: Direction of the vehicle always
pointing up.
“Setting map orientation”
(page 3-14)
*6Scale indicator:
Indicates the scale of the map. Touch
the icon to display the scale bar.
The map scale can be adjusted using
the scale bar.
“Operating with touch panel op-
eration” (page 3-10)
*7Arrow:
Indicates the distance to the next
guide point and the turning direction
at that guide point.
*8Stored location (orange):
Displays the locations that are stored
in the Address Book. Icons can be
changed according to personal prefer-
ences.
“Storing location” (page 6-2)
*9Avoid Area (green or blue):
Displays the areas to avoid that are
stored in the Address Book with green
or blue icons. During the route search,
the route guidance is performed by
searching for a route that avoids those areas.
“Storing avoid area”
(page 6-7)
*10Street name:
Displays the name of the street the
vehicle is currently driving on.
*11Traffic indicator:
Displays the reception condition of the
traffic information transmitted from
the provider.
Green: Reception condition is good.
Gray: Reception condition is not good.
No mark: Subscription to NavTraffic
service is not detected.
BirdviewTM(3D) MAP
BirdviewTMdisplays the map from an
elevated perspective. In BirdviewTM, it is
easy to recognize an image of the route
because it provides a panoramic view over
a long distance.
IMA0073
INFO:
Note the following items about the BirdviewTM
display.
.“BirdviewTM” is a registered trademark of
Clarion Co., Ltd.
.The map in BirdviewTMalways appears with
the current forward direction facing up.
BUILDING GRAPHICS
In an area where the building graphics are
stored in the map data, the building
graphics are displayed when the map is
zoomed in. On the 2D map display, these
are called “Building footprint graphics”,
and on the Birdview
TMdisplay, these are
called “3D building graphics”.
The method to look at the map is the same
for the 2D and Birdview
TMmaps.
3. Map settings
3-3
Condition: Language=NAM_English/

Black plate (96,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
5. Route guidance
5-6
2. The location is stored in the AddressBook. The corresponding icon is dis-
played at the set location on the map.
VIEWING INFORMATION ABOUT
SEARCHED LOCATION
Information (street address and phone
number) about places stored in the map
data can be displayed.
IRG00981. Select [Place Info] and push .
JNE0144M
2. Information about the location is dis-
played.
3. Push to return to the previous
screen.
INFO:
.
If [Call] is displayed on the right side of the
screen, it is possible to call the location
indicated.
.The Bluetooth®Hands-Free Phone system is
required to be active and the cellular phone
connected to call the location indicated.
.Information about locations is not displayed
while driving.
Condition: Language=NAM_English/

Black plate (140,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
6. Storing location/route
6-18
1.Highlight [Resize Area] and push
.
2. Highlight the range from 5 available levels.
3. After highlighting the range, push
.
INFO:
Turning the center dial to change the scale of
the map.
Push / (if so equipped)
to change the scale of the map.
FWY
Sets the route to avoid freeways.
IST01431. Highlight [FWY].
To include freeways in the Avoid Area,
push to illuminate this indica-
tor.
IST01442. The Avoid Area is displayed in green if it includes a freeway or in blue if it does
not include a freeway.
INFO:
If the current vehicle location is set to an Avoid
Area, the system will not provide route gui-
dance.
Delete
Deletes the Avoid Area.
IST0145
1. Highlight [Delete] and push .
IST01462. A confirmation message is displayed.
Confirm the contents of the message,
highlight [Yes] and push . The
stored item is deleted from the Address
Book.
Condition: Language=NAM_English/

Black plate (152,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
7. Viewing technical information
7-6
.Connected Search:
Connected Search gives you the ability
to conduct a point of interest search
around the vehicle location via the
Destination menu of the navigation
system. This search links to the Infiniti
Connection database which may have
destination information more up-to-
date than your Infiniti hard-drive navi-
gation system.
“Setting by Infiniti ConnectionTM”
(page 4-14)
. Drive Zone:
Drive Zone feature allows you to
monitor the movement of your vehicle
in and out of specified regions. Using
the Infiniti Connection website or the
Interactive Voice Response (IVR), you
can define a series of allowed or
restricted regions, and are then alerted
via your chosen notification method
when the vehicle enters or leaves a
designated region. You can also query
the Infiniti Connection website to see a
listing of alert notifications received.
. Max Speed Alert:
Max Speed Alert allows you to monitor
the speed of your vehicle by receiving alerts. You can set the maximum speed
via the Infiniti Connection website, and
if your vehicle exceeds the specified
speed threshold, you will receive a
notification via the chosen method.
You can also query the Infiniti Connec-
tion website to view a listing of Max
Speed Alert notifications.
. Mobile Information Service (if so
equipped):
Mobile Information Service (MIS) deli-
vers information such as the latest
news headlines, stock quotes and
sports scores set in the Infiniti Connec-
tion website to be displayed on your
navigation screen or be read out.
“Viewing information feeds”
(page 7-9)
. Infiniti Personal Assistant:
Infiniti Personal Assistant delivers a
high‐quality assistant‐like service by
providing a quick‐assist program de-
signed to provide immediate informa-
tion or assistance. Services and
features are driver‐centric and enable
you to make restaurant, hotel or airline
reservations, purchase movie, theater
or sporting event tickets, and receive
local information based on your re- quests.
“Connecting to Interactive Voice
Menu”
(page 7-10)
. Valet Alert:
Valet Alert notifies you if the vehicle
moves outside a 0.2 mile radius of the
location set on the Infiniti Connection
website. You can activate Valet Alert
from the "Voice Menu" and saying
"Valet Alert" when the call is con-
nected.
“Connecting to Interactive Voice
Menu” (page 7-10)
Notice to Bluetooth®Hands-free
phone users
The Bluetooth®Hands-free phone system
will be disabled and not be able to take
phone calls while the vehicle is connected
to the Infiniti Connection Response Spe-
cialists or the emergency support staff at
the Infiniti Response Center. This is to
avoid various services by Infiniti Connec-
tion Response Specialists (such as route
guidance) and Infiniti Connection emer-
gency support staff being interrupted by
incoming calls. Incoming phone calls re-
ceived while the vehicle is connected to the
Service Center will not be listed in the call
Condition: Language=NAM_English/

Black plate (153,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
history of the Bluetooth®Hands-free
phone system. However those incoming
calls may be listed in the call history of
your mobile phone, depending on its
capabilities. After disconnecting communi-
cation with the Infiniti Connection Re-
sponse Specialist or Infiniti Connection
emergency support staff, check the incom-
ing call history on your mobile phone when
it is safe to do so.
Service application
A separately purchased Infiniti Connection
subscription is required. For detailed in-
formation, contact an INFINITI retailer or
refer to the following Infiniti Connection
website:
www.infiniticonnection.com (for U.S.)
https://canada.infiniticonnection.com (for
Canada)
INFO:
If the vehicle is owned by another person and is
resold, the subscription for this service must be
canceled and all data stored on the device must
be deleted.
Operating tips
WARNING!GUID-D56B9698-6357-41FF-A5C7-FC6C7993EDEA. Use the Infiniti Connection services after
stopping your vehicle in a safe location.
If you have to use the Infiniti Connection
services while driving, exercise extreme
caution at all times so full attention may
be given to vehicle operation.
. If you are unable to devote full attention
to vehicle operation while talking with
the Infiniti Connection services, pull off
the road to a safe location and stop your
vehicle.
.Do not use the Infiniti Connection
service with the engine or the hybrid
system stopped. Doing so may dis-
charge the vehicle battery.
. The Infiniti Connection services cannot
be used under the following conditions:
—
Infiniti Connection subscription has ex-
pired.
—The vehicle is outside the area where thecellular network service is receivable.
—The vehicle is in a location with poorsignal reception such as tunnels, under-
ground parking garages, behind build-
ings or in mountainous areas.
—The line is busy.
—The TCU (Telematics Communication
Unit) or other systems of your vehicle
are not working properly.
—The Infiniti Connection services network system is disabled.
. Information Feeds download cannot be
used when the vehicle is connected to
the Infiniti Connection Data Center and
Infiniti Connection Response Center.
. Communication with the Infiniti Con-
nection Data Center is related to the
data communication mode and may
cause occasional difficulty in receiving
signals, and the signal receivable area
may be limited compared to regular
mobile phones.
. You may hear clicks or experience
interruptions while speaking with the
Infiniti Connection Response Specia-
lists. This is due to a shift in the
connection zone and is not a malfunc-
tion.
7. Viewing technical information
7-7
Condition: Language=NAM_English/

Black plate (157,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
(for U.S.) /1-855-892-7418 (for Canada) or
refer to the Infiniti Connection website
www.infiniticonnection.com (for U.S.)/
https://canada.infiniticonnection.com (for
Canada).
1. Push.
2. Highlight [Infiniti Connection] and push .
JNG0163M
3. Highlight [Connect to Voice Menu] and
push .
4. The system connects to the Infiniti
Connection Response Center and menu
options will be announced. Speak your
preferred option.
.Destination Assistance
Set a destination using a Interactive
Voice Response (IVR) system.
.Roadside AssistanceConnect to the Roadside Response
Specialist.
.Valet AlertTurns on the Valet Alert function and
monitor the vehicle movement in
and out of the certain scope.
.Personal AssistanceConnects to the Infiniti Connection
Response Specialist.
JNG0187X
INFO:
.
You can also connect to an Infiniti Connec-
tion Interactive Voice Menu using the IVR
soft button
*1on the map.
INFO:
.
After selecting [Connect to Voice Menu] and
pushing button, it may take some
time until the system initiates connection,
depending on the technical environment
and whether the TCU (Telematics Commu-
nication Unit) is being used by other
services.
.To avoid disconnecting the line, do not turn
off the engine or hybrid system.
.The Bluetooth®Hands-free phone system (if
so equipped) will be disabled and it will not
be possible to take phone calls while the
vehicle is connected to the operators at the
Infiniti Connection Response Center.
“Notice to Bluetooth®Hands-free
phone users” (page 7-6)
VIEWING INFORMATION FEEDS HIS-
TORY
The information feeds that were previously
referred to are displayed.
1. Push.
2. Highlight [Infiniti Connection] and push .
7. Viewing technical information
7-11
Condition: Language=NAM_English/

Black plate (161,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
.An indicator light onshows the
readiness of the emergency support system.
If the indicator light is not illuminated,
pushing does not connect your
vehicle to the Response Specialist.
The indicator light blinks while connected to
the Infiniti Connection Response Center.
.Even when the indicator light is illuminated,
connection to the Infiniti Connection Re-
sponse Center may not be possible. In such
cases contact with the police or other
agencies should be made using other
devices such as telephones.
.To avoid disconnecting the line, do not turn
off the engine or hybrid system.
.The Bluetooth®Hands-free phone system
will be disabled and it is not possible to
take phone calls while the vehicle is
connected to the emergency support staff
at the Infiniti Connection Response Center.
“Notice to Bluetooth®Hands-free
phone users” (page 7-6)
VIEWING INFORMATION ABOUT CUR-
RENT VEHICLE LOCATION
This displays the information about the
vehicle location on the route when driving
according to route guidance.
IIN0042BASIC OPERATION
1. Push.
2. Highlight the preferred item and push .
3. Push to return to the previous
screen. Push

Black plate (180,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
8. Other settings
8-2
SETTINGS SCREEN
The navigation system can be customized
to make it easier for you to use.
ISE0059BASIC OPERATION
1. Push.
2. Highlight the preferred setting item and push .
Available setting items
. [Navigation]:
Adjust various settings of the naviga-
tion system.
“Navigation setting” (page 8-5)
. [Audio]:
Refer to the vehicle Owner’s Manual.
. [Phone]:
Refer to the vehicle Owner’s Manual. .
[Bluetooth]:
Set Bluetooth
®Audio and Phone.
Refer to the vehicle Owner’s Manual.
. [Volume & Beeps]:
“Volume adjustment” (page 8-11)
. [Rear Display] (if so equipped):
Refer to the vehicle Owner’s Manual.
. [ECO DRIVE] (if so equipped):
Refer to the vehicle Owner’s Manual.
. [Driver Assistance] (if so equipped):
Refer to the vehicle Owner’s Manual.
. [Others]:
—
[Rear Display] (if so equipped):
Refer to the vehicle Owner’s Manual.
—[Display]:
“Display settings” (page 8-3)
—[Comfort]:
This item is displayed when the ignition
switch is in the ON position.
Refer to the vehicle Owner’s Manual.
—[Language & Units]:
“Language and unit settings”
(page 8-13)
—[Clock]:
“Clock settings” (page 8-12)
—[Voice Recognition]:
“System feedback announcement
modes”(page 9-15)
—[Infiniti Connection] (if so equipped):
“Infiniti ConnectionTM”(page 7-3)
—[Camera] (if so equipped):
Refer to the vehicle Owner’s Manual.
—[Sonar] (if so equipped):Adjust the parking sonar detection
sensitivity, etc.
Refer to the vehicle Owner’s Manual.
—[Image Viewer]:Refer to the vehicle Owner’s Manual.
INFO:
The displayed items vary depending on the
equipped options.
Condition: Language=NAM_English/

Black plate (194,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
9. Voice recognition
9-2
INFINITI VOICE RECOGNITION
INFINITI Voice Recognition allows hands-
free operation of the navigation system
and other systems equipped on this
vehicle, in one of two modes, Standard
Mode or Alternate Command Mode. Stan-
dard Mode allows the operation of Naviga-
tion, Phone, Audio, Information and Help.
The commands that are available are
always shown on the display and an-
nounced by the system. To perform opera-
tions, simply follow the prompts given by
the system. In Standard Mode, hands-free
operation of Change map view, Route
selection and Bluetooth Audio, etc. is not
available through Voice Recognition.
Alternate Command Mode allows advanced
operations. When this mode is active, an
expanded list of commands can be spoken
after pushing >, and the voice
command menu prompts are turned off.
Note that in this mode the recognition
success rate may be affected because the
number of available commands and ways
of speaking each command are increased.
Otherwise, it is recommended that Alter-
nate Command Mode be turned OFF and
Standard Mode be used for the best recognition performance.
“Alternate command mode”
(page 9-9)
INFO:
.
For U.S. customers, Standard Mode is
selected by default. For Canadian custo-
mers, Alternate Command Mode is the
default mode.
.To improve recognition success when Alter-
nate Command Mode is active, try using the
Speaker Adaptation function available in
that mode.
“Speaker adaptation” (page 9-15)
Otherwise, it is recommended that Alternate
Command Mode be turned OFF and Stan-
dard Mode be used for the best recognition
performance.
.For the voice commands for the audio,
phone and other systems, refer to the
vehicle Owner’s Manual. The following sec-
tions refer only to the navigation, phone and
information systems.
.The voice recognition system cannot be
operated when the retractable hard top is
not closed (for G37 Convertible only).
STANDARD MODE
CONFIRMING HOW TO USE VOICE
COMMANDS
When operating the voice recognition
system for the first time or if help is
preferred to use the system, the User
Guide can be displayed.
It is possible to confirm how to use voice
commands by accessing a simplified User
Guide, which contains basic instructions
and tutorials for several voice commands.
IVR0072
Basic operation
1. Push .
2. Highlight [Others] and push .
3. Highlight [Voice Recognition] and push .
Condition: Language=NAM_English/

Black plate (218,1)
[ Edit: 2012/ 11/ 8 Model: 08TJ-N ]
9. Voice recognition
9-26
Vehicle Phone Com-
mandsCommand Action
Dial Number Makes a call to a spoken phone number.
Quick Dial Makes a call to a contact that is stored in the Quick Dial.
Phonebook Makes a call to a contact that is stored in a mobile phone.
Call History Incoming Calls Makes a call to an incoming call number.
Outgoing Calls Makes a call to a dialed number.
Missed Calls Makes a call to a missed calls number.
International Call Makes an international call by allowing more than 10 digits to be spoken.
Call
Makes a call to a contact that is stored in either Quick Dial or Phonebook.
Please say “Call”followed by a stored name.
Audio Commands Command Action
CD Starts to play a CD.
FM Turns to the FM band, selecting the station last played.
AM Turns to the AM band, selecting the station last played.
XM Turns to the SiriusXM Satellite Radio band, selecting the channel last played.
USB Turns on the USB memory.
Bluetooth Audio Turns on the Bluetooth audio player.
AUX (if so equipped) Turns on the AUX.
General Commands Command Action
Go back Corrects the last recognition result to return to the previous screen.
Exit Cancels Voice Recognition.
Condition: Language=NAM_English/
