OBD port INFINITI FX35 2007 Service Manual

AT-46
TROUBLE DIAGNOSIS
Revision: 2006 July 2007 FX35/FX45
How to Perform Trouble Diagnosis for Quick and Accurate RepairNCS001BE
INTRODUCTION
The TCM receives a signal from the vehicle speed sensor, accelerator pedal position sensor (throttle position
sensor) or PNP switch and provides shift control or lock-up control via A/T solenoid valves.
The TCM also communicates with the ECM by means of a signal
sent from sensing elements used with the OBD-related parts of the
A/T system for malfunction-diagnostic purposes. The TCM is capa-
ble of diagnosing malfunctioning parts while the ECM can store mal-
functions in its memory.
Input and output signals must always be correct and stable in the
operation of the A/T system. The A/T system must be in good oper-
ating condition and be free of valve seizure, solenoid valve malfunc-
tion, etc.
It is much more difficult to diagnose a error that occurs intermittently
rather than continuously. Most intermittent errors are caused by poor
electric connections or improper wiring. In this case, careful check-
ing of suspected circuits may help prevent the replacement of good
parts.
A visual check only may not find the cause of the errors. A road test
with CONSULT-II (or GST) or a circuit tester connected should be
performed. Follow the AT- 4 6 , "
WORK FLOW" .
Before undertaking actual checks, take a few minutes to talk with a
customer who approaches with a driveability complaint. The cus-
tomer can supply good information about such errors, especially
intermittent ones. Find out what symptoms are present and under
what conditions they occur. A “DIAGNOSTIC WORKSHEET” as
shown on the example (Refer to AT- 4 8
) should be used.
Start your diagnosis by looking for “conventional” errors first. This will
help troubleshoot driveability errors on an electronically controlled
engine vehicle.
Also check related Service bulletins.
WORK FLOW
A good understanding of the malfunction conditions can make troubleshooting faster and more accurate.
In general, each customer feels differently about a malfunction. It is important to fully understand the symp-
toms or conditions for a customer complaint.
Make good use of the two sheets provided, “Information From Customer” (Refer to AT- 4 7
) and “DIAGNOSTIC
WORKSHEET” (Refer to AT- 4 8
), to perform the best troubleshooting possible.
SAT631IB
SAT632I
SEF234G

DTC P0744 A/T TCC S/V FUNCTION (LOCK-UP) AT-127
D E
F
G H
I
J
K L
M A
B
AT
Revision: 2006 July 2007 FX35/FX45
DTC P0744 A/T TCC S/V FUNCTION (LOCK-UP)PFP:31940
DescriptionNCS001D1
This malfunction is detected when the A/T does not shift into 5th gear position or the torque converter clutch
does not lock-up as instructed by the TCM. This is not only caused by electrical malfunction (circuits open or
shorted) but also by mechanical malfunction such as control valve sticking, improper solenoid valve operation,
etc.
CONSULT-II Reference ValueNCS001D2
On Board Diagnosis LogicNCS001D3

This is an OBD-II self-diagnostic item.

Diagnostic trouble code “P0744 A/T TCC S/V FNCTN” with CONSULT-II or 3rd judgement flicker without
CONSULT-II is detected under the following conditions.
–When A/T cannot perform lock-up even if electrical circuit is good.
–When TCM detects as irregular by comparing difference value with slip rotation.
Possible CauseNCS001D4

Harness or connectors
(Solenoid circuit is open or shorted.)

Torque converter clutch solenoid valve

Hydraulic control circuit
DTC Confirmation ProcedureNCS001D5
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC Confirmation Procedure” has been previously performed, always turn ignition switch OFF and
wait at least 10 seconds before performing the next test.
After the repair, perform the following procedure to confirm the malfunction is eliminated.
WITH CONSULT-II
1. Start engine and Select “TCC SOL FNCTN CHECK” of “DTC WORK SUPPORT” mode for “A/T” with CONSULT-II and touch
“START”.
2. Accelerate vehicle to more than 80 km/h (50 MPH) and maintain the following condition continuously until “TESTING” has turned
to “COMPLETE”. (It will take approximately 30 seconds after
“TESTING” shows.)
ACCELE POSI: More than 1.0/8 (at all times during step 4)
TCC SOLENOID: 0.4 - 0.6 A
SLCT LVR POSI: “D” position
[Reference speed: Constant speed of more than 80 km/h (50
MPH)]
–Make sure “GEAR” shows “5”.
–For shift schedule, refer to AT- 3 6 0 , "Vehicle Speed at Which Lock-up Occurs/Releases" .
–If “TESTING” does not appear on CONSULT-II for a long time, select “SELF-DIAG RESULTS”. In
case a 1st trip DTC other than P0744 is shown, refer to applicable “TROUBLE DIAGNOSIS FOR
DTC”.
3. Make sure that “OK” is displayed. (If “NG” is displayed, refer to AT- 1 2 8 , "
Diagnostic Procedure" .)
Refer to shift schedule, AT- 3 6 0 , "
Vehicle Speed at Which Lock-up Occurs/Releases" .
WITH GST
Follow the procedure “WITH CONSULT-II”.
Item name Condition Display value (Approx.)
TCC SOLENOID Slip lock-up is active 0.2 - 0.4 A
Lock-up is active 0.4 - 0.6 A
BCIA0031E

EC-1
ENGINE CONTROL SYSTEM
B ENGINE
CONTENTS
C
D E
F
G H
I
J
K L
M
SECTION
A
EC
Revision: 2006 July 2007 FX35/FX45
ENGINE CONTROL SYSTEM
VQ35DE
INDEX FOR DTC ...................................................... 15
DTC No. Index .................................................... ... 15
Alphabetical Index ............................................... ... 19
PRECAUTIONS ..................................................... ... 23
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ............................................................. ... 23
Precautions for Procedures without Cowl Top Cover ... 23
On Board Diagnostic (OBD) System of Engine and
A/T ....................................................................... ... 23
Precaution ........................................................... ... 24
PREPARATION ...................................................... ... 27
Special Service Tools .......................................... ... 27
Commercial Service Tools ................................... ... 28
ENGINE CONTROL SYSTEM ............................... ... 29
System Diagram .................................................. ... 29
Multiport Fuel Injection (MFI) System ................. ... 30
Electronic Ignition (EI) System ............................ ... 32
Fuel Cut Control (at No Load and High Engine
Speed) ................................................................. ... 33
AIR CONDITIONING CUT CONTROL .................. ... 34
Input/Output Signal Chart .................................... ... 34
System Description ............................................. ... 34
AUTOMATIC SPEED CONTROL DEVICE (ASCD) ... 35
System Description ............................................. ... 35
Component Description ....................................... ... 36
CAN COMMUNICATION ....................................... ... 37
System Description ............................................. ... 37
EVAPORATIVE EMISSION SYSTEM .................... ... 38
Description .......................................................... ... 38
Component Inspection ........................................ ... 41
Removal and Installation ..................................... ... 42
How to Detect Fuel Vapor Leakage .................... ... 42
ON BOARD REFUELING VAPOR RECOVERY
(ORVR) ................................................................... ... 45
System Description ............................................. ... 45
Diagnostic Procedure .......................................... ... 46
Component Inspection ........................................ ... 48 POSITIVE CRANKCASE VENTILATION ..............
... 50
Description ........................................................... ... 50
Component Inspection ......................................... ... 50
IVIS (INFINITI VEHICLE IMMOBILIZER SYSTEM-
NATS) ..................................................................... ... 52
Description ........................................................... ... 52
ON BOARD DIAGNOSTIC (OBD) SYSTEM ......... ... 53
Introduction .......................................................... ... 53
Two Trip Detection Logic ..................................... ... 53
Emission-Related Diagnostic Information ............ ... 54
Malfunction Indicator Lamp (MIL) ........................ ... 67
OBD System Operation Chart ............................. ... 71
BASIC SERVICE PROCEDURE ............................ ... 76
Basic Inspection .................................................. ... 76
Idle Speed and Ignition Timing Check ................. ... 81
Procedure After Replacing ECM ......................... ... 82
VIN Registration .................................................. ... 82
Accelerator Pedal Released Position Learning ... ... 83
Throttle Valve Closed Position Learning .............. ... 83
Idle Air Volume Learning ..................................... ... 83
Fuel Pressure Check ........................................... ... 85
TROUBLE DIAGNOSIS ......................................... ... 87
Trouble Diagnosis Introduction ............................ ... 87
DTC Inspection Priority Chart .............................. ... 93
Fail-Safe Chart .................................................... ... 95
Symptom Matrix Chart ......................................... ... 96
Engine Control Component Parts Location ......... .100
Vacuum Hose Drawing ........................................ .106
Circuit Diagram .................................................... .107
ECM Harness Connector Terminal Layout .......... .109
ECM Terminals and Reference Value .................. .109
CONSULT-II Function (ENGINE) ......................... .118
Generic Scan Tool (GST) Function ...................... .129
CONSULT-II Reference Value in Data Monitor .... .132
Major Sensor Reference Graph in Data Monitor
Mode .................................................................... .134
TROUBLE DIAGNOSIS - SPECIFICATION VALUE .137
Description ........................................................... .137
Testing Condition ................................................. .137

EC-8Revision: 2006 July 2007 FX35/FX45
Precautions for Procedures without Cowl Top Cover
.685
On Board Diagnostic (OBD) System of Engine and
A/T ....................................................................... .685
Precaution ........................................................... .686
PREPARATION ...................................................... .689
Special Service Tools .......................................... .689
Commercial Service Tools ................................... .690
ENGINE CONTROL SYSTEM ............................... .691
System Diagram .................................................. .691
Multiport Fuel Injection (MFI) System .................. .692
Electronic Ignition (EI) System ............................ .694
Fuel Cut Control (at No Load and High Engine
Speed) ................................................................. .695
AIR CONDITIONING CUT CONTROL ................... .696
Input/Output Signal Chart .................................... .696
System Description .............................................. .696
AUTOMATIC SPEED CONTROL DEVICE (ASCD) .697
System Description .............................................. .697
Component Description ....................................... .698
CAN COMMUNICATION ........................................ .699
System Description .............................................. .699
EVAPORATIVE EMISSION SYSTEM .................... .700
Description ........................................................... .700
Component Inspection ......................................... .703
Removal and Installation ..................................... .704
How to Detect Fuel Vapor Leakage ..................... .704
ON BOARD REFUELING VAPOR RECOVERY
(ORVR) ................................................................... .707
System Description .............................................. .707
Diagnostic Procedure .......................................... .708
Component Inspection ......................................... .710
POSITIVE CRANKCASE VENTILATION .............. .712
Description ........................................................... .712
Component Inspection ......................................... .712
IVIS (INFINITI VEHICLE IMMOBILIZER SYSTEM-
NATS) ..................................................................... .714
Description ........................................................... .714
ON BOARD DIAGNOSTIC (OBD) SYSTEM ......... .715
Introduction .......................................................... .715
Two Trip Detection Logic ..................................... .715
Emission-related Diagnostic Information ............. .716
Malfunction Indicator Lamp (MIL) ........................ .730
OBD System Operation Chart ............................. .732
BASIC SERVICE PROCEDURE ............................ .738
Basic Inspection .................................................. .738
Idle Speed and Ignition Timing Check ................. .743
Procedure After Replacing ECM ......................... .744
VIN Registration .................................................. .744
Accelerator Pedal Released Position Learning ... .745
Throttle Valve Closed Position Learning .............. .745
Idle Air Volume Learning ..................................... .745
Fuel Pressure Check ........................................... .747
TROUBLE DIAGNOSIS ......................................... .749
Trouble Diagnosis Introduction ............................ .749
DTC Inspection Priority Chart .............................. .755
Fail-Safe Chart .................................................... .757
Symptom Matrix Chart ......................................... .758
Engine Control Component Parts Location ......... .762
Vacuum Hose Drawing ........................................ .769 Circuit Diagram ....................................................
.770
ECM Harness Connector Terminal Layout ........... .772
ECM Terminals and Reference Value .................. .772
CONSULT-II Function (ENGINE) ......................... .781
Generic Scan Tool (GST) Function ...................... .793
CONSULT-II Reference Value in Data Monitor .... .796
Major Sensor Reference Graph in Data Monitor
Mode .................................................................... .800
TROUBLE DIAGNOSIS - SPECIFICATION VALUE .802
Description ........................................................... .802
Testing Condition ................................................. .802
Inspection Procedure ........................................... .802
Diagnostic Procedure ........................................... .803
TROUBLE DIAGNOSIS FOR INTERMITTENT INCI-
DENT ...................................................................... .812
Description ........................................................... .812
Diagnostic Procedure ........................................... .812
POWER SUPPLY AND GROUND CIRCUIT .......... .813
Wiring Diagram .................................................... .813
Diagnostic Procedure ........................................... .814
Ground Inspection ................................................ .819
DTC U1000, U1001 CAN COMMUNICATION LINE .820
Description ........................................................... .820
On Board Diagnosis Logic ................................... .820
DTC Confirmation Procedure ............................... .820
Wiring Diagram .................................................... .821
Diagnostic Procedure ........................................... .822
DTC U1010 CAN COMMUNICATION .................... .823
Description ........................................................... .823
On Board Diagnosis Logic ................................... .823
DTC Confirmation Procedure ............................... .823
Diagnostic Procedure ........................................... .824
DTC P0011, P0021 IVT CONTROL ........................ .825
Description ........................................................... .825
CONSULT-II Reference Value in Data Monitor Mode .826
On Board Diagnosis Logic ................................... .826
DTC Confirmation Procedure ............................... .827
Wiring Diagram .................................................... .828
Diagnostic Procedure ........................................... .831
Component Inspection ......................................... .835
Removal and Installation ...................................... .836
DTC P0031, P0032, P0051, P0052 A/F SENSOR 1
HEATER .................................................................. .837
Description ........................................................... .837
CONSULT-II Reference Value in Data Monitor Mode .837
On Board Diagnosis Logic ................................... .837
DTC Confirmation Procedure ............................... .837
Wiring Diagram .................................................... .838
Diagnostic Procedure ........................................... .841
Component Inspection ......................................... .843
Removal and Installation ...................................... .843
DTC P0037, P0038, P0057, P0058 HO2S2 HEATER .844
Description ........................................................... .844
CONSULT-II Reference Value in Data Monitor Mode .844
On Board Diagnosis Logic ................................... .844
DTC Confirmation Procedure ............................... .845

EC-28
[VQ35DE]
PREPARATION
Revision: 2006 July 2007 FX35/FX45
Commercial Service ToolsNBS003L0
Tool name
(Kent-Moore No.) Description
Leak detector
i.e.: (J-41416) Locating EVAP leak
EVAP service port
adapter
i.e.: (J-41413-OBD) Applying positive pressure through EVAP service
port
Fuel filler cap adapter
i.e.: (MLR-8382) Checking fuel tank vacuum relief valve opening
pressure
Socket wrench Removing and installing engine coolant temperature sensor
Oxygen sensor thread
cleaner
i.e.: (J-43897-18)
(J-43897-12) Reconditioning the exhaust system threads
before installing a new oxygen sensor. Use with
anti-seize lubricant shown below.
a: 18 mm diameter with pitch 1.5 mm for
Zirconia Oxygen Sensor
b: 12 mm diameter with pitch 1.25 mm for
Titania Oxygen Sensor
Anti-seize lubricant
i.e.: (Permatex
TM
133AR or equivalent
meeting MIL
specification MIL-A-
907) Lubricating oxygen sensor thread cleaning tool
when reconditioning exhaust system threads.
S-NT703
S-NT704
S-NT815
S-NT705
AEM488
S-NT779

ON BOARD DIAGNOSTIC (OBD) SYSTEM EC-59
[VQ35DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2006 July 2007 FX35/FX45
FREEZE FRAME DATA AND 1ST TRIP FREEZE FRAME DATA
The ECM records the driving conditions such as fuel system status, calculated load value, engine coolant tem-
perature, short term fuel trim, long term fuel trim, engine speed, vehicle speed, absolute throttle position, base
fuel schedule and intake air temperature at the moment a malfunction is detected.
Data which are stored in the ECM memory, along with the 1st trip DTC, are called 1st trip freeze frame data.
The data, stored together with the DTC data, are called freeze frame data and displayed on CONSULT-II or
GST. The 1st trip freeze frame data can only be displayed on the CONSULT-II screen, not on the GST. For
details, see EC-121, "
Freeze Frame Data and 1st Trip Freeze Frame Data" .
Only one set of freeze frame data (either 1st trip freeze frame data or freeze frame data) can be stored in the
ECM. 1st trip freeze frame data is stored in the ECM memory along with the 1st trip DTC. There is no priority
for 1st trip freeze frame data and it is updated each time a different 1st trip DTC is detected. However, once
freeze frame data (2nd trip detection/MIL on) is stored in the ECM memory, 1st trip freeze frame data is no
longer stored. Remember, only one set of freeze frame data can be stored in the ECM. The ECM has the fol-
lowing priorities to update the data.
For example, the EGR malfunction (Priority: 2) was detected and the freeze frame data was stored in the 2nd
trip. After that when the misfire (Priority: 1) is detected in another trip, the freeze frame data will be updated
from the EGR malfunction to the misfire. The 1st trip freeze frame data is updated each time a different mal-
function is detected. There is no priority for 1st trip freeze frame data. However, once freeze frame data is
stored in the ECM memory, 1st trip freeze data is no longer stored (because only one freeze frame data or 1st
trip freeze frame data can be stored in the ECM). If freeze frame data is stored in the ECM memory and freeze
frame data with the same priority occurs later, the first (original) freeze frame data remains unchanged in the
ECM memory.
Both 1st trip freeze frame data and freeze frame data (along with the DTCs) are cleared when the ECM mem-
ory is erased. Procedures for clearing the ECM memory are described in EC-66, "
HOW TO ERASE EMIS-
SION-RELATED DIAGNOSTIC INFORMATION" .
SYSTEM READINESS TEST (SRT) CODE
System Readiness Test (SRT) code is specified in Service $01 of SAE J1979.
As part of an enhanced emissions test for Inspection & Maintenance (I/M), certain states require the status of
SRT be used to indicate whether the ECM has completed self-diagnosis of major emission systems and com-
ponents. Completion must be verified in order for the emissions inspection to proceed.
If a vehicle is rejected for a State emissions inspection due to one or more SRT items indicating “INCMP”, use
the information in this Service Manual to set the SRT to “CMPLT”.
In most cases the ECM will automatically complete its self-diagnosis cycle during normal usage, and the SRT
status will indicate “CMPLT” for each application system. Once set as “CMPLT”, the SRT status remains
“CMPLT” until the self-diagnosis memory is erased.
Occasionally, certain portions of the self-diagnostic test may not be completed as a result of the customer's
normal driving pattern; the SRT will indicate “INCMP” for these items.
NOTE:
The SRT will also indicate “INCMP” if the self-diagnosis memory is erased for any reason or if the ECM mem-
ory power supply is interrupted for several hours.
If, during the state emissions inspection, the SRT indicates “CMPLT” for all test items, the inspector will con-
tinue with the emissions test. However, if the SRT indicates “INCMP” for one or more of the SRT items the
vehicle is returned to the customer untested.
NOTE:
If MIL is ON during the state emissions inspection, the vehicle is also returned to the customer untested even
though the SRT indicates “CMPLT” for all test items. Therefore, it is important to check SRT (“CMPLT”) and
DTC (No DTCs) before the inspection.
SRT Item
The table below shows required self-diagnostic items to set the SRT to “CMPLT”.
Priority Items
1 Freeze frame data Misfire — DTC: P0300 - P0306
Fuel Injection System Function — DTC: P0171, P0172, P0174, P0175
2 Except the above items (Includes A/T related items)
3 1st trip freeze frame data

EC-690
[VK45DE]
PREPARATION
Revision: 2006 July 2007 FX35/FX45
Commercial Service ToolsNBS004JN
Tool name
(Kent-Moore No.) Description
Leak detector
i.e.: (J-41416) Locating the EVAP leak
EVAP service port
adapter
i.e.: (J-41413-OBD) Applying positive pressure through EVAP service
port
Fuel filler cap adapter
i.e.: (MLR-8382) Checking fuel tank vacuum relief valve opening
pressure
Socket wrench Removing and installing engine coolant temperature sensor
Oxygen sensor thread
cleaner
i.e.: (J-43897-18)
(J-43897-12) Reconditioning the exhaust system threads
before installing a new oxygen sensor. Use with
anti-seize lubricant shown below.
a: J-43897-18 18 mm diameter with pitch 1.5
mm for Zirconia Oxygen Sensor
b: J-43897-12 12 mm diameter with pitch 1.25
mm for Titania Oxygen Sensor
Anti-seize lubricant
i.e.: (Permatex
TM
133AR or equivalent
meeting MIL
specification MIL-A-
907) Lubricating oxygen sensor thread cleaning tool
when reconditioning exhaust system threads.
S-NT703
S-NT704
S-NT815
S-NT705
AEM488
S-NT779

ON BOARD DIAGNOSTIC (OBD) SYSTEM EC-721
[VK45DE]
C
D E
F
G H
I
J
K L
M A
EC
Revision: 2006 July 2007 FX35/FX45
FREEZE FRAME DATA AND 1ST TRIP FREEZE FRAME DATA
The ECM records the driving conditions such as fuel system status, calculated load value, engine coolant tem-
perature, short term fuel trim, long term fuel trim, engine speed, vehicle speed, absolute throttle position, base
fuel schedule and intake air temperature at the moment a malfunction is detected.
Data which are stored in the ECM memory, along with the 1st trip DTC, are called 1st trip freeze frame data.
The data, stored together with the DTC data, are called freeze frame data and displayed on CONSULT-II or
GST. The 1st trip freeze frame data can only be displayed on the CONSULT-II screen, not on the GST. For
details, see EC-784, "
Freeze Frame Data and 1st Trip Freeze Frame Data" .
Only one set of freeze frame data (either 1st trip freeze frame data or freeze frame data) can be stored in the
ECM. 1st trip freeze frame data is stored in the ECM memory along with the 1st trip DTC. There is no priority
for 1st trip freeze frame data and it is updated each time a different 1st trip DTC is detected. However, once
freeze frame data (2nd trip detection/MIL on) is stored in the ECM memory, 1st trip freeze frame data is no
longer stored. Remember, only one set of freeze frame data can be stored in the ECM. The ECM has the fol-
lowing priorities to update the data.
For example, the EGR malfunction (Priority: 2) was detected and the freeze frame data was stored in the 2nd
trip. After that when the misfire (Priority: 1) is detected in another trip, the freeze frame data will be updated
from the EGR malfunction to the misfire. The 1st trip freeze frame data is updated each time a different mal-
function is detected. There is no priority for 1st trip freeze frame data. However, once freeze frame data is
stored in the ECM memory, 1st trip freeze data is no longer stored (because only one freeze frame data or 1st
trip freeze frame data can be stored in the ECM). If freeze frame data is stored in the ECM memory and freeze
frame data with the same priority occurs later, the first (original) freeze frame data remains unchanged in the
ECM memory.
Both 1st trip freeze frame data and freeze frame data (along with the DTCs) are cleared when the ECM mem-
ory is erased. Procedures for clearing the ECM memory are described in EC-728, "
HOW TO ERASE EMIS-
SION-RELATED DIAGNOSTIC INFORMATION" .
SYSTEM READINESS TEST (SRT) CODE
System Readiness Test (SRT) code is specified in Service $01 of SAE J1979.
As part of an enhanced emissions test for Inspection & Maintenance (I/M), certain states require the status of
SRT be used to indicate whether the ECM has completed self-diagnosis of major emission systems and com-
ponents. Completion must be verified in order for the emissions inspection to proceed.
If a vehicle is rejected for a State emissions inspection due to one or more SRT items indicating “INCMP”, use
the information in this Service Manual to set the SRT to “CMPLT”.
In most cases the ECM will automatically complete its self-diagnosis cycle during normal usage, and the SRT
status will indicate “CMPLT” for each application system. Once set as “CMPLT”, the SRT status remains
“CMPLT” until the self-diagnosis memory is erased.
Occasionally, certain portions of the self-diagnostic test may not be completed as a result of the customer's
normal driving pattern; the SRT will indicate “INCMP” for these items.
NOTE:
The SRT will also indicate “INCMP” if the self-diagnosis memory is erased for any reason or if the ECM mem-
ory power supply is interrupted for several hours.
If, during the state emissions inspection, the SRT indicates “CMPLT” for all test items, the inspector will con-
tinue with the emissions test. However, if the SRT indicates “INCMP” for one or more of the SRT items the
vehicle is returned to the customer untested.
NOTE:
If MIL is ON during the state emissions inspection, the vehicle is also returned to the customer untested even
though the SRT indicates “CMPLT” for all test items. Therefore, it is important to check SRT (“CMPLT”) and
DTC (No DTCs) before the inspection.
SRT Item
The table below shows required self-diagnostic items to set the SRT to “CMPLT”.
Priority Items
1 Freeze frame data Misfire — DTC: P0300 - P0308
Fuel Injection System Function — DTC: P0171, P0172, P0174, P0175
2 Except the above items (Includes A/T related items)
3 1st trip freeze frame data

GI-54
TERMINOLOGY
Revision: 2006 July 2007 FX35/FX45
Nonvolatile random access memory NVRAM ***
On board diagnostic system OBD system Self-diagnosis
Open loop OL Open loop
Oxidation catalyst OC Catalyst
Oxidation catalytic converter system OC system ***
Oxygen sensor O2S Exhaust gas sensor
Park position switch *** Park switch
Park/neutral position switch PNP switch Park/neutral switch
Inhibitor switch
Neutral position switch
Periodic trap oxidizer system PTOX system ***
Positive crankcase ventilation PCV Positive crankcase ventilation
Positive crankcase ventilation valve PCV valve PCV valve
Powertrain control module PCM ***
Programmable read only memory PROM ***
Pulsed secondary air injection control sole-
noid valve PAIRC solenoid valve AIV control solenoid valve
Pulsed secondary air injection system PAIR system Air induction valve (AIV) control
Pulsed secondary air injection valve PAIR valve Air induction valve
Random access memory RAM ***
Read only memory ROM ***
Scan tool ST ***
Secondary air injection pump AIR pump ***
Secondary air injection system AIR system ***
Sequential multiport fuel injection system SFI system Sequential fuel injection
Service reminder indicator SRI ***
Simultaneous multiport fuel injection sys-
tem *** Simultaneous fuel injection
Smoke puff limiter system SPL system ***
Supercharger SC ***
Supercharger bypass SCB ***
System readiness test SRT ***
Thermal vacuum valve TVV Thermal vacuum valve
Three way catalyst TWC Catalyst
Three way catalytic converter system TWC system ***
Three way + oxidation catalyst TWC + OC Catalyst
Three way + oxidation catalytic converter
system TWC + OC system ***
Throttle body TB Throttle chamber
SPI body
Throttle body fuel injection system TBI system Fuel injection control
Throttle position TP Throttle position
Throttle position sensor TPS Throttle sensor
Throttle position switch TP switch Throttle switch
Torque converter clutch solenoid valve TCC solenoid valve Lock-up cancel solenoid
Lock-up solenoid
NEW TERM
NEW ACRONYM /
ABBREVIATION OLD TERM

PG-72
HARNESS CONNECTOR
Revision: 2006 July 2007 FX35/FX45
HARNESS CONNECTOR (SLIDE-LOCKING TYPE)

A new style slide-locking type connector is used on certain systems and components, especially those
related to OBD.

The slide-locking type connectors help prevent incomplete locking and accidental looseness or discon-
nection.

The slide-locking type connectors are disconnected by pushing or pulling the slider. Refer to the figure
below.
CAUTION:

Never pull the harness or wires when disconnecting the connector.

Be careful not to damage the connector support bracket when disconnecting the connector.
[Example]
SEL769V
