Introduction
FOREWORD
Thank you for choosing HYUNDAI Vehicle. We are pleased to welcome you to the
growing number of discriminating people who drive HYUNDAI Vehicle. The advanced
engineering and high-quality construction of each HYUNDAI vehcile we build is
something of which we’re very proud.
Your Owner’s Manual will introduce you to the features and operation of your new
HYUNDAI vehicle. It is suggested that you read it carefully because the information it
contains can contribute greatly to the satisfaction you receive from your new car.
HYUNDAI Motor India Limited. also recommends that service and maintenance on
your vehicle be performed by an authorized HYUNDAI dealer.
HYUNDAI MOTOR INDIA LIMITED
Note : Because future owners will also need the information included in this manual,
if you sell this HYUNDAI, please leave the manual in the vehicle for their use.
Thank you.
CAUTION
Severe engine and transmission damage may result from the use of poor quality
fuels and lubricants that do not meet HYUNDAI specifications. You must always use
high quality fuels and lubricants that meet the specifications listed on Page 3-11 in
the Vehicle Specifications section of the Owner’s Manual.
Copyright 2020 HYUNDAI Motor India Limited. All rights reserved. No part of this
publication may be reproduced, stored in any retrieval system or transmitted in any
form or by any means without the prior written permission of HYUNDAI Motor India
Limited.

1-4
Introduction
DANGER
DANGER indicates a hazardous
situation which, if not avoided, will
result in death or serious injury.
WARNING
WARNING indicates a hazardous
situation which, if not avoided, could
result in death or serious injury.
CAUTION
CAUTION indicates a hazardous
situation which, if not avoided, could
result in minor or moderate injury.
NOTICE
NOTICE indicates a situation which,
if not avoided, could result in vehicle
damage.
FUEL REQUIREMENTS
Petrol engine
Unleaded
Your new vehicle is designed to use only
unleaded fuel having an Octane Rating
of RON (Research Octane Number) 91 /
AKI (Anti-Knock Index) 87 or higher. (Do
not use methanol blended fuels)
Your new vehicle is designed to obtain
maximum performance with UNLEADED
FUEL, as well as minimize exhaust
emissions and spark plug fouling.
CAUTION
NEVER USE LEADED FUEL. The use
of leaded fuel is detrimental to the
catalytic converter and will damage the
engine control system’s oxygen sensor
and affect emission control.
Never add any fuel system cleaning
agents to the fuel tank other than what
has been specified (We recommend
that you consult an authorized
HYUNDAI dealer for details.)
WARNING
• Do not “top off” after the nozzle
automatically shuts off when
refueling.
• Always check that the fuel cap is
installed securely to prevent fuel
spillage in the event of an accident.

1-5
01
Petrol containing alcohol and
methanol
Gasohol, a mixture of petrol and ethanol
(also known as grain alcohol), and
petrol or gasohol containing methanol
(also known as wood alcohol) are being
marketed along with or instead of leaded
or unleaded petrol.
Do not use gasohol containing more
than 10% ethanol, and do not use petrol
or gasohol containing any methanol.
Either of these fuels may cause
drivability problems and damage to the
fuel system, engine control system and
emission control system.
Discontinue using gasohol of any kind if
drivability problems occur.
Vehicle damage or driveability
problems may not be covered by the
manufacturer’s warranty if they result
from the use of:
1. Gasohol containing more than 10%
ethanol.
2. Petrol or gasohol containing methanol.
3. Leaded fuel or leaded gasohol.
CAUTION
Never use gasohol which contains
methanol. Discontinue use of any
gasohol product which impairs
drivability.
Other fuels
Using fuels such as;
- Silicone (Si) contained fuel,
- MMT (Manganese, Mn) contained fuel,
- Ferrocene (Fe) contained fuel, and
- Other metallic additives contained
fuels,
may cause vehicle and engine damage
or cause plugging, misfiring, poor
acceleration, engine stalling, catalyst
melting, abnormal corrosion, life cycle
reduction, etc.
Also, the Malfunction Indicator Lamp
(MIL) may illuminate.
NOTICE
Damage to the fuel system or
performance problem caused by the
use of these fuels may not be covered
by your New Vehicle Limited Warranty.

1-6
Introduction
Use of MTBE
HYUNDAI recommends avoiding fuels
containing MTBE (Methyl Tertiary Butyl
Ether) over 15.0% vol. (Oxygen Content
2.7% weight) in your vehicle.
Fuel containing MTBE over 15.0%
vol. (Oxygen Content 2.7% weight)
may reduce vehicle performance and
produce vapor lock or hard starting.
CAUTION
Your New Vehicle Limited Warranty
may not cover damage to the
fuel system and any performance
problems that are caused by the use
of fuels containing methanol or fuels
containing MTBE (Methyl Tertiary Butyl
Ether) over 15.0% vol. (Oxygen Content
2.7% weight.)
Do not use methanol
Fuels containing methanol (wood
alcohol) should not be used in your
vehicle. This type of fuel can reduce
vehicle performance and damage
components of the fuel system, engine
control system and emission control
system.
Fuel Additives
HYUNDAI recommends that you use
unleaded petrol which has an Octane
Rating of RON (Research Octane
Number) 91 / AKI (Anti-Knock Index) 87
or higher.
For customers who do not use good
quality petrols including fuel additives
regularly, and have problems starting or
the engine does not run smoothly, one
bottle of additives added to the fuel tank
at every 10,000 km.
Additives are available from your
authorized HYUNDAI dealer along with
information on how to use them. Do not
mix other additives.
Operation in foreign countries
If you are going to drive your vehicle in
another country, be sure to:
• Observe all regulations regarding
registration and insurance.
• Determine that acceptable fuel is
available.

1-7
01
Diesel engine
Diesel fuel
Diesel engine must be operated only on
commercially available diesel fuel that
complies with EN 590 or comparable
standard. (EN stands for “European
Norm”). Do not use marine diesel fuel,
heating oils, or non-approved fuel
additives, as this will increase wear and
cause damage to the engine and fuel
system. The use of non-approved fuels
and / or fuel additives will result in a
limitation of your warranty rights.
Diesel fuel of above cetane 51 is used
in your vehicle. If two types of diesel
fuel are available, use summer or winter
fuel properly according to the following
temperature conditions.
• Above -5°C (23°F) ... Summer type
diesel fuel.
• Below -5°C (23°F) ... Winter type diesel
fuel.
Watch the fuel level in the tank very
carefully : If the engine stop s through
fuel failure, the circuits must be
completely purged to permit restarting.
CAUTION
Do not let any petrol or water enter the
tank. This would make it necessary to
drain it out and to bleed the lines to
avoid jamming the injection pump and
damaging the engine.
CAUTION
Diesel Fuel (if equipped with DPF)
It is recommended to use the regulated
automotive diesel fuel for diesel vehicle
equipped with the DPF system.
If you use diesel fuel including high
sulfur (more than 50 ppm sulfur) and
unspecified additives, it can cause the
DPF system to be damaged and white
smoke can be emitted.
Biodiesel
Commercially supplied Diesel blends of
no more than 7% biodiesel, commonly
known as “B7 Diesel” may be used
in your vehicle if Biodiesel meets EN
14214 or equivalent specifications. (EN
stands for “European Norm”). The use
of biofuels exceeding 7% made from
rapeseed methyl ester (RME), fatty
acid methyl ester (FAME), vegetable oil
methyl ester (VME) etc. or mixing diesel
exceeding 7% with biodiesel will cause
increased wear or damage to the engine
and fuel system. Repair or replacement
of worn or damaged components due to
the use of non approved fuels will not be
covered by the manufactures warranty.
CAUTION
• Never use any fuel, whether diesel,
B7 biodiesel or otherwise, that fails
to meet the latest petroleum industry
specification.
• Never use any fuel additives
or treatments that are not
recommended or approved by the
vehicle manufacturer.

2-2
Hyundai Warranty Policy
HYUNDAI NEW VEHICLE WARRANTY
Hyundai Motor India Limited herein-
after called “HMIL”, warrants that
each new Hyundai vehicle sold shall
be free from any defects in material
and workmanship, under normal use
and maintenance, subject to the fol-
lowing terms and conditions.
1. Warranty Period
This warranty for hyundai vehicle
shall exist for a period as per option
selected on page F1 by the first pur-
chaser from the date of delivery
whichsoever is earlier. However the
warranty for CRETA being used for
commercial purpose such as Taxi/
Tourist operation is 36
months/100,000 kilometers from the
date of delivery to the first purchaser
which soever is earlier. This warranty
is transferable to subsequent owner
for the remaining warranty period.
This warranty is applicable only in In-
dia and not transferable to any other
country.
2. What is covered
Except as provided in paragraph 3
hereof, our Authorized Dealers shall
either repair or replace, any Hyundai
genuine part that is acknowledged by
HMIL to be defective in material or
workmanship within the warranty pe-
riod stipulated above, at no cost to
the owner of the Hyundai vehicle for
parts or labour. Such defective parts
which have been replaced will be-
come the property of HMIL
3. What is not covered
This warranty shall not apply to:
▶Normal maintenance services
other than the three free ser-
vices, including without limita-
tion, cleaning and polishing, mi-
nor adjustments, engine tuning,
oil/fluid changes, filters replen-
ishment, fastener retightening,
wheel balancing, wheel align-
ment and tyre rotation etc.
▶Replacement of parts as a result
of normal wear and tear such as
spark plugs, belts, brake pads
and linings, clutch disc/facing,
filters, wiper blades, bulbs, fuses,
etc.
Damage or failure resulting from :
▶Negligence of proper mainte-
nance as required in this Owner’s
Manual and Service Booklet.
▶Misuse, abuse, accident, theft,-
flooding or fire.
▶Use of improper or insufficientfu-
el, fluids or lubricants.
▶Use of parts other than Hyundai
Genuine Parts.
▶Any device and/or accessories-
not supplied by HMIL.
▶Modifications, alterations, tam-
pering or improper repair.
▶Parts used in applications of-
which they were not designed or
not approved by HMIL.
▶Slight irregularities not rec-
ognised as affecting quality or-
function of the vehicle or parts,-
such as slight noise or
vibrations,or items considered-
characteristic of the vehicle.
▶Airborne “fallout”, Industrialfall
out, acid rain, hail and wind-
storms, or other Acts of God.

Exterior overview (I) ........................................................................................ 3-2
Exterior overview (II)
....................................................................................... 3-3
Interior overview
............................................................................................. 3-4
Instrument panel overview
............................................................................ 3-5
Engine compartment
...................................................................................... 3-6
Dimensions
...................................................................................................... 3-8
Engine specification
....................................................................................... 3-8
Bulb wattage
................................................................................................... 3-9
Tires and wheels
............................................................................................3-10
Recommended lubricants and capacities
....................................................3-11
Recommended SAE viscosity number ................................................................... 3-12
Vehicle identification number (VIN) .............................................................3-14
Vehicle certification label
..............................................................................3-14
Tire specification and pressure label
............................................................ 3-15
Engine number
............................................................................................... 3-15
Air conditioner compressor label
.................................................................3-16
3. Vehicle information
3

3-5
03
The actual shape may differ from the illustration.
OBI3010004OBI3010004
INSTRUMENT PANEL OVERVIEW
1. Lighting control/Turn signals switch ...........................................................................................6-42
2. Driver Assist button
....................................................................................................................... 8-2
3. Instrument cluster
......................................................................................................................... 5-2
4. Horn
.............................................................................................................................................. 6-22
5. Driver’s air bag
.............................................................................................................................4-42
6. Wipers and Washers switch
....................................................................................................... 6-50
7. Steering wheel audio controls*
.................................................................................................. 6-88
8. Engine Start/Stop button*
............................................................................................................ 7-9
9. Shift lever
...................................................................................................................................... 7-15
10. USB port
......................................................................................................................................6-87
11. Power outlet
............................................................................................................................... 6-80
12. Climate control system*
............................................................................................................6-53
13. Infotainment system
..................................................................................................................6-87
14. Hazard warning light button
....................................................................................................... 9-2
15. Passenger’s front air bag
...........................................................................................................4-43
16. Glove box
.................................................................................................................................... 6-78
* : if equipped

3-6
Vehicle information
1. Engine coolant reservoir ............................................................................................................ 10-30
2. Engine oil filler cap
................................................................................................................... 10-26
3. Brake/clutch* fluid reservoir
.................................................................................................... 10-33
4. Air cleaner
................................................................................................................................. 10-39
5. Fuse box
.....................................................................................................................................10-61
6. Battery
....................................................................................................................................... 10-46
7. Windshield washer fluid reservoir ............................................................................................ 10-36
8. Radiator cap
................................................................................................................................ 10-31
9. Engine oil dipstick
..................................................................................................................... 10-26
ENGINE COMPARTMENT
The actual engine room in the vehicle may differ from the illustration.
OBI3090001/OBC3090003ROBI3090001/OBC3090003R
„„Petrol Engine (1.0 T-GDi)Petrol Engine (1.0 T-GDi)
„„Petrol Engine (Smartstream G1.2)Petrol Engine (Smartstream G1.2)

3-7
03
1. Engine coolant reservoir ............................................................................................................ 10-30
2. Engine oil filler cap
................................................................................................................... 10-26
3. Brake/clutch* fluid reservoir
.................................................................................................... 10-33
4. Air cleaner
................................................................................................................................. 10-39
5. Fuse box
.....................................................................................................................................10-61
6. Battery
....................................................................................................................................... 10-46
7. Windshield washer fluid reservoir ............................................................................................ 10-36
8. Radiator cap
................................................................................................................................ 10-31
9. Engine oil dipstick
..................................................................................................................... 10-26
The actual engine room in the vehicle may differ from the illustration.
OBI3090002OBI3090002
„„Diesel Engine (1.5 WGT)Diesel Engine (1.5 WGT)
