climate settings Hyundai Nexo 2019 Owner's Manual

3-62
Convenient features of your vehicle
Outside temperature gauge
This gauge indicates the current out-
side air temperature by 1 degrees F
(1 degrees C).
- Temperature range :-40°F ~ 140°F
(-40°C ~ 60°C)
Note that the temperature indicated
on the LCD display may not change
as quickly as the outside tempera-
ture (there may be a slight delay
before the temperature changes.) The temperature unit (from °C to °F
or from °F to °C) can be changed by:
- Press the AUTO button while
pressing the OFF button on the cli-
mate control unit for 3 seconds
- Go to General settings mode →
Unit → Temperature in the AVN dis-
play.
Both the temperature unit on the
cluster LCD display and climate con-
trol screen will change.
Odometer
The odometer indicates the total dis-
tance that the vehicle has been driv-
en and should be used to determine
when periodic maintenance should
be performed.
OFE048106NOFE048104N

3-151
Convenient features of your vehicle
3
Adjusting the driver and passenger
side temperature equally
Press the "SYNC" button to oper-ate the driver and passenger side
temperature equally.
The passenger side temperature
will be set to the same temperature
as the driver side temperature.
Push the driver side temperature control switch. The driver and pas-
senger side temperature will be
adjusted equally.
Adjusting the driver and passenger
side temperature individually
Press the "SYNC" button again to
operate the driver and passenger
side temperature individually. The
button indicator will turn off.
Temperature conversion
If the battery has been discharged or
disconnected, the temperature mode
display will reset to Fahrenheit.
To change the temperature unit from
°F to °C or °C to °F:
- Press the AUTO button while press-ing the OFF button on the climate
control unit for 3 seconds.
- Go to General settings mode → Unit
→ Temperature in the AVN display.
The temperature unit on both the
cluster LCD display and climate con-
trol screen will change.
Air intake control (8)
The air intake control button is used
to select either Fresh mode (outside
air) or Recirculation mode (cabin air).
Recirculation mode
When Recirculation mode is selected, air
from the passenger
compartment will be
recirculated through the
system and heated or
cooled according to the
function selected.
Fresh mode
When Fresh mode is selected, air enters the
vehicle from outside and
is heated or cooled
according to the function
selected.
OFE048310N

5-38
Driving your vehicle
ECO+ mode
ECO+ mode improves
fuel efficiency with ultra
power saving driving
mode.
When ECO+ mode is selected by pressing and holding the DRIVE
MODE button, the ECO+ indicator
will illuminate.
Distance to empty may not change when the air conditioner/heater
system is off. However, actual dis-
tance may be extended.
Air conditioner/heater system turns off (except the defroster) but you
may turn it on if necessary.
When the drive mode is switched from the ECO+ mode to a different
mode, it is changed to air condi-
tioner/heater operation status of
the ECO mode.
Whenever the vehicle is restarted, the Drive Mode will reverse back to
NORMAL mode.
If ECO + mode is activated, the maximum vehicle speed is limited
below 60 mph (100 km/h).
Drive mode change alert
The driver can select the Drive mode
change alert on the AVN screen.
Go to "Vehicle settings → Drive
mode →Drive mode change alert".
The information, which will be shown
whenever the drive mode is
changed.
[Detailed alert] : A change of the
drive mode is
shown by an image
of the vehicle.
[Simple alert] : A change of the drive mode is indicated by
a short message on
top of the screen.
[No alert] : A change of the drive mode is not indicated.
ECO mode climate control
ECO Mode Climate Control helps
extend driving range by reducing the
heating and cooling power of the cli-
mate control.
The driver can activate/deactivate
the system on the AVN screen.
Go to "Vehicle settings → Drive
mode →Eco mode climate control".
