NAVIGATION SYSTEM AV-151
C
D E
F
G H
I
J
L
M A
B
AV
Revision: 2006 December 2006 FX35/FX45
2. CHECK CAN COMMUNICATION
Check CAN communication. Refer to AV- 1 3 8 , "
CAN Communication Check" .
OK or NG
OK >> Replace display control unit.
NG >> After filling out CAN DIAG SUPPORT MONITOR check sheet, GO TO LAN-3, "
Precautions When
Using CONSULT-II" .
Voice Guidance Is Not HeardNKS003KY
Symptom: Voice guidance does not sound at route guidance.
1. CHECK HARNESS
1. Turn ignition switch OFF.
2. Disconnect NAVI control unit and audio unit connectors.
3. Check continuity between NAVI control unit harness connector (A) B208 terminals 12, 14 and audio unit harness connector (B)
M60 terminals 36, 34.
4. Check continuity between NAVI control unit harness connector (A) B208 terminals 12, 14 and ground.
OK or NG
OK >> GO TO 2.
NG >> Repair harness or connector.
2. CHECK VOICE GUIDANCE SIGNAL
1. Connect NAVI control unit and audio unit connectors.
2. Turn ignition switch ON.
3. Check voltage waveform between NAVI control unit harness connector B208 terminals 12 and 14 with CONSULT-II or oscillo-
scope.
OK or NG
OK >> Replace audio unit.
NG >> Replace NAVI control unit. 12 – 36 : Continuity should exist.
14 – 34 : Continuity should exist.
12, 14 – Ground : Continuity should not exist.
SKIB7865E
12 – 14:
SKIB7003ESKIB3609E
Page 758 of 4462
AV-152
NAVIGATION SYSTEM
Revision: 2006 December 2006 FX35/FX45
Example of Symptoms Possible No MalfunctionNKS003KZ
For Navigation System operation information, refer to Navigation System Owner's Manual.
BASIC OPERATIONS
NOTE:
Locations stored in the Address Book and other memory functions may be lost if the vehicle's battery is disconnected or is disc harged. If
this occurs, service the vehicle's battery as necessary and re-enter the information in the Address Book.
VEHICLE MARKS
Symptom Possible cause Possible solution
No image is displayed. The brightness is at the lowest setting. Adjust the brightness of the display.
The display is turned off. Press and hold the button to turn on the
display.
No voice guidance is available.
The volume is too high or too low. The volume is not set correctly, or it is turned
off. Adjust the volume of voice guidance.
No map is displayed on the
screen. The DVD-ROM is not inserted, or it is inserted
upside down. Insert the DVD-ROM correctly.
A screen other than map screen is displayed. Press the “MAP” button.
The pickup lens of the DVD unit is dirty. The pickup lens can become dirty depending
on the usage of the vehicle. Contact a NISSAN
dealer or qualified workshop for pickup lens
cleaning.
The screen is too dim.
The movement is slow. The temperature in the interior of the vehicle is
low. Wait until the interior of the vehicle has
warmed up.
Some pixels in the display are
darker or brighter than others. This condition is an inherent characteristic of
liquid crystal displays. This is not a malfunction.
Some menu items cannot be
selected. Some menu items become unavailable while
the vehicle is driven. Park the vehicle in a safe location, then oper-
ate the navigation system.
Symptom Possible cause Possible solution
Names of roads and locations dif-
fer between plan view and BIRD-
VIEW
™ . This is because the quantity of the displayed
information is reduced so that the screen does
not become difficult to read. There is also a
chance that names of the roads or locations
may be displayed several times, and the names
appearing on the screen may be different
because of a processing procedure. This is not a malfunction.
The vehicle mark is not displayed
in the correct position. The vehicle was transported after the ignition
switch was turned off, for example, by a ferry or
car transporter. Drive the vehicle for a while on a road where
GPS signals can be received.
The position and direction of the vehicle mark
may be incorrect depending on the driving envi-
ronments and the levels of positioning accuracy
of the navigation system. This is not a malfunction. Drive the vehicle for
a while to automatically correct the position
and direction of the vehicle mark.
When the vehicle is travelling on a
new road, the vehicle mark is
located on another road nearby. The system automatically places the vehicle
mark on the nearest available road, because
the new road is not stored in the map data. Updated road information will be included in
the next version of the DVD-ROM.
The screen does not switch to the
night screen even after turning on
the headlights. The daytime screen was set the last time the
headlights were turned on. Set the screen to the night screen mode using
button when turning on the headlights.
The map does not scroll even
when the vehicle is moving. The current location map screen is not dis-
played. Press the “MAP” button.
The vehicle mark is not displayed. The current location map screen is not dis-
played. Press the “MAP” button.
Page 759 of 4462
NAVIGATION SYSTEM AV-153
C
D E
F
G H
I
J
L
M A
B
AV
Revision: 2006 December 2006 FX35/FX45
DVD-ROM
ROUTE CALCULATION AND VISUAL GUIDANCE
The GPS indicator on the screen
remains gray. GPS signals cannot be received depending on
the vehicle location, such as in a parking
garage, on a road that has numerous tall build-
ings, etc. Drive on an open, straight road for a while.
A sufficient amount of GPS satellites is not
available. Please wait for the satellites to move to loca-
tions available for the navigation system.
The location of the vehicle mark is
misaligned from the actual posi-
tion. When using tire chains or replacing the tires,
speed calculations based on the speed sensor
may be incorrect. Drive the vehicle for a while [at approximately
30 km/h (19 MPH) for about 30 minutes] to
automatically correct the vehicle's mark posi-
tion. If this does not correct the vehicle mark
position, contact a NISSAN dealer or qualified
workshop.
The map data has a mistake or is incomplete
(the vehicle mark position is always misaligned
in the same area). Updated road information will be included in
the next version of the DVD-ROM.
Symptom Possible cause Possible solution
Symptom Possible cause Possible solution
The message “Error” appears. The DVD-ROM is dirty or partially damaged. Check the DVD-ROM and wipe it clean with a
soft cloth.
If any damage, replace the DVD-ROM.
Symptom Possible cause Possible solution
In the auto re-route calculation,
waypoints are not included. Waypoints that you have already passed are
not included in the auto re-route calculation. To go to that waypoint again, it is necessary to
edit the route.
Route information is not dis-
played. Route calculation has not yet been performed.
Set the destination and perform route calcula-
tion.
Vehicle is not driving on the suggested route. Drive on the suggested route.
Route guidance is set to off. Turn on the route guidance.
The auto re-route calculation (or
detour calculation) suggests the
same route as the one previously
suggested. Route calculations took priority conditions into
consideration, but the same route was calcu-
lated. This is not a malfunction.
A waypoint cannot be added. Five waypoints are already set on the route,
including the ones that you have already
passed. A maximum of 5 waypoints can be set on the
route. If you want to go to 6 or more waypoints,
perform route calculations several times, as
necessary.
The suggested route is not dis-
played. Roads near the destination cannot be calcu-
lated. Reset the destination to a main or ordinary
road, and recalculate the route.
The starting point and destination are too close. Set a more distant destination.
The starting point and destination are too far
away. Divide your trip by selecting one or two inter-
mediate destinations, and perform a global
route calculation based on multiple route cal-
culations.
There are time restricted roads (day of week,
time) near the current vehicle location or desti-
nation. Set [Use Time Restricted Roads] to off.
The part of the route already
passed is deleted. A route is managed by sections between way-
points. If passing the first waypoint, the section
between the starting point and the waypoint is
deleted. (It may not be deleted depending on
the area.) This is not a malfunction.
Page 760 of 4462
AV-154
NAVIGATION SYSTEM
Revision: 2006 December 2006 FX35/FX45
VOICE GUIDANCE
An indirect route is suggested. If there are restrictions (such as one-way
streets) on roads close to the starting point or
destination, the system may suggest an indirect
route. Adjust the location of the starting point or desti-
nation.
The system may suggest an indirect route
because route calculation does not take into
consideration some areas such as narrow
streets (grey roads). Reset the destination to a main or ordinary
road, and recalculate the route.
The landmark information does
not correspond to the actual infor-
mation. This may be caused by insufficient or incorrect
data on the DVD-ROM. Updated information will be included in the
next version of the DVD-ROM.
The suggested route does not
exactly connect with the starting
point, waypoints, or destination. There is no data for route calculation closer to
these locations. Set the starting point, waypoints and destina-
tion on a main road, and perform route calcula-
tion.
Symptom Possible cause Possible solution
Symptom Possible cause Possible solution
Voice guidance is not available. Voice guidance is only available at certain inter-
sections marked with . In some cases, voice
guidance is not available even when the vehicle
should make a turn. This is not malfunction.
The vehicle has deviated from the suggested
route. Go back to the suggested route or request
route calculation again.
Voice guidance is set to off. Turn on the voice guidance.
Route guidance is set to off. Turn on the route guidance.
The guidance content does not
correspond to the actual condition. The content of voice guidance may vary,
depending on the types of intersections where
turns are made. Follow all traffic rules and regulations.
Page 761 of 4462
NAVIGATION SYSTEM AV-155
C
D E
F
G H
I
J
L
M A
B
AV
Revision: 2006 December 2006 FX35/FX45
Removal and Installation of NAVI Control UnitNKS003LK
REMOVAL
1. Remove passenger side seat. Refer to SE-97, "Removal and Installation" .
2. Remove clips (4), and remove NAVI control unit cover.
3. Remove screws (2) and nut (1) with power tool, and remove NAVI control unit.
4. Remove screws (4) with power tool and remove brackets.
INSTALLATION
Installation is the reverse order of removal.
Removal and Installation of GPS AntennaNKS003LL
REMOVAL
1. Remove audio unit. Refer to AV- 4 3 , "Removal and Installation of
Audio Unit" .
2. Remove screw (1) and remove GPS antenna.
INSTALLATION
Installation is the reverse order of removal.
PKIA3129E
SKIA5822E
SKIA5823E
SKIA5824E
Page 762 of 4462
AV-156
NAVIGATION SYSTEM
Revision: 2006 December 2006 FX35/FX45
Removal and Installation of A/C and AV SwitchNKS003LM
For A/C and AV switch removal and installation procedures, refer to AV- 4 4 , "Removal and Installation for A/C
and AV Switch" .
Removal and Installation of Display UnitNKS003LN
For display unit removal and installation procedures, refer to AV- 4 3 , "Disassembly and Assembly for Audio
Unit" .
Removal and Installation of Display Control UnitNKS003LO
For display control unit removal and installation procedures, refer to AV- 9 2 , "Removal and Installation of Dis-
play Control Unit"
Page 3340 of 4462
IDX-6
ALPHABETICAL INDEX
Molding - See Exterior ................... EI-25, EI-30, EI-33
Multiport fuel injection (MFI) system .... EC-31, EC-691
Multiport fuel injection precautions ....................... GI-7
N
NATS - Wiring diagram .................................... BL-208
NAVI - Wiring diagram ..................................... AV-100
Navigation system ............................................. AV-93
NONDTC - Wiring diagram .............................. AT-186
NVH troubleshooting (EM) .............................. EM-171
NVH troubleshooting (EM)(VQ35DE) ............... EM-13
NVH troubleshooting (Final drive) ......... FFD-6, RFD-7
NVH troubleshooting (Propeller shaft) ................. PR-3
NVH troubleshooting (Transfer) ........................... TF-8
O
O2H2B1 - Wiring diagram .................. EC-175
, EC-845
O2H2B2 - Wiring diagram .................. EC-177, EC-847
O2S2B1 - Wiring diagram .. EC-273, EC-284, EC-297,
EC-943
, EC-954, EC-967
O2S2B2 - Wiring diagram .. EC-275, EC-286, EC-299,
EC-945
, EC-956, EC-969
Oil cooler (engine)(VQ35DE) ............................. LU-14
Oil filter(VK45DE) .............................................. LU-28
Oil filter(VQ35DE) .............................................. LU-10
Oil pan (engine)(VK45DE) .............................. EM-187
Oil pan (engine)(VQ35DE) ................................ EM-30
Oil pressure (engine)(VK45DE) ......................... LU-25
Oil pressure (engine)(VQ35DE) ........................... LU-8
Oil pressure relief valve (engine)(VQ35DE) ........ LU-6
Oil pump (A/T) ................................................. AT-312
Oil pump (engine)(VK45DE) .............................. LU-31
Oil pump (engine)(VQ35DE) .............................. LU-17
Oil pump regulator valve (engine)(VK45DE) ..... LU-31
Oil pump regulator valve (engine)(VQ35DE) ..... LU-17
Oil seal replacement (engine)(VK45DE) ......... EM-228
Oil seal replacement (engine)(VQ35DE) .......... EM-98
Oil seal replacement (front of final drive) .......... FFD-9,
RFD-10
Oil seal replacement (side of final drive) ......... FFD-11,
RFD-14
On board diagnostic system .............................. EC-54
ORVR (On-board Refueling Vapor Recovery) .. EC-46,
EC-706
Out side mirror .................................................. GW-92
Overheat .......................................... EC-497, EC-1171
P
Park/Neutral position switch ............ EC-489
, EC-1154
Park/neutral position switch (A/T) .................... AT-112
Parking brake control ........................................... PB-4
PCV (positive crankcase ventilation) ... EC-51, EC-711
PGC/V - Wiring diagram .. EC-399, EC-407, EC-1065,
EC-1073
PHASE - Wiring diagram ............................... EC-1039
PHSB1 - Wiring diagram .................................. EC-370
PHSB2 - Wiring diagram .................................. EC-372
Pilot bushing replacement - See Pilot
converter(VQ35DE) ........................................ EM-124
Piston assembly(VK45DE) ............................. EM-259
Piston assembly(VQ35DE) ............................. EM-136
Piston pin inspection(VK45DE) ....................... EM-265
Piston pin inspection(VQ35DE) ...................... EM-141
Piston ring inspection(VK45DE) ..................... EM-266
Piston ring inspection(VQ35DE) ..................... EM-142
Piston to bore clearance(VK45DE) ................. EM-269
Piston to bore clearance(VQ35DE) ................ EM-145
PNP/SW - Wiring diagram . EC-491, EC-1156, AT-113
POS - Wiring diagram ..................... EC-363, EC-1032
POWER - Wiring diagram ................................... PG-4
Power door mirror .............................................. BL-21
Power seat ......................................................... SE-92
Power steering fluid level ........................ PS-8, MA-37
Power steering gear ........................................... PS-17
Power steering hydraulic pressure .................... PS-29
Power steering oil pump .................................... PS-29
Power steering pressure (PSP) sensor ........... EC-472
Power steering system bleeding .......................... PS-8
Power supply routing .......................................... PG-3
Power window .................................................. GW-15
PRE/SE - Wiring diagram EC-430, EC-436, EC-1096,
EC-1102
Precations for Leak detection dye .................. ATC-16
Precautions (General) ........................................... GI-4
Pressure switch 1 .............................. AT-152, AT-171
Pressure switch 2 ............................................ AT-164
Pressure switch 3 .............................. AT-148, AT-173
Pressure switch 5 .............................. AT-156, AT-175
Pressure switch 6 .............................. AT-160, AT-177
Pressure test (A/T) ............................................. AT-54
Propeller shaft ........................................... PR-4, PR-7
Propeller shaft on vehicle service ............. PR-4, PR-7
Propeller shaft vibration ............................ PR-4, PR-7
PS/SEN - Wiring diagram ............... EC-473, EC-1138
R
R/VIEW - Wiring diagram .................................. DI-119
Radiator(VK45DE) ............................................ CO-41
Radiator(VQ35DE) ............................................ CO-14
Rear bumper ....................................................... EI-17
Rear combination lamp removal and installation ..........
LT-154
Rear door ............................................ BL-148, GW-62
Rear seat ......................................................... SE-105
Rear suspension ............................................... RSU-5
Rear view monitor ............................................. DI-116
Rear window defogger ..................................... GW-67
Refrigerant connection precaution .................... ATC-8
Refrigerant discharging evacuating charging ATC-137
Refrigerant general precaution ......................... ATC-7
Refrigerant lines ............................................ ATC-137
Refrigerant pressure sensor .......... EC-662, EC-1341,
ATC-89
, ATC-154
Refrigeration cycle .......................................... ATC-21
Page 3918 of 4462
PG-66
HARNESS
Revision: 2006 December 2006 FX35/FX45
FTTS EC Fuel Tank Temperature Sensor
FUELB1 EC Fuel Injection System Function (Bank 1)
FUELB2 EC Fuel Injection System Function (Bank 2)
H/AIM LT Headlamp Aiming Control System
H/LAMP LT Headlamp
H/PHON AV Hands Free Telephone
HORN WW Horn
HSEAT SE Heated Seat
I/KEY BL Intelligent Key System
I/MIRR GW Inside Mirror (Auto Anti-Dazzling Mirror)
IATS EC Intake Air Temperature Sensor
ICC ACS Intelligent Cruise Control System
ICC/BS EC ICC Brake Switch
ICC/SW EC ICC Steering Switch
ICCBOF EC ICC Brake Switch
IGNSYS EC Ignition System
ILL LT Illumination
INF/D AV Vehicle Information and Integrated Switch System
INJECT EC Injector
IVCB1 EC Intake Valve Timing Control Solenoid Valve Bank 1
IVCB2 EC Intake Valve Timing Control Solenoid Valve Bank 2
IVCSB1 EC Intake Valve Timing Control Position Sensor Bank 1
IVCSB2 EC Intake Valve Timing Control Position Sensor Bank 2
IVTB1 EC Intake Valve Timing Control System (Bank 1)
IVTB2 EC Intake Valve Timing Control System (Bank 2)
KEYLES BL Remote Keyless Entry System
KS EC Knock Sensor
LDW DI Lane Departure Warning System
M/ANT AV Manual Antenna
MAFS EC Mass Air Flow Sensor
MAIN AT Main Power Supply and Ground Circuit
MAIN EC Main Power Supply and Ground Circuit
MES AV Mobile Entertainment System
METER DI Speedometer, Tachometer, Temp. and Fuel Gauges
MIL/DL EC MIL & Data Link Connectors
MIRROR GW Power Door Mirror
MMSW AT Manual Mode Switch
NATS BL Nissan Anti-Theft System
NAVI AV Navigation System
NONDTC AT Non-Detective Items
O2H2B1 EC Heated Oxygen Sensor 2 Heater Bank 1
O2H2B2 EC Heated Oxygen Sensor 2 Heater Bank 2
O2S2B1 EC Heated Oxygen Sensor 2 Bank 1
O2S2B2 EC Heated Oxygen Sensor 2 Bank 2 Code Section Wiring Diagram Name
Page 4180 of 4462
SE-42
AUTOMATIC DRIVE POSITIONER
Revision: 2006 December 2006 FX35/FX45
Check CAN Communication SystemNIS001V0
1. CHECK SELF-DIAGNOSTIC RESULT
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carry out CAN communication.
1. Connect CONSULT-II, and turn ignition switch ON.
2. Touch “AUTO DRIVE POS.” on “SELECT SYSTEM” screen.
3. Touch “SELF-DIAG RESULTS” on “SELECT DIAG MODE” screen.
4. Check display content in self-diagnostic results.
Displayed U1000?
Yes >> GO TO LAN-3, "Precautions When Using CONSULT-II" .
No >> Inspection END.
Symptom ChartNIS001V1
Symptom Diagnoses / service procedure Refer to
page
Only setting change function cannot be set with display. Interacted display system (without NAVI)
AV- 5 4
Navigation system (with NAVI)AV- 9 3
A part of seat system does not operate
(both automatically and manually). 1. Check sliding motor circuit
SE-43
2. Check reclining motor circuit SE-45
3. Check front lifter motor circuitSE-46
4. Check rear lifter motor circuitSE-47
5. If the above systems are normal, replace the driver
seat control unit SE-15
A part of steering tilt, telescopic and door mirror does not
operate (both automatically and manually). 1. Check tilt motor circuit
SE-50
2. Check telescopic motor circuitSE-49
3. Check driver side mirror motor circuit SE-51
4. Check passenger side mirror motor circuit SE-53
5. If the above systems are normal, replace the
automatic drive positioner control unit SE-15
A part of seat system does not operate
(only automatic operation). 1. Check sliding sensor circuit
SE-55
2. Check reclining sensor circuitSE-56
3. Check front lifting sensor circuitSE-57
4. Check rear lifting sensor circuitSE-58
5. If the above systems are normal, replace the driver
seat control unit SE-15
A part of steering tilt, telescopic system and door mirror
system dose not operate (only automatic operation). 1. Check steering and door mirror sensor power supply
and ground circuit SE-64
2. Check driver side mirror sensor circuit
SE-61
3. Check passenger side mirror sensor circuitSE-62
4. Check tilt sensor circuitSE-60
5. Check telescopic sensor circuitSE-59
6. If all the above systems are normal, replace the
automatic drive positioner control unit SE-15
Page 4290 of 4462
SRS-42
FRONT PASSENGER AIR BAG MODULE
Revision: 2006 December 2006 FX35/FX45
FRONT PASSENGER AIR BAG MODULEPFP:K8515
Removal and InstallationNHS0007N
REMOVAL
CAUTION:
Before servicing SRS, turn ignition switch OFF, disconnect both battery cables and wait at least 3
minutes.
Always work from the side of or under front passenger air bag module.
1. Disconnect front passenger air bag module connector (1).
2. Remove glove box assembly and instrument passenger lower panel. Refer to IP-11, "
Removal and Instal-
lation" .
3. Remove display control unit, if navigation system is equipped.
4. Remove tire pressure warning control unit, if tire pressure warning control system is equipped.
5. Remove the front passenger air bag module fixing bolt and nuts, then remove front passenger air bag module.
CAUTION:
Always place front passenger air bag module with caution
label side facing upward.
Do not insert any foreign objects (screwdriver, etc.) into
front passenger air bag module.
Do not disassemble front passenger air bag module.
Do not use old bolts after removal; replace with new bolts.
PHIA1337E
PHIA0322E
PHIA0325E
