AT-4Revision: 2005 July 2005 FX
In “N” Position, Vehicle Moves .............................
.196
Large Shock (“N” to “D” Position) ........................ .197
Vehicle Does Not Creep Backward in “R” Position .200
Vehicle Does Not Creep Forward in “D” Position . .203
Vehicle Cannot Be Started from D
1 ..................... .205
A/T Does Not Shift: D
1 → D2 ............................... .208
A/T Does Not Shift: D
2 → D3 ............................... .210
A/T Does Not Shift: D
3 → D4 ............................... .212
A/T Does Not Shift: D
4 → D5 ............................... .215
A/T Does Not Perform Lock-up ........................... .217
A/T Does Not Hold Lock-up Condition ................. .219
Lock-up Is Not Released ..................................... .221
Engine Speed Does Not Return to Idle ............... .221
Cannot Be Changed to Manual Mode ................. .223
A/T Does Not Shift: 5th Gear → 4th Gear ........... .223
A/T Does Not Shift: 4th Gear → 3rd Gear ........... .225
A/T Does Not Shift: 3rd Gear → 2nd Gear .......... .227
A/T Does Not Shift: 2nd Gear → 1st Gear ........... .229
Vehicle Does Not Decelerate by Engine Brake ... .231
SHIFT CONTROL SYSTEM ................................... .233
Control Device Removal and Installation ............. .233
Control Rod Removal and Installation ................. .234
Adjustment of A/T Position .................................. .235
Checking of A/T Position ..................................... .235
A/T SHIFT LOCK SYSTEM .................................... .236
Description ........................................................... .236
Shift Lock System Electrical Parts Location ........ .236
Wiring Diagram — AT — SHIFT .......................... .237
Diagnostic Procedure .......................................... .238
KEY INTERLOCK CABLE ..................................... .240
Components ........................................................ .240
Removal and Installation ..................................... .241
ON-VEHICLE SERVICE ......................................... .243
Control Valve with TCM and A/T Fluid Temperature
Sensor 2 .............................................................. .243
Parking Components (2WD Models Only) ........... .255
Rear Oil Seal ....................................................... .262
Revolution Sensor Components (2WD Models Only) ....................................................................
.263
AIR BREATHER HOSE .......................................... .268
Removal and Installation ...................................... .268
TRANSMISSION ASSEMBLY ................................ .270
Removal and Installation (2WD Models) .............. .270
Removal and Installation (AWD Models) ............. .273
OVERHAUL ............................................................ .278
Components ......................................................... .278
Oil Channel .......................................................... .286
Locations of Adjusting Shims, Needle Bearings,
Thrust Washers and Snap Rings ......................... .288
DISASSEMBLY ...................................................... .290
Disassembly ......................................................... .290
REPAIR FOR COMPONENT PARTS ..................... .308
Oil Pump .............................................................. .308
Front Sun Gear, 3rd One-way Clutch ................... .311
Front Carrier, Input Clutch, Rear Internal Gear .... .313
Mid Sun Gear, Rear Sun Gear, High and Low
Reverse Clutch Hub ............................................. .318
High and Low Reverse Clutch ............................. .323
Direct Clutch ........................................................ .326
ASSEMBLY ............................................................ .328
Assembly (1) ........................................................ .328
Adjustment ........................................................... .341
Assembly (2) ........................................................ .344
SERVICE DATA AND SPECIFICATIONS (SDS) ... .351
General Specifications ......................................... .351
Vehicle Speed at Which Gear Shifting Occurs ..... .351
Vehicle Speed at Which Lock-up Occurs/Releases .352
Stall Speed ........................................................... .352
Line Pressure ....................................................... .352
A/T Fluid Temperature Sensor ............................. .352
Turbine Revolution Sensor ................................... .353
Vehicle Speed Sensor A/T (Revolution Sensor) .. .353
Reverse Brake ..................................................... .353
Total End Play ...................................................... .353

AT-8
PRECAUTIONS
Revision: 2005 July 2005 FX
Precautions ACS002L6

Before connecting or disconnecting the A/T assembly har-
ness connector, turn ignition switch OFF and disconnect
the battery cable from the negative terminal. Because bat-
tery voltage is applied to TCM even if ignition switch is
turned OFF.

After performing each TROUBLE DIAGNOSIS, perform
“DTC (Diagnostic Trouble Code) Confirmation Procedure”.
If the repair is completed the DTC should not be displayed
in the “DTC Confirmation Procedure”.

Always use the specified brand of ATF. Refer to MA-12, "Fluids and Lubricants" .

Use lint-free paper not cloth rags during work.

After replacing the ATF, dispose of the waste oil using the methods prescribed by law, ordinance, etc.

Before proceeding with disassembly, thoroughly clean the outside of the transmission. It is important to
prevent the internal parts from becoming contaminated by dirt or other foreign matter.

Disassembly should be done in a clean work area.

Use lint-free paper or towels for wiping parts clean. Common shop rags can leave fibers that could inter-
fere with the operation of the transmission.

Place disassembled parts in order for easier and proper assembly.

All parts should be carefully cleansed with a general purpose, non-flammable solvent before inspection or
reassembly.

Gaskets, seals and O-rings should be replaced any time the transmission is disassembled.

It is very important to perform functional tests whenever they are indicated.

The valve body contains precision parts and requires extreme care when parts are removed and serviced.
Place disassembled valve body parts in order for easier and proper assembly. Care will also prevent
springs and small parts from becoming scattered or lost.

Properly installed valves, sleeves, plugs, etc. will slide along bores in valve body under their own weight.

Before assembly, apply a coat of recommended ATF to all parts. Apply petroleum jelly to protect O-rings
and seals, or hold bearings and washers in place during assembly. Do not use grease.

Extreme care should be taken to avoid damage to O-rings, seals and gaskets when assembling.

After overhaul, refill the transmission with new ATF.

When the A/T drain plug is removed, only some of the ATF is drained. Old ATF will remain in torque con-
verter and ATF cooling system.
Always follow the procedures under “Changing A/T Fluid” in the AT section when changing A/T fluid. Refer
to AT- 1 2 , "
Changing A/T Fluid" , AT- 1 3 , "Checking A/T Fluid" .
SEF289H
SEF217U

AT-270
TRANSMISSION ASSEMBLY
Revision: 2005 July 2005 FX
TRANSMISSION ASSEMBLYPFP:31020
Removal and Installation (2WD Models)ACS002S1
COMPONENTS
REMOVAL
CAUTION:
When removing the transmission assembly from engine, first remove the crankshaft position sensor
(POS) from the transmission assembly.
Be careful not to damage sensor edge.
1. Disconnect the battery cable from the negative terminal.
2. Remove engine cover.
3. Remove A/T fluid level gauge.
4. Remove engine under cover with power tool.
5. Remove front cross bar. Refer to FSU-8, "
Components"
6. Remove exhaust front tube and center muffler with power tool. Refer to EX-3, "Removal and Installation" .
7. Remove three way catalyst. Refer to EM-26, "
Removal and Installation" .
8. Remove rear propeller shaft. Refer to PR-9, "
Removal and Installation" .
9. Remove control rod. Refer to AT- 2 3 4 , "
Control Rod Removal and Installation" .
1. A/T fluid charging pipe 2. O-ring 3. Engine mounting insulator (rear)
4. Rear engine mounting member 5. Copper washer 6. Fluid cooler tube
7. Bracket 8. Transmission assembly 9. A/T fluid level gauge
SCIA6379E

TRANSMISSION ASSEMBLY AT-273
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2005 July 2005 FX
Removal and Installation (AWD Models) ACS0033A
COMPONENTS (FOR VQ35DE)
1. A/T fluid charging pipe 2. O-ring 3. Engine mounting insulator (rear)
4. Rear engine mounting member 5. Copper washer 6. Bracket
7. Fluid cooler tube 8. Bracket 9. Transmission assembly
10. A/T fluid level gauge
SCIA6425E

AT-274
TRANSMISSION ASSEMBLY
Revision: 2005 July 2005 FX
COMPONENTS (FOR VK45DE)
REMOVAL
CAUTION:
When removing the transmission assembly from engine, first remove the crankshaft position sensor
(POS) from the transmission assembly.
Be careful not to damage sensor edge.
1. Disconnect the battery cable from the negative terminal.
2. Remove engine cover.
3. Remove A/T fluid level gauge.
4. Remove engine under cover with power tool.
5. Remove front cross bar. Refer to FSU-8, "
Components" .
6. Remove exhaust front tube and center muffler with power tool. Refer to EX-3, "
Removal and Installation" .
7. Remove three way catalyst. Refer to EM-182, "
Removal and Installation" .
8. Remove front propeller shaft. Refer to PR-5, "
Removal and Installation" .
9. Remove rear propeller shaft. Refer to PR-9, "
Removal and Installation" .
10. Remove control rod. Refer to AT- 2 3 4 , "
Control Rod Removal and Installation" .
1. A/T fluid charging pipe 2. O-ring 3. Engine mounting insulator (rear)
4. Rear engine mounting member 5. Copper washer 6. Bracket
7. Fluid cooler tube 8. Bracket 9. Bracket
10. Bracket 11. Transmission assembly 12. A/T fluid level gauge
SCIA6426E

ATC-158
REFRIGERANT LINES
Revision: 2005 July 2005 FX
Checking for Refrigerant LeaksAJS00163
Perform a visual inspection of all refrigeration parts, fittings, hoses and components for signs of A/C lubricant
leakage, damage and corrosion. A/C lubricant leakage may indicate an area of refrigerant leakage. Allow
extra inspection time in these areas when using either an electronic refrigerant leak detector or fluorescent
dye leak detector (SST: J-42220).
If dye is observed, confirm the leak with an electronic refrigerant leak detector. It is possible a prior leak was
repaired and not properly cleaned.
When searching for leaks, do not stop when one leak is found but continue to check for additional leaks at all
system components and connections.
When searching for refrigerant leaks using an electronic leak detector, move the probe along the suspected
leak area at 1 to 2 inches per second and no further than 1/4 inch from the component.
CAUTION:
Moving the electronic leak detector probe slower and closer to the suspected leak area will improve
the chances of finding a leak.
Checking System for Leaks Using the Fluorescent Leak DetectorAJS00164
1. Check A/C system for leaks using the UV lamp and safety goggles (SST: J42220) in a low sunlight area (area without windows preferable). Illuminate all components, fittings and lines. The dye will appear as a
bright green/yellow area at the point of leakage. Fluorescent dye observed at the evaporator drain open-
ing indicates an evaporator core assembly (tubes, core or expansion valve) leak.
2. If the suspected area is difficult to see, use an adjustable mirror or wipe the area with a clean shop rag or cloth, with the UV lamp for dye residue.
3. After the leak is repaired, remove any residual dye using dye cleaner (SST: J43872) to prevent future mis- diagnosis.
4. Perform a system performance check and verify the leak repair with an approved electronic refrigerant leak detector.
NOTE:
Other gases in the work area or substances on the A/C components, for example, anti-freeze, windshield
washer fluid, solvents and lubricants, may falsely trigger the leak detector. Make sure the surfaces to be
checked are clean.
Clean with a dry cloth or blow off with shop air.
Do not allow the sensor tip of the detector to contact with any substance. This can also cause false readings
and may damage the detector.
Dye InjectionAJS00165
(This procedure is only necessary when recharging the system or when the compressor has seized and was
replaced.)
1. Check A/C system static (at rest) pressure. Pressure must be at least 345 kPa (3.52 kg/cm
2 , 50 psi).
2. Pour one bottle (1/4 ounce / 7.4 cc) of the A/C refrigerant dye into the injector tool (SST: J 41459).
3. Connect the injector tool to the A/C Low-pressure side service fitting.
4. Start engine and switch A/C ON.
5. When the A/C operating (compressor running), inject one bottle (1/4 ounce / 7.4 cc) of fluorescent dye through the low-pressure service valve using dye injector tool (SST: J-41459) (refer to the manufacture’s
operating instructions).
6. With the engine still running, disconnect the injector tool from the service fitting. CAUTION:
Be careful the A/C system or replacing a component, pour the dye directly into the open system
connection and proceed with the service procedures.
7. Operate the A/C system for a minimum of 20 minutes to mix the dye with the system oil. Depending on the leak size, operating conditions and location of the leak, it may take from minutes to days for the dye to
penetrate a leak and become visible.
8. Attach a blue label as necessary.

BRAKE PIPING AND HOSE BR-11
C
D E
G H
I
J
K L
M A
B
BR
Revision: 2005 July 2005 FX
BRAKE PIPING AND HOSEPFP:46210
Hydraulic CircuitAFS001MY
CAUTION:

All hoses and piping (tubes) must be free from excessive bending, twisting and pulling.

Make sure there is no interference with other parts when turning steering both clockwise and
counterclockwise.

The brake piping is an important safety part. If a brake fluid leak is detected, always disassemble
the parts. Replace applicable part with a new one, if necessary.

Be careful not to splash brake fluid on painted areas; it way cause paint damage. If brake fluid is
splashed on painted areas, wash it away with water immediately.

Do not bend or twist brake hose sharply, or strongly pull it.

When removing components, cover connections so that no dirt, dust, or other foreign matter gets
in.

Refill with new brake fluid “ DOT 3 ”.

Do not reuse drained brake fluid.
Removal and Installation of Front Brake Piping and Brake Hose AFS001MZ
REMOVAL
1. Drain brake fluid. Refer to BR-9, "Drain and Refill" .
2. Using a flare nut wrench, remove brake tube from brake hose.
3. Remove union bolt and remove brake hose from caliper assembly.
4. Remove lock plate and remove brake hose from the vehicle.
INSTALLATION
1. Install brake hose by aligning with the protrusion on caliper assembly, and tighten union bolt to the specified torque.
NOTE:
Do not reuse copper washer.
2. Install brake hose to brake tube, partially tighten flare nut as far as possible by hand, then secure it to bracket with lock plate.
3. Using a flare nut wrench, tighten flare nut to the specified torque.
4. Refill brake fluid and bleed air. Refer to BR-10, "
Bleeding Brake
System" .
SFIA1941E
SFIA1204E

BR-12
BRAKE PIPING AND HOSE
Revision: 2005 July 2005 FX
Removal and Installation of Rear Brake Piping and Brake Hose AFS001N0
REMOVAL
1. Drain brake fluid. Refer to BR-9, "Drain and Refill" .
2. Using a flare nut wrench, remove brake tube from brake hose.
3. Remove bolt.
4. Remove union bolt, and then remove brake hose from caliper assembly.
INSTALLATION
1. Install brake hose to caliper assembly positioning hole and tighten union bolt to the specified torque.
NOTE:
Do not reuse copper washer.
2. Install brake hose to brake tube, partially tighten flare nut as far as possible by hand, then tighten bolt to the specified torque.
3. Using a flare nut wrench, tighten flare nut to the specified torque.
4. Refill brake fluid and bleed air. Refer to BR-10, "
Bleeding Brake
System" .
Inspection After InstallationAFS001N1
CAUTION:
If a leak is detected at the connections, retighten it or, if necessary, replace the damaged part.
1. Check brake lines (tubes and hoses), and connections for fluid leaks, damage, twist, deformation, contact with other parts, and loose connections. Replace any damage parts.
2. While depressing brake pedal under a force of 785 N (80 kg, 177 lb) with engine running for approximately 5 seconds, check for fluid leakage from each part. : 23.5 N·m (2.4 kg-m, 17 ft-lb)
SFIA1942E

BR-22
FRONT DISC BRAKE
Revision: 2005 July 2005 FX

Do not reuse drained brake fluid.
1. Install disc rotor.
2. Install caliper assembly to the vehicle, and tighten bolts to the specified torque.
CAUTION:
When attaching caliper assembly to the vehicle, wipe any
oil off knuckle spindle, washers and caliper assembly
attachment surfaces.
3. Install brake hose to brake caliper assembly, and tighten union bolt to the specified torque.
CAUTION:

Do not reuse copper washers for union bolt.

Attach brake hose to caliper assembly together with
union bolt and washers.
4. Refill new brake fluid and bleed air. Refer to BR-10, "
Bleeding Brake System" .
5. Attach tires to the vehicle.
Disassembly and Assembly of Brake Caliper AssemblyAFS001S1
DISASSEMBLY
1. Remove sliding pin bolt, and then remove the pad, shim, shim cover, and pad retainer from the torque member.
2. Remove sliding pins and sliding pin boots from torque member.
3. Place a wooden block as shown in the figure, and blow air from union bolt mounting hole to remove pistons and piston boots.
CAUTION:
Do not get your fingers caught in piston.
SFIA1205E
SFIA1204E
MAA0272D

BR-28
REAR DISC BRAKE
Revision: 2005 July 2005 FX
INSTALLATION
CAUTION:

Refill with new brake fluid “DOT 3”.

Do not reuse drained brake fluid.
1. Install disc rotor.
2. Install caliper assembly to the vehicle, and tighten bolts to the specified torque. CAUTION:
Before installing caliper assembly to the vehicle, wipe off oil and grease on washer seats on axle
assembly and mounting surface of caliper assembly.
3. Install brake hose to caliper assembly and tighten union bolt to the specified torque.
CAUTION:

Do not reuse copper washer for union bolt.

Securely attach brake hose to protrusion on caliper assembly.
4. Refill new brake fluid and bleed air. Refer to BR-10, "
Bleeding Brake System" .
5. Install tires to the vehicle.
Disassembly and Assembly of Brake Caliper AssemblyAFS001NE
DISASSEMBLY
1. Remove sliding pin bolt, and then remove pad, shim, shim cover, and pad retainer from torque member and cylinder.
2. Remove sliding pin boot from torque member.
3. As shown in the figure, using a flat-bladed screwdriver, remove retaining ring from cylinder body.
4. Place a wooden block as shown in the figure, and blow air from union bolt mounting hole to remove pistons and piston boots.
CAUTION:
Do not get your fingers caught in piston.
5. Using a flat-bladed screwdriver, remove piston seals from cylin- der body.
CAUTION:
Be careful not to damage cylinder inner wall.
SBR028A
BRD0041D
SFIA0999E
