4-126Monitor, climate, audio, phone and voice recognition systems
SAA2549
Speaker adaptation function (for
Alternate Command Mode)
The voice recognition system has a func-
tion to learn the user’s voice for better
voice recognition performance. The system
can memorize the voices of up to three
persons.
Having the system learn the user’s voice:
1. Push the SETTING button on the instru- ment panel and select the “Others”
key.
2. Select the “Voice Recognition” key.
3. Select the “Speaker Adaptation” key.
SAA2550
4. Select the user whose voice is memor-
ized by the system.
5. Select the “Start Speaker Adaptation
Learning” key.
SAA2551
6. Select a category to be learned by the
system from the following list.
.Phone Commands.Navigation Commands.Information Commands.Audio Commands.Help Commands
The voice commands in the category
are displayed.
7. Select a voice command and then push the ENTER button.
The voice recognition system starts.

TROUBLESHOOTING GUIDE
The system should respond correctly to all voice commands without difficulty. If problems are encountered, follow the solutions given in
this guide for the appropriate error.
Where the solutions are listed by number, try each solution in turn, starting with number one, until the problem is resolved.
Symptom/error messageSolution
The system fails to interpret the command correctly. 1. Ensure that the command format is valid, see“Command List”(P.4-108).
2. Speak clearly without pausing between words and at a level appropriate to the ambient noise level.
3. Ensure that the ambient noise level is not excessive, for example, windows open or defrost on.
NOTE:
If it is too noisy to use the phone, it is likely that voice commands will not be recognized.
4. If optional words of the command have been omitted, then the command should be tried with these in place.
The system consistently selects the wrong voicetag in
the phonebook. 1. Ensure that the voicetag requested matches what was originally stored. (See
“Bluetooth
®Hands-Free Phone
System (models with navigation system)” (P.4-77).)
2. Replace one of the voicetags being confused with a different voicetag.
Monitor, climate, audio, phone and voice recognition systems4-129

6. Plan for the shortest route..Utilize a map or navigation system todetermine the best route to save
time.
7. Avoid idling.
.Shutting off your engine when safe for stops exceeding 30-60 seconds
saves fuel and reduces emissions.
8. Buy an automated pass for toll roads.
.Automated passes permit drivers to use special lanes to maintain cruis-
ing speed through the toll and avoid
stopping and starting.
9. Winter warm up.
.Limit idling time to minimize impact to fuel economy.
.Vehicles typically need no more than30 seconds of idling at start-up to
effectively circulate the engine oil
before driving.
.Your vehicle will reach its ideal
operating temperature more quickly
while driving versus idling.
10. Keeping your vehicle cool.
.Park your vehicle in a covered
parking area or in the shade when-
ever possible.
.When entering a hot vehicle, open- ing the windows will help to reduce
the inside temperature faster, result-
ing in reduced demand on your A/C
system. .
Keep your engine tuned up.
. Follow the recommended scheduled
maintenance.
. Keep the tires inflated to the correct
pressure. Low tire pressure increases
tire wear and lowers fuel economy.
. Keep the wheels in correct alignment.
Improper alignment increases tire wear
and lowers fuel economy.
. Use the recommended viscosity engine
oil. (See “Engine oil and oil filter
recommendation” (P.9-6).)
Starting and driving5-47
INCREASING FUEL ECONOMY

10 Index
A
ABS (Anti-lock Braking System) ......................... 5-57
Advanced air bag system .................................. 1-43
Air bag systemAdvanced air bag system ............................. 1-43
Front passenger air bag and status light ...... 1-45
Front-seat mounted side-impact supplemental
air bag system ............................................. 1-48
Roof-mounted curtain side-impact
supplemental air bag system ....................... 1-48
Air bag warning labels ...................................... 1-51
Air bag warning light ............................... 1-51, 2-17
Air cleaner housing filter ................................... 8-20
Air conditioner
Air conditioner service ................................. 4-38
Air conditioner specification label ................ 9-12
Air conditioning system refrigerant and
lubricant recommendations ................... 4-38, 9-7
Automatic climate control ............................ 4-31
In-cabin microfilter ....................................... 4-38
Alarm, How to stop alarm (see vehicle
security system) ................................................ 2-29
Alcohol, drugs and driving .................................. 5-8
All-wheel drive (AWD) ........................................ 5-48
All-wheel drive (AWD) driving
safety precautions .............................................. 5-8
All-wheel drive (AWD) warning light .................. 2-12
Antenna ............................................................ 4-76
Anti-lock Braking System (ABS) ......................... 5-57
Anti-lock braking system (ABS) warning light .... 2-13 Appearance care
Exterior appearance care ................................ 7-2
Interior appearance care ................................ 7-4
Ashtrays (See cigarette lighter and ashtrays) .... 2-43
Audible reminders ............................................ 2-19
Audio operation precautions ............................. 4-39
Audio system .................................................... 4-39
Steering wheel audio controls ...................... 4-74
Autolight system ............................................... 2-35
Automatic Automatic adjusting function
(front windows) ............................................ 2-52
Automatic climate control ............................ 4-32
Automatic transmission fluid (ATF) ............... 8-12
Climate control ............................................ 4-31
Door locks ..................................................... 3-5
Drive positioner ........................................... 3-28
Driving with automatic transmission ............ 5-14
Moonroof ..................................................... 2-53
Seat positioner ............................................ 3-28
Average fuel consumption and speed ................ 2-26
Avoiding collision and rollover ............................ 5-6
B
Battery .............................................................. 8-15 Battery saver system ................................... 2-37
Intelligent Key .............................................. 8-25
Variable voltage control system ................... 8-18
Before starting the engine ................................ 5-12 Belts (See drive belts) ....................................... 8-18
Bluetooth
®hands-free phone system
(models with navigation system) ....................... 4-77
Bluetooth
®hands-free phone system
(models without navigation system) .................. 4-87
Bluetooth
®streaming audio ............................. 4-66
Brake Anti-lock Braking System (ABS) .................... 5-57
Brake and clutch fluid .................................. 8-13
Brake fluid ................................................... 8-14
Brake system ............................................... 5-53
Parking brake operation ............................... 5-21
Warning light ............................................... 2-13
Break-in schedule ............................................. 5-46
Brightness control Display ON/OFF button .................................. 4-9
Instrument panel ......................................... 2-38
Bulb check/instrument panel ............................ 2-12
Bulb replacement .............................................. 8-27
C
Cabin air filter ................................................... 4-38
Capacities and recommended fuel/lubricants ...... 9-2
Car phone or CB radio ...................................... 4-76
Card holder ....................................................... 2-48
Cargo net retainers ........................................... 2-50
Catalytic converter, Three way catalyst ................ 5-4
CD/CF/USB memory care and cleaning ............. 4-73
Center multi-function control panel ..................... 4-3

FilterAir cleaner housing filter .............................. 8-20
Changing engine oil and filter ...................... 8-10
Flashers (See hazard warning flasher switch) ...... 6-2
Flat tire ............................................................... 6-3
Flat towing ........................................................ 9-19
Floor mat cleaning .............................................. 7-5
Fluid Automatic transmission fluid (ATF) ............... 8-12
Brake and clutch fluid .................................. 8-13
Brake fluid ................................................... 8-14
Capacities and
recommended fuel/lubricants ........................ 9-2
Engine coolant ............................................... 8-8
Engine oil .................................................... 8-10
Power steering fluid ..................................... 8-13
Window washer fluid ................................... 8-14
FM-AM-SAT radio with Compact Disc
(CD) player ........................................................ 4-53
Fog light switch ................................................ 2-39
Front passenger air bag and status light ........... 1-45
Front power seat adjustment ............................... 1-3
Front seat, Front seat adjustment ........................ 1-3
Front-seat active head restraints ....................... 1-12
Fuel Capacities and
recommended fuel/lubricants ........................ 9-2
Fuel economy............................................... 5-47
Fuel economy information (display) .............. 4-11
Fuel information ............................................. 9-4
Fuel octane rating .......................................... 9-4 Fuel-filler cap ............................................... 3-21
Fuel-filler door ............................................. 3-21
Gauge ............................................................ 2-9
LOOSE FUEL CAP warning ............................. 3-23
Fuel Efficient Driving Tips .................................. 5-46
Fuses ................................................................ 8-23
Fusible links ..................................................... 8-23
G
Garage door opener HomeLink®Universal Transceiver ................. 2-56
Gas cap ............................................................ 3-21
Gauge ................................................................. 2-6 Engine coolant temperature gauge ................. 2-8
Fuel gauge ..................................................... 2-9
Odometer....................................................... 2-7
Speedometer ................................................. 2-7
Tachometer .................................................... 2-8
Trip computer .............................................. 2-26
General maintenance .......................................... 8-2
Glove box ......................................................... 2-46
Golf bag stowing .............................................. 2-49
H
Hands-free phone system, Bluetooth®
(models with navigation system) ....................... 4-77
Hands-free phone system, Bluetooth®
(models without navigation system) .................. 4-87
Hazard warning flasher switch ............................ 6-2
Head restraints (front seats) ............................... 1-9 Head restraints (rear seats) ............................... 1-13
Headlights Bulb replacement ......................................... 8-28
Headlight switch .......................................... 2-35
Xenon headlights ......................................... 2-34
Heated seats .................................................... 2-39
Heater, Automatic climate control ..................... 4-31
HomeLink
®Universal Transceiver ...................... 2-56
Hood release .................................................... 3-17
Hook, Coat hooks ............................................. 2-49
Horn ................................................................. 2-39
I
Ignition switch (Push-button) ................................................. 5-9
Manual transmission models ....................... 5-19
Immobilizer system ........................................... 2-30
In-cabin microfilter ............................................ 4-38
Indicator Dot matrix display ....................................... 2-20
Lights .......................................................... 2-17
INFINITI Vehicle Immobilizer System .................. 2-30
INFINITI voice recognition system .................... 4-101
INFO button ........................................................ 4-9
Inside mirror ..................................................... 3-25
Inspection/maintenance (I/M) test .................... 9-23
Instrument brightness control ........................... 2-38
Instrument panel ................................................ 2-4
Intelligent cruise control (ICC) system ............... 5-24 Preview function .......................................... 5-45
10-3

MirrorInside mirror ................................................ 3-25
Outside mirrors ............................................ 3-26
Vanity mirror ................................................ 3-27
Monitor, Rearview monitor ................................ 4-23
Moonroof .......................................................... 2-52
N
New vehicle break-in ......................................... 5-46
No key warning ................................................. 2-22
O
Odometer............................................................ 2-7
Off-road recovery ................................................ 5-7
Oil Capacities and
recommended fuel/lubricants ........................ 9-2
Changing engine oil and filter ...................... 8-10
Checking engine oil level ............................. 8-10
Engine oil .................................................... 8-10
Engine oil viscosity ........................................ 9-7
Oil filter replacement indicator ..................... 2-24
Operation, Indicators for operation ................... 2-22
Outside air temperature .................................... 2-27
Outside mirrors ................................................. 3-26
Overheat, If your vehicle overheats ................... 6-11
Owner’s Manual/Service Manual
order information .............................................. 9-24
P
Panic alarm ...................................................... 3-15
Parking Brake break-in ............................................. 5-54
Parking brake operation ............................... 5-21
Parking brake release warning ..................... 2-23
Parking on hills ........................................... 5-49
Phone
Bluetooth
®hands-free phone system
(models with navigation system) .................. 4-77
Bluetooth
®hands-free phone system
(models without navigation system) ............. 4-87
Car phone or CB radio ................................. 4-76
Power Front seat adjustment .................................... 1-3
Power door lock ............................................. 3-4
Power outlet ................................................ 2-42
Power steering fluid ..................................... 8-13
Power steering system ................................. 5-53
Power windows ............................................ 2-50
Precautions
Audio operation ........................................... 4-39
Braking precautions ..................................... 5-53
Child restraints ............................................ 1-22
Cruise control .............................................. 5-22
Maintenance .................................................. 8-5
Seat belt usage ........................................... 1-13
Supplemental restraint system ..................... 1-38
When starting and driving .............................. 5-3
Pre-crash seat belts .......................................... 1-16 Predictive course line settings .......................... 4-29
Preview function ............................................... 5-54
Preview function (for Intelligent cruise
control system) ................................................. 5-45
Preview Function warning light .......................... 2-16
Push starting .................................................... 6-10
Push warning (Automatic
Transmission models) ....................................... 2-22
Push-button ignition switch ....................... 5-9, 5-10R
Radio ................................................................ 4-39
Car phone or CB radio ................................. 4-76
FM-AM-SAT radio with Compact Disc
(CD) player ................................................... 4-53
Rain-sensing auto wiper system ........................ 2-33
Rapid air pressure loss ....................................... 5-7
Readiness for inspection/maintenance (I/M) test
(US only) .......................................................... 9-23 Rear seats .......................................................... 1-7
Rear window and outside mirror
defroster switch ................................................ 2-34
Rearview monitor .............................................. 4-23
Recorders, Event data ....................................... 9-23
Registering your vehicle in another country ...... 9-10
Remote keyless entry system ............................ 3-14
Reporting safety defects ................................... 9-22
Roadside assistance program ............................. 6-2
Rollover .............................................................. 5-6
Roof, Moonroof ................................................. 2-53
10-5
