6 In case of emergency
Hazard warning flasher switch ..................................... 6-2
Roadside assistance program ........................................ 6-2
Emergency INFINITI Direct Response Hybrid
®
System shut off ................................................................. 6-3
Flat tire ........................................................................\
......... 6-3Tire Pressure Monitoring System (TPMS) ............ 6-3
Run-flat tires ................................................................. 6-4 If the vehicle does not start .......................................... 6-5
Confirm battery is discharged ................................ 6-5
Jump starting ..................................................................... 6-5
Push starting ....................................................................... 6-7
If your vehicle overheats ................................................ 6-8
Towing your vehicle ......................................................... 6-9
Towing recommended by INFINITI .................... 6-10
Vehicle recovery (freeing a stuck vehicle) ......... 6-11
Page 331 of 440
unnecessary electrical systems (light,
heater, air conditioner, etc.).
3. Connect jumper cables in the sequence as illustrated (
???).
CAUTION
.Always connect positive (+) to posi-
tive (+) and negative (−) to body
ground (as illustrated) − not to the
12-volt battery.
. Make sure the jumper cables do not
touch moving parts in the engine
compartment and that clamps do
not contact any other metal.
4. Start the engine of the booster vehicle
and let it run for a few minutes.
5. Start the hybrid system of the vehicle being jump started
.
CAUTION
If the hybrid system does not start right
away, push the ignition switch to the
OFF position and wait 10 seconds
before trying again. 6. After starting your hybrid system, care-
fully disconnect the negative cable and
then the positive cable (
???).
NOTE:
If it is not possible to turn the hybrid system
ON by following this procedure, it is
recommended that you contact an INFINITI
retailer immediately. Do not attempt to start the engine by
pushing.CAUTION
.
Automatic Transmission (AT) models
cannot be push-started or tow-
started. Attempting to do so may
cause transmission damage.
. Three-way catalyst equipped models
should not be started by pushing
since the three-way catalyst may be
damaged.
. Never try to start the vehicle by
towing it; when the engine starts,
the forward surge could cause the
vehicle to collide with the tow vehi-
cle.
. Hybrid models cannot be push-
started or tow-started. Attempting
to do so may cause electrical or
transmission damage.
In case of emergency6-7
PUSH STARTING
Page 333 of 440
When towing your vehicle, all State (Pro-
vincial in Canada) and local regulations for
towing must be followed. Incorrect towing
equipment could damage your vehicle. Tow-
ing instructions are available from an
INFINITI retailer. Local service operators
are familiar with the applicable laws and
procedures for towing. To assure proper
towing and to prevent accidental damage to
your vehicle, INFINITI recommends that you
have a service operator tow your vehicle. It is
advisable to have the service operator care-
fully read the following precautions.
WARNING
.Never ride in a vehicle that is being
towed.
. Never get under your vehicle after it
has been lifted by a tow truck.
CAUTION
.When towing, make sure that the
transmission, axles, steering system
and powertrain are in working con-
dition. If any unit is damaged, dollies
must be used.
. Always attach safety chains before towing.
For information about towing your vehicle
behind a recreational vehicle (RV), see “Flat
towing” (P.10-18).
In case of emergency6-9
TOWING YOUR VEHICLE
Page 334 of 440
6-10In case of emergency
SCE0788
Two-Wheel Drive (2WD) models
TOWING RECOMMENDED BY
INFINITI
Two-Wheel Drive (2WD) models
INFINITI recommends that your vehicle be
towed with the driving (rear) wheels off the
ground or place the vehicle on a flat bed
truck as illustrated. The vehicle should only
be loaded onto a flat bed using a winch.
WARNING
If your vehicle needs to be towed, do it
with the rear wheels raised. If the rearwheels are on the ground when towing,
the electric motor may generate electri-
city. This may damage the INFINITI
Direct Response Hybrid
®System com-
ponents and cause a fire.
CAUTION
. Never tow automatic transmission
models with the rear wheels on the
ground or four wheels on the ground
(forward or backward), as this may
cause serious and expensive damage to the transmission. If it is necessary
to tow the vehicle with the front
wheels raised, always use towing
dollies under the rear wheels.
. When towing rear wheel drive models
with the front wheels on the ground
or on towing dollies: Push the ignition
switch to the ACC or ON position,
and secure the steering wheel in a
straight-ahead position with a rope
or similar device.
Page 335 of 440
SCE0488
All-Wheel Drive (AWD) models
Intelligent All-Wheel Drive (AWD)
models
INFINITI recommends that towing dollies be
used when towing your vehicle or the vehicle
be placed on a flat bed truck as illustrated.
The vehicle should only be loaded onto a flat
bed using a winch.
CAUTION
Never tow Intelligent AWD models with
any of the wheels on the ground as this
may cause serious and expensive da-
mage to the powertrain.
VEHICLE RECOVERY (freeing a
stuck vehicle)
There are two options to recover a stuck
vehicle: pulling and rocking. For additional
information regarding these options, please
refer to the following sections.
Pulling a stuck vehicle
WARNING
To avoid vehicle damage, serious perso-
nal injury or death when recovering a
stuck vehicle:
.Contact a professional towing ser-
vice to recover the vehicle if you have
any questions regarding the recovery
procedure.
. Do not use the vehicle tie-downs to
tow or free a stuck vehicle.
. Only use devices specifically designed
for vehicle recovery and follow the
manufacturer’s instructions.
. Always pull the recovery device
straight out from the front of the
vehicle. Never pull at an angle.
. Route recovery devices so they do
not touch any part of the vehicle
In case of emergency6-11
Page 336 of 440
6-12In case of emergency
except the attachment point.
If your vehicle is stuck in sand, snow, mud,
etc., use a tow strap or other device
designed specifically for vehicle recovery.
Always follow the manufacturer’s instruc-
tions for the recovery device.
NOTE:
Do not use the tie-down hooks for towing
or vehicle recovery.
Rocking a stuck vehicle
If your vehicle is stuck in sand, snow, mud,
etc., use the following procedure:
1. Turn off the Vehicle Dynamic Control (VDC) system.
2. Make sure the area in front and behind the vehicle is clear of obstructions.
3. Turn the steering wheel right and left to clear an area around the front tires.
4. Slowly rock the vehicle forward and backward.
.Shift back and forth between R (Re-verse) and D (Drive).
.Apply the accelerator as little aspossible to maintain the rocking mo-
tion.
.Release the accelerator pedal before shifting between R and D.
.Do not spin the tires above 35 MPH(55 km/h).
5. If the vehicle cannot be freed after a few tries, contact a professional towing
service to remove the vehicle.
WARNING
.Stand clear of a stuck vehicle.
. Do not spin your tires at high speed.
This could cause them to explode and
result in serious injury. Parts of your
vehicle could also overheat and be
damaged.
