HYUNDAI GX350 L 2005 User Guide

A100A03A-AATGuide to Hyundai Genuine Parts1. What are Hyundai Genuine Parts?
Hyundai Genuine Parts are the same parts
used by Hyundai Motor Company to manu-
facture vehicles. They are designed and
tested for the optimum safety, performance,
and reliability to our customers.
2. Why should you use genuine parts?
Hyundai Genuine Parts are engineered and
built to meet rigid manufacturing require-
ments. Using imitation, counterfeit or used
salvage parts is not covered under the
Hyundai New Vehicle Limited Warranty or
any other Hyundai warranty. In addition, any
damage to or failure of Genuine Hyundai
Parts caused by the installation or failure ofan imitation, counterfeit or used salvage part
is not covered by any Hyundai Warranty.
3. How can you tell if you are purchasing
Hyundai Genuine Parts?
Look for the Hyundai Genuine Parts Logo on
the package (see below).
Hyundai Genuine Parts exported to the United
States are packaged with labels written only
in English.
Hyundai Genuine Parts are only sold through
authorized Hyundai Dealerships.
To find the closest authorized dealer call
1-800-826-CARS
A100A01L
A100A02L A100A04LA100A03L
xgflhma-0.p656/16/04, 3:05 PM 11
ProCarManuals.com

A000A01A-AATThis Owner's Manual should be considered a part of the car and remain with it when it is sold for the use of the next owner.
OWNER'S I.D.
ORIGINAL OWNER
ADDRESS
CITY STATEZIP CODE
DELIVERY DATE
(Date Sold to Original Retail purchaser)
DEALER NAME DEALER NO.
ADDRESS
CITY STATEZIP CODE
xgflhma-0.p656/16/04, 3:05 PM 12
ProCarManuals.com

FEATURES OF YOUR HYUNDAI
1
Fuel Recommendations ................................................ 1-2
Breaking In Your New Hyundai ..................................... 1-3
Keys.............................................................................. 1-3
Door Locks (Theft-Alarm System) ......................... 1-4, 1-7
Power Windows ............................................................ 1-9
Seat (Power Seat) ............................................. 1-10, 1-13
I.M.S (Integrated Memory System) .............................1-14
Seat Belt.....................................................................1-17
Child Restraint System ...............................................1-24
Supplemental Restraint (Airbag) System ....................1-31
Instrument Cluster and Indicator Lights...................... 1-38
Warning and Indicator Light ........................................1-40
Multi-function Light Switch..........................................1-46
Windshield Wiper/Washer Switch...............................1-48
Trip Computer.............................................................1-51
Sunroof.......................................................................1-55
Mirror...........................................................................1-60
Homelink Mirror...........................................................1-62
Hood Release .............................................................1-72
Cruise Control.............................................................1-75
Heating and Cooling Control .......................................1-78
Stereo Sound System.................................................1-93
Antenna.....................................................................1-118
1
xgflhma-1.p656/16/04, 3:02 PM 1
ProCarManuals.com

1FEATURES OF YOUR HYUNDAI2
FUEL RECOMMENDATIONS
B010A02L
CAUTION:
Your Hyundai's New Vehicle Limited War-
ranty may not cover damage to the fuel
system and any performance problems that
are caused by the use of fuels containing
methanol or fuels containing MTBE (Methyl
Tertiary Butyl Ether) over 15.0% vol. (Oxy-
gen Content 2.7% weight.)
B010B01A-AATWhat About Gasohol?Gasohol (a mixture of 90% unleaded gasoline
and 10% ethanol or grain alcohol) may be used
in your Hyundai. However, if your engine devel-
ops driveability problems, the use of 100%
unleaded gasoline is recommended. Fuels with
unspecified quantities of alcohol, or alcohols
other than ethanol, should not be used.
B010A03A-AATUse Unleaded GasolineUnleaded gasoline with a Pump Octane
Rating of 87 (Research Octane Number 91)
or higher must be used in your Hyundai.
If leaded gasoline is used, it will cause the
catalytic converter to become ineffective and
the emission control system to malfunction.
This can also result in increased maintenance
expense.
To avoid accidental use of leaded fuel, the larger
nozzle used with leaded gasoline at service
stations cannot be inserted into the fuel tank
opening of your Hyundai.
B010C01A-AATUse of MTBEHyundai recommends that fuels containing
MTBE (Methyl Tertiary Butyl Ether) over 15.0%
vol. (Oxygen Content 2.7% weight) should not
be used in your Hyundai.
Fuel containing MTBE over 15.0% vol. (Oxygen
Content 2.7% weight) may reduce vehicle per-
formance and produce vapor lock or hard
starting.B010D01A-AATDo Not Use MethanolFuels containing methanol (wood alcohol) should
not be used in your Hyundai. This type of fuel
can reduce vehicle performance and damage
components of the fuel system.
!
CAUTION:
o Do not "TOP-OFF" after the first nozzle
shut off when refueling.
o The fuel cap must be tightened at least
3 clicks, otherwise " " light may illu-
minate.
UNLEADED
FUEL ONLY
!
xgflhma-1.p656/16/04, 3:02 PM 2
ProCarManuals.com

1
FEATURES OF YOUR HYUNDAI
3
KEY
BREAKING IN YOUR NEW HYUNDAI
B010E01A-AATGasolines for Cleaner AirTo help contribute to cleaner air, Hyundai rec-
ommends that you use gasolines treated with
detergent additives, which help prevent deposit
formation in the engine. These gasolines will
help the engine run cleaner and enhance per-
formance of the Emission Control System.B010F01A-AATOperation in Foreign CountriesIf you are going to drive your Hyundai in another
country, be sure to:
o Observe all regulations regarding registra-
tion and insurance.
o Determine that acceptable fuel is available.
B020A01S-AATDuring the First 1,200 Miles (2,000 Km)No formal "break-in" procedure is required with
your new Hyundai. However, you can contrib-
ute to the economical operation and durability of
your Hyundai by observing the following recom-
mendations during the first 1,200 miles (2,000
km).
o Don't drive faster than 55 MPH (88 km/h).
o While driving, keep your engine speed (rpm,
or revolutions per minute) between 2,000
rpm and 4,000 rpm.
o Use moderate acceleration. Don't start
quickly or depress the accelerator pedal
fully.
o For the first 200 miles (300 km), try to avoid
hard stops.
o Don't lug the engine (in other words, don't
drive so slowly in too high a gear that the
engine "bucks"-shift to a lower gear).
o Whether going fast or slow, vary your speed
from time to time.
o Don't let the engine idle longer than 3 minutes
at one time.
o Don't tow a trailer during the first 1,200 miles
(2,000 km) of operation.
B030A01Y-AATKEYSFor greater convenience, your Hyundai has
two master keys and a sub key. The master
keys will open all locks on your vehicle. The sub
key will only function in the ignition and the door
locks.
Leaving your sub key with a parking attendant
will ensure that your vehicle's trunk, trunk lid
release, glovebox compartment and rear trunk
access may not be unlocked in your absence.NOTE:Before leaving your sub key with a parking
attendant, make sure that the lock levers of
the rear seat back lock and the trunk lid lock
are switched to the "LOCK" position.
HXG116
Master key
Sub key
xgflhma-1.p656/16/04, 3:02 PM 3
ProCarManuals.com

1FEATURES OF YOUR HYUNDAI4
DOOR
ILLUMINATED IGNITION SWITCH
!
B030C01Y-AATB040A01Y-AAT
DOOR LOCKS
Whenever a door is opened, the ignition switch
will be illuminated for your convenience, pro-
vided the ignition switch is not in the "ON"
position.
The light will go off approximately 10 seconds
after closing the door or when the ignition switch
is turned on.
B030C01L
WARNING:
o Unlocked doors can be dangerous. Be-
fore you drive away (especially if there
are children in the car), be sure that all the
doors are securely closed and locked so
that the doors cannot be opened from
the inside. This helps ensure that the
doors will not be opened accidentally.
Also, when combined with the proper
use of seat belts, locking the doors helps
keep occupants from being ejected from
the car in case of an accident.
o Before opening the door, always look for
and avoid oncoming traffic.
o In case of accident, the door is unlocked
automatically.
B030B01A-AATRecord Your Key NumberA code number is stamped on the number plate
that came with the keys to your Hyundai. This
key number plate should not be left with the keys
but kept in a safe place, not in the vehicle. The
key number should also be recorded in a place
where it can be found in an emergency.
If you need additional keys, or if you should lose
your keys, your authorized Hyundai dealer can
make new keys if you can supply the key
number.
B030B01L
xgflhma-1.p656/16/04, 3:02 PM 4
ProCarManuals.com

1
FEATURES OF YOUR HYUNDAI
5
B040C03L
UNLOCK
LOCK
HXG018 B040B01A-AAT
Locking and unlocking front doors with a
key
B040C02Y-AATLocking From the OutsideThe doors can be locked without a key. To lock
the doors, first push the inside lock switch to the
"LOCK" position so that the red mark on the
switch is not visible, then close the door.
The door will not lock if the key is left in the ignition
switch when the front doors close. This is
normal.NOTE:o When locking the door this way, be care-
ful not to lock the door with the ignition
key left in the vehicle.
o To prevent against theft, always remove
the ignition key, close all windows, and
lock all doors and the trunk lid when
leaving your vehicle unattended.
B040D02S-AATLocking From the Insideo To lock the doors from the inside, simply
close the door and push the lock switch to the
"LOCK" position. When this is done, neither
the outside nor the passenger's inside door
handle can be used.
o The driver's door can be opened by pulling
the inside door handle even if the lock switch
is depressed.NOTE:When the door is locked, the red mark on the
switch is not visible. o The door can be locked or unlocked with a
key.
o Lock the door by turning the key toward the
front of the vehicle and unlock it by turning the
key toward the rear.
HXGS226LOCK UNLOCK
xgflhma-1.p656/16/04, 3:02 PM 5
ProCarManuals.com

1FEATURES OF YOUR HYUNDAI6
KEYLESS ENTRY SYSTEM
CENTRAL DOOR LOCKSB040G02L-AATThe central door locking switch is located on the
driver's arm rest. It is operated by depressing
either the front or rear of the door lock switch.NOTE:o When pushing the front portion of the
driver's door lock switch, all vehicle doors
will lock.
If any door is open when the switch is
depressed, the door will remain locked
when closed.
o When pushing the rear portion of the
switch, all vehicle doors will unlock.
B040G02L-1
LOCK
UNLOCK
B070F01L-AATLocking doors1. Close all doors.
2. Push the " " button on the transmitter.
3. All doors will lock and the turn signal lights will
blink once to indicate that the system is
armed.Unlocking doors1. Push the " " button on the transmitter.
2. All doors will unlock and the turn signal lights
will blink twice to indicate that the system is
disarmed.Releasing the trunk lidPush the " " button on the transmitter for
longer than 1 second.
B040E04A-AATCHILD-PROTECTOR REAR DOOR LOCKYour Hyundai is equipped with a "child-protec-
tor" rear door lock assembly. When the lock
mechanism is engaged, the rear door cannot be
opened from the inside. Its use is recommended
whenever there are small children in the rear
seat.
To engage the child-protector feature so the
door cannot be opened from the inside, move
the child-protector lever to the " " position and
close the door. Move the lever to the " "
position when normal door operation is desired.
If you wish to be able to open the door from the
outside, the outside door handle will function
normally.
B040E03L
xgflhma-1.p656/16/04, 3:02 PM 6
ProCarManuals.com

1
FEATURES OF YOUR HYUNDAI
7
THEFT-ALARM SYSTEMB070A01S-AAT(If Installed)This system is designed to provide protection
from unauthorized entry into the car. This sys-
tem is operated in three stages : the first is the
"Armed" stage, the second is the "Alarm" stage,
and the third is the "Disarmed" stage. If trig-
gered, the system provides an audible alarm.B070B03Y-AATArmed StagePark the car and stop the engine. Arm the
system as described below.
1) Remove the ignition key from the ignition
switch.
2) Make sure that the engine hood and trunk lid
are locked.
3) Lock the doors using the transmitter of the
keyless entry system.
After completion of the steps above, the turn
signal light will blink once to indicate that the
system is armed.NOTE:1) If any door, trunk lid or engine hood
remains open, the system will not be
armed.
2) If this happens, rearm the system as
described above.
CAUTION:
Do not arm the system until all passengers
have left the car. If the system is armed while
a passenger(s) remains in the car, the alarm
may be activated when the remaining
passenger(s) leaves the car.B070C03L-GATAlarm StageThe alarm will be activated if any of the following
occurs while the car is parked and the system
is armed.
HXGS123
!
CAUTION:
Avoid trying to start the engine while the
system is armed.
!
1) A front or rear door is opened without using
the transmitter.
2) The trunk lid is opened without using the
transmitter.
3) The engine hood is opened.
The turn signal lights will blink continuously and
the siren will sound for 27 seconds. (EC only/
Except E.C: This happens 3 times). To turn off
the system, unlock the door or trunk lid with the
transmitter.
xgflhma-1.p656/16/04, 3:02 PM 7
ProCarManuals.com

1FEATURES OF YOUR HYUNDAI8
B070E02HP-GATReplacing the batteryWhen the transmitter's battery begins to get
weak, it may take several pushes on the button
to lock or unlock the doors, and the LED will not
light. Replace the battery as soon as possible.
Battery type : CR2032
Replacement instructions:
1. Carefully separate the case with a blade
screwdriver as shown in the illustration.
HEF-192A
Screwdriver
CAUTION:
Only the transmitter can disarm the armed
stage. If the transmitter does not disarm the
system, it is necessary to take the following
steps;
1. Unlock the door with the key, which will
cause the alarm to be activated.
2. Insert the key in the ignition key cylinder
and turn the ignition key to "ON" posi-
tion.
3. Wait for 30 seconds.
After completing the steps above, the sys-
tem will be disarmed.
!
HXG117
UNLOCK
LOCK
TRUNK
B070D04L-AATDisarmed StageThe system will be disarmed when the following
step is taken:
The driver's or passenger's door is unlocked by
depressing the " " button on the transmitter.
After completion of the steps above, the turn
signal lights will blink twice to indicate that the
system is disarmed.
xgflhma-1.p656/16/04, 3:02 PM 8
ProCarManuals.com
