INFINITI Q60 COUPE 2015 Quick Reference Guide

9
Outside Mirror Control Switch
To select the right or left side mirror, turn the control
switch
1 right or left.
To adjust the mirror angle, move the control switch

1 up, down, right or left.
To prevent accidentally moving the mirror, turn and
set the switch to the middle (neutral) position.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.
Starting/Stopping the Engine
AUTOMATIC TRANSMISSION (if so equipped)
It is important to make sure the INFINITI Intelligent
Key is with you (that is, in your pocket or purse).
Depress the brake pedal.



•

If the brake pedal is not depressed, pushing the

ignition switch once enters the ACC mode.



•

If the ignition switch is pushed a second time, the

vehicle will enter the ON mode.
Press the ignition switch
START/STOP button to start the engine.
MANUAL TRANSMISSION (if so equipped)
Depress the brake pedal.



•

If the brake pedal is not depressed, pushing the ignition switch once en\
ters the
ACC mode.



•

If the ignition switch is pushed a second time, the vehicle will enter t\
he
ON mode.
Depress the clutch pedal to the floor.
Move the shift lever to the N (NEUTRAL) position.
Press the ignition switch
START/STOP button.
TURNING THE ENGINE OFF
For an automatic transmission, move the shift lever to the P (PARK) position, apply the
parking brake and push the ignition switch.
For a manual transmission, depress the clutch pedal and the foot brake, \
place the vehicle in
1st gear, apply the parking brake and push the ignition switch.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
1
To stop the front seat from sliding, press the seatback button 2 again. To return the front seat to its original position:



1.

Push or pull the seatback backward until it locks in place.



2.

Press the seatback button 2 to slide the front seat backward.
For more information, refer to the “Safety — Seats, seat belts and supplemental restraint system (sectio\
n 1) ” of your
Owner’s Manual.
1811810_15b_Q60_G_Coupe_Convert_QRG_091514.indd 99/15/14 1:26 PM

10
first drive features
Headlight Control Switch
HEADLIGHT CONTROL
Turn the headlight control switch to the
position
1 to turn on the front parking, side
marker, tail, license plate and instrument panel
lights. Turn the switch to the position
2 to turn on
the headlights.
AUTOLIGHT SYSTEM
The autolight system will automatically turn the headlights on when it i\
s dark and off when
it is light. The system will keep the headlights on for a period of time\
after you turn the
ignition off and all the doors are closed.
To activate the autolight system, turn the headlight control switch to t\
he AUTO
position 3
then push the ignition switch to ON. To deactivate the autolight system, turn the headlight
control switch to the OFF,
position 1 or
position 2.
HIGH BEAM SELECT
Push the headlight control switch forward 4 to
select the high beam function. The blue indicator
light
illuminates in the instrument panel. Pull
the headlight switch back to the original position to
select the low beam. The blue indicator light
will extinguish.
Pull and release the headlight control switch 5 to
flash the headlight high beams on and off.
FOG LIGHT SWITCH
The headlights must be in the auto position or the
low beams
selected for the fog lights to operate.
Turn the switch (inside collar) to the
position 6
to turn the fog lights on.
Turn the switch (inside collar) to the
OFF position to turn the fog lights off.
LANE CHANGE SIGNAL
Move the lever up or down until the turn signal begins to flash but the \
lever does not latch
to signal a lane change. Hold the lever until the lane change is complet\
ed.
Move the lever up or down until the turn signal begins to flash but the \
leve r does not latch
and release the lever. The turn signal will automatically flash 3 times.\

Choose the appropriate method to signal a lane change based on the road and
traffic conditions.
For more information, refer to the “Instruments and controls (sectio\
n 2)” of your Owner’s Manual.
3
1
2
6
5
4
1811810_15b_Q60_G_Coupe_Convert_QRG_091514.indd 109/15/14 1:26 PM

11
Automatic Climate Controls
1 AUTO BUTTON/DRIVER’S SIDE TEMPERATURE CONTROL DIAL
The automatic mode may be used year-round. Press the AUTO button to turn the system
on, and the system will automatically control the inside temperature (a\
utomatic cooling
and/or dehumidified heating), air flow distribution and fan speed.
Turn the driver’s side temperature control dial to the left for coole\
r air or right for warmer air.
2 DUAL BUTTON/PASSENGER’S SIDE TEMPERATURE CONTROL DIAL
Press the DUAL button to turn the passenger’s side temperature controls on or off. T\
his
will allow the passenger’s side temperature to be adjusted independen\
tly from the
driver’s side by turning the passenger’s side temperature control \
dial.
Turn the passenger’s side temperature control dial left for cooler ai\
r or right for warmer air.
3 FAN SPEED CONTROL BUTTONS
To manually adjust the fan speed, press the button to increase the fan speed or
press the
button to decrease the fan speed.
123
45
67
8
9
Windshield Wiper and Washer Switch
Move the lever to one of the following positions to
operate the windshield wipers:
1 Mist (MIST) – One sweep operation of
the wipers.
2 Auto (AUTO) (if so equipped) – Operates the
rain-sensing wipers intermittently. To increase
or decrease wiper sensitivity, twist the control
ring
3.
4 Low (LO) – Wipers operate at a continuous
low-speed.
5 High (HI) – Wipers operate at a continuous
high-speed.
6 Pull the lever toward you to activate the washer.
The wipers will operate several times.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
3MIST
OFF
AUTO LO
HI1
2
4
5
6
1811810_15b_Q60_G_Coupe_Convert_QRG_091514.indd 119/15/14 1:26 PM

12
first drive features
4 DEFROSTING/DEFOGGING FRONT AND SIDE WINDOWS
Press the defroster control button to turn the system on. The A/C automatically turns
on when the defroster mode is selected. This feature removes humidity fr\
om the air.
Turn the temperature control dial 1 to set the desired temperature.
To defrost the front and side windows, set the temperature controls and \
fan speed
controls to their maximum settings.
5 MODE BUTTON
Press the MODE button
to cycle through the following air flow outlets:



Air flows from the center and side vents.



Air flows from the center, side and foot vents.



Air flows mainly from the foot vents.



Air flows from the defroster and foot vents.
6 DEFROSTING REAR WINDOW AND OUTSIDE MIRRORS
Push the rear window and outside mirror defroster switch to turn the system on or off.
This function automatically turns off after approximately 15 minutes.
7 INTAKE AIR CONTROL BUTTON



AIR RECIRCULATION
Press the intake air control button
to recirculate interior air inside the vehicle. The
indicator light on the
side will illuminate. This system is used to avoid outside
odors and to help adjust the inside vehicle temperature more effectively\
.
The air recirculation mode cannot be activated when the air conditioner \
is in the front
defroster mode
or the front defroster and foot vent mode .



OUTSIDE AIR CIRCULATION
Press the intake air control button to draw outside air into the passenger compartment.
The indicator light on the
side will illuminate.



AUTOMATIC INTAKE AIR CONTROL
In the auto mode, the intake air will be controlled automatically. To ma\
nually control
the intake air, press the intake air control button. To return to the au\
tomatic control
mode, press the intake air control button for about 2 seconds.
8 A/C BUTTON
Press the
A/C button to turn the air conditioner system on or off. This system helps \
cool
and dehumidify the air inside the cabin and defog the windows.
9 OFF BUTTON
Press the OFF button to turn the climate control system off.
For more information, refer to the “Instruments and controls (section 2)” and the “Monitor, climate, audio, phone and voice
recognition systems (section 4)” of your Owner’s Manual.
1811810_15b_Q60_G_Coupe_Convert_QRG_091514.indd 129/15/14 1:26 PM

13
FM/AM/SiriusXM®* Satellite Radio with CD/DVD Player
(with Navigation System) (if so equipped)
1 ON•OFF BUTTON/VOL (volume) CONTROL KNOB
Press the ON•OFF button to turn the system on or off.
Turn the VOL (volume) control knob right or left to increase or decrease the volume\
.
2 SEEK•CAT AND TRACK BUTTONS
To scan quickly through each broadcasting station, press the SEEK•CAT button or the
TRACK button to stop at the previous or next broadcast station.
For satellite radio, press the
SEEK•CAT button or the TRACK button to switch to the first
channel of the previous or next category.
Press the SEEK•CAT button or the TRACK button to change tracks on a CD.
Press and hold the SEEK•CAT button or the TRACK button to fast forward or rewind a
track on a CD.
3 AUDIO BUTTON/TUNE/FOLDER CONTROL KNOB
To manually tune the radio, turn the TUNE/FOLDER control knob left or right.
Press the AUDIO button to access the audio settings screen.
4 STATION PRESET BUTTONS
Twelve stations can be set for the FM band, 6 for the AM band and 18 for\
satellite radio.
To store a station in a preset, you must first select a radio band by pr\
essing the

AM•FM/SAT button
5 then tune to the desired AM, FM or satellite radio station.
Then press and hold the desired station preset button ( 1-6) until the preset number is
updated on the display and the sound is briefly muted. The channel indic\
ator will then
display, and the sound will resume. Programing is now complete.
To retrieve a previously set station, select the radio band where the pr\
eset was stored
then press the corresponding station select button (
1-6).
*SiriusXM® Satellite Radio is only available on vehicles equipped with an optional\
satellite radio subscription service.
For more information, refer to the “Monitor, climate, audio, phone and voice recognition systems (secti\
on 4)” of your
Owner’s Manual.
123
4
5
1811810_15b_Q60_G_Coupe_Convert_QRG_091514.indd 139/15/14 1:26 PM

14
first drive features
Conventional (Fixed Speed) Cruise Control
The cruise control system enables you to set a
constant cruising speed once the vehicle has
reached 25 MPH (40 km/h).
The system will automatically maintain the set speed



until you tap the brake pedal, accelerate, cancel or



turn the system off.
To activate the cruise control, push the ON/OFF
switch 1. The CRUISE indicator light in the



instrument panel will illuminate.
To set a cruising speed, accelerate the vehicle to the desired speed, push the
COAST/SET switch
2 and release. The CRUISE SET indicator light in the instrument panel
will illuminate. Take your foot off the accelerator pedal. Your vehicle \
will maintain the
set speed.
To reset at a faster cruising speed, push and hold the ACCEL/RES switch 3. When the



vehicle attains the desired speed, release the switch.
To reset at a slower cruising speed, push and hold the COAST/SET switch 2. Release the



switch when the vehicle slows to the desired speed.
To cancel the preset speed, tap the brake pedal or push the CANCEL switch 4.
To turn off cruise control, push the ON/OFF switch 1. The CRUISE indicator light
in the



instrument panel will extinguish.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
USB (Universal Serial Bus) Connection Port/iPod® Interface
The USB port 1 is located in the center console
under the arm rest.
When a compatible USB memory device or iPod®
is plugged into the USB port, compatible audio
and video files stored on the device can be
played through the vehicle’s audio system and
front display.
For more information, refer to the “Monitor, climate, audio, phone
and voice recognition systems (section 4)” of your Owner’s Manual.1
1
2
34
1811810_15b_Q60_G_Coupe_Convert_QRG_091514.indd 149/15/14 1:26 PM

15
Intelligent Cruise Control (ICC) System (if so equipped)
VEHICLE-TO-VEHICLE DISTANCE CONTROL MODE
To set Vehicle-To-Vehicle Distance Control mode, press
the ON/OFF button
1 for less than 1.5 seconds.
The CRUISE indicator light
2 will illuminate.
Accelerate to the desired speed.
Push down on the
COAST/SET switch 3 and release
it. Cruise control will be set to the desired speed.
Press the distance button 4 repeatedly to change
the set distance between long, middle and short.
When a vehicle is not detected ahead of you in the
lane, the set distance and set vehicle speed indicator
lights will illuminate
5 in set mode.
When a vehicle is detected ahead of you in the lane,
the vehicle ahead detection, set distance and set
vehicle speed indicator lights will illuminate
6 in
set mode.
To reset at a faster cruising speed, push up and hold the ACCEL/RES
switch
7. When the vehicle attains the desired speed, release the switch.
To reset at a slower cruising speed, push down and hold the COAST/SET
switch
3. Release the switch when the vehicle slows to the desired speed.
To cancel the preset speed, push the CANCEL switch 8 or tap the brake pedal. The set
vehicle speed indicator
5 will extinguish.
To turn off cruise control, press the ON/OFF button 1. The CRUISE indicator light 2 in the
instrument panel will extinguish.
To set conventional (fixed speed) cruise control mode:
While cruise control is off, press the ON/OFF
button 1 and hold it down for more than 1.5
seconds. The CRUISE indicator light will illuminate.
Accelerate to the desired speed.
Push down on the
COAST/SET switch and release it. The SET indicator light will illuminate.
Cruise control should be set to the desired speed.
To switch between the two cruise control modes:
When one of the two cruise modes is in use, you must turn the system off\
, and then turn it
on again to select the other cruise control mode.
For more information, refer to the “Starting and driving (section 5)” of your Owner’s Manual.
1
2
3
4
5
6
78
1811810_15b_Q60_G_Coupe_Convert_QRG_091514.indd 159/15/14 1:26 PM

16
Opening/Closing the Hard Top (Convertible models)
Before opening or closing the retractable hard top,
refer to your Owner’s Manual for detailed warnings and
cautions regarding hard top operation.
The trunk area must be absolutely empty or it may result
in damage to the hard top.
Preparing to Lower the Hard Top
1.

The vehicle must be on a level surface when
operating the hard top.
2.


Make sure that the trunk area is absolutely empty.
3.


Pull up on the strap to open the trunk

room partition.
4.


Secure the partition hooks into holders until they
latch. If the trunk room partition hooks
are not latched in the holders, the hard
top cannot be operated and the

CHECK
SEPARATOR indicator will illuminate on the
vehicle information display located between
the tachometer and speedometer.
5.


Securely close the trunk before operating the

hard top.
Hard Top Operation
1.


Move the shift lever to the
P (PARK) position
(automatic transmission) or move the shift lever to
the N (NEUTRAL) position (manual transmission)
and apply the parking brake.
2.


Start the engine.
3.


Press the hard top operating switch, located on the center console, to OPEN

or CLOSE and
hold until the top is fully positioned.
4.

The ROOF OPEN or ROOF CLOSED indicator will display when the hard top is
fully positioned.
For more information, refer to the “Pre-driving checks and adjustments (section 3)” of your Owner’s Manual.

first drive features
1811810_15b_Q60_G_Coupe_Convert_QRG_091514.indd 169/15/14 1:27 PM

17
Bluetooth® Hands-free Phone System
A c ellular telephone should not be used while
driving so full at tention may be given to
vehicle operation.*
SYSTEM OPERATING TIPS
Press the or but ton to interrupt the voice
prompts at any time and speak a command af ter
the tone.
For vehicles not equipped with Navigation:



•



To use the system faster, you may speak the second level commands with t\
he main
menu command on the main menu. For example, press the
or button and after the
tone, say “Call Redial”.
Trip Computer
When the
button 1
is pressed, the following
modes will appear on the vehicle information
display
2:



•


MPG

– Displays the current fuel consumption.



•


MPG/MPH
– Displays the average fuel consumption
and speed since the last reset.



—


To reset the displayed MPG/MPH, press and hold

the
button 3 for more than 1 second. Both
displayed MPG/MPH will reset at the same time.



•


TIME/MILES

– Displays the elapsed time and total
distance the vehicle has been driven since the
last reset.



—


To reset the elapsed time/miles, press and hold the button 3 for more than
1 second. Both elapsed time/miles will reset at the same time.



•


RANGE

– Displays the estimated distance to empty (dte) the vehicle can b\
e driven
before refueling.



•


OUTSIDE TEMP

– Displays the exterior air temperature including a low temperature
warning feature.



•


SETTING

– Allows you to set reminders for alerts and maintenance intervals o\
r change the
language and units used in the system.



—


Press the button 3
to cycle through the various setting modes.



—


Press the button 1
to choose the selected mode.



•


WARNING

– Displays when a warning is present.
Press the
button
3 for approximately 1 second to reset the currently displayed trip
odometer to zero.
For more information, refer to the “Instruments and controls (section 2)” of your Owner’s Manual.
Bluetooth®
Controls
*Some jurisdictions prohibit the use of cellular telephones while drivin\
g.
system guide
1
2
3
1811810_15b_Q60_G_Coupe_Convert_QRG_091514.indd 179/15/14 1:27 PM

18
system guide
For vehicles equipped with Navigation:



•



Refer to “Voice recognition (section 9)” of your
Navigation System Owner’s Manual for more
information.
The “Help” command can be used to hear a list of
available commands at any time.
Reduce background noise as much as possible by closing
windows and pointing HVAC vents away from the ceiling.
Say commands after the tone or press the or button to say a command at any time.
Speak naturally without long pauses and without raising your voice.
When speaking Phonebook names, please be aware some phones require the l\
ast name
to be spoken before the first name. For example, “Michael Smith” m\
ay be spoken as
“Smith Michael”.
To cancel a Voice Recognition session, simply wait 5 seconds, say “Ca\
ncel” or “Quit”, or
press and hold the
button for 5 seconds.
If the Voice Recognition system does not recognize your voice commands, \
train the system
using the Speaker Adaptation Mode. See your Owner’s Manual for detail\
ed information.
For more detailed information and instructions, refer to your cellular p\
hone’s Owner’s
Manual and visit
www.InfinitiUSA.com/bluetooth.
Bluetooth® System with Navigation (if so equipped)
CONNECTING PROCEDURE
The vehicle must be stationary when connecting
the phone.







1.
Press the

PHONE button on the instrument panel or
the
button on the steering wheel and select the
“Connect Phone” key.
2.


Initiate connecting from the phone.
• The connecting procedure varies according to each


cellular phone model. For detailed connecting
instructions and a list of compatible phones, please
visit www.InfinitiUSA.com/bluetooth.
• When prompted for a PIN code, enter “1234” from


the handset. (The PIN code is assigned by INFINITI
and cannot be changed.)


3.

When connecting is complete, the screen will return


to the “Phone” menu.
Microphone
1811810_15b_Q60_G_Coupe_Convert_QRG_091514.indd 189/15/14 1:27 PM
