tire pressure INFINITI EX 2013 Quick Reference Guide

*See your Owner’s Manual for information.
01
INSTRUMENT BRIGHTNESS
cONTROL SwITcH*
02
TRIP cOMPUTER S wITcHES
03
LO w TIRE PRESSURE wARNING LIGHT
04
HEADLIGHT AND TURN SIGNAL cONTROL
05 wINDSHIELD wIPER / w
ASHER SwITcH
06
STEERING wHEEL SwITcHE S FOR
AUDIO* / BLUETOOTH® / NAVIGATION
07
INTELLIGENT cRUISE c ONTROL BUTTONS
08
PUSH BUTTON IGNITION
09 w
ARNING SYSTEMS S wITcH*
10
INTELLIGENT BRAKE ASSIST (IBA)
OFF S wITcH*
11
DYNAMIc DRIVER ASSISTANc E SwIT cH*
12
INTELLIGENT KEY PORT
13
TILT / TELESc OPIc STEERING
wHEEL S wITcH*
14
HOOD RELEASE*
15
VEHIcLE DYNAMIc cONTROL (VDc)
OFF S wITcH*
16 c
ONTROL PANEL DISPLAY ScREEN*
17
AUDIO SYSTEM
18
AUTOMATIc cLIMATE cONTROLS
19
FRONT PASSENGER AIR BAG STATUS LIGHT*
01
Behind
steering wheel Behind
steering wheel
On
steering column
0405
08
0910
16
17
18
19
11
1213
14
02
03
0706
15Behind
steering wheel

table of contents
Additional information about your vehicle is also available in your Owner’s Manual, Navigation System Owner’s Manual and at www.InfinitiUSA.com.
• A cellular telephone should not be used for any purpose while driving so full attention
may be given to vehicle operation.
• Always wear your seat belt.
• Supplemental air bags do not replace proper seat belt usage.
• Children 12 and under should always ride in the rear seat properly secured in child
restraints or seat belts according to their age and weight.
• Do not drink and drive.
For more information, refer to the “Safety –– Seats, seat belts and supplemental
restraint system (section 1)”, “Monitor, climate, audio, phone and voice recognition
systems (section 4)” and the “Starting and driving (section 5)” of your Owner’s Manual.
new system features Blind Spot warning (BS w) System (if so equipped) ....................2
essential information Loose Fuel c ap ................................................. 3
Tire Pressure Monitoring System (TPMS) ............................ 3
first drive features INFINITI Intelligent Key™ System .................................. 4
Liftgate Release ................................................ 5
Seat Adjustments ............................................... 5
Automatic Drive Positioner (if so equipped) ..........................6
Outside Mirror c ontrol Switch ..................................... 6
Starting/Stopping the Engine ..................................... 7
Headlight control Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .\
. . . . . 7
w indshield wiper/w asher Switch .................................. 8
c limate c ontrols (if so equipped) .................................. 9
FM/AM/SiriusXM
™ Satellite Radio with cD/DVD Player
(with Navigation System - if so equipped) .......................... 11
USB/iPod
® Interface (models with Navigation System - if so equipped) .... 12
c onventional (Fixed Speed) c ruise control ......................... 12
Intelligent c ruise control (Icc) System (if so equipped) ...............13
Fuel-Filler Door ................................................ 14
system guide Trip c omputer ..................................................... 15
Bluetooth® Hands-free Phone System (if so equipped) ..................15
System Operating Tips ........................................ 16
Bluetooth
® System with Navigation (if so equipped) ................16
Bluetooth® System without Navigation (if so equipped) .............18
Navigation System (if so equipped) ............................... 20
DVD Player (if so equipped) ...................................... 21
HomeLink
® Universal Transceiver (if so equipped) ................... 22

3
Loose Fuel Cap
A LOOSE FUEL CAP warning message will appear in
the dot matrix liquid crystal display

01 when the
fuel-filler cap is not tightened correctly.

To tighten, turn the cap clockwise until a single click
is heard.

The warning message will disappear when the vehicle
detects the fuel-filler cap is properly tightened and the
reset button

02 is pressed.

If the cap is not properly tightened, the Malfunction
Indicator Light
may illuminate.
For more information, refer to the “Instruments and controls (section 2)” and
the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
Tire Pressure Monitoring System (TPMS)

A ChECk tIrE PrESSUrE warning message will
appear in the dot matrix liquid crystal display

01
and the low tire pressure warning light
02 will

illuminate when one or more tires are low on
pressure and air is needed.
• The tire pressures should be checked when the
tires are cold. The tires are considered cold after
the vehicle has been parked for 3 hours or more or
driven less than 1 mile (1.6km) at moderate speeds.

After tire pressures are adjusted, drive the vehicle at
speeds above 16 MPH (25km/h). The ChECk tIrE
PrESSUrE warning message and the low tire pressure
warning light will disappear.

when the low tire pressure warning light flashes for 1 minute and then remains on, the TPMS
is not functioning properly. Have the system checked by an INFINITI retailer.

Tire pressure rises and falls depending on the heat caused by the vehicle’s operation and the
outside temperature. Low outside temperature can lower the temperature of the air inside the
tire, which can cause a lower tire inflation pressure. This may cause the low tire pressure
warning light to illuminate. If the warning light illuminates in low ambient temperature,
check the tire pressure in your tires.
• Check the tire pressure (including the spare tire) often and always prior to long distance trips.

The Tire and Loading Information label contains valuable information. Please refer to section 9,
“Technical and consumer information”, in your Owner’s Manual for the location of the Tire and
Loading Information label.
For more information, refer to the “Instruments and controls (section 2)”, the “Starting and driving (section 5)” and the
“Maintenance and do-it-yourself (section 8)” of your Owner’s Manual.
essential information
01
01
02
02
