automatic transmission fluid INFINITI M HYBRID 2013 Owner's Manual

The hill start assist system automatically
keeps the brakes applied to help prevent
the vehicle from rolling backwards in the
time it takes the driver to release the brake
pedal and apply the accelerator when the
vehicle is stopped on a hill.
The hill start assist system will operate
automatically under the following condi-
tions:
.The transmission is shifted to a forward
or reverse gear.
. The vehicle is stopped completely on a
hill by applying the brake.
The maximum holding time is 2 seconds.
After 2 seconds the vehicle will begin to
roll back and the hill start assist system
will stop operating completely.
The hill start assist system will not operate
when the transmission is shifted to the N
(Neutral) or P (Park) position or on a flat
and level road.
When staring the vehicle on a steep uphill
grade, wait one second after shifting the
selector lever into the driving position.FREEING A FROZEN DOOR LOCK
To prevent a door lock from freezing, apply
deicer through the key hole. If the lock
becomes frozen, heat the key before
inserting it into the key hole or use the
Intelligent Key system.
ANTIFREEZE
In the winter when it is anticipated that the
outside temperature will drop below 328F
(08C), check antifreeze to assure proper
winter protection. For additional informa-
tion, see “Engine cooling system” in the
“8. Maintenance and do-it-yourself” sec-
tion.
12-VOLT BATTERY
If the 12-volt battery is not fully charged
during extremely cold weather conditions,
the 12-volt battery fluid may freeze and
damage the 12-volt battery. To maintain
maximum efficiency, the 12-volt battery
should be checked regularly. For additional
information, see “12-volt battery” in the
“8. Maintenance and do-it-yourself” sec-
tion.
DRAINING OF COOLANT WATER
If the vehicle is to be left outside without
antifreeze, drain the cooling system, in-
cluding the engine block. Refill before
operating the vehicle. For details, see
“Engine cooling system” in the“8. Main-
tenance and do-it-yourself” section and
“Inverter cooling system” in the“8. Main-
tenance and do-it-yourself” section.
TIRE EQUIPMENT
SUMMER tires have a tread designed to
provide superior performance on dry pave-
ment. However, the performance of these
tires will be substantially reduced in snowy
and icy conditions. If you operate your
vehicle on snowy or icy roads, INFINITI
recommends the use of MUD & SNOW or
ALL SEASON tires on all four wheels.
Consult an INFINITI retailer for the tire
type, size, speed rating and availability
information.
For additional traction on icy roads,
studded tires may be used. However, some
U.S. states and Canadian provinces prohi-
bit their use. Check local, state and
provincial laws before installing studded
tires.
Starting and driving5-101
COLD WEATHER DRIVING

8 Maintenance and do-it-yourself
Maintenance requirement.................................... 8-2
Scheduled maintenance .................................. 8-2
General maintenance....................................... 8-2
Where to go for service ................................... 8-2
General maintenance ........................................... 8-3 Explanation of maintenance items ................... 8-3
Maintenance precautions ..................................... 8-5
Engine compartment check locations ................... 8-7 VQ35HR engine ............................................... 8-7
Engine cooling system ......................................... 8-9
Checking engine coolant level ....................... 8-10
Changing engine coolant ............................... 8-10
Inverter cooling system...................................... 8-11
Checking inverter coolant level ...................... 8-12
Changing inverter coolant.............................. 8-12
Engine oil .......................................................... 8-12
Checking engine oil level............................... 8-12
Changing engine oil and filter ....................... 8-13
Automatic transmission fluid ............................. 8-15
Power steering fluid........................................... 8-15
Brake fluid......................................................... 8-16 Brake fluid .................................................... 8-16
Window washer fluid ......................................... 8-17
12-volt battery ................................................... 8-18 Checking battery fluid level ........................... 8-19 Jump starting ............................................... 8-19
Spark plugs ...................................................... 8-19 Replacing spark plugs ................................. 8-20
Air cleaner ........................................................ 8-20
Windshield wiper blades ................................... 8-21 Cleaning ...................................................... 8-21
Replacing..................................................... 8-22
Brakes .............................................................. 8-23 Self-adjusting brakes ................................... 8-23
Brake pad wear warning .............................. 8-23
Fuses ................................................................ 8-24 Engine compartment or trunk room.............. 8-24
Passenger compartment............................... 8-25
Intelligent Key battery replacement ................... 8-26
Lights................................................................ 8-29 Headlights ................................................... 8-29
Exterior and interior lights ........................... 8-30
Wheels and tires ............................................... 8-32 Tire pressure ............................................... 8-32
Tire labeling ................................................ 8-36
Types of tires............................................... 8-38
Tire chains ................................................... 8-39
Changing wheels and tires........................... 8-39

8-4Maintenance and do-it-yourself
Accelerator pedal:Check the pedal for
smooth operation and make sure the pedal
does not catch or require uneven effort.
Keep the floor mat away from the pedal.
Automatic transmission P (Park) mechan-
ism: On a fairly steep hill, check that your
vehicle is held securely with the selector
lever in the P (Park) position without
applying any brakes.
Brake pedal: Check the pedal for smooth
operation. If the brake pedal suddenly
goes down further than normal, the pedal
feels spongy or the vehicle seems to take
longer to stop, see an INFINITI retailer
immediately. Keep the floor mat away from
the pedal.
Brakes: Check that the brakes do not pull
the vehicle to one side when applied.
Parking brake: Check the parking brake
operation regularly. The vehicle should be
securely held on a fairly steep hill with only
the parking brake applied. If the parking
brake needs adjusted, see an INFINITI
retailer.
Seat belts: Check that all parts of the seat
belt system (for example, buckles, an-
chors, adjuster and retractors) operate
properly and smoothly, and are installed securely. Check the belt webbing for cuts,
fraying, wear or damage.
Seats:
Check seat position controls such as
seat adjusters, seatback recliner, etc. to
ensure they operate smoothly and that all
latches lock securely in every position.
Check that the head restraints move up
and down smoothly and that the locks (if
so equipped) hold securely in all latched
positions.
Steering wheel: Check for changes in the
steering conditions, such as excessive free
play, hard steering or strange noises.
Warning lights and chimes: Make sure that
all warning lights and chimes are operating
properly.
Windshield defroster: Check that the air
comes out of the defroster outlets properly
and in sufficient quantity when operating
the heater or air conditioner.
Windshield wiper and washer*: Check that
the wipers and washer operate properly
and that the wipers do not streak.
Under the hood and vehicle
The maintenance items listed here should
be checked periodically (for example, each
time you check the engine oil or refuel). 12-volt battery*:
Check the fluid level in
each cell. It should be between the MAX
and MIN lines. Vehicles operated in high
temperatures or under severe condition
require frequent checks of the battery fluid
level.
NOTE:
Care should be taken to avoid situations
that can lead to potential 12-volt battery
discharge and potential no-start condi-
tions such as:
1. Installation or extended use of electro-
nic accessories that consume 12-volt
battery power when the engine is not
running (Phone chargers, GPS, DVD
players, etc.)
2. Vehicle is not driven regularly and/or
only driven short distances.
In these cases, the 12-volt battery may
need to be charged to maintain 12-volt
battery health.
Brake fluid level*: Make sure that the
brake fluid level is between the MAX and
MIN lines on the reservoir.
Engine coolant level*: Check the coolant
level when the engine is cold.
Engine drive belts*: Make sure that no belt

.Try to avoid direct skin contact with used
oil. If skin contact is made, wash
thoroughly with soap or hand cleaner
as soon as possible.
. Keep used engine oil out of reach of
children.When checking or replacement is required,
we recommend an INFINITI retailer for
servicing.
CAUTION
.Use only Genuine NISSAN Matic S ATF.
Do not mix with other fluids.
. Using automatic transmission fluid other
than Genuine NISSAN Matic S ATF will
cause deterioration in driveability and
automatic transmission durability, and
may damage the automatic transmis-
sion, which is not covered by the INFINITI
new vehicle limited warranty.
JVM0054X
Check the fluid level in the reservoir.
The fluid level should be checked using the
HOT range (
*1: HOT MAX.,*2: HOT MIN.)
at fluid temperatures of 122 to 1768F (50
to 808C) or using the COLD range (
*3:
COLD MAX.,
*4: COLD MIN.) at fluid
temperatures of 32 to 868F(0to30 8C).
If the fluid is below the MIN line, add
Genuine NISSAN E-PSF. Remove the cap
and fill through the opening.
Maintenance and do-it-yourself8-15
AUTOMATIC TRANSMISSION FLUID POWER STEERING FLUID

9-2Technical and consumer information
The following are approximate capacities. The actual refill capacities may be a little different. When refilling, follow the procedure
instructed in the“8. Maintenance and do-it-yourself” section to determine the proper refill capacity.
Capacity (Approximate)
Recommended specifications
US measure Imp measure Liter
Fuel 17-7/8 gal 14-7/8 gal 67.4 See “Fuel recommendation”later in this section.
Engine oil*4
Drain and refill
With oil filter change 5-1/8 qt
4-3/8 qt 4.9
.Engine oil with API Certification Mark*1
. Viscosity SAE 5W-30
Without oil filter change 4-7/8 qt 4.0 qt 4.6
Engine cooling system With reservoir 9-1/8 qt7-5/8 qt 8.6 Pre-diluted Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent
Reservoir 7/8 qt3/4 qt 0.8
Inverter cooling system With reservoir 2-3/4 qt2-1/4 qt 2.6
Pre-diluted Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent
Reservoir 1/2 qt
1/2 qt 0.5
Automatic transmission fluid ——— Genuine NISSAN Matic S ATF*2
Differential gear oil ——— API GL-5 Synthetic Gear Oil, Viscosity SAE 75W-90*3
Power steering fluid (PSF) Refill to the proper oil level according to the instructions in the “8.
Maintenance and do-it-yourself” section. Genuine NISSAN E-PSF or equivalent*5
Brake fluid Genuine NISSAN Super Heavy Duty Brake Fluid*6 or equivalent DOT 3
Multi-purpose grease Without limited slip differential NLGI No. 2 (Lithium soap base)
With limited slip differential
Air conditioning system refrigerant ——— HFC-134a (R-134a)*7
Air conditioning system lubricants ——— ND-OIL11
Window washer fluid ——— Genuine NISSAN Windshield Washer Concentrate Cleaner & Antifreeze or equivalent
CAPACITIES AND RECOMMENDED FUEL/
LUBRICANTS

*1:For additional information, see“Engine oil and oil filter recommendation ”later in this section.*2:Using automatic transmission fluid other than Genuine NISSAN Matic S ATF will cause deterioration in driveability and automatic transmission durability, and may damage the automatic
transmission, which is not covered by the INFINITI new vehicle limited warranty.
*3:See an INFINITI retailer for service for synthetic oil.*4:For additional information, see “Engine oil”in the“8. Maintenance and do-it-yourself” section for changing engine oil.*5:Use of a power steering fluid other than Genuine NISSAN E-PSF will prevent the power steering system from operating properly.*6:Available in mainland US through an INFINITI retailer.*7:For additional information, see“Vehicle identification”later in this section for air conditioner specification label.
Technical and consumer information9-3

10 Index
Number
12-volt battery charge warning light ................. 2-11
A
ABS (Anti-lock Braking System) ......................... 5-97
Accelerator downshift - In D (Drive) position - ... 5-16
Active noise control ........................................ 5-103
Active trace control ........................................... 5-99
Adaptive front lighting system (AFS) .................. 2-42
Adjustable headrests .......................................... 1-8
Advanced air bag system .................................. 1-43
Aiming control, Adaptive front lighting
system (AFS) ..................................................... 2-42
Air bag system
Advanced air bag system ............................. 1-43
Front passenger air bag and status light ...... 1-45
Front-seat mounted side-impact
supplemental air bag system ....................... 1-48
Roof-mounted curtain side-impact
supplemental air bag system ....................... 1-48
Air bag warning labels ...................................... 1-51
Air bag warning light ............................... 1-51, 2-17
Air cleaner housing filter ................................... 8-20
Air conditioner Air conditioner service ................................. 4-48
Air conditioner specification label ................ 9-11
Air conditioning system refrigerant and
lubricant recommendations .................. 4-48, 9-7
Automatic climate control ............................ 4-34 In-cabin microfilter ....................................... 4-48
Operation (See automatic climate control) .... 4-34
Air filter In-cabin microfilter ....................................... 4-48
Air vent ............................................................... 7-5
Alarm How to stop alarm (see vehicle
security system) ........................................... 2-35
Alcohol, drugs and driving .................................. 5-8
Antenna ............................................................ 4-87
Anti-lock Braking System (ABS) ......................... 5-97
Anti-lock braking system (ABS) warning light .... 2-11
Appearance care Exterior appearance care ................................ 7-2
Interior appearance care ................................ 7-4
Approaching Vehicle Sound for Pedestrians
(VSP) system .................................. Hybrid System-9
Armrest ............................................................. 1-10
Ashtrays (See cigarette lighter and ashtrays) .... 2-52
Assist charge gauge ................. Hybrid System-5, 2-8
Audible reminders ............................................ 2-20
Audio operation precautions ............................. 4-49
Audio system .................................................... 4-49
Steering wheel audio controls ...................... 4-85
Auto closure ..................................................... 3-20
Autolight system ............................................... 2-40
Automatic Automatic climate control .................. 4-37, 4-41
Automatic transmission fluid (ATF) ............... 8-15
Climate control ............................................ 4-34 Door locks ..................................................... 3-6
Drive positioner ........................................... 3-28
Driving with automatic transmission ............ 5-13
Seat positioner ............................................ 3-28
Automatic moonroof.......................................... 2-60
Average fuel consumption and speed ................ 2-31
Avoiding collision and rollover ............................ 5-7
B
Battery .............................................................. 8-18
Battery replacement, Intelligent Key ............... 3-2
Battery saver system ................................... 2-41
Intelligent Key .............................................. 8-26
Before starting the INFINITI Direct Response
Hybrid
TMSystem ............................................... 5-12
Blind Spot Intervention (BSI) ON
indicator light ................................................... 2-18
Blind Spot Warning (BSW) system/Blind Spot
Intervention
TM(BSI) system ............................... 5-31
Blind Spot Warning (BSW)/Blind Spot
Intervention (BSI) system warning light ............. 2-11
Bluetooth
®hands-free phone system
(models with navigation system) ....................... 4-88
Bluetooth
®hands-free phone system
(models without navigation system) .................. 4-98
Booster seats .................................................... 1-35
Brake Anti-lock Braking System (ABS) .................... 5-97
Brake fluid ................................................... 8-16

10-2
Brake force distribution ............................... 5-99
Brake system ............................................... 5-94
Brake system warning light (yellow) ............. 2-12
Brake warning light (red) ............................. 2-12
Parking brake operation ............................... 5-18
Brake assist ...................................................... 5-95
Break-in schedule ............................................. 5-89
Brightness control Display ON/OFF button ................................ 4-10
Instrument panel ......................................... 2-44
BSI system operation ........................................ 5-35
BSW system operation ...................................... 5-33
Bulb check/instrument panel ............................ 2-11
Bulb replacement .............................................. 8-29
C
Cabin air filter ................................................... 4-48
Capacities and recommended fuel/lubricants ...... 9-2
Car phone or CB radio ...................................... 4-87
Card holder ....................................................... 2-56
Catalytic converter Three way catalyst ......................................... 5-4
CD/CF/USB memory care and cleaning ............. 4-84
Center multi-function control panel ..................... 4-4
Changing inverter coolant ................................. 8-12
Check tire pressure warning .............................. 2-25
Checking battery fluid level ............................... 8-19
Checking inverter coolant level ......................... 8-12
Child restraints ................................................. 1-20 Booster seats ............................................... 1-35
LATCH system .............................................. 1-22 Precautions on child restraints ..................... 1-20
Child safety ...................................................... 1-18
Child safety rear door lock .................................. 3-6
Chimes
Audible reminders ....................................... 2-20
Seat belt warning light and chime ............... 2-16
Cigarette lighter and ashtrays ........................... 2-52
Circuit breaker Fusible link .................................................. 8-24
Cleaning exterior and interior ....................... 7-2, 7-4
Climate control Automatic climate control ............................ 4-34
Clock ................................................................ 2-51
Coat hooks ....................................................... 2-57
Cockpit ........................................................ 0-6, 2-3
Cold weather driving ....................................... 5-101
Compact Disc (CD) player (See audio system) ... 4-68
Compact spare tire ........................................... 8-41
Console box ...................................................... 2-55
Controller Center multi-function control panel ................ 4-6
Controls
Control panel button ...................................... 4-4
INFINITI Controller .......................................... 4-6
Coolant
Capacities and recommended
fuel/ lubricants .............................................. 9-2
Changing engine coolant ............................. 8-10
Checking engine coolant level ...................... 8-10
Corrosion protection ........................................... 7-7
Cruise control ................................................... 5-44 Fixed speed cruise control (on ICC system) ... 5-65
Intelligent cruise control (ICC) system .......... 5-46
Cruise indicator ................................................ 2-26 Cup holders ...................................................... 2-53
Current fuel consumption .................................. 2-31
D
Daytime running light system ........................... 2-42
Defroster switch
Rear window and outside mirror
defroster switch ........................................... 2-39
Dimensions ......................................................... 9-9
Direct Response Hybrid
TMSystem warning
light ................................................................ 2-13
Display cleaning ................................................. 4-8
Display controls (See center multi-function
control panel) ..................................................... 4-4
Distance Control Assist (DCA) system ................ 5-68
Distance Control Assist (DCA) system
switch indicator ................................................ 2-27
Distance Control Assist (DCA) system
warning light .................................................... 2-13
Distance to empty ............................................. 2-31
Dot matrix liquid crystal display ....................... 2-21
Drive positioner ................................................ 3-28
Driving Cold weather driving .................................. 5-101
Driving with automatic transmission ............ 5-13
Precautions when starting and driving ........... 5-3
Driving the vehicle ............................................ 5-13
DVD player operation ........................................ 4-69

E
ECO drive indicator light ................................... 2-18
ECO mode ......................................................... 5-19
ECO pedal system ............................................. 5-20
Economy
Fuel ............................................................. 5-89
Efficient use of your vehicle ............ Hybrid System-8
Elapsed time ..................................................... 2-31
Elapsed time and trip odometer ........................ 2-31
Emergency hybrid system shut off ...................... 6-2
Emergency shut-off system ............. Hybrid System-4
Emission control information label .................... 9-11
Emission control system warranty ..................... 9-18
Energy flow ............................ Hybrid System-5, 4-11
Energy monitor ................................................. 2-29
Energy monitors .............................. Hybrid System-5
Engine Before starting the INFINITI Direct Response
Hybrid
TMSystem .......................................... 5-12
Break-in schedule ........................................ 5-89
Capacities and
recommended fuel/lubricants ........................ 9-2
Changing engine coolant ............................. 8-10
Changing engine oil and filter ...................... 8-13
Checking engine coolant level ...................... 8-10
Checking engine oil level ............................. 8-12
Emergency engine shut off ........................... 5-11
Engine block heater ................................... 5-102
Engine compartment check locations ............. 8-7
Engine cooling system ................................... 8-9 Engine oil .................................................... 8-12
Engine oil and oil filter recommendation ........ 9-6
Engine oil replacement indicator .................. 2-27
Engine oil viscosity ........................................ 9-7
Engine serial number ................................... 9-10
Engine specifications ..................................... 9-8
If your vehicle overheats .............................. 6-12
Starting the INFINITI Direct Response
Hybrid
TMSystem .......................................... 5-13
Engine coolant temperature gauge .................... 2-32
Entry/exit function Automatic drive positioner ........................... 3-28
EV mode odometer and twin trip odometer ....... 2-31
Event Data Recorders (EDR) ............................... 9-21
Exhaust gas (carbon monoxide) .......................... 5-3
F
F.M.V.S.S./C.M.V.S.S. certification label ............. 9-10
Fail-safe ............................................................ 5-16
Filter Air cleaner housing filter .............................. 8-20
Changing engine oil and filter ...................... 8-13
Flashers (See hazard warning flasher switch) .... 2-45
Flat tire ............................................................... 6-2
Flat towing ........................................................ 9-17
Floor mat ............................................................ 7-6
Fluid
Automatic transmission fluid (ATF) ............... 8-15
Brake fluid ................................................... 8-16
Capacities and
recommended fuel/lubricants ........................ 9-2 Engine coolant ............................................... 8-9
Engine oil .................................................... 8-12
Power steering fluid ..................................... 8-15
Window washer fluid ................................... 8-17
FM-AM-SAT radio with Compact Disc
(CD) player ........................................................ 4-65
Fog light switch ................................................ 2-44
Forest Air
TM....................................................... 4-43
Forward Collision Warning (FCW) system ........... 5-81
Front passenger air bag and status light ........... 1-45
Front power seat adjustment ............................... 1-3
Front seat Front seat adjustment .................................... 1-3
Front-seat active head restraints ......................... 1-7
Fuel Capacities and
recommended fuel/lubricants ........................ 9-2
Fuel economy............................................... 5-89
Fuel economy information (display) .............. 4-12
Fuel octane rating .......................................... 9-4
Fuel recommendation ..................................... 9-4
Fuel-filler cap ............................................... 3-22
Fuel-filler door ............................................. 3-22
Gauge ............................................................ 2-8
Fuel economy history ...................... Hybrid System-7
Fuses ................................................................ 8-24
Fusible links ..................................................... 8-24
G
Garage door opener
HomeLink®Universal Transceiver ................. 2-66
10-3

10-8
Status light, Front passenger air bag ................ 1-45
SteeringHeated steering wheel ................................. 2-45
Power steering fluid ..................................... 8-15
Power steering system ................................. 5-93
Steering lock release
malfunction indicator ................................... 2-24
Steering-wheel-mounted controls
for audio ...................................................... 4-85
Tilt/telescopic steering ................................. 3-24
Steering lock (if so equipped) ........................... 5-10
Storage ............................................................. 2-53
Streaming audio via Bluetooth
®(models with
navigation system) ............................................ 4-77
Sun visors ........................................................ 3-25
Sunglasses holder ............................................ 2-54
Sunshade (rear) ................................................ 2-62
Supplemental air bag warning labels ................ 1-51
Supplemental air bag warning light ......... 1-51, 2-17
Supplemental restraint system .......................... 1-38 Precautions on supplemental
restraint system ........................................... 1-38
Switch Autolight switch ........................................... 2-40
Fog light switch ........................................... 2-44
Hazard warning flasher switch ..................... 2-45
Headlight switch .......................................... 2-40
Ignition switch ............................................. 5-13
Ignition switch automatic
transmission models .................................... 5-13
Intelligent Brake Assist (IBA) OFF switch ...... 2-49 Power door lock switch .................................. 3-5
Rear window and outside mirror
defroster switch ........................................... 2-39
Turn signal switch ........................................ 2-44
Vehicle dynamic control (VDC) off switch ...... 2-50
Warning systems switch ............................... 2-49
T
Tachometer ......................................................... 2-8
Theft (INFINITI Vehicle Immobilizer System) Engine start ................................................. 2-35
Three-way catalyst .............................................. 5-4
Tilt/telescopic steering ...................................... 3-24
“TIMER” indicator.............................................. 2-26
Tire pressure
Low tire pressure warning light .................... 2-15
Tires Flat tire .......................................................... 6-2
Low tire pressure warning system ... 5-4, 6-2, 8-32
Spare tire .................................................... 8-41
Tire and Loading information label ...... 8-34, 9-11
Tire chains ................................................... 8-39
Tire dressing .................................................. 7-4
Tire pressure................................................ 8-32
Tire pressure information (display) ............... 4-12
Tire pressure monitoring
system (TPMS) .............................. 5-4, 6-2, 8-32
Tire replacement indicator ............................ 2-27
Tire rotation ................................................. 8-39
Types of tires ............................................... 8-38
Uniform tire quality grading ......................... 9-17 Wheel/tire size .............................................. 9-8
Wheels and tires .......................................... 8-32
Touch screen system ........................................... 4-6
Towing
Flat towing ................................................... 9-17
Tow truck towing .......................................... 6-13
Towing a trailer ............................................ 9-17
TPMS Tire pressure monitoring system ... 5-4, 6-2, 8-32
Tire pressure warning system ....... 5-4, 6-2, 8-32
Trailer towing .................................................... 9-17
Transceiver HomeLink
®Universal Transceiver ................. 2-66
Transmission Automatic transmission fluid (ATF) ............... 8-15
Driving with automatic transmission ............ 5-13
Transmission selector lever lock release ...... 5-17
Transmitter (See remote keyless entry system) ... 3-14
Traveling or registering your vehicle in
another country .................................................. 9-9
Trip computer ................................................... 2-29
Trip odometer ................................................... 2-31
Trunk Interior trunk lid release .............................. 3-21
Light ............................................................ 2-66
Trunk hooks ................................................. 2-57
Trunk lid ...................................................... 3-18
Trunk lid release switch ............................... 3-19
Trunk open request switch ........................... 3-19
Trunk release power cancel switch ............... 3-20
Turn signal switch ............................................. 2-44
