clock setting INFINITI G37 2012 Owners Manual

Black plate (17,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]GUID-5BF1CCAC-1271-471E-83A1-FF109419BE46
SSI0671
1. Side ventilator (P.4-30)
2. Meters and gauges (P.2-6)
3. Center ventilator (P.4-30)
4. Audio system (P.4-41)
5. Clock (P.2-42)
6. Center multi-function control panel — Navigation system* (if so
equipped)
— Vehicle information and setting
buttons (P.4-9)
— Bluetooth ®
Hands-Free Phone Sys-
tem (if so equipped) (P.4-90, P.4-100) — Audio system (P.4-41)
7. Center display (P.4-3)/Navigation sys-
tem* (if so equipped)
8. Hazard warning flasher switch (P.2-39)
9. Front passenger supplemental air bag
(P.1-41)
10. Fuse box cover (P.8-24)
11. Parking brake (for Automatic Trans-
mission models)
— Parking (P.5-20)
12. Push-button ignition switch (P.5-9)
13. Automatic climate control system
(P.4-31)
14. Cigarette lighter and ashtray (if so
equipped) (P.2-44) or storage box (if
so equipped) (P.2-50)
— Power outlet (if so equipped)
(P.2-43)
15. Parking brake (for Manual Transmis-
sion models)
— Parking (P.5-20)
16. Heated seat switch (if so equipped)
(P.2-40)
17. SNOW mode switch (if so equipped)
(P.2-41)
18. Rear window and outside mirror (if so
equipped) defroster switch (P.2-34)
Illustrated table of contents
0-11INSTRUMENT PANEL

Black plate (82,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]2-4 Instruments and controls GUID-F966D69B-15F8-48D0-A86B-A60F682B16E9
SSI0671
1. Side ventilator (P.4-30)
2. Meters and gauges (P.2-6)
3. Center ventilator (P.4-30)
4. Audio system (P.4-41)
5. Clock (P.2-42)
6. Center multi-function control panel — Navigation system* (if so
equipped)
— Vehicle information and setting
buttons (P.4-9)
— Bluetooth ®
Hands-Free Phone Sys-
tem (if so equipped) (P.4-90, P.4-100) — Audio system (P.4-41)
7. Center display (P.4-3)/Navigation sys-
tem* (if so equipped)
8. Hazard warning flasher switch (P.2-39)
9. Front passenger supplemental air bag
(P.1-41)
10. Fuse box cover (P.8-24)
11. Parking brake (for Automatic Trans-
mission models)
— Parking (P.5-20)
12. Push-button ignition switch (P.5-9)
13. Automatic climate control system
(P.4-31)
14. Cigarette lighter and ashtray (if so
equipped) (P.2-44) or storage box (if
so equipped) (P.2-50)
— Power outlet (if so equipped)
(P.2-43)
15. Parking brake (for Manual Transmis-
sion models)
— Parking (P.5-20)
16. Heated seat switch (if so equipped)
(P.2-40)
17. SNOW mode switch (if so equipped)
(P.2-41)
18. Rear window and outside mirror (if so
equipped) defroster switch (P.2-34)INSTRUMENT PANEL

Black plate (120,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]2-42 Instruments and controls GUID-D6E40EC7-7E3A-4BCB-BCDD-525F5F5A56AE
JVS0022X
The vehicle should be driven with the
Vehicle Dynamic Control (VDC) system on
for most driving conditions.
If the vehicle is stuck in mud or snow, the
VDC system reduces the engine output to
reduce wheel spin. The engine speed will
be reduced even if the accelerator is
depressed to the floor. If maximum engine
power is needed to free a stuck vehicle,
turn the VDC system off.
To turn off the VDC system, push the VDC
OFF switch. The
indicator will illumi-
nate.
Push the VDC OFF switch again or restart
the engine to turn on the system. (See “ Vehicle Dynamic Control (VDC) system ”
(P.5-55).) GUID-DC9CAC82-B97F-47EC-AD18-AF6DB1F26506
SIC3325
If the power supply is disconnected, the
clock will not indicate the correct time.
Readjust the time.
ADJUSTING THE TIME GUID-9687E000-FB4A-4A09-9D4E-BA64FB958022
1. To set the clock forward, push the
button
* 1
.
2. To set the clock backward, push the
button
* 2
.
3. To move forward or backward faster,
push and hold the button more than 5
seconds.
For details about display clock adjustment
(if so equipped), see “ How to use SETTING
button ” (P.4-14).VEHICLE DYNAMIC CONTROL (VDC) OFF
SWITCH CLOCK

Black plate (196,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]4-18 Monitor, climate, audio, phone and voice recognition systems SAA2487
Clock settings (models with navi-
gation system) GUID-B9CF9FB9-D5FE-4867-98B3-5D7755C52672
The display as illustrated will appear when
pushing the SETTING button and selecting
the “ Clock ” key.
On-screen Clock: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When this item is turned to ON, a clock is
always displayed in the upper right corner
of the screen.
This clock will indicate the time almost
exactly because it is always adjusted by
the GPS system. Clock Format (24h): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When this item is turned to ON, the 24-
hour clock is displayed. When this item is
not turned to ON, the 12-hour clock is
displayed.
Offset (hour)/(min): GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Adjust the time by increasing or decreasing
per hour or per minute.
Daylight Saving Time: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Turn this item to ON for daylight saving
time application.
Time Zone: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
Choose the time zone from the following
. Pacific
. Mountain
. Central
. Eastern
. Atlantic
. Newfoundland
. Hawaii
. Alaska SAA3019
Others settings (models with navi-
gation system) GUID-5502AFAA-980F-4CBD-AAF3-40F5218DA4F3
The Others settings display will appear
when pushing the SETTING button and
selecting the “ Others ” key.
The following items are available:
. Comfort
. Language & Units
. Voice Recognition
. Camera
. Sonar
. Image Viewer
