Page 8 of 394
0 Illustrated table of contents
Seats, seat belts and Supplemental Restraint
System (SRS) ....................................................... 0-2
Exterior front ....................................................... 0-3
Exterior rear......................................................... 0-4
Passenger compartment ...................................... 0-5
Cockpit ................................................................ 0-6 Instrument panel................................................. 0-8
Meters and gauges ............................................. 0-9
Engine compartment ......................................... 0-10
VQ37VHR engine ......................................... 0-10
Warning and indicator lights ............................. 0-11
Page 13 of 394
0-6Illustrated table of contents
JVC0426X
1. Side ventilator (P.4-2)
2. Headlight, fog light and turn signalswitch (P.2-36)
3. Steering wheel —Horn (P.2-43) —
Driver supplemental air bag
(P.1-42)
— Heated steering wheel (if so
equipped)*
— Steering system (P.5-104) 4. Windshield wiper and washer switch
(P.2-33)
5. Hazard warning flasher switch (P.6-2)
6. Shift lever (P.5-15)
7. INFINITI controller*
8. Vehicle Dynamic Control (VDC) OFF switch (P.2-43, P.5-108)
9. Trunk lid release switch (P.3-19)
10. Instrument brightness control switch (P.2-42)
11. TRIP/RESET switch for twin trip od- ometer (P.2-7)
12. Electric tilting/telescopic steering wheel switch (if so equipped)
(P.3-24)
13. Manual tilting/telescopic steering wheel lever (if so equipped) (P.3-24)
14. Steering-wheel-mounted controls (left side)
—Audio control steering switch*
— Hands-Free Phone System switch*
— Voice recognition system switch*
15. Steering-wheel-mounted controls (right side)
—Trip computer switches (P.2-28)
— Cruise control switches (if so
equipped) (P.5-56)
COCKPIT
Page 16 of 394
JVC0428X
1. Tachometer (P.2-8)
2. Warning/Indicator lights (P.2-12)
3. Speedometer (P.2-7)
4. Engine coolant temperature gauge(P.2-8)
5. Vehicle information display (P.2-20)/ Odometer/twin trip odometer (P.2-7)
6. Fuel gauge (P.2-9)
Illustrated table of contents0-9
METERS AND GAUGES
Page 18 of 394
Warninglight Name
Page
Anti-lock Braking System (ABS)
warning light 2-12
Brake warning light
2-13
Charge warning light2-13
Forward emergency braking
system warning light* 2-13
Low fuel warning light
2-14
Low tire pressure warning light 2-14
Master warning light 2-16
Power steering warning light* 2-16
Seat belt warning light 2-16
Supplemental air bag warning
light 2-16
Vehicle Dynamic Control (VDC)
warning light2-17Indicator
light Name
Page
ECO drive indicator light
2-17
Exterior light indicator2-17
Front fog light indicator light
2-17
Front passenger air bag status
light2-17
High beam assist indicator
light*2-18
High beam indicator light
2-18
Malfunction Indicator Light
(MIL)2-18
Security indicator light 2-19
Turn signal/hazard indicator
lights
2-19
Vehicle Dynamic Control (VDC)
off indicator light2-19
*: if so equipped
Illustrated table of contents0-11
WARNING AND INDICATOR LIGHTS
Page 20 of 394
1 Safety—Seats, seat belts and supplemental
restraint system
Seats................................................................... 1-2
Front seats ...................................................... 1-3
Rear seats ....................................................... 1-5
Armrest ........................................................... 1-7
Head restraints/headrests ................................... 1-8 Adjustable head
restraint/headrest components........................ 1-9
Non-adjustable head
restraint/headrest components........................ 1-9
Remove ........................................................... 1-9
Install............................................................ 1-10
Adjust ........................................................... 1-10
Seat belts .......................................................... 1-12
Precautions on seat belt usage ..................... 1-12
Pregnant women ........................................... 1-14
Injured persons ............................................. 1-14
Pre-crash seat belts with comfort function
(front seats) (if so equipped) ......................... 1-14
Three-point type seat belt ............................. 1-15
Seat belt extenders ....................................... 1-21
Seat belt maintenance................................... 1-21
Child safety ....................................................... 1-22 Infants........................................................... 1-23
Small children ............................................... 1-23
Larger children .............................................. 1-23 Child restraints ................................................. 1-24
Precautions on child restraints..................... 1-24
Lower Anchors and Tethers for CHildren
System (LATCH) ............................................ 1-26
Rear-facing child restraint installation
using LATCH................................................. 1-28
Rear-facing child restraint installation using
the seat belts .............................................. 1-30
Forward-facing child restraint installation
using LATCH................................................. 1-33
Forward-facing child restraint installation
using the seat belts ..................................... 1-35
Installing top tether strap ............................ 1-38
Booster seats .............................................. 1-39
Supplemental restraint system .......................... 1-42 Precautions on supplemental
restraint system........................................... 1-42
INFINITI Advanced Air Bag System
(front seats) ................................................. 1-47
Front seat-mounted side-impact supplemental
air bag and roof-mounted curtain side-impact
supplemental air bag systems ..................... 1-52
Seat belts with pretensioners (front seats).... 1-54
Supplemental air bag warning labels ........... 1-55
Supplemental air bag warning light ............. 1-55
Repair and replacement procedure............... 1-56
Page 32 of 394
SSS0016
SSS0014
WARNING
.Every person who drives or rides in this
vehicle should use a seat belt at all
times. Children should be properly re-
strained in the rear seat and, if appro-
priate, in a child restraint.
. The seat belt should be properly ad-
justed to a snug fit. Failure to do so may
reduce the effectiveness of the entire
restraint system and increase the chance
or severity of injury in an accident.
Serious injury or death can occur if the
seat belt is not worn properly.
. Always route the shoulder belt over your
shoulder and across your chest. Never
run the belt behind your back, under
your arm or across your neck. The belt
should be away from your face and neck,
but not falling off your shoulder.
. Position the lap belt as low and snug as
possible AROUND THE HIPS, NOT THE
WAIST. A lap belt worn too high could
increase the risk of internal injuries in an
accident.
. Be sure the seat belt tongue is securely
fastened to the proper buckle. .
Do not wear the seat belt inside out or
twisted. Doing so may reduce its effec-
tiveness.
. Do not allow more than one person to
use the same seat belt.
. Never carry more people in the vehicle
than there are seat belts.
. If the seat belt warning light glows
continuously while the ignition is turned
ON with all doors closed and all seat
belts fastened, it may indicate a mal-
function in the system. Have the system
checked by an INFINITI retailer.
. No changes should be made to the seat
belt system. For example, do not modify
the seat belt, add material or install
devices that may change the seat belt
routing or tension. Doing so may affect
the operation of the seat belt system.
Modifying or tampering with the seat
belt system may result in serious perso-
nal injury.
. Once a seat belt pretensioner has
activated, it cannot be reused and must
be replaced together with the retractor.
See an INFINITI retailer.
. Removal and installation of the preten-
sioner seat belt system components
Safety —Seats, seat belts and supplemental restraint system1-13
Page 49 of 394
1-30Safety—Seats, seat belts and supplemental restraint system
applicable). Not all child restraints fit in
all types of vehicles.
5. Check to make sure the child restraint is properly secured prior to each use. If
the child restraint is loose, repeat steps
1 through 4.
SSS0100
REAR-FACING CHILD RESTRAINT IN-
STALLATION USING THE SEAT BELTS
WARNING
. The three-point seat belt with Automatic
Locking Retractor (ALR) must be used
when installing a child restraint. Failure
to use the ALR mode will result in the
child restraint not being properly se-
cured. The restraint could tip over or be
loose and cause injury to a child in a
sudden stop or collision. Also, it can
change the operation of the front pas- senger air bag. See
“Front passenger air
bag and status light” (P.1-49).
. When installing a child restraint system
in the rear center position, both the
center seat belt connector tongue and
buckle tongue must be secured (for
models with rear seat folding). See
“Rear center seat belt (models with rear
seat folding)” (P.1-18).
Page 54 of 394
7. Check to make sure the child restraintis properly secured prior to each use. If
the child restraint is loose, repeat steps
1 through 6.
FORWARD-FACING CHILD RESTRAINT
INSTALLATION USING THE SEAT
BELTS
WARNING
. The three-point seat belt with Automatic
Locking Retractor (ALR) must be used
when installing a child restraint. Failure
to use the ALR mode will result in the
child restraint not being properly se-
cured. The restraint could tip over or be
loose and cause injury to a child in a
sudden stop or collision. Also, it can
change the operation of the front pas-
senger air bag. See “Front passenger air
bag and status light” (P.1-49).
. When installing a child restraint system
in the rear center position, both the
center seat belt connector tongue and
buckle tongue must be secured (for
models with rear seat folding). See
“Rear center seat belt (models with rear seat folding)”
(P.1-18).
SSS0640
Forward-facing (front passenger seat) —
step 1
Refer to all Warnings and Cautions in the
“Child safety” and“Child restraints” sec-
tions before installing a child restraint.
Follow these steps to install a forward-
facing child restraint using the vehicle seat
belt in the rear seats or in the front
passenger seat:
1. If you must install a child restraint in
the front seat, it should be placed in a
forward-facing direction only. Move the
seat to the rearmost position. Child
restraints for infants must be used in
the rear-facing direction and, therefore,
must not be used in the front seat.
Safety —Seats, seat belts and supplemental restraint system1-35
Page 57 of 394
1-38Safety—Seats, seat belts and supplemental restraint system
9. Check to make sure the child restraint
is properly secured prior to each use. If
the seat belt is not locked, repeat steps
2 through 8.
JVR0192X
Forward-facing —step 10
10. If the child restraint is installed in the
front passenger seat, place the ignition
switch in the ON position. The front
passenger air bag status light
should illuminate. If this light is not
illuminated, see “Front passenger air
bag and status light” (P.1-49).Move
the child restraint to another seating
position. Have the system checked by
an INFINITI retailer.
After the child restraint is removed and the
seat belt is fully retracted, the ALR mode
(child restraint mode) is canceled.
JVR0258X
INSTALLING TOP TETHER STRAP
WARNING
Child restraint anchorages are designed to
withstand only those loads imposed by
correctly fitted child restraints. Under no
circumstances are they to be used to attach
adult seat belts, or other items or equip-
ment to the vehicle. Doing so could damage
the child restraint anchorages. The child
restraint will not be properly installed using
the damaged anchorage, and a child could
be seriously injured or killed in a collision.
Page 61 of 394
1-42Safety—Seats, seat belts and supplemental restraint system
JVR0192X
7. If the booster seat is installed in the
front passenger seat, push the ignition
switch to the ON position. The front
passenger air bag status light
may
or may not illuminate depending on the
size of the child and the type of booster
seat used. See “Front passenger air
bag and status light” (P.1-49).
PRECAUTIONS ON SUPPLEMENTAL
RESTRAINT SYSTEM
This Supplemental Restraint System (SRS)
section contains important information
concerning the following systems:
.Driver and passenger front-impact sup-
plemental air bags (INFINITI Advanced
Air Bag System)
. Front seat-mounted side-impact supple-
mental air bag
. Roof-mounted curtain side-impact sup-
plemental air bag
. Seat belt with pretensioner
Supplemental front-impact air bag system:
The INFINITI Advanced Air Bag System can
help cushion the impact force to the head
and chest of the driver and front passenger
in certain frontal collisions.
Front seat-mounted side-impact supple-
mental air bag system: This system can
help cushion the impact force to the chest
and pelvis area of the driver and front
passenger in certain side impact collisions.
The side air bag is designed to inflate on
the side where the vehicle is impacted.
Roof-mounted curtain side-impact supple-
mental air bag system: This system can
help cushion the impact force to the head of occupants in front and rear outboard
seating positions in certain side impact
collisions. The curtain air bags are de-
signed to inflate on the side where the
vehicle is impacted.
These supplemental restraint systems are
designed to
supplementthe crash protec-
tion provided by the driver and passenger
seat belts and are not a substitutefor
them. Seat belts should always be cor-
rectly worn and the occupant seated a
suitable distance away from the steering
wheel, instrument panel and door fin-
ishers. (See “Seat belts” (P.1-12) for
instructions and precautions on seat belt
usage.)
The supplemental air bags operate only
when the ignition switch is in the ON
position.
After pushing the ignition switch to the ON
position, the supplemental air bag warn-
ing light illuminates. The supplemental air
bag warning light will turn off after about
7 seconds if the systems are operational.
SUPPLEMENTAL RESTRAINT SYSTEM
