SERVICE DATA AND SPECIFICATIONS (SDS)
EM-269
< SERVICE INFORMATION > [VK45DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
CYLINDER HEAD
Unit: mm (in)
Valve Dimensions
Unit: mm (in)
827U 8.27 (0.3256)
828U 8.28 (0.3260)
829U 8.29 (0.3264)
830U 8.30 (0.3268)
831U 8.31 (0.3272)
832U 8.32 (0.3276)
833U 8.33 (0.3280)
834U 8.34 (0.3283)
835U 8.35 (0.3287)
836U 8.36 (0.3291)
837U 8.37 (0.3295)
838U 8.38 (0.3299)
839U 8.39 (0.3303)
840U 8.40 (0.3307)
Identification (stamped
) mark Thickness mm (in)
Items Standard Limit
Surface distortion Less than 0.03 (0.0012) 0.1 (0.004)
PBIC0183E
Items Standard
Valve head diameter “D” Intake 36.0 - 36.3 (1.417 - 1.429) Exhaust 31.2 - 31.5 (1.228 - 1.240)
Valve length “L” Intake 96.57 (3.8020)
Exhaust 94.50 (3.7205)
Valve stem diameter “d” Intake 5.972 - 5.980 (0.2351 - 0.2354)
Exhaust 5.962 - 5.970 (0.2347 - 0.2350)
Valve seat angle “ α” Intake
45°15 ′ - 45 °45 ′
Exhaust
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

GI-1
