DESCRIPTION ACS-9
[ICC]
C
D E
F
G H
I
J
L
M A
B
ACS
Revision: 2006 December 2006 FX35/FX45
Components DescriptionNKS003EL
CAN CommunicationNKS003EM
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tric control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN-H line, CAN-L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only.
CAN COMMUNICATION UNIT
Refer to LAN-32, "CAN Communication Unit" .
Component Vehicle-to-
vehicle
distance
control mode Conventional
(fixed speed) cruise
control mode Brake assist
(with pre-
view func- tion) Description
ICC unit ××× Operates electric throttle control actuator and brake
booster based on that sensor signals and CAN commu-
nication data, then controls vehicle distance.
ICC sensor ×× Irradiates laser beam, and receives reflected laser
beam to measure distance from preceding vehicle.
ECM ××× Transmits throttle position signal and ICC steering
switch signal to ICC unit through CAN communication.
ABS actuator and electric
unit (control unit) ×××
Transmits wheel speed sensor signal to ICC unit
through CAN communication.
Brake pressure sensor ×× Detects fluid pressure in master cylinder.
Brake booster ×× Adjusts brake fluid pressure, based on command from
ICC unit.
BCM × Transmit front wiper request signal to ICC unit through
CAN communication.
TCM ×× Transmits gear position signal and output shaft revolu-
tion signal to ICC unit through CAN communication.
Unified meter and A/C amp. ××× Receives ICC system display signal, ICC warning lamp
signal and buzzer output signal from ICC unit through
CAN communication.
ICC brake switch, stop
lamp switch ××× Transmit operating signal to ICC unit when touching
brake pedal. ICC unit cancels cruise system at driver's
brake operation.
ICC brake hold relay × Receives stop lamp driving signal from ICC unit, and
turns stop lamp ON.
Parking brake switch ×× The cruise system is cancelled when applied.

AT-1
AUTOMATIC TRANSMISSION
C TRANSMISSION/TRANSAXLE
CONTENTS
D E
F
G H
I
J
K L
M
SECTION AT
A
B
AT
Revision: 2006 December 2006 FX35/FX45
AUTOMATIC TRANSMISSION
INDEX FOR DTC ................................................... ..... 5
Alphabetical Index ............................................... ..... 5
DTC No. Index .................................................... ..... 6
PRECAUTIONS ..................................................... ..... 7
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ............................................................. ..... 7
Precautions for On Board Diagnostic (OBD) System
of A/T and Engine ............................................... ..... 7
Precautions ......................................................... ..... 8
Service Notice or Precautions ............................. ..... 9
PREPARATION ...................................................... ... 10
Special Service Tools .......................................... ... 10
Commercial Service Tools ................................... .... 11
A/T FLUID .............................................................. ... 12
Changing A/T Fluid ............................................. ... 12
Checking A/T Fluid .............................................. ... 13
A/T Fluid Cooler Cleaning ................................... ... 15
A/T CONTROL SYSTEM ....................................... ... 18
Cross-sectional View (2WD Models) ................... ... 18
Cross-sectional View (VQ35DE Models for AWD) ... 19
Cross-sectional View (VK45DE Models for AWD) ... 20
Shift Mechanism .................................................. ... 21
TCM Function ...................................................... ... 32
CAN Communication ........................................... ... 33
Input/Output Signal of TCM ................................. ... 33
Line Pressure Control ......................................... ... 34
Shift Control ........................................................ ... 35
Lock-up Control ................................................... ... 37
Engine Brake Control .......................................... ... 38
Control Valve ....................................................... ... 38
ON BOARD DIAGNOSTIC (OBD) SYSTEM ......... ... 40
Introduction ......................................................... ... 40
OBD-II Function for A/T System .......................... ... 40
One or Two Trip Detection Logic of OBD-II ......... ... 40
OBD-II Diagnostic Trouble Code (DTC) .............. ... 40
Malfunction Indicator Lamp (MIL) ........................ ... 43
TROUBLE DIAGNOSIS ......................................... ... 44
DTC Inspection Priority Chart ............................. ... 44
Fail-safe .............................................................. ... 44 How to Perform Trouble Diagnosis for Quick and
Accurate Repair ................................................... ... 46
A/T Electrical Parts Location ............................... ... 51
Circuit Diagram .................................................... ... 52
Inspections Before Trouble Diagnosis ................. ... 53
Check Before Engine Is Started .......................... ... 57
Check at Idle ........................................................ ... 57
Cruise Test - Part 1 .............................................. ... 58
Cruise Test - Part 2 .............................................. ... 60
Cruise Test - Part 3 .............................................. ... 61
Vehicle Speed at Which Gear Shifting Occurs .... ... 62
Vehicle Speed at Which Lock-up Occurs/Releases ... 63
Symptom Chart .................................................... ... 64
TCM Input/Output Signal Reference Values ........ ... 89
CONSULT-II Function (A/T) ................................. ... 90
Diagnostic Procedure without CONSULT-II ......... .102
DTC U1000 CAN COMMUNICATION LINE ........... .104
Description ........................................................... .104
On Board Diagnosis Logic ................................... .104
Possible Cause .................................................... .104
DTC Confirmation Procedure .............................. .104
Wiring Diagram — AT — CAN ............................. .105
Diagnostic Procedure .......................................... .106
DTC P0615 START SIGNAL CIRCUIT .................. .107
Description ........................................................... .107
CONSULT-II Reference Value ............................. .107
On Board Diagnosis Logic ................................... .107
Possible Cause .................................................... .107
DTC Confirmation Procedure .............................. .107
Wiring Diagram — AT — STSIG ......................... .108
Diagnostic Procedure .......................................... .109
DTC P0700 TCM .................................................... .. 111
Description ........................................................... ..111
On Board Diagnosis Logic ................................... ..111
Possible Cause .................................................... ..111
DTC Confirmation Procedure .............................. ..111
Diagnostic Procedure .......................................... ..111
DTC P0705 PARK/NEUTRAL POSITION SWITCH .112
Description ........................................................... .112
CONSULT-II Reference Value ............................. .112

AT-4Revision: 2006 December 2006 FX35/FX45 A/T Does Not Shift: 5th Gear
→ 4th Gear ........... .219
A/T Does Not Shift: 4th Gear → 3rd Gear ........... .221
A/T Does Not Shift: 3rd Gear → 2nd Gear .......... .223
A/T Does Not Shift: 2nd Gear → 1st Gear ........... .225
Vehicle Does Not Decelerate by Engine Brake ... .227
SHIFT CONTROL SYSTEM ................................... .229
Control Device Removal and Installation ............. .229
Control Rod Removal and Installation ................. .230
Adjustment of A/T Position .................................. .231
Checking of A/T Position ..................................... .231
A/T SHIFT LOCK SYSTEM .................................... .232
Description ........................................................... .232
Shift Lock System Electrical Parts Location ........ .232
Wiring Diagram — AT — SHIFT .......................... .233
Diagnostic Procedure .......................................... .234
KEY INTERLOCK CABLE ..................................... .236
Components ........................................................ .236
Removal and Installation ..................................... .237
ON-VEHICLE SERVICE ......................................... .239
Control Valve with TCM and A/T Fluid Temperature
Sensor 2 .............................................................. .239
Parking Components (2WD Models Only) ........... .251
Rear Oil Seal ....................................................... .258
Revolution Sensor Components (2WD Models
Only) .................................................................... .259
AIR BREATHER HOSE .......................................... .264
Removal and Installation ..................................... .264
TRANSMISSION ASSEMBLY ............................... .266
Removal and Installation (2WD Models) ............. .266
Removal and Installation (AWD Models) ............. .269 OVERHAUL ............................................................
.274
Components ......................................................... .274
Oil Channel .......................................................... .288
Locations of Adjusting Shims, Needle Bearings,
Thrust Washers and Snap Rings ......................... .291
DISASSEMBLY ...................................................... .294
Disassembly ......................................................... .294
REPAIR FOR COMPONENT PARTS ..................... .312
Oil Pump .............................................................. .312
Front Sun Gear, 3rd One-way Clutch ................... .315
Front Carrier, Input Clutch, Rear Internal Gear .... .317
Mid Sun Gear, Rear Sun Gear, High and Low
Reverse Clutch Hub ............................................. .323
High and Low Reverse Clutch ............................. .329
Direct Clutch ........................................................ .332
ASSEMBLY ............................................................ .335
Assembly (1) ........................................................ .335
Adjustment ........................................................... .349
Assembly (2) ........................................................ .352
SERVICE DATA AND SPECIFICATIONS (SDS) ... .359
General Specifications ......................................... .359
Vehicle Speed at Which Gear Shifting Occurs ..... .359
Vehicle Speed at Which Lock-up Occurs/Releases .360
Stall Speed ........................................................... .360
Line Pressure ....................................................... .360
A/T Fluid Temperature Sensor ............................. .360
Turbine Revolution Sensor ................................... .361
Vehicle Speed Sensor A/T (Revolution Sensor) .. .361
Reverse Brake ..................................................... .361
Total End Play ...................................................... .361

AT-8
PRECAUTIONS
Revision: 2006 December 2006 FX35/FX45
Precautions NCS001AP

Before connecting or disconnecting the A/T assembly har-
ness connector, turn ignition switch OFF and disconnect
the battery cable from the negative terminal. Because bat-
tery voltage is applied to TCM even if ignition switch is
turned OFF.

After performing each TROUBLE DIAGNOSIS, perform
“DTC (Diagnostic Trouble Code) Confirmation Procedure”.
If the repair is completed the DTC should not be displayed
in the “DTC Confirmation Procedure”.

Always use the specified brand of ATF. Refer to MA-12, "Fluids and Lubricants" .

Use lint-free paper not cloth rags during work.

After replacing the ATF, dispose of the waste oil using the methods prescribed by law, ordinance, etc.

Before proceeding with disassembly, thoroughly clean the outside of the transmission. It is important to
prevent the internal parts from becoming contaminated by dirt or other foreign matter.

Disassembly should be done in a clean work area.

Use lint-free paper or towels for wiping parts clean. Common shop rags can leave fibers that could inter-
fere with the operation of the transmission.

Place disassembled parts in order for easier and proper assembly.

All parts should be carefully cleansed with a general purpose, non-flammable solvent before inspection or
reassembly.

Gaskets, seals and O-rings should be replaced any time the transmission is disassembled.

It is very important to perform functional tests whenever they are indicated.

The valve body contains precision parts and requires extreme care when parts are removed and serviced.
Place disassembled valve body parts in order for easier and proper assembly. Care will also prevent
springs and small parts from becoming scattered or lost.

Properly installed valves, sleeves, plugs, etc. will slide along bores in valve body under their own weight.

Before assembly, apply a coat of recommended ATF to all parts. Apply petroleum jelly to protect O-rings
and seals, or hold bearings and washers in place during assembly. Do not use grease.

Extreme care should be taken to avoid damage to O-rings, seals and gaskets when assembling.

After overhaul, refill the transmission with new ATF.

When the A/T drain plug is removed, only some of the ATF is drained. Old ATF will remain in torque con-
verter and ATF cooling system.
Always follow the procedures under “Changing A/T Fluid” in the AT section when changing A/T fluid. Refer
to AT- 1 2 , "
Changing A/T Fluid" , AT- 1 3 , "Checking A/T Fluid" .
SEF289H
SEF217U

A/T FLUID AT-15
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2006 December 2006 FX35/FX45
A/T Fluid Cooler CleaningNCS001AV
Whenever an automatic transmission is replaced, the A/T fluid cooler mounted in the radiator must be
inspected and cleaned.
Metal debris and friction material, if present, can become trapped in the A/T fluid cooler. This debris can con-
taminate the newly serviced A/T or, in severe cases, can block or restrict the flow of ATF. In either case, mal-
function of the newly serviced A/T may result.
Debris, if present, may build up as ATF enters the cooler inlet. It will be necessary to back flush the cooler
through the cooler outlet in order to flush out any built up debris.
A/T FLUID COOLER CLEANING PROCEDURE
1. Position an oil pan under the A/T's inlet and outlet cooler hoses.
2. Identify the inlet and outlet A/T fluid cooler hoses.
3. Disconnect the A/T fluid cooler inlet and outlet rubber hoses from the steel cooler tubes or bypass valve.
NOTE:
Replace the cooler hoses if rubber material from the hose
remains on the tube fitting.
4. Allow any ATF that remains in the cooler hoses to drain into the oil pan.
5. Insert the extension adapter hose of a can of Transmission Cooler Cleaner (Nissan P/N 999MP-AM006) into the cooler out-
let hose.
CAUTION:

Wear safety glasses and rubber gloves when spraying
the Transmission Cooler Cleaner.

Spray Transmission Cooler Cleaner only with adequate
ventilation.

Avoid contact with eyes and skin.

Do not breath vapors or spray mist.
6. Hold the hose and can as high as possible and spray Transmis- sion Cooler Cleaner in a continuous stream into the cooler outlet hose until ATF flows out of the cooler
inlet hose for 5 seconds.
7. Insert the tip of an air gun into the end of the cooler outlet hose.
8. Wrap a shop rag around the air gun tip and of the cooler outlet hose.
9. Blow compressed air regulated to 5 to 9 kg/cm
2 (70 to 130 psi)
through the cooler outlet hose for 10 seconds to force out any
remaining ATF.
10. Repeat steps 5 through 9 three additional times.
11. Position an oil pan under the banjo bolts that connect the A/T fluid cooler steel lines to the transmission.
12. Remove the banjo bolts.
13. Flush each steel line from the cooler side back toward the trans- mission by spraying Transmission Cooler Cleaner in a continuous stream for 5 seconds.
14. Blow compressed air regulated to 5 to 9 kg/cm
2 (70 to 130 psi) through each steel line from the cooler
side back toward the transmission for 10 seconds to force out any remaining ATF.
15. Ensure all debris is removed from the steel cooler lines.
16. Ensure all debris is removed from the banjo bolts and fittings.
17. Perform AT- 1 6 , "
A/T FLUID COOLER DIAGNOSIS PROCEDURE" .
SCIA3830E
SCIA3831E
SCIA3832E

AT-16
A/T FLUID
Revision: 2006 December 2006 FX35/FX45
A/T FLUID COOLER DIAGNOSIS PROCEDURE
NOTE:
Insufficient cleaning of the cooler inlet hose exterior may lead to inaccurate debris identification.
1. Position an oil pan under the automatic transmission's inlet and outlet cooler hoses.
2. Clean the exterior and tip of the cooler inlet hose.
3. Insert the extension adapter hose of a can of Transmission Cooler Cleaner (Nissan P/N 999MP-AM006) into the cooler out-
let hose.
CAUTION:

Wear safety glasses and rubber gloves when spraying
the Transmission Cooler Cleaner.

Spray Transmission Cooler Cleaner only with adequate
ventilation.

Avoid contact with eyes and skin.

Do not breath vapors or spray mist.
4. Hold the hose and can as high as possible and spray Transmis- sion Cooler Cleaner in a continuous stream into the cooler outlet hose until ATF flows out of the cooler
inlet hose for 5 seconds.
5. Tie a common white, basket-type coffee filter to the end of the cooler inlet hose.
6. Insert the tip of an air gun into the end of the cooler outlet hose.
7. Wrap a shop rag around the air gun tip and end of cooler outlet hose.
8. Blow compressed air regulated to 5 to 9 kg/cm
2 (70 to 130 psi)
through the cooler outlet hose to force any remaining ATF into
the coffee filter.
9. Remove the coffee filter from the end of the cooler inlet hose.
10. Perform AT- 1 7 , "
A/T FLUID COOLER INSPECTION PROCE-
DURE" .
SCIA3831E
SCIA3833E
SCIA3834E

AT-32
A/T CONTROL SYSTEM
Revision: 2006 December 2006 FX35/FX45
TCM FunctionNCS001AZ
The function of the TCM is to:

Receive input signals sent from various switches and sensors.

Determine required line pressure, shifting point, lock-up operation, and engine brake operation.

Send required output signals to the respective solenoids.
CONTROL SYSTEM OUTLINE
The automatic transmission senses vehicle operating conditions through various sensors or signals. It always
controls the optimum shift position and reduces shifting and lock-up shocks.
CONTROL SYSTEM DIAGRAM
SENSORS (or SIGNALS)

TCM

ACTUATORS
PNP switch
Accelerator pedal position signal
Closed throttle position signal
Wide open throttle position signal
Engine speed signal
A/T fluid temperature sensor
Revolution sensor
Vehicle speed signal
Manual mode switch signal
Stop lamp switch signal
Turbine revolution sensor
ATF pressure switch Shift control
Line pressure control
Lock-up control
Engine brake control
Timing control
Fail-safe control
Self-diagnosis
CONSULT-II communication line
Duet-EA control
CAN system Input clutch solenoid valve
Direct clutch solenoid valve
Front brake solenoid valve
High and low reverse clutch
solenoid valve
Low coast brake solenoid valve
Torque converter clutch solenoid
valve
Line pressure solenoid valve
A/T CHECK indicator lamp
Starter relay
Back-up lamp relay
SCIA5325E

A/T CONTROL SYSTEM AT-33
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2006 December 2006 FX35/FX45
CAN CommunicationNCS001B0
SYSTEM DESCRIPTION
CAN (Controller Area Network) is a serial communication line for real time application. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Many elec-
tronic control units are equipped onto a vehicle, and each control unit shares information and links with other
control units during operation (not independent). In CAN communication, control units are connected with 2
communication lines (CAN-H line, CAN-L line) allowing a high rate of information transmission with less wiring.
Each control unit transmits/receives data but selectively reads required data only. For details, refer to LAN-32,
"CAN Communication Unit" .
Input/Output Signal of TCMNCS001B1
*1: Spare for vehicle speed sensor·A/T (revolution sensor)
*2: Spare for accelerator pedal position signal
*3: If these input and output signals are different, the TCM triggers the fail-safe function.
*4: Used as a condition for starting self-diagnostics; if self-diagnostics are not started, it is judged that there is some kin d of error.
*5: Input by CAN communications
*6: Output by CAN communications Control item
Line
pressure control Vehicle
speed
control Shift
control Lock-up
control Engine
brake
control Fail-safe
function (*3) Self-diag-
nostics
function
Input Accelerator pedal position signal
(*5)XXXXXXX
Vehicle speed sensor A/T
(revolution sensor) XXXXXXX
Vehicle speed sensor MTR
(*1) (*5)X
Closed throttle position signal
(*5)X (*2) X X X X (*4)
Wide open throttle position signal
(*5)XX (*4)
Turbine revolution sensor 1 X X X X X
Turbine revolution sensor 2
(for 4th speed only) X XXXX
Engine speed signals
(*5)XXXXXXX
Stop lamp switch signal
(*5)XXX X (*4)
A/T fluid temperature sensors 1, 2XXXX XX
ASCD or
ICC Operation signal
(*5)XXX
Overdrive cancel
signal
(*5)X
Out-
put Direct clutch solenoid (ATF pres-
sure switch 5) XX XX
Input clutch solenoid (ATF pressure
switch 3) XX XX
High and low reverse clutch sole-
noid (ATF pressure switch 6) XX XX
Front brake solenoid (ATF pressure
switch 1) XX XX
Low coast brake solenoid (ATF
pressure switch 2) XX XXX
Line pressure solenoid XXXXXXX
TCC solenoid X X X
Self-diagnostics table
(*6)X
Sta rter rela y XX

AT-194
TROUBLE DIAGNOSIS FOR SYMPTOMS
Revision: 2006 December 2006 FX35/FX45
4. CHECK A/T FLUID LEVEL
Check the A/T fluid level. Refer to AT- 1 3 , "
Checking A/T Fluid" .
OK or NG
OK >> GO TO 5.
NG >> Refill ATF.
5. CHECK LINE PRESSURE
Check line pressure at idle with selector lever in “D” position. Refer
to AT- 5 4 , "
LINE PRESSURE TEST" .
OK or NG
OK >> GO TO 8.
NG-1 >> Line pressure high: GO TO 6.
NG-2 >> Line pressure low: GO TO 7.
6. DETECT MALFUNCTIONING ITEM
1. Check control valve with TCM. Refer to AT- 2 3 9 , "
Control Valve with TCM and A/T Fluid Temperature Sen-
sor 2" .
2. Disassemble A/T. Refer to AT- 2 9 4 , "
DISASSEMBLY" .
3. Check the following.
–Oil pump assembly. Refer to AT- 3 1 2 , "Oil Pump" .
OK or NG
OK >> GO TO 8.
NG >> Repair or replace damaged parts.
7. DETECT MALFUNCTIONING ITEM
1. Check control valve with TCM. Refer to AT- 2 3 9 , "
Control Valve with TCM and A/T Fluid Temperature Sen-
sor 2" .
2. Disassemble A/T. Refer to AT- 2 9 4 , "
DISASSEMBLY" .
3. Check the following.
–Oil pump assembly. Refer to AT- 3 1 2 , "Oil Pump" .
–Power train system. Refer to AT- 2 9 4 , "DISASSEMBLY" .
–Transmission case. Refer to AT- 2 9 4 , "DISASSEMBLY" .
OK or NG
OK >> GO TO 8.
NG >> Repair or replace damaged parts.
SAT638A
SAT494G

TROUBLE DIAGNOSIS FOR SYMPTOMS AT-197
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2006 December 2006 FX35/FX45
5. DETECT MALFUNCTIONING ITEM
1. Disassemble A/T. Refer to AT- 2 9 4 , "
DISASSEMBLY" .
2. Check the following.
–Reverse brake. Refer to AT- 2 9 4 , "DISASSEMBLY" .
OK or NG
OK >> GO TO 9.
NG >> Repair or replace damaged parts.
6. CHECK LINE PRESSURE
Check the line pressure with the engine idling. Refer to AT- 5 4 , "
LINE
PRESSURE TEST" .
OK or NG
OK >> GO TO 9.
NG-1 >> Line pressure high: GO TO 7.
NG-2 >> Line pressure low: GO TO 8.
7. DETECT MALFUNCTIONING ITEM
1. Check control valve with TCM. Refer to AT- 2 3 9 , "
Control Valve with TCM and A/T Fluid Temperature Sen-
sor 2" .
2. Disassemble A/T. Refer to AT- 2 9 4 , "
DISASSEMBLY" .
3. Check the following.
–Oil pump assembly. Refer to AT- 3 1 2 , "Oil Pump" .
OK or NG
OK >> GO TO 9.
NG >> Repair or replace damaged parts.
8. DETECT MALFUNCTIONING ITEM
1. Check control valve with TCM. Refer to AT- 2 3 9 , "
Control Valve with TCM and A/T Fluid Temperature Sen-
sor 2" .
2. Disassemble A/T. Refer to AT- 2 9 4 , "
DISASSEMBLY" .
3. Check the following.
–Oil pump assembly. Refer to AT- 3 1 2 , "Oil Pump" .
–Power train system. Refer to AT- 2 9 4 , "DISASSEMBLY" .
–Transmission case. Refer to AT- 2 9 4 , "DISASSEMBLY" .
OK or NG
OK >> GO TO 9.
NG >> Repair or replace damaged parts.
SAT494G
