Page 31 of 389
FEATURES OF YOUR HYUNDAI 1- 23
WARNING:
o The side impact airbag is supplemental to
the driver's and the passenger's seat beltsystems and is not a substitute for them.Therefore your seat belts must be worn atall times while the vehicle is in motion. Theairbags deploy only in certain side impactconditions severe enough to cause sig-nificant injury to the vehicle occupants.
o For best protection from the side impact airbag system and to avoid being injuredby the deploying side impact airbag, bothfront seat occupants should sit in an up-right position with the seat belt properlyfastened. The driver's hands should beplaced on the steering wheel at the 9:00and 3:00 o'clock positions. Thepassenger's arms and hands should beplaced on their laps.
o Do not use any accessory seat covers.
o Use of seat covers could prevent or re- duce the effectiveness of the system.
o Do not install any accessories on the side or near the side impact airbag.
o Do not use excessive force on the side of the seat.
o Do not place any objects over the airbag or between the airbag and yourself.
o Do not place any objects (an umbrella, bag, etc.) between the front door and thefront seat. Such objects may become dan-gerous projectiles and cause injury if thesupplemental side impact airbag inflates.
Your Hyundai is equipped with a side impactairbag in each front seat. The purpose of theairbag is to provide the vehicle's driver and/or thefront passenger with additional protection thanthat offered by the seat belt alone. The sideimpact airbags are designed to deploy only dur-ing certain side-impact collisions, depending onthe crash severity, angle, speed and point ofimpact. The side impact airbags are not de-signed to deploy in all side impact situations.
B990B04Y-AAT Side Impact Airbag
B990B02Y
o To prevent unexpected deployment of the
side impact airbag that may result in per- sonal injury,avoid impact to the side airbagsensor when the ignition key is on.
B240C02Y-GAT SRS Care The SRS is virtually maintenance-free and there are no parts you can safely service by yourself.The entire SRS system must be inspected by anauthorized Hyundai dealer 10 years after thedate that the vehicle was manufactured. Any work on the SRS system, such as removing, installing, repairing, or any work on the steeringwheel must be performed by a qualified Hyundaitechnician. Improper handling of the SRS sys-tem may result in serious personal injury.
YT10355A
Page 32 of 389
FEATURES OF YOUR HYUNDAI
1- 24 o Do not tamper with or disconnect SRS
wiring, or other components of the SRS system. Doing so could result in injury,due to accidental firing of the airbags orby rendering the SRS inoperative.
o If components of the airbag system must be discarded, or if the vehicle must be
scrapped, certain safety preca utions must
be observed. Your Hyundai dealer knowsthese precautions and can give you the
necessary information. Failure to followthese precautions and procedures could
increase the risk of personal injury.
o If you sell your vehicle, be sure to inform the new owner of these important pointsand make certain that this manual is trans-ferred to the new owner.
o If your car was flooded and has soaked carpeting or water on flooring, youshouldn't try to start engine; have the car
towed to authorized Hyundai dealer.
WARNING:
o Do not install a child restraint system in
the front passenger seat position.
A child restraint system must never be placed in the front seat. The infant or childcould be severely injured by an airbagdeployment in case of an accident.
o Extreme Hazard! Do not use a reward facing restraint on a seat protected by anairbag in front of it!
o Modification to SRS components or wir- ing, including the addition of any kind ofbadges to the pad covers or modifications
to the body structure, can adversely affectSRS performance and lead to possibleinjury.
o For cleaning the airbag pad covers, use only a soft, dry cloth or one which hasbeen moistened with plain water. Solventsor cleaners could adversely affect theairbag covers and proper deployment ofthe system.
o No objects should be placed over or near the airbag modules on the steering wheel,instrument panel, and the frontpassenger's panel above the glove box,because any such object could cause harmif the vehicle is in a crash severe enoughto cause the airbags to inflate.
o If the airbags inflate, they must be re- placed by an authorized Hyundai dealer.
Page 33 of 389
FEATURES OF YOUR HYUNDAI 1- 25
B250A01GK-GAT INSTRUMENTS AND CONTROLS
1. Head Light Leveling Device (If installed)
2. Traction Control System (If installed)
3. Panel Brightness Control Knob(Rheostat Switch) (If installed)
4. Multi-Function Light
5. Windshield Wiper/Washer Switch
6. Front Fog Light Switch (If installed)
7. Rear Fog Light Switch (If installed)
8. Hazard Warning Switch
9. Digital Clock
10. Front Seat Warmer (If installed)
11. Passenger's Air Bag (If installed)
12. Passenger's side Drink Holder
13. Hood Release Lever
14. Fuse Box Relay
15. Steering Wheel Tilt Lever
16. Horn and Driver's Airbag
17. Cruise Control Switch (If installed)
18. Heating and Cooling Controls
19. Ashtray
20. Cigarette Lighter
21. Shift Lever
22. Audio System (If installed)
23. Multi Guage (If installed)
24. Parking Brake Lever
25. Glove Box
26. Center Console
CAUTION:When installing a container of liquid air freshener inside the vehicle, do not place it near theinstrument cluster nor on the instrument panel surface. If there is any leakage from the airfreshener onto these areas (Instrument cluster, instrument panel or air ventilator), it may damagethese parts. If the liquid from the air freshener does leak onto these areas, wash them with waterimmediately. HGK001A
12
3
4 5
67 8 9
10
11 12
13 14 15 16 1718 1920 21 2223 24 25 26
Page 34 of 389
FEATURES OF YOUR HYUNDAI
1- 26
HGK026C
B260A01GK-GAT INSTRUMENT CLUSTER AND INDICATOR LIGHTS
1234 5 6 7 8
9 10 11 12
1314
151617 18 19 20
1. Speedometer
2. Turn Signal Indicator Light
3. Odometer/Trip Odometer
4. Automatic Transaxle Position Indicator Light (If installed)
5. Coolant Temperature Gauge
6. Trip Computer
7. Fuel Gauge 8. Tachometer
9. Traction Control Indicator Light (If installed)
10. Door Ajar Warning Light
11. Odometer/Trip Odometer Reset Knob
12. Charging System Warning Light
13. SRS (Airbag) Warning Light
14. Seat Belt Warning Light
15. High Beam Indicator Light
16. Oil Pressure Warning Light17. Malfunction Indicator Light (If installed)
18. Low Fuel Warning Light
19. Parking Brake/Brake Fluid Level Warning
Light
20. Trip Computer Reset Knob
21. Cruise Indicator (If installed)
22. Tailgate Open Warning Light
23. Anti-Lock Brake Warning Light (If installed)
2
2122
23
Page 35 of 389
FEATURES OF YOUR HYUNDAI 1- 27
B260B01GK-GAT
SRS (Airbag) Service Reminder Indicator (SRI)
The SRS service reminder indicator (SRI) comes on and flashes for about 6 seconds after theignition key is turned to the "ON" position or afterthe engine is started, after which it will go out. This light also comes on when the SRS is not working properly. If the SRI does not come on orilluminates continuously when the ignition key isturned to "ON", or continuously remains on afterflashing for about 6 seconds when you turned theignition key to the "ON" position or started theengine, or if it comes on while driving, have theSRS inspected by an authorized Hyundai Dealer. B260P02Y-GAT
ABS Service Reminder Indicator (SRI)(If installed)
When the key is turned to the "ON" position, the Anti-Lock Brake System will come on and thengo off in a few seconds. If the ABS SRI remainson, comes on while driving, or does not come onwhen the key is turned to the "ON" position, thisindicates that there may be a problem with theABS.If this occurs, have your vehicle checked by yourHyundai dealer as soon as possible. The normalbraking system will still be operational, but with-out the assistance of the anti-lock brake system. B260F01A-AAT
High Beam Indicator Light
The high beam indicator light comes on when-ever the headlights are switched to the highbeam or flash position.
B260D01A-AAT
Turn Signal Indicator Lights
The blinking green arrows on the instrumentpanel show the direction indicated by the turnsignals. If the arrow comes on but does not blink,blinks more rapidly than normal, or does notilluminate at all, a malfunction in the turn signalsystem is indicated. Your dealer should be con-sulted for repairs. B260G01A-AAT
Low Oil Pressure Warning Light
CAUTION:If the oil pressure warning light stays onwhile the engine is running, serious enginedamage may result. The oil pressure warninglight comes on whenever there is insufficientoil pressure. In normal operation, it shouldcome on when the ignition switch is turnedon, then go out when the engine is started. Ifthe oil pressure warning light stays on whilethe engine is running, there may be a seriousmalfunction.If this happens, stop the car as soon as it issafe to do so, turn off the engine and checkthe oil level. If the oil level is low, fill the engineoil to the proper level and start the engineagain. If the light stays on with the enginerunning, turn the engine off immediately. Inany instance where the oil light stays onwhen the engine is running, the engine shouldbe checked by an authorized Hyundai dealerbefore the car is driven again.
WARNING:If the both ABS SRI and Parking Brake/Brakefluid level warning lights remain "ON" orcome on while driving, there may be a prob-
lem with E.B.D (Electronic Brake Force Dis-tribution).If this occurs, avoid sudden stops and haveyour vehicle checked by your Hyundai dealeras soon as possible.
AIR
BAG
Page 36 of 389
FEATURES OF YOUR HYUNDAI
1- 28
B260J01S-GAT Charging System Warning Light
The charging system warning light should come on when the ignition is turned on, then go outwhen the engine is running. If the light stays onwhile the engine is running, there is a malfunctionin the electrical charging system. If the lightcomes on while you are driving, stop, turn off theengine and check under the hood. First, makecertain the generator drive belt is in place. If it is,check the tension of the belt.And then, have the system checked by yourHyundai dealer. CAUTION: If the drive belt (generator belt) is loose,broken, or mission while the vehicle is driv-ing, there may be a serious malfunction, en-gine could overheat because this belt alsodrives the water pump. B260L01A-GAT
Door Ajar Warning Light
The door ajar warning light warns you that a dooris not completely closed.
B260H01GK-AAT Parking Brake/Low Brake Fluid Level Warning Light
CAUTION: If you suspect brake trouble, have your brakeschecked by a Hyundai dealer as soon aspossible. Driving your car with a problem ineither the brake electrical system or brakehydraulic system is dangerous, and couldresult in a serious injury or death. Warning Light Operation The parking brake/brake fluid level warning light should come on when the parking brake is ap-plied and the ignition switch is turned to "ON" or"START". After the engine is started, the lightshould go out in three seconds.If the parking brake is not applied, the warninglight should come on when the ignition switch isturned to "ON" or "START", then go out in threeseconds. If the light comes on at any other time,you should slow the vehicle and bring it to acomplete stop in a safe location off the roadway.The brake fluid level warning light indicates thatthe brake fluid level in the brake master cylinderis low and hydraulic brake fluid conforming toDOT 3 or DOT 4 specifications should be added.After adding fluid, if no other trouble is found, thecar should be immediately and carefully driven toa Hyundai dealer for inspection. If further troubleis experienced, the vehicle should not be drivenat all but taken to a dealer by a professionaltowing service or some other safe method. Your Hyundai is equipped with dual-diagonalbraking systems. This means you still have brak-ing on two wheels even if one of the dual systemsshould fail. With only one of the dual systemsworking, more than normal pedal travel andgreater pedal pressure are required to stop thecar. Also, the car will not stop in as short adistance with only half of the brake system work-ing. If the brakes fail while you are driving, shift toa lower gear for additional engine braking andstop the car as soon as it is safe to do so.
B260M01A-AAT
Low Fuel Level Warning Light
The low fuel level warning light comes on when the fuel tank is approaching empty. When itcomes on, you should add fuel as soon aspossible. Driving with the fuel level warning lighton or with the fuel level below "E" can cause theengine to misfire and damage the catalytic con-verter.
B260K01F-AAT Tail Gate Open Warning Light
This light remains on unless the tail gate is completely closed and latched.
B265C01O-AAT Traction Control Indicator Lights (If installed)
The traction control indicators change operation according to the ignition switch position andwhether the system is in operation or not.They will illuminate when the ignition key isturned to the "ON" position, but should go outafter three seconds. If the TCS or TCS-OFF
Page 37 of 389
FEATURES OF YOUR HYUNDAI 1- 29
B280A01A-AAT FUEL GAUGE The needle on the gauge indicates the approxi- mate fuel level in the fuel tank. The fuel capacityis given in Section 9. B290A02A-AAT ENGINE COOLANT TEMPERATURE GAUGE
B270A01A-AATBRAKE PAD WEAR WARNING SOUNDThe front disc brake pads have wear indicators
that should make a high-pitched squealing orscraping noise when new pads are needed. The
sound may come and go or be heard all the time
when the vehicle is moving. It may also be heardwhen the brake pedal is pushed down firmly.
Excessive rotor damage will result if the wornpads are not replaced. See your Hyundai dealerimmediately.
HGK133
HGK132
B260N01GK-AAT
Malfunction Indicator Light (If installed)
This light illuminates when there is a malfunction of an exhaust gas related component, and thesystem is not functioning properly so that theexhaust gas regulation values are not satisfied.This light will also illuminate when the ignition keyis turned to the "ON" position, and will go out afterengine starting. If it illuminates while driving, ordoes not illuminate when the ignition key isturned to the "ON" position, take your car to yournearest authorized Hyundai dealer and have thesystem checked.
B260E01HP-GAT Seat Belt Warning Light (If Installed)
The seat belt warning light blinks for about 6 seconds when the ignition key is turned from the"OFF" position to "ON" or "START".
B260Q01E-GAT
Cruise Indicator (If Installed)
The cruise indicator light in the instrument cluster is illuminated when the cruise control main switchon the end of the barrel is pushed.The indicator light does not illuminate when thecruise control main switch is pushed a secondtime.Information about the use of cruise control isbeginning on page 1-46.indicator stays on, take your car to your autho- rized Hyundai dealer and have the systemchecked. See section 2 for more informationabout the TCS.
Page 38 of 389
FEATURES OF YOUR HYUNDAI
1- 30 B330A02A-AAT TACHOMETER
HGK131A
The tachometer registers the speed of your en- gine in revolutions per minute (rpm). CAUTION: The engine should not be raced to such aspeed that the needle enters the red zone onthe tachometer face. This can cause severeengine damage and may void your warranty.
WARNING:Never remove the radiator cap when the en-gine is hot. The engine coolant is under pres-sure and could erupt and cause severe burns.Wait until the engine is cool before removingthe radiator cap. The needle on the engine coolant temperature gauge should stay in the normal range. If itmoves across the dial to "H" (Hot), pull over andstop as soon as possible and turn off the engine.Then open the hood and, after the engine hascooled, check the coolant level and the waterpump drive belt. If you suspect cooling systemtrouble, have your cooling system checked by aHyundai dealer as soon as possible. B300A01A-GAT SPEEDOMETER Your Hyundai's speedometer is calibrated in kilometers per hour or miles per hour.
HGK130A
B310B01GK-GAT ODOMETER/TRIP ODOMETER
HGK028A
Function of digital odometer/trip odom- eter
Pushing in the reset switch on the right side of speedometer when the ignition switch is turned"ON" will display the following sequence:
HGK055A
132
Page 39 of 389
FEATURES OF YOUR HYUNDAI 1- 31
The trip computer is a microcomputer-controlled driver information gauge that displays informa-tion related to driving, such as estimated dis-tance to empty, average speed and drive time onthe LCD. RESET SWITCH
o The reset switch is used to zero the multi-functional display mode.
o Pushing in the reset switch on the left side of tacometer changes the display as follows;
HGK095A
B400B02GK-GAT TRIP COMPUTER
1. DISTANCE TO EMPTYDISTANCE TO EMPTY
AVERAGE SPEED DRIVE TIME
o This mode provides the estimated distance to empty from the current fuel level in the fuel tank.
o The trip computer may not register additional fuel if less than 6 liters of fuel are added to thevehicle.
o When the battery has been reinstalled after being discharged or disconnected, drive morethan 32km for an accurate distance to empty. HGK056
1. Odometer The odometer records the total driving distance in kilometers or miles, and is useful for keeping arecord for maintenance intervals. NOTE: Any alteration of the odometer may void yourwarranty coverage. 2,3 Trip odometer Records the distance of 2 trips in kilometers or miles.TRIP A:
First distance you have traveled from
your origination point to a first destination.TRIP B: Second distance from the first destina-
tion to the final destination. To shift from TRIP A to TRIP B, press the reset switch. When pressed for 1 second, it will resetto 0. A Type
B Type
A Type
B Type
Page 40 of 389
FEATURES OF YOUR HYUNDAI
1- 32 3. DRIVE TIME
HGK058
o This mode indicates the drive time travelled since the last drive time reset.
o To reset the drive time to zero, press and hold the reset switch for more than 1 second while the drive time is being displayed.
NOTE:
o When the distance to empty is less than 50
km, the symbol will always come on andthe distance to empty digits will indicate"---" with flash until more fuel is added.
o The distance to empty can differ from the actual tripmeter according to driving con-ditions.
o The distance to empty can vary according to the driving conditions, driving patternor vehicle speed.
2. AVERAGE SPEED
o This mode indicates the average speed trav- elled since the last average speed reset.
o To reset the average speed to zero, press and hold the reset switch for more than 1 second while the average speed is beingdisplayed. HGK057A B330C01GK-GAT
MULTI GAUGE (If installed)Multi gauge is consists of torque gauge, instan- taneous fuel consumption gauge and volt gauge. Torque gauge It shows instantaneous change of the torque by rpm.
HGK229A
HGK230
A Type
B Type
A TypeB Type
