Hyundai Elantra GT 2017 Quick Reference Guide

FEATURES AND CONTROLS
ELANTRA GT
19 18
HYUNDAI
Audio control
VOLUME
SEEK / PRESET

Change station
MODE
MUTE

Change the
audio source
VOLUME
Raises or lowers
speaker volume.
MUTE

Mute the microphone during a call.
TALK
Activates voice recognition.
CALL
Answer, places, and transfers calls.
END
Ends calls or cancels functions.
Bluetooth control
Cruise indicator
Cruise set indicator
To set a cruising speed

1.
Press CRUISE button
and the CRUISE indicator will illuminate in
the instrument cluster.
Accelerate to desired cruising speed (above 20 mph)
2. Press SET - button
and remove your foot from the accelerator pedal.
To Accelerate or DeceleratePress RES +
button

up to increase set cruising speed.
Press SET -
button
down to decrease set cruising speed.
To Cancel Cruising SpeedPress CANCEL button
, depress brake pedal, or press
CRUISE
button
.
Cruise control systemSTEERING WHEEL CONTROLS


ANDROIDAUTO™




MULTIMEDIA
ELANTRA GT
21 20
HYUNDAI
VOICE RECOGNITION TIPSYour vehicle is equipped with Voice Recognition technology which allows
drivers to operate their phones without having to take their eyes off the road
to minimize distractions.
Voice recognition performance may be affected if driving with windows
and sun roof open; when the heating-cooling system is on; when passing
a tunnel or when driving on rugged and uneven roads.
For complete list of commands, refer to your Owner’s Manual or Navigation
System Manuals (if equipped).
BLUETOOTH OPERATIONAL TIPSIn the following situations you or the other party may have difficulty
hearing each other:
1. Keep the Bluetooth volume to a low level. High level volume may result
in distortion and echo.
2. When driving on a rough road, high speeds and/or with the window open.
3. When the air conditioning vents are facing the microphone and/or when
the air conditioning fan is at the max speed.
VOLUME
Raises or lowers speaker volume.
MUTE

Mute the microphone during a call.
TALK
Activates voice recognition.
CALL
Answer, places, and transfers calls.
END
Ends calls or cancels functions.
Steering wheel Bluetooth controlPhone compatibility website: www.hyundaiusa.com/bluetooth


ANDROIDAUTO™
ANDROIDAUTO™

MULTIMEDIA
ELANTRA GT
23 22
HYUNDAI
1. Press the SETUP
button.
2. Select “Phone” by turning and pressing the TUNE
knob.
3. Select “Phone Pair” by turning and pressing the TUNE knob.
4. Enable Bluetooth on your phone.
5.
Select “Elantra GT” from the Bluetooth
® device list on your mobile phone.
Input passkey displayed on the screen when applicable.
6. After pairing is completed, transfer of the contact list to the audio system
will begin (if your phone is supported).
7. If your phone prompts a phonebook access request, it is advisable to
check the box "Always allow" or "Don't ask again". Standard AudioVehicle must be parked to complete pairing process.Please visit www.hyundaiusa.com/Bluetooth for a list of compatible phones tested to work with
Hyundai’s Bluetooth
® system.
BLUETOOTH PHONE PAIRING
Elanta GT
Elanta GT
Phone setup (pairing phone) with Navigation2. Press to search for
Bluetooth phones.3.
Pair your car after your mobile
phone detects the Bluetooth device.
4. Enter the passkey or accept
the authorization popup.
(The default passkey is 0000.)5. Connect Bluetooth. 1. Press the PHONE button in the head unit or
button in the
steering wheel remote control.
NOTE: Vehicle must be parked to
complete pairing process.


ANDROIDAUTO™
ANDROIDAUTO™

MULTIMEDIA
ELANTRA GT
25 24
HYUNDAI
BLUE LINK TELEMATICS SYSTEM
You can download the Blue Link mobile app to your
compatible smart phone from the following sites:

• iPhone
® — Apple
® App Store
• Android
™ — Google Play
™
Remote Start enables you to remotely start your vehicle from virtually
anywhere. For vehicles equipped with full-automatic temperature control,
you can also enable climate control remotely and turn on the front window
defroster, ensuring a warm or cool car is ready to go when you are.
•
To use this feature, you must have a Blue Link Personal
Identification Number (PIN). To create or change your PIN,
log on to www.MyHyundai.com.
Remote Start Blue Link Mobile App• Remote Start will automatically shut off after 10 minutes or after selected
engine timer runs out in navigation vehicles.
• While this feature is active, the parking lights will blink until vehicle is
turned off or when vehicle is in operation.
• To continue operation of the vehicle, the proximity key must be inside
the vehicle with the driver prior to pressing the brake and being able to
move the gearshift from the P (Park) position.Remember:
Scan to see list of
compatible devices and
to download the app.
Visit HyundaiBlueLink.com FAQs to
see a list of compatible devices.
NOTE:
Remote Start is not available on all models. Remote Start is only
available for Push Start equipped vehicle with an Automatic Transmission
or Dual Clutch Transmission (DCT). Remote Start with Climate Control
additionally requires Fully Automatic Temperature Control.
Blue Link subscription is required. To enroll, please visit your dealership
or MyHyundai.com.
Press the
button for access to the voice-response menu of services.
- You can say:
Service Link
Roadside Assistance
Blue Link Account Services
Help
Cancel
Press the button for Destination Search Powered by Google
TM.
- For vehicle equipped with factory-installed navigation systems.
- For non-navigation, this button functions with Android Auto or Apple
Carplay.
Press the
button for SOS Emergency Assistance.
Visit HyundaiBlueLink.com for more information or refer to your Blue Link
User’s Manuall for detailed information on system operation.
For immediate assistance with subscription services, please call
1-855-2BLUELINK (1-855-225-8354).Google
TM
is a registered trademark of Google, Inc.









MULTIMEDIA
ELANTRA GT
27 26
HYUNDAI
STANDARD AUDIO Press POWER button
to turn radio on.
• TUNING / LISTENING TO CHANNELS
1. Press the Radio
button.
2. Turn the TUNE/ENTER
knob to select the desired channel and press the knob.

NOTE
A clear view of the southern sky is recommended to ensure XM
® radio reception.
• SETTING PRESET MEMORY BUTTONS (FM/AM/XM
® )
Press and hold any preset button (1-6)
until audible beep is heard
to store current channel.
• ADJUSTING THE SOUND CONTROL
1. Press the SETUP/CLOCK
button.
2. Select “Sound Settings” by turning and pressing the TUNE/ENTER
knob.
3. Select “Bass”, “Middle”, “Treble”, “Fader”, or “Balance” by turning and
pressing the TUNE/ENTER
knob.
4. Adjust the sound by turning and pressing the TUNE/ENTER
knob.
Blue Link Telematics SystemYour audio display will change during Blue Link system use. Please refer
to the Blue Link User’s Manual for detailed information on system use.Please refer to your Owner’s Manual for more detailed information on how to use your audio
system.
Complimentary XM
® subscription ends three months following the vehicle date of sale.
Please contact XM® Radio at 1-800-XM-RADIO (1-800-967-2346) to renew your XM
®
subscription.
Audio mode
Preconditions:• Ignition is OFF
• Alarm is armed (i.e., vehicle locked by key fob Remote Door Lock)
• Gearshift level is in the P (Park) position
• Brake pedal is not depressed
• Engine hood is securely closed
• All the doors are closed and locked
• The tailgate or trunk lid is closed
• The security/panic system is not activated
• The proximity key is not inside the vehicle
• The battery power is not low
• Vehicle is located in an open area
• It has been less than 4 days since last vehicle ignition off
• Vehicle located in area with good cell receptionRemote Start will terminate:• After 10 minutes or after selected engine timer runs out in navigation
vehicles
• Brake is pressed without proximity key inside vehicle
• Alarm is triggered without proximity key inside vehicle
• Door/trunk is opened from inside the vehicleNotice: Laws in some communities may restrict the use of the
features that remotely start the engine. For example, some laws may
require a person using the remote start feature to have the vehicle in
view when doing so or limit the length of time a vehicle engine may
idle. Please check local and state regulations for any requirements
and restrictions on remote starting of vehicles and engine idling time.
WARNING!
Do not remote start vehicle in an enclosed environment (i.e., closed garage). Prolonged operation of a
motor vehicle in an enclosed environment can cause a harmful build-up of carbon monoxide. Carbon
monoxide is harmful to your health. Exposure to high levels of carbon monoxide can cause headaches,
dizziness or in extreme cases unconsciousness and/or death. Do not leave children or animals
unattended in a vehicle while using the remote start function.
CAUTION!
If the vehicle’s windshield wipers are left on when the vehicle was last driven, then the wipers will turn
on if the remote start function is activated. To avoid damage to the wiper blades (i.e., due to heavy ice
or snow accumulated on the windshield), please always turn the vehicle’s windshield wipers off when
parking the vehicle.


ANDROIDAUTO™
ANDROIDAUTO™

MULTIMEDIA
ELANTRA GT
29 28
HYUNDAI
NAVIGATION
Audio mode Press POWER button
to turn radio on.
• TUNING/LISTENING TO CHANNELS
1. Press RADIO button
.
2. Turn the TUNE/FILE

Knob to desired channel.
3. If the AM or FM has been selected, press the knob.
NOTE
A clear view of the southern sky is recommended to ensure XM
®
radio reception.
• SETTING PRESET MEMORY BUTTONS (FM/AM/XM
®
)
Press and hold any preset button (1-6)
On the screen until audible
beep is heard to store current channel.
•
ADJUSTING THE SOUND CONTROL
1. Press SETUP button
.
2. Touch Sound button on screen .
Blue Link Telematics SystemYour audio display will change during Blue Link system use. Please refer
to the Blue Link User’s Manual for detailed information on system use.
BLUE
LINK RADIO
NAVI
SETUP
INFO
Destination menuNOTE:Flick up / down to scroll through the Navigation Menu.Basic features on the Navi Menu screen1 Set the destination by address search2 Select from the previously input
addresses and POI’s3 Runs Google Local Search4 Select the desired item in the POI
sub-categories5 Search gas stations6 Search restaurants
7 Search emergency facilities8 Search the destination with the
address book9 Search the destination by phone number10 Type freeway name and exit /
entrance to search11 Type the 1st Street name,
the State, the 2nd Street name12 Type coordinates to search
2
3
4
15
6
7
8
9
10
11
12


ANDROIDAUTO™
ANDROIDAUTO™

MULTIMEDIA
ELANTRA GT
31 30
HYUNDAI
CAR SETUP1. Press the SETUP button.
2. Touch the “Connectivity” icon
on the screen.
3. Select “On” for Android Auto.
4. Connect your Android phone to the vehicle USB port. Agree to
the notification and disclaimers on your phone then the “Android
Auto” icon will appear confirming the setup.
For more detailed information on how to operate Android Auto,
please refer to your navigation manual.
For additional Android Auto support, please refer to the Android
Auto Support Website
https://support.google.com/androidauto/
Android Auto, Google Play, Android, and other marks are
trademarks of Google Inc.
REQUIREMENTS:
- Micro USB cable
- OS Android™ 5.0 or higher
- Compatible Android Phone
- Data and wireless plan for applicable features
BEFORE YOU BEGIN:
- Android Auto features may operate differently than on your phone.
- Message and data charges may apply when using Android Auto.
- Android Auto relies on the performance of your phone. If you
experience performance issues:
- Close all apps and then restart them or
- Disconnect and then reconnect your phone
- Using the micro USB cable that was provided with your phone is
recommended.
- When Android Auto is active, your in-vehicle voice recognition
system is disabled and you will be using talk to Google™ to make
your requests.
PHONE SETUP Turn on the Bluetooth
® on your phone and connect the micro USB
cable to your phone and the USB port on the vehicle.
Phone will prompt you to download the Android Auto app and update
other needed apps (i.e. Google Maps™, Google Play Music™, Google
Now™).
NOTE:
Vehicle must be parked.
- Location mode setting should be set to High accuracy.
- Vehicle and phone setup should be completed in one sitting. If phone
setup needs to be resumed, we recommend to Force Stop the
Android Auto app on the Phone then reopen the app and accept the
Disclaimer notifications.
ANDROID AUTO SUPPORThttps://support.google.com/androidauto/
ANDROID AUTO ™


ANDROID
AUTO™
ANDROID
AUTO™

MULTIMEDIA
ELANTRA GT
33 32
HYUNDAI
REQUIREMENTS
- Apple Lightning
® cable
- Latest iOS
- iPhone
® 5 or above
- Data and wireless plan for applicable features
BEFORE YOU BEGIN
- Apple® CarPlay features may operate differently than on our phone.
- Message and data charges may apply when using Apple CarPlay.
- Apple CarPlay relies on the performance of your phone. If you
experience performance issues:
- Close all apps and then restart them or
- Disconnect and then reconnect your phone
- Using the Apple Lightning cable that was provided with your phone
is recommended.
- When Apple CarPlay is active, your voice recognition system is
disabled and you will be using Siri
® to make your requests.
CAR SETUP1. Press the SETUP button.
2. Touch the “Connectivity” icon on the screen.
3. Touch “iOS” on the Connectivity Settings screen then touch “On”
to enable Apple CarPlay.
4. Connect your Apple iPhone to the vehicle USB port then touch
‘OK’ when the pop-up message appears. The Apple CarPlay icon
will now appear on the vehicle Home screen confirming the setup.
APPLE CARPLAY ™
Apple CarPlay, Apple, and other marks are trademarks of Apple Inc.
PHONE SETUP
On your phone, go to Settings >
General > Restrictions > CarPlay to
allow CarPlay access.
On your phone, go to Settings >
General > Siri and ensure Siri is
turned ON.









MULTIMEDIA
ELANTRA GT
35 34
HYUNDAI
Apple CarPlay uses Siri to perform many actions like sending
messages, placing calls, and looking up/setting POI/Destinations. A
Siri session can be initiated on any screen by:
1. Touch and holding the HOME icon
1 on the CarPlay screen or
2. Press the steering wheel VOICE RECOGNITION
13 button.
Note: Ensure Siri feature is set to ON in your phone (Go to Settings >
General > Siri).
3. Say any of the following commands;
!Ÿ“Text ‘Call you later’” to send a text message.
!Ÿ“Read text messages” to read available text message.
!Ÿ“Call ” to make a phone call.
!Ÿ“Find ” to locate a POI/Destination.PHONE
Touch the PHONE
5 icon to access the Phone screen. Siri will
automatically asks ‘Who you would like to call’ when the PHONE
5
icon is selected.
NOTE: Phone call sound quality is dependent on the wired
connection. Using the Lightning cable that came with the phone is
recommended.
APPLE MUSIC
Touch the APPLE MUSIC
6 icon to access the Apple Music screen.
APPLE MAPS
Touch the APPLE MAPS
7 icon to access the Apple Map screen.
MESSAGES
Touch the MESSAGES 8 icon to access the Message screen. Siri
will automatically asks ‘To hear unread messages or create a new
one’ when the MESSAGE icon is selected.
3rd PARTY APPS
Supported CarPlay apps that are downloaded on your phone will
appear on the CarPlay screen. Touch the apps icons to access those
supported apps.
NOTE:
A list of the supported CarPlay supported apps can be found
at http://www.apple.com/ios/carplay/
Ensure phone has latest version of the 3rd Party Apps.
CarPlay Home Screen
SIRI1 HOME ICON2 WIRELESS CONNECTIVTY3 CELLULAR SIGNAL4 PHONE TIME5 PHONE6 APPLE MUSIC™
7 APPLE MAPS8 MESSAGES9
3RD PARTY APPS
10 SCREEN PAGE INDICATOR11 EXIT TO HYUNDAI 12 CURRENT CARPLAY AUDIO PLAYING
2
3
41
5
6
7
89
10
11
12
13


ANDROIDAUTO™
ANDROIDAUTO™

MULTIMEDIA
ELANTRA GT
37 36
HYUNDAI
Use the jack to connect an external
audio device and listen to it through
the audio system speakers in your
vehicle.NOTE
To operate your iPod
® through the
vehicle’s audio system, connect your
Apple supplied USB cable to the USB port
iPod
® is a trademark of Apple Inc.
AUX, USB AND iPod
® PORT
CLOCK ADJUSTMENT
Hour
Pressing the H button will advance the
time displayed by one hour.Minute
Pressing the M button will advance the
time displayed by one minute.
Press the H and M buttons at the same
time for more than 5 seconds to toggle
between 12- and 24-hour formats.
With Navigation SystemThe clock automatically sets itself to
the correct time.
SEAT WARMER AND VENTILATION SEATS
Each time you press the button,
the setting is charged as follows:
OFF
HIGH
MEDIUM
LOW
CHILD-PROTECTOR REAR DOOR LOCK
Lock( )Insert a key into the hole and
turn it to the lock( )position.Unlock( )Allows opening the rear door handle
from inside and outside the vehicle.
FEATURES AND CONTROLS
For effective ventilation, use with A/C
on and Bi-Level mode.


ANDROIDAUTO™
ANDROIDAUTO™
