jack points INFINITI G37 2010 Owners Manual

Getting the spare tire and tools Raise the trunk floor cover
 1
using the tab
 A
.
Remove jacking tools located inside the trunk
as illustrated.
The spare tire is located under the jacking tools.
Remove the cap
 2
holding the spare tire. Jacking up the vehicle and removing
the damaged tire WARNING● Never get under the vehicle while it is sup-
ported only by the jack. If it is necessary to
work under the vehicle, support it with
safety stands.
● Use only the jack provided with your vehicle
to lift the vehicle. Do not use the jack pro-
vided with your vehicle on other vehicles.
The jack is designed for lifting only your ve-
hicle during a tire change.
● Use the correct jack-up points. Never use any
other part of the vehicle for jack support.
● Never jack up the vehicle more than
necessary.
● Never use blocks on or under the jack.
● Do not start or run the engine while vehicle is
on the jack, as it may cause the vehicle to
move. This is especially true for vehicles
with limited slip differentials.
● Do not allow passengers to stay in the ve-
hicle while it is on the jack.
Carefully read the caution label attached to the
jack body and the following instructions.Jacking tools — Sedan SCE0659
Jacking tools — Coupe SCE0695 Spare — Sedan and Coupe SCE0702
6-4 In case of emergency
 —
—
04/21/10—debbie


6. Recheck oil level with the dipstick.
It is normal to add some oil between oil mainte-
nance intervals or during the break-in period,
depending on the severity of operating condi-
tions.
CAUTIONOil level should be checked regularly. Operat-
ing the engine with an insufficient amount of oil
can damage the engine, and such damage is
not covered by warranty.
CHANGING ENGINE OIL AND FILTER
Vehicle set-up 1. Park the vehicle on a level surface and
apply the parking brake.
2. Run the engine until it reaches operating
temperature.
3. Turn the engine off and wait more than 15
minutes.
4. Raise and support the vehicle using a
suitable floor jack and safety jack stands.
● Place the safety jack stands under the
vehicle jack-up points.
● A suitable adapter should be attached to
the jack stand saddle. 5. Remove the plastic engine undercover.
a. Remove the small plastic clip at the center
point of the undercover.
b. Then remove the other bolts that hold the
undercover in place.
CAUTIONMake sure the correct lifting and support
points are used to avoid vehicle damage.
Engine oil and filter 1. Place a large drain pan under the drain
plug.
2. Remove the oil filler cap.
3. Remove the drain plug
 1
with a wrench
and completely drain the oil.
CAUTIONBe careful not to burn yourself, as the engine oil
is hot. Two-wheel drive (2WD) models SDI2335
Maintenance and do-it-yourself
8-9
 —
—
04/21/10—debbie
