brake pads replacement INFINITI G37 2010 Owners Manual

Brake pad wear warning The disc brake pads have audible wear warn-
ings. When a brake pad requires replacement, it
will make a high pitched scraping sound when
the vehicle is in motion. This scraping sound
will first occur only when the brake pedal is
depressed. After more wear of the brake pad,
the sound will always be heard even if the brake
pedal is not depressed. Have the brakes
checked as soon as possible if the warning
sound is heard.
The dot matrix liquid crystal display
 1
is
located between the tachometer and the speed-
ometer, and it displays the automatic transmis-
sion position indicator (if so equipped), the
Intelligent Cruise Control (ICC) system (if so
equipped) information, the Intelligent Key op-
eration information and other warnings and
information. For details about the automatic transmission
position indicator, see “INDICATOR LIGHTS” ear-
lier in this section. For details about the ICC
system, see “INTELLIGENT CRUISE CONTROL
(ICC) SYSTEM” in the “5. Starting and driving”
section. For the details about the Intelligent Key
system, see “INTELLIGENT KEY SYSTEM” in the
“3. Pre-driving checks and adjustments”
section. SIC4293
DOT MATRIX LIQUID CRYSTAL DISPLAY
Instruments and controls
2-19
 —
—
10/12/09—tbrooks


If you wax the surface of the hood, be careful
not to let wax get into the washer nozzle
 A
.
This may cause clogging or improper wind-
shield washer operation. If wax gets into the
nozzle, remove it with a needle or small pin
 B
.
Be careful not to damage the nozzle. If the brakes do not operate properly, have the
brakes checked by an INFINITI retailer.
SELF-ADJUSTING BRAKES Your vehicle is equipped with self-adjusting
brakes.
The disc-type brakes self-adjust every time the
brake pedal is applied.
WARNINGSee an INFINITI retailer for a brake system
check if the brake pedal height does not return
to normal.
BRAKE PAD WEAR WARNING The disc brake pads have audible wear warn-
ings. When a brake pad requires replacement, it
will make a high pitched scraping sound when
the vehicle is in motion. This scraping sound
will first occur only when the brake pedal is
depressed. After more wear of the brake pad,
the sound will always be heard even if the brake
pedal is not depressed. Have the brakes
checked as soon as possible if the wear warn-
ing sound is heard. Under some driving or climate conditions, occa-
sional brake squeak, squeal or other noise may
be heard. Occasional brake noise during light to
moderate stops is normal and does not affect
the function or performance of the brake sys-
tem.
Proper brake inspection intervals should be fol-
lowed. For additional information, see the main-
tenance log section of your “INFINITI Service
and Maintenance Guide” for maintenance inter-
vals.
SDI2362BRAKES
Maintenance and do-it-yourself
8-19
 —
—
04/21/10—debbie
