Terminals and Reference Value for BOSE Speaker Amp.AKS00BMO
Terminal
(Wire color)
ItemSignal
input/
outputCondition
Reference valueExample of
symptom
+–Igni-
tion
switchOperation
1 (R) GroundBattery power
supply Input OFF – Battery voltageSystem does not
work properly.
9 (LG) 10 (B/Y)Audio sound
signal rear LHOutput ON
Receive audio
signalNo sound from
rear door speaker
LH.
11 (OR) 12 (B/P)Audio sound
signal rear RHOutput ONNo sound from
rear door speaker
RH.
13 (L) 14 (B/W)Audio sound
signal front LHOutput ON
Receive audio
signalNo sound from
front door
speaker LH and
instrument
speaker LH.
15 (BR) 16 (B/R)Audio sound
signal front RHOutput ONNo sound from
front door
speaker RH and
instrument
speaker RH.
17 (B) GroundGround
(Power)– ON – Approx. 0VBOSE speaker
amp. dose not
work properly.
18
(R/L)2 (B)Audio sound
signal (Instru-
ment CEN-
TER)Output ONReceive audio
signalNo sound from
instrument
speaker CEN-
TER.
19 (W) 3 (B) Woofer signal Output ONReceive audio
signalNo sound from
woofer.
20 (G) 4 (G/W) Tweeter signal Output ONReceive audio
signalNo sound from
tweeter.
22 (P) GroundAmp ON sig-
nal (woofer)Output ON – Approx. 12VWoofer does not
work properly.
SKIA0177E
SKIA0177E
SKIA0177E
SKIA0177E
SKIA0177E

AUDIO
AV-35
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2004 November 2004 FX35/FX45
A/C and AV Switch Self-Diagnosis FunctionAKS00BMP
It can check ON/OFF operation of each switch in the A/C and AV switch and diagnose the input signals to the
audio steering wheel switch.
STARTING THE SELF-DIAGNOSIS MODE
1. Turn ignition switch from OFF to ACC.
2. Within 10 seconds press and hold the switches “MUTE/II ” and
“PREV ” simultaneously for 3 seconds.
DIAGNOSIS FUNCTION
The following are checked:

All the indicators (LED) in the A/C and AV switch.

Continuity of the switches by sounding the buzzer when the A/C and AV switch is pressed.

Continuity of harness between A/C and AV switch and audio steering wheel switch.
EXITING THE SELF-DIAGNOSIS MODE

Turn ignition switch OFF.
Trouble DiagnosisAKS00BMQ
The majority of the audio malfunctions are the result of outside causes (bad CD/cassette, electromagnetic
interference, etc.). Check the symptoms below to diagnose the malfunction.
MALFUNCTION WITH RADIO, TAPE AND CD (BASE SYSTEM)
Make sure that operation excepting audio system can be done with A/C and AV switch. If not, refer AV- 8 4 , "A/
C and AV Switch Does Not Operate" to repair malfunctioning parts.
SKIA4972E
Symptom Check item
Inoperative

Audio unit power supply circuit. Refer to AV- 3 9 , "Power Supply Circuit
Inspection" .

Audio communication line (With out navigation system). Refer to , AV- 8 2 ,
"Audio Communication Line Inspection" .

Audio communication line (With navigation system). Refer to AV-131, "Self-
Diagnosis Mode (DCU)" .

A/C and AV switch. Refer to AV-41, "A/C and AV Switch Inspection" .

Audio unit
Audio steering wheel switch dose not operate

Audio steering wheel switch. Refer to AV- 4 0 , "Audio Steering Wheel Switch
Inspection" .

A/C and AV switch. Refer to AV-41, "A/C and AV Switch Inspection" .
One or several speaker does not sound

Front door speaker

Rear door speaker

Audio unit
Poor sound

Audio unit

Speaker
Noisy

Audio unit

Each electrical equipment

AV-36
AUDIO
Revision: 2004 November 2004 FX35/FX45
MALFUNCTION WITH RADIO, TAPE AND CD (BOSE SYSTEM)
Make sure that operation excepting audio system can be done with A/C and AV switch. If not, refer AV- 8 4 , "A/
C and AV Switch Does Not Operate" (without navigation system), AV- 1 3 1 , "Self-Diagnosis Mode (DCU)" (with
navigation system) to repair malfunctioning parts.
Symptom Check item
Inoperative

Audio unit power supply circuit. Refer to AV- 3 9 , "Power Supply Circuit
Inspection" .

Audio communication line (Without navigation system). Refer to AV- 8 2 ,
"Audio Communication Line Inspection" .

Audio communication line (With navigation system). Refer to AV-131, "Self-
Diagnosis Mode (DCU)" .

A/C and AV switch. Refer to AV- 4 1 , "A/C and AV Switch Inspection" .

Audio unit
Audio steering wheel switch dose not operate

Audio steering wheel switch. Refer to AV-40, "Audio Steering Wheel Switch
Inspection" .

A/C and AV switch. Refer to AV- 4 1 , "A/C and AV Switch Inspection" .
One or several speaker does not sound

BOSE speaker amp. power supply and ground circuit. Refer to AV- 3 9 ,
"Power Supply Circuit Inspection" .

Front door speaker

Rear door speaker

BOSE speaker amp.AV- 4 2 , "BOSE Speaker Amp. Inspection" .

Audio unit
Woofer does not sound

Woofer

BOSE speaker amp
Speed sensitive volume system dose not work

Vehicle speed signal. Refer to AV- 4 2 , "Vehicle Speed Signal Inspection" .

Audio unit
Poor sound

Audio unit

BOSE speaker amp

Speaker

Woofer
Noisy

Audio unit

BOSE speaker amp

Each electrical equipment

AUDIO
AV-41
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2004 November 2004 FX35/FX45
3. CHECK SPIRAL CABLE
1. Disconnect spiral cable connector (Audio steering wheel switch harness side).
2. Check continuity between spiral cable connector terminal 24,
31, 32 and terminal 20, 17, 16.
OK or NG
OK >> GO TO 4
NG >> Replace spiral cable.
4. CHECK AUDIO STEERING WHEEL SWITCH
Check resistance audio steering wheel switch connector M203 ter-
minals.
OK or NG
OK >> Replace A/C and AV switch.
NG >> Replace audio steering wheel switch.
A/C and AV Switch InspectionAKS00BMU
1. A/C AND AV SWITCH SELF-DIAGNOSIS FUNCTION
1. Start A/C and AV switch self-diagnosis function. Refer to AV- 3 5 , "
A/C and AV Switch Self-Diagnosis Func-
tion" .
2. Operate A/C and AV switch.
Does the A/C and AV switch is operated normally?
YES >> INSPECTION END (System is OK)
NO >> GO TO 2.
2. CHECK A/C AND AV SWITCH POWER SUPPLY AND GROUND
Check A/C and AV switch power supply and gruoud circuit. Refer to AV- 8 0 , "
Power Supply and Ground Circuit
Check for A/C and AV Switch" (Without Navigation System), AV- 1 4 9 , "Power Supply and Ground Circuit
Check for A/C and AV Switch" (With Navigation System).
OK or NG
OK >> Replace A/C and AV switch.
NG >> Repair malfunctioning parts.24 – 20 : Continuity should exist.
31 – 17 : Continuity should exist.
32 – 16 : Continuity should exist.
SKIB0521E
Terminal Switch name ConditionResistance
(Ω)
16
17Power Depress power switch. Approx. 0
Seek down Depress seek down switch. Approx. 165
Volume (down) Depress volume down switch. Approx. 652
20Mode Depress mode switch. Approx. 0
Seek up Depress seek up switch. Approx. 165
Volume (up) Depress volume up switch. Approx. 652
SKIA9400E

AV-88
NAVIGATION SYSTEM
Revision: 2004 November 2004 FX35/FX45
NAVIGATION SYSTEMPFP:25915
System DescriptionAKS00BMX
The navigation system periodically calculates the vehicle's current
position according to the following three signals: Travel distance of
the vehicle as determined by the vehicle speed sensor, turning angle
of the vehicle as determined by the gyroscope (angular velocity sen-
sor), and the direction of vehicle travel as determined by the GPS
antenna (GPS information).
The current position of the vehicle is then identified by comparing the
calculated vehicle position with map data read from the map DVD-
ROM, which is stored in the DVD-ROM drive (map-matching), and
indicated on the screen with a current-location mark.
By comparing the vehicle position detection results found by the
GPS and by map-matching, more accurate vehicle position data can
be used.
The current vehicle position will be calculated by detecting the dis-
tance the vehicle moved from the previous calculation point and its
direction.
TRAVEL DISTANCE
Travel distance calculations are based on the vehicle speed sensor input signal. Therefore, the calculation
may become incorrect as the tires wear down. To prevent this, an automatic distance fine adjustment function
has been adopted.
TRAVEL DIRECTION
Change in the travel direction of the vehicle is calculated by a gyroscope (angular velocity sensor) and a GPS
antenna (GPS information). As the gyroscope and GPS antenna have both merit and demerit, input signals
from them are prioritized in each situation. However, this order of priority may change in accordance with more
detailed travel conditions so that the travel direction is detected more accurately.
MAP-MATCHING
Map-matching is a function that repositions the vehicle on the road
map when a new location is judged to be the most accurate. This is
done by comparing the current vehicle position, calculated by the
method described in the position detection principle, with the road
map data around the vehicle, read from the map DVD-ROM stored in
the DVD-ROM drive.
Therefore, the vehicle position may not be corrected after the vehicle
is driven over a certain distance or time in which GPS information is
hard to receive. In this case, the current location mark on the display
must be corrected manually.
CAUTION:
The road map data is based on data stored in the map DVD-
ROM.
SKIA6215E
SEL684V
Type Advantage Disadvantage
Gyroscope (angular velocity sensor)

Can detect the vehicle's turning angle
quite accurately.
Direction errors may accumulate when the
vehicle is driven for long distances without
stopping.
GPS antenna (GPS information)

Can detect the vehicle's travel direction
(North/South/East/West).
Correct direction cannot be detected when
the vehicle speed is low.
SEL685V

NAVIGATION SYSTEM
AV-89
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2004 November 2004 FX35/FX45

In map-matching, alternative routes to reach the destination will
be shown and prioritized, after the road on which the vehicle is
currently driven has been judged and the current-location mark
has been repositioned.
If there is an error in distance and/or direction, the alternative
routes will be shown in different order of priority, and the wrong
road can be avoided.
If two roads are running in parallel, they are of the same priority.
Therefore, the current-location mark may appear on either of
them alternately, depending on maneuvering of the steering
wheel and configuration of the road.

Map-matching does not function correctly when the road on
which the vehicle is driving is new and not recorded in the map
DVD-ROM, or when the road pattern stored in the map data and
the actual road pattern are different due to repair.
When driving on a road not present in the map, the map-match-
ing function may find another road and position the current-loca-
tion mark on it. Then, when the correct road is detected, the
current-location mark may leap to it.

Effective range for comparing the vehicle position and travel
direction calculated by the distance and direction with the road
data read from the map DVD-ROM is limited. Therefore, when
there is an excessive gap between the current vehicle position
and the position on the map, correction by map-matching is not possible.
GPS (GLOBAL POSITIONING SYSTEM)
GPS (Global Positioning System) has been developed and con-
trolled by the US Department of Defense. The system utilizes GPS
satellite (NAVSTAR), sending out radio waves while flying on an orbit
around the earth at the height of approx. 21,000 km (13,000 miles).
The GPS receiver calculates the vehicle's position in three dimen-
sions (latitude/longitude/altitude) according to the time lag of the
radio waves received from four or more GPS satellites (three-dimen-
sional positioning). If radio waves were received only from three
GPS satellites, the GPS receiver calculates the vehicle's position in
two dimensions (latitude/longitude), utilizing the altitude data calcu-
lated previously by using radio waves from four or more GPS satel-
lites (two–dimensional positioning).
Accuracy of the GPS will deteriorate under the following conditions.

In two–dimensional positioning, the GPS accuracy will deteriorate when the altitude of the vehicle position
changes.

There may be an error of approximately 10 m (30 ft) in position detected by three-dimensional positioning,
which is more accurate than two–dimensional positioning. The accuracy can be even lower depending on
the arrangement of the GPS satellites utilized for the positioning.

Position detection is not possible when the vehicle is in an area where radio waves from the GPS satellite
do not reach, such as in a tunnel, parking lot in a building, and under an elevated highway. Radio waves
from the GPS satellites may not be received when some object is located over the GPS antenna.

Position correction by GPS is not available while the vehicle is stopped.
SEL686V
SKIA0613E
SEL526V

AV-90
NAVIGATION SYSTEM
Revision: 2004 November 2004 FX35/FX45
COMPONENT DESCRIPTION
NAVI Control Unit

The gyro (angular speed sensor) and the DVD-ROM drive are
built-in units that control the navigation functions.

Signals are received from the gyro, the vehicle speed sensor,
and the GPS antenna. Vehicle location is determined by com-
bining this data with the data contained in the DVD-ROM map.
Locational information is shown on LCD panel.
DVD-ROM Drive
Maps, traffic control regulations, and other pertinent information can
be easily read from the DVD-ROM disc.
Map DVD-ROM

The map DVD-ROM has maps, traffic control regulations, and other pertinent information.

To improve DVD-ROM map matching and route determination functions, the DVD-ROM uses an exclusive
Nissan format. Therefore, the use of a DVD-ROM provided by other manufacturers cannot be used.
Gyro (Angular Speed Sensor)

The oscillator gyro sensor is used to detect changes in vehicle steering angle.

The gyro is built into the navigation (NAVI) control unit.
BIRDVIEW™
The BIRDVIEW™ provides a detailed and easily seen display of road conditions covering the vehicle's imme-
diate to distant area.

MAP DISPLAY
PKIA0248E
PKIA0249E
SKIA6098E

NAVIGATION SYSTEM
AV-91
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2004 November 2004 FX35/FX45

BIRDVIEW™
Description

Display area: Trapezoidal representation showing approximate
distances (Wn, D, and Wd).

Ten horizontal grid lines indicate display width while six vertical
grid lines indicate display depth and direction.

Pushing the “ZOOM IN” button during operation displays the
scale change and the view point height on the left side of the
screen.
The height of the view point increases or decreases when
“ZOOM” or “WIDE” is selected with the joystick.
MAP DISPLAY
Function of each icon is as follows:
1. Azimuth indication.
2. Position marker.
–The tip of the arrow shows the current location. The shaft of the
arrow indicates the direction in which the vehicle is traveling.
3. GPS reception signal (indicates current reception conditions).
4. Distance display (shows the distance in a reduced scale).
SKIA6099E
SKIA5613E
SKIA6100E

AV-92
NAVIGATION SYSTEM
Revision: 2004 November 2004 FX35/FX45
FUNCTION OF CENTER SWITCH
Display with Pushed “DEST” Button

Easy Mode

Expert Mode
The function of each icon is as follows:
SKIA3509E
SKIA3510E
IconMode
Description
Easy Expert
Address Book×Favorite place can be saved to memory.
Address/Street××The destination can be searched from the address.
Point of Interest (POI)××The destination of favorite facility can be searched.
Previous Dest.×The previous ten destinations stored in memory are displayed.
Intersection×The destination can be searched from the intersection.
City×The destination can be searched from city name.
Map×The destination can be searched from the map.
Phone Number×When two or more countries are included in one DVD-ROM, the destination can be
searched for under the country name.
Home×Sets the home as a destination.
Help×Explanation of navigational functions appear on the display.
Country××Select country (USA, CANADA)
