clutch INFINITI G37 2012 Owners Manual

Black plate (20,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]0-14 Illustrated table of contents GUID-4EFFD432-519B-49EA-B9D3-B7E9FD7A6615
SDI2709
VQ25HR/VQ37VHR ENGINE GUID-2D649F04-F3DE-4C0A-877A-1F56F5C15998
1. Fuse/fusible link holder (P.8-24)
2. Battery (P.8-17)
3. Engine oil filler cap (P.8-11)
4. Brake fluid reservoir (P.8-15)
5. Clutch fluid reservoir (Manual Trans- mission models) (P.8-15)
6. Window washer fluid reservoir
(P.8-16)
7. Power steering fluid reservoir (P.8-14)
8. Air cleaner (P.8-21) 9. Radiator filler cap (P.8-9)
10. Drive belts (P.8-19)
11. Coolant reservoir (P.8-9)
12. Engine oil dipstick (for VQ37VHR
engine model) (P.8-11)
13. Engine oil dipstick (for VQ25HR en-
gine model) (P.8-11)ENGINE COMPARTMENT

Black plate (91,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]CAUTION. If the warning light comes on while
driving there may be a malfunction in
the AWD system. Reduce the vehicle
speed and have your vehicle checked by
an INFINITI retailer as soon as possible.
. If the AWD warning light blinks on when
you are driving:
— blinks rapidly (about twice a sec-
ond):
Pull off the road in a safe area, and
idle the engine. The driving mode will
change to 2WD to prevent the AWD
system from malfunctioning. If the
warning light turns off, you can drive
again.
— blinks slowly (about once every 2
seconds):
Pull off the road in a safe area, and
idle the engine. Check that all tire
sizes are the same, tire pressure is
correct and tires are not worn.
. If the warning light is still on after the
above operations, have your vehicle
checked by an INFINITI retailer as soon as possible.
or Anti-lock Braking
System (ABS) warning light GUID-999CB2F5-4FF3-4D41-ACF3-7E00ED4B6C0F
When the ignition switch is in the ON
position, the Anti-lock Braking System
(ABS) warning light illuminates and then
turns off. This indicates the ABS is opera-
tional.
If the ABS warning light illuminates while
the engine is running, or while driving, it
may indicate the ABS is not functioning
properly. Have the system checked by an
INFINITI retailer.
If an ABS malfunction occurs, the anti-lock
function is turned off. The brake system
then operates normally, but without anti-
lock assistance. (See “ Brake system ” (P.5-
51).)
Automatic transmission check
warning light (if so equipped) GUID-A564A816-81E3-40F1-8684-0ED502ABDB57
When the ignition switch is pushed to the
ON position, the light comes on for 2
seconds. If the light comes on at any other
time, it may indicate the transmission is
not functioning properly. Have your INFINITI
retailer check and repair the transmission. or Brake warning light GUID-9EF95796-7290-4F31-AB06-6BE1BB80003D
This light functions for both the parking
brake and the foot brake systems.
Parking brake indicator: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When the ignition switch is in the ON
position, the light comes on when the
parking brake is applied.
Low brake fluid warning light: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When the ignition switch is in the ON
position, the light warns of a low brake
fluid level. If the light comes on while the
engine is running with the parking brake
not applied, stop the vehicle and perform
the following:
1. Check the brake fluid level. If brake
fluid is necessary, add fluid and have
the system checked by your INFINITI
retailer. (See “ Brake and clutch fluid ”
(P.8-15).)
2. If the brake fluid level is correct, have
the warning system checked by an
INFINITI retailer.
Anti-lock Braking System (ABS) warning
indicator: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
When the parking brake is released and
the brake fluid level is sufficient, if both
the brake warning light and the Anti-lock
Instruments and controls
2-13

Black plate (101,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]8. Engine start operation indicator
(Manual Transmission models) GUID-6F348F29-B160-4632-B05C-A45F6D5E7AD7
This indicator means that the engine will
start by pushing the ignition switch with
the clutch pedal depressed.
9. Parking brake release warning GUID-7289EFE7-F400-4C19-9597-F8AA159911CA
This warning appears when the vehicle
speed is above 4 MPH (7 km/h) and the
parking brake is applied.
10. Low fuel warning GUID-2FE47C40-46BC-4EC8-AC52-E90EBB5F8B0F
This warning appears when the fuel level in
the tank is getting low. Refuel as soon as it
is convenient, preferably before the fuel
gauge reaches the empty (E) position.
There is a small reserve of fuel remaining
in the tank when the fuel gauge reaches
the empty (E) position.
11. Low washer fluid warning GUID-54C94524-E0BC-4326-8A11-B2CD705757A6
This warning appears when the washer
tank fluid is at a low level. Add washer fluid
as necessary. (See “ Window washer fluid ”
(P.8-16).)
12. Door/trunk open warning (igni-
tion switch is in the ON position) GUID-50585695-BAF8-48B7-8A81-CEA312693DE1
This warning appears if any of the doors and/or the trunk lid are open or not closed
securely. The vehicle icon indicates which
door or the trunk lid is open on the display.
13. Loose fuel cap warning GUID-479E9C15-B26C-477B-8AA7-ED29D6CD76ED
This warning appears when the fuel-filler
cap is not tightened correctly after the
vehicle has been refueled. (See “ Fuel-filler
door ” (P.3-23).)
14. Check tire pressure warning GUID-174D3E5C-C80F-432A-944F-EE13C51D1486
This warning appears when the low tire
pressure warning light in the meter illumi-
nates to indicate the low tire pressure. If
this warning appears, stop the vehicle and
adjust the tire pressure to the recom-
mended COLD tire pressure shown on the
Tire and Loading Information label. (See
“ Low tire pressure warning light ” (P.2-15)
and “ Tire Pressure Monitoring System
(TPMS) ” (P.5-4).)
15. “ Time to rest ” indicator GUID-9639DC97-247E-4499-BA1B-AFF133E94400
This indicator appears when the set “ time
to rest ” indicator activates. You can set the
time for up to 6 hours. (See “ Trip
computer ” (P.2-26).) 16. Low outside temperature warn-
ing GUID-E9986E7D-DDA6-4BCF-8D8E-D8F9C645C41B
This warning appears if the outside tem-
perature is below 37 8 F (3 8 C). The warning
can be set not to be displayed. (See “ Trip
computer ” (P.2-26).)
17. Cruise indicator GUID-8437A118-88BE-4895-A266-56D415AE4EC7
Cruise main switch indicator: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
The indicator is displayed when the cruise
control main switch is pushed. When the
main switch is pushed again, the indicator
disappears. When the cruise control main
switch indicator is displayed, the cruise
control system is operational.
Cruise set switch indicator: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
The indicator is displayed while the vehicle
speed is controlled by the cruise control
system. If the indicator blinks while the
engine is running, it may indicate that the
cruise control system is not functioning
properly. Have the system checked by an
INFINITI retailer.
See “ Cruise control ” (P.5-21) for details.
Instruments and controls
2-23

Black plate (330,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]5-10 Starting and driving SSD0824
OPERATING RANGE FOR ENGINE
START FUNCTION GUID-AD538490-C217-4791-BBA1-E0D349567B64
The Intelligent Key can only be used for
starting the engine when the Intelligent
Key is within the specified operating range
* 1
.
When the Intelligent Key battery is almost
discharged or strong radio waves are
present near the operating location, the
Intelligent Key system ’ s operating range
becomes narrower and may not function
properly.
If the Intelligent Key is within the operating
range, it is possible for anyone, even someone who does not carry the Intelligent
Key, to push the ignition switch to start the
engine.
. The trunk area is not included in the
operating range but the Intelligent Key
may function.
. If the Intelligent Key is placed on the
instrument panel, rear parcel shelf,
inside the glove box or door pocket,
the Intelligent Key may not function.
. If the Intelligent Key is placed near the
door or window outside the vehicle, the
Intelligent Key may function. SSD1021
PUSH-BUTTON IGNITION SWITCH
OPERATION GUID-A0C2E067-D7A3-43F9-A9B9-0A01FE60AF79
When the ignition switch is pushed without
depressing the brake pedal (automatic
transmission model) or the clutch pedal
(manual transmission model), the ignition
switch position will change as follows:
. Push center once to change to ACC.
. Push center two times to change to ON.
. Push center three times to change to
OFF. (No position illuminates.)
. Push center four times to return to ACC.
. Open or close any door to return to
LOCK during the OFF position.

Black plate (333,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]GUID-047D7FCF-6A67-40C6-9132-4B63D7D41A18
1. Apply the parking brake.
2. Automatic Transmission (AT) model:
Move the selector lever to the P (Park)
or N (Neutral) position. (P is recom-
mended.)
The starter is designed not to operate
unless the selector lever is in either of
the above positions.
Manual Transmission (MT) model:
Move the shift lever to the N (Neutral)
position. Depress the clutch pedal fully
to the floor.
The starter is designed not to operate
unless the clutch pedal is fully de-
pressed.
The Intelligent Key must be carried
when operating the ignition switch.
3. Push the ignition switch to the ON
position. Depress the brake pedal (AT
model) or the clutch pedal (MT model)
and push the ignition switch to start
the engine.
To start the engine immediately, push
and release the ignition switch while
depressing the brake pedal or clutch
pedal (MT model) with the ignition
switch in any position. .
If the engine is very hard to start in
extremely cold weather or when
restarting, depress the accelerator
pedal a little (approximately 1/3 to
the floor) and while holding, crank
the engine. Release the accelerator
pedal when the engine starts. .
If the engine is very hard to start
because it is flooded, depress the
accelerator pedal all the way to the
floor and hold it. Push the ignition
switch to the ON position to start
cranking the engine. After 5 or 6
seconds, stop cranking by pushing
the ignition switch to OFF. After
cranking the engine, release the
accelerator pedal. Crank the engine
with your foot off the accelerator
pedal by depressing the brake pedal
and pushing the push-button igni-
tion switch to start the engine. If the
engine starts, but fails to run, repeat
the above procedure.
CAUTION Do not operate the starter for more than 15
seconds at a time. If the engine does not
start, push the ignition switch to OFF and wait 10 seconds before cranking again,
otherwise the starter could be damaged.
4. Warm-up
Allow the engine to idle for at least 30
seconds after starting. Do not race the
engine while warming it up. Drive at
moderate speed for a short distance
first, especially in cold weather. In cold
weather, keep the engine running for a
minimum of 2 - 3 minutes before
shutting it off. Starting and stopping
the engine over a short period of time
may make the vehicle more difficult to
start.
VQ37VHR engine: When racing the
engine up to 4,000 rpm or more under
no load condition, the engine will enter
the fuel cut mode.
5. To stop the engine, shift the selector
lever to the P (Park) position (AT model)
or move the shift lever to the N
(Neutral) position (MT model), and push
the ignition switch to the OFF position.
Starting and driving
5-13STARTING THE ENGINE

Black plate (338,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]5-18 Starting and driving4. Push down the shift lock
* B
as
illustrated.
5. Push the selector lever button
* C
and
move the selector lever to N (Neutral)
position
* D
while holding down the
shift lock.
Now the vehicle may be moved to the
desired location.
If the lever cannot be moved out of P
(Park), have an INFINITI retailer check the
automatic transmission system as soon as
possible.
Adaptive shift control (ASC) GUID-F11A26ED-2920-48C5-B33E-4D8F7EBFD667
The adaptive shift control system automa-
tically operates when the transmission is
in the "D" (drive) and "DS" (Drive Sport)
position and selects an appropriate gear
depending on the road conditions such as
uphill, downhill or curving roads.
Control on uphill and curving roads: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
A low gear is maintained that suits the
degree of the slope or curve to allow
smooth driving with a small number of
shifts.
Control on downhill roads: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
The adaptive shift control system shifts to
a low gear that suits the degree of the slope, and uses the engine braking to
reduce the number of times that the brake
must be used.
Control on winding roads: GUID-D73A39BF-43C8-459F-9C24-47B7F579C407
A low gear is maintained on continuous
curves that involve repeated acceleration
and deceleration, so that smooth accelera-
tion is available instantly when the accel-
erator pedal is depressed.
NOTE:
. Adaptive shift control may not operate
when the transmission oil temperature
is low immediately after the start of
driving or when it is very hot.
. During some driving situations, hard
braking for example, the adaptive shift
control may automatically operate. The
transmission may automatically shift
to a lower gear for engine braking. This
increases engine speed but not vehicle
speed. Vehicle speed is controlled by
the accelerator pedal when the vehicle
is in the Adaptive shift control mode.
. When the adaptive shift control oper-
ates, the transmission sometimes
maintains a lower gear for a longer
period of time than when adaptive shift
control is not operating. Engine speed will be higher for a specific vehicle
speed while ASC system is operating
than when ASC is not operating.
MANUAL TRANSMISSION GUID-55540C91-1BB1-4931-BE6A-9E10E00B9B1A
WARNING . Do not downshift abruptly on slippery
roads. This may cause a loss of control.
. Do not over-rev the engine when shifting
to a lower gear. This may cause a loss of
control or engine damage.
CAUTION . Do not rest your foot on the clutch pedal
while driving. This may damage the
clutch.
. Fully depress the clutch pedal before
shifting to help prevent transmission
damage.
. Stop your vehicle completely before
shifting into R (Reverse).
. When the vehicle is stopped for a period
of time, for example at a stop light, shift
to N (Neutral) and release the clutch

Black plate (339,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]pedal with the foot brake applied.
SSD0536
Shifting GUID-BAB0D075-05C4-461C-A3A3-BBEAB0A0E7FF
To change gears, or when upshifting or
downshifting, fully depress the clutch
pedal, shift into the appropriate gear, then
slowly and smoothly release the clutch
pedal.
This vehicle is equipped with a short throw
shifter manual transmission. To ensure
smooth gear changes, fully depress the
clutch pedal before operating the shift
lever. If the clutch pedal is not fully
depressed before the transmission is
shifted, a gear noise may be heard.
Transmission damage could occur. Start the vehicle in 1st gear and shift to
2nd, 3rd, 4th, 5th and 6th gear in
sequence according to vehicle speed.
To back up, depress the shift lever and
then move it to the R (Reverse) gear after
stopping the vehicle completely.
The shift lever returns to its original
position when the shift lever is moved to
the N (Neutral) position.
If it is difficult to move the shift lever into
the R (Reverse) or 1st gear, shift to the N
(Neutral) position, and then release the
clutch pedal once. Fully depress the clutch
pedal again and shift into the R (Reverse)
or 1st gear.
Suggested upshift speeds GUID-34BBD803-93B2-4C9A-A203-4D769208DB15
The following are suggested vehicle
speeds for shifting into a higher gear.
These suggestions relate to fuel economy
and vehicle performance. Actual upshift
speeds will vary according to road condi-
tions, the weather and individual driving
habits.
Starting and driving
5-19

Black plate (342,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]5-22 Starting and driving. in heavy traffic or in traffic that varies in
speed
. on winding or hilly roads
. on slippery roads (rain, snow, ice, etc.)
. in very windy areas
Doing so could cause a loss of vehicle
control and result in an accident.
CAUTIONOn manual transmission models, do not
shift into N (Neutral) without depressing the
clutch pedal when the cruise control is set.
Should this occur, depress the clutch pedal
and turn the main switch off immediately.
Failure to do so may cause engine damage. SSD0600
1. ACCELERATE/RESUME switch
2. COAST/SET switch
3. CANCEL switch
4. MAIN (ON·OFF) switch
CRUISE CONTROL OPERATIONS GUID-FEFB0214-0115-446A-8D35-5777F46212FE
The cruise control allows driving at a speed
between 25 to 89 MPH (40 to 144 km/h)
without keeping your foot on the accel-
erator pedal.
To turn on the cruise control, push the
MAIN switch on. The CRUISE indicator will
come on.
To set cruising speed, accelerate your
vehicle to the desired speed, push the COAST/SET switch and release it. (The
CRUISE SET indicator will come on in the
instrument panel.) Take your foot off the
accelerator pedal. Your vehicle will main-
tain the set speed.
. To pass another vehicle, depress the
accelerator pedal. When you release
the pedal, the vehicle will return to the
previously set speed.
. The vehicle may not maintain the set
speed on winding or hilly roads. If this
happens, drive without the cruise con-
trol.
To cancel the preset speed, follow any of
these methods:
a) Push the CANCEL button. The SET
indicator will go out.
b) Tap the brake pedal. The SET indicator
will go out.
c) Move the selector lever to the N
(Neutral) position. The SET indicator
will go out.
d) Turn the MAIN switch off. Both the
CRUISE indicator and SET indicator
will go out.
. If you depress the brake pedal while
pushing the ACCELERATE/RESUME or
COAST/SET switch and reset at the

Black plate (343,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]cruising speed, the cruise control will
disengage. Turn the MAIN switch off
once and then turn it on again.
. The cruise control will automatically
cancel if the vehicle slows more than
8 MPH (12 km/h) below the set speed.
. If you depress the clutch pedal (Manual
Transmission models) or move the
selector lever to N (Neutral) position
(Automatic Transmission models), the
cruise control will be canceled.
To reset at a faster cruising speed, use one
of the following methods:
. Depress the accelerator pedal. When
the vehicle attains the desired speed,
push and release the COAST/SET
switch.
. Push and hold the ACCELERATE/RE-
SUME switch. When the vehicle attains
the speed you desire, release the
switch.
. Push, then quickly release the ACCEL-
ERATE/RESUME switch. Each time you
do this, the set speed will increase by
about 1 MPH (1.6 km/h).
To reset at a slower cruising speed, use
one of the following methods:
. Lightly tap the brake pedal. When the vehicle attains the desired speed, push
the COAST/SET switch and release it.
. Push and hold the COAST/SET switch.
Release the switch when the vehicle
slows down to the desired speed.
. Push, then quickly release the COAST/
SET switch. Each time you do this, the
set speed will decrease by about 1 MPH
(1.6 km/h).
To resume the preset speed, push and
release the ACCELERATE/RESUME switch.
The vehicle will resume the last set
cruising speed when the vehicle speed is
over 25 MPH (40 km/h). GUID-E7651926-4BC1-4070-A1DC-B90D2ECCC5B1
The Intelligent Cruise Control (ICC) system
automatically maintains a selected dis-
tance from the vehicle traveling in front of
you according to that vehicle ’ s speed (up
to the set speed), or at the set speed when
the road ahead is clear.
The ICC function can be set to one of two
cruise control modes:
. Vehicle-to-vehicle distance control
mode:
For maintaining a selected distance
between your vehicle and the vehicle
in front of you up to the preset speed.
. Conventional (fixed speed) cruise con-
trol mode:
For cruising at a preset speed.
WARNING . Always drive carefully and attentively
when using either cruise control mode.
Read and understand the Owner ’ s Man-
ual thoroughly before using the cruise
control. To avoid serious injury or death,
do not rely on the system to prevent
accidents or to control the vehicle ’ s
speed in emergency situations. Do not
use cruise control except in appropriate
road and traffic conditions.
Starting and driving
5-23INTELLIGENT CRUISE CONTROL (ICC)
SYSTEM (if so equipped)

Black plate (407,1)
[ Edit: 2012/ 1/ 17 Model: V36-D ]8 Maintenance and do-it-yourself Maintenance requirement ....................................... 8-3
Scheduled maintenance ..................................... 8-3
General maintenance .......................................... 8-3
Where to go for service ...................................... 8-3
General maintenance .............................................. 8-4
Explanation of maintenance items ...................... 8-4
Maintenance precautions ........................................ 8-6
Engine compartment check locations ...................... 8-8
VQ25HR/VQ37VHR engine .................................. 8-8
Engine cooling system ............................................ 8-9
Checking engine coolant level .......................... 8-10
Changing engine coolant .................................. 8-10
Engine oil ............................................................. 8-11
Checking engine oil level .................................. 8-11
Changing engine oil and filter .......................... 8-11
Automatic transmission fluid ................................ 8-14
Power steering fluid .............................................. 8-14
Brake and clutch fluid .......................................... 8-15
Brake fluid ....................................................... 8-15
Clutch fluid (if so equipped) ............................. 8-15
Window washer fluid ............................................ 8-16 Battery ................................................................. 8-17
Coupe ............................................................. 8-17
Sedan and coupe ............................................ 8-17
Jump starting .................................................. 8-18
Variable voltage control system ............................ 8-19
Drive belts ........................................................... 8-19
Spark plugs ......................................................... 8-20
Replacing spark plugs .................................... 8-20
Air cleaner ........................................................... 8-21
Windshield wiper blades ...................................... 8-22
Cleaning ......................................................... 8-22
Replacing ........................................................ 8-22
Brakes ................................................................. 8-23
Self-adjusting brakes ...................................... 8-23
Brake pad wear warning ................................. 8-23
Fuses ................................................................... 8-24
Engine compartment ....................................... 8-24
Passenger compartment .................................. 8-25
Intelligent Key battery replacement ...................... 8-26
