
) position.
(Push the A/C button to turn the air conditioning system on and set the air intake control to the fresh air (
)
position.) For maximum heat, move the tempera- ture control to "Warm". B690A01MC-DAT
B670E02A-AAT Temperature Control This control is used to adjust the degree of heating or cooling desired.
Demist-Level
Air is discharged through the wind- shield demister nozzle, side demister nozzle and side ventilator.
B670D06MCR
B670E01MC
B690A01MC-D
COOL WARM

1FEATURES OF YOUR HYUNDAI
94DEMISTING/DEFOGGINGVENTILATIONBI-LEVEL HEATING
B720A01MC-DAT Use the heating/ventilation system to demist or defog the windshield: To remove interior fog on the windshield:
o Set the air flow control to the demist(
) position. (Push the A/C button
to turn the air conditioning system on and set the air intake control to the fresh air (
) position.)
o Set the temperature control to the desired position.
o Set the fan speed control between
"1" and "4" position.
B700B02A-AAT Your Hyundai is equipped with bi-level heating controls. This makes it pos- sible to have cooler air from the dash-board vents and warmer air from the floor outlets at the same time. To use this feature:
o Set the air intake control to the fresh
air (
) position.
o Set the air flow control at the bi-level (
) position.
o Adjust the fan speed control to the
desired speed.
o Set the temperature control between "Cool" and "Warm". B710A01A-AAT To operate the ventilation system:
o Set the air intake control to "Fresh"
mode (
).
o To direct all intake air to the dash-
board vents, set the air flow control to the (
) position.
o Adjust the fan speed control to the
desired speed.
o Set the temperature control between "Cool" and "Warm".
B700B01MC-DB710A01MC-DB720A01MC-D

1
FEATURES OF YOUR HYUNDAI
95
To remove the frost or exterior fog on the windshield:
o Set the air flow control to the demist
(
) position. (Push the A/C button
to turn the air conditioning system on and set the air intake control to the fresh air (
) position.)
o Set the temperature control to warm.
o Set the fan speed control to position "3" or "4".
B720A02MC-D B730A01L-AAT Operation Tips
o To keep dust or unpleasant fumes
from entering the car through the ventilation system, temporarily set the air intake control at the (
)
position. Be sure to return the control to the (
) position when the irrita-
tion has passed to keep fresh air in the vehicle. This will help keep thedriver alert and comfortable.
o Air for the heating/cooling system is
drawn in through the grilles just aheadof the windshield. Care should be taken that these are not blocked by leaves, snow, ice or other obstruc-tions.
o To prevent interior fog on the wind-
shield, set the air intake control tothe fresh air (
) position, fan speed
to the desired position, turn on the air conditioning system, and adjust tem-perature control to desired tempera- ture.
NOTE: When the A/C is operated continu- ously on the floor-demist level (
)
or demist level (
), it may cause fog
to form on the exterior windshield. If this occurs, set the air flow control to the face level position (
) and fan
speed control to the low position.

1FEATURES OF YOUR HYUNDAI
96
B740B01MC-DAT Air Conditioning Operation (Cooling) To use the air conditioning to cool the interior:
o Turn on the fan control switch.
o Turn on the air conditioning switch by
pushing in on the switch. The air conditioning indicator light should come on at the same time.
o Set the temperature control to "Cool". ("Cool" provides maximum cooling.The temperature may be moderatedby moving the control toward "Warm".) o Adjust the fan speed control to the
desired speed. For greater cooling, turn the fan speed control to one of the higher speeds or temporarily se- lect the (
) position on the air
intake control.
B740B01MC-D
AIR CONDITIONING SYSTEM
B740A01A-AAT (If Installed) Air Conditioning Switch
The air conditioning is turned on by pushing the A/C button on the heating/ air conditioning control panel.
B740A01MC-D

1
FEATURES OF YOUR HYUNDAI
97
B740D01A-AAT Operation Tips
o If the interior of the car is hot when you first get in, open the windows for a few minutes to expel the hot air.
o When you are using the air condition-
ing system, keep all windows closedto keep hot air out.
o When moving slowly, as in heavy
traffic, shift to a lower gear. Thisincreases engine speed, which in turn increases the speed of the air conditioning compressor.
o On steep grades, turn the air condi- tioning off to avoid the possibility ofthe engine overheating.
o During winter months or in periods when the air conditioning is not usedregularly, run the air conditioning onceevery month for a few minutes. This will help circulate the lubricants and keep your system in peak operatingcondition.
B740C01MC-AAT De-Humidified Heating
For dehumidified heating:
o Turn on the fan control switch.
o Turn on the air conditioning switch. The air conditioning indicator light should come on at the same time.
o Set the air intake control to the fresh air (
) position.
o Adjust the fan speed control to the
desired speed.
o For more rapid action, set the fan at one of the higher speeds.
o Adjust the temperature control to provide the desired amount of warmth.
B740C01MC-D

1FEATURES OF YOUR HYUNDAI
98
B760A01MC
CLIMATE CONTROL AIR FIL- TER
!
The climate control air filter is located in the passenger cabin in front of the evaporator unit behind the glove box. It functions to decrease the amount ofpollutants entering the car. To replace the climate control air filter, refer to the page 6-16.
B760A07A-DAT
(For Evaporator and Blower Unit)
CAUTION:
o Replace the filter every 15,000 km (10,000 miles) or once a year. If the car is being driven in severe con-ditions such as dusty, rough roads, more frequent climate con- trol air filter inspections andchanges are required.
o When the air flow rate is de-
creased, it must be checked at anauthorised dealer.
Inside of a vehicle
Evaporator core
Blower
FilterInside air
Outside air

1
FEATURES OF YOUR HYUNDAI
99
B750A01L
STEREO SOUND SYSTEM
Ionosphere
AM reception
Mountains
Buildings Unobstructed
area
FM radio station
B750A03L
Ionosphere
FM receptionObstructed area
Iron bridges
FM broadcasts are transmitted at high frequencies and do not bend to follow the earth's surface. Because of this, FM broadcasts generally begin to fadeat short distances from the station. Also, FM signals are easily affected by buildings, mountains, or other obstruc-tions. These can result in certain listen- ing conditions which might lead you to believe a problem exists with your ra-dio. The following conditions are normal and do not indicate radio trouble:
AM broadcasts can be received at greater distances than FM broadcasts. This is because AM radio waves are transmitted at low frequencies. Theselong, low frequency radio waves can follow the curvature of the earth rather than travelling straight out into the at-mosphere. In addition, they curve around obstructions so that they can provide better signal coverage.
B750A02A-AAT How Car Audio Works
AM and FM radio signals are broadcast from transmitter towers located around your city. They are intercepted by theradio antenna on your car. This signal is then received by the radio and sent to your car speakers.When a strong radio signal has reached your vehicle, the precise engineering of your audio system ensures the bestpossible quality reproduction. Howev- er, in some cases the signal coming to your vehicle may not be strong andclear. This can be due to factors such as the distance from the radio station,
B750A02L
closeness of other strong radio stations or the presence of buildings, bridges orother large obstructions in the area.
