FRONT DRIVE SHAFTFAX-21
< SERVICE INFORMATION > [AWD]
C
EF
G H
I
J
K L
M A
B
FA X
N
O P
7. Install housing to spider assembly. Apply Nissan genuine grease or equivalent to housing.
8. Install boot securely into grooves (indicated by *marks) shown in the figure.
CAUTION:
If there is grease on boot mo unting surfaces (indicated by *
marks) of shaft and housing, boot may come off. Remove
all grease from surfaces.
9. Make sure boot installation length “L
1 L2” is the length indicated
below. Insert a flat-bladed screwdriver or similar tool into smaller
side of boot. Bleed air from boot to prevent boot deformation.
CAUTION:
 Boot may break if boot installation le ngth is less than standard value.
 Take care not to touch the tip of screw driver to inside surface of boot.
10. Install new larger and smaller boot bands securely. NOTE:
Discard old boot bands; replace with new ones.
11. After installing housing and shaft, rotate boot to check whether or not the actual position is correc t. If boot position is not correct,
secure boot with new boot bands again.
12. Install circular clip. NOTE:
Discard old circular clip; replace with new one.
Wheel Side
Assemble in steps 14 to 23 of FAX-13, "On-Vehicle Inspection".
Disassembly and Assembly (Right Side)INFOID:0000000001327519
COMPONENTS
Grease amount : 95 − 105 g (3.35 − 3.70 oz)
SDIA1445E
Boot installation Length “L1 L2”:
VK45DE models (L
1) : 95 − 97 mm (3.74 − 3.82 in)
VQ35DE models (L
2) : 150.9 − 152.9 mm (5.94 − 6.02 in)
PDIA1255E
SFA395
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

FAX-22
< SERVICE INFORMATION >[AWD]
FRONT DRIVE SHAFT
