same size and you are only replacing
2 of the 4 tires, install the new tires
on the rear axle. Placing new tires on
the front axle may cause loss of
vehicle control in some driving condi-
tions and cause an accident and
personal injury.
.If the wheels are changed for any
reason, always replace with wheels
which have the same off-set dimen-
sion. Wheels of a different off-set
could cause premature tire wear,
degrade vehicle handling character-
istics and/or interference with the
brake discs/drums. Such interference
can lead to decreased braking effi-
ciency and/or early brake pad/shoe
wear. See “Wheels and tires” (P.10-
9) of this manual for wheel off-set
dimensions.
.Since the spare tire is not equipped
with the TPMS, when a spare tire is
mounted or a wheel is replaced, the
TPMS will not function and the low
tire pressure warning light will flash
for approximately 1 minute. The light
will remain on after 1 minute. Have
your tires replaced and/or TPMS
system reset as soon as possible. It
is recommended you visit an INFINITI
retailer for these services..Replacing tires with those not origin-
ally specified by INFINITI could affect
the proper operation of the TPMS.
.The TPMS sensor may be damaged if
it is not handled correctly. Be careful
when handling the TPMS sensor.
.When replacing the TPMS sensor, the
ID registration may be required. It is
recommended you contact an
INFINITI retailer for ID registration.
.Do not use a valve stem cap that is
not specified by INFINITI. The valve
stem cap may become stuck.
.Be sure that the valve stem caps are
correctly fitted. Otherwise the valve
may be clogged up with dirt and
cause a malfunction or loss of pres-
sure.
.Do not install a damaged or deformed
wheel or tire even if it has been
repaired. Such wheels or tires could
have structural damage and could fail
without warning.
.The use of retread tire is not recom-
mended.
.For additional information regarding
tires, refer to “Important Tire Safety
Information” (US) or “Tire Safety
Information” (Canada) in the War-ranty Information Booklet.
Intelligent All-Wheel Drive (AWD)
models
CAUTION
.Always use tires of the same type,
size, brand, construction (bias, bias-
belted or radial), and tread pattern
on all four wheels. Failure to do so
may result in a circumference differ-
ence between tires on the front and
rear axles which will cause excessive
tire wear and may damage the trans-
mission, transfer case and differential
gears.
.ONLY use spare tires specified for
the Intelligent AWD model.
If excessive tire wear is found, it is recom-
mended that all four tires be replaced with
tires of the same size, brand, construction
and tread pattern. The tire pressure and
wheel alignment should also be checked and
corrected as necessary. It is recommended
you visit an INFINITI retailer for this service.
Do-it-yourself8-37

8-38Do-it-yourself
Wheel balance
Unbalanced wheels may affect vehicle hand-
ling and tire life. Even with regular use,
wheels can get out of balance. Therefore,
they should be balanced as required.
Wheel balance service should be performed
with the wheels off the vehicle. Spin
balancing the wheels on the vehicle could
lead to mechanical damage.
For additional information regarding tires,
refer to “Important Tire Safety Information”
(US) or “Tire Safety Information” (Canada) in
the INFINITI Warranty Information Booklet.
Care of wheels
See “Cleaning exterior” (P.7-2) for details
about care of the wheels.
Emergency tire puncture repair kit
(if so equipped)
The emergency tire puncture repair kit
(Emergency Tire Sealant) is supplied with
the vehicle instead of a spare tire. It can be
used to temporarily repair minor tire punc-
tures. If possible, have the vehicle towed to a
facility that can repair or replace the flat tire.
Using the emergency tire puncture repair kit
may cause a malfunction of the tire pressure
sensor and cause the low tire pressure
warning light to illuminate.See “Flat tire” (P.6-3) for more details.
JACKING UP THE VEHICLE AND
REPLACING TIRES
This section contains the information about
the vehicle jack-up procedures and the tire
replacement.
NOTE:
Jacking tools are not equipped as standard
with this vehicle. It is recommended you
contact an INFINITI retailer about acquiring
the tools.
For models with run-flat tires, you can
continue driving to a safe location even if
they are punctured. (See “Run-flat tires”
(P.6-4) and “Run-flat tires” (P.8-32).)
For models with the emergency tire punc-
ture repair kit, you can temporarily fix a
minor tire puncture using it. (See “Repairing
a flat tire (for models with emergency tire
puncture repair kit)” (P.6-5).)
WARNING
.Make sure the parking brake is
securely applied and the transmission
into the P (Park) position.
.Never change tires when the vehicle
is on a slope, ice or slippery areas.This is hazardous.
.Never change tires if oncoming traf-
fic is close to your vehicle. Wait for
professional road assistance.

9-18Maintenance and schedules
105,000 Miles/126 Months/
168,000 Km
Standard maintenance:.Replace In-cabin microfilter.Replace Intelligent Key battery.Perform tire rotation (1).Replace spark plugs (2) (3).Replace engine coolant* (4)Severe maintenance:
.Inspect brake pads and rotors.Inspect exhaust system.Inspect steering gear and linkage.Inspect axle and suspension parts.Inspect propeller shaft (AWD models).Inspect drive shaft boots (AWD models)
(1) If your vehicle is equipped with different sized
tires in the front and rear, tires cannot be rotated.
(2) Performed based on the number of miles only.
(3) Replace spark plug when the plug gap exceeds
0.043 in (1.1 mm) even if within specified periodic
replacement mileage.
(4) First replacement interval is 105,000 miles
(168,000 km) or 84 months. After first replace-
ment, replace every 75,000 miles (120,000 km)
or 60 months.
*: Maintenance items and intervals with "*" are
recommended by INFINITI for reliable vehicle
operation. The owner need not perform such
maintenance in order to maintain the emission
warranty or manufacturer recall liability. Other
maintenance items and intervals are required.
110,000 Miles/132 Months/
176,000 Km
Standard maintenance:.Inspect brake lines and cables.Inspect brake pads and rotors.Inspect drive belts (1).Inspect propeller shaft (AWD models).Inspect drive shaft boots (AWD models).Inspect stop lamp switch and brake pedal
position switch (2)
.Inspect transfer fluid.Inspect differential gear oil.Replace engine oil and filter (3).Perform tire rotation (4)

10-2Technical and consumer information
The following are approximate capacities. The actual refill capacities may be a little different. When refilling, follow the procedure
instructed in the “8. Do-it-yourself” section to determine the proper refill capacity.
Fluid typeCapacity (approximate)
Recommended Fluids/Lubricants
Metric
MeasureUS
MeasureImperial
Measure
Fuel 76 L 20 gal 16-5/8 gal

See “Fuel information” (P.10-4).
Engine oil
*1Drain and refill*1: For additional
information, see
“Engine oil” (P.8-
6).Two-Wheel
Drive (2WD)
modelWith oil filter
change5.3 L 5-5/8 qt 4-5/8 qt

Genuine “NISSAN Motor Oil 0W-20 SN” (or equivalent) is recommended.


If the above motor oil (or engine oil) is not available, a synthetic 0W-20 GF-5 SN motor oil (or
engine oil) may be used. Damage caused by the use of motor oil (or engine oil) other than as
recommended is not covered under INFINITI’s new vehicle limited warranty. For additional
information, see “Engine oil and oil filter recommendation” (P.10-6). Without oil fil-
ter change5.1 L 5-3/8 qt 4–1/2 qt
All-Wheel
Drive (AWD)
modelWith oil filter
change5.9 L 6-1/4 qt 5-1/4 qt
Without oil fil-
ter change5.7 L 6 qt 5 qt
Engine coolant Standard and
premium
gradeTotal (with re-
servoir)9.3 L 9-7/8 qt 8-1/8 qt

Pre-diluted Genuine NISSAN Long Life Antifreeze/Coolant (blue) or equivalent
Reservoir 0.5 L 1/2 qt 1/2 qt
Sport grade Total (with re-
servoir)10.4 L 11 qt 9-1/8 qt
Reservoir 0.5 L 1/2 qt 1/2 qt
Intercooler coolant Total (with reservoir) 3.2 L 3-3/8 qt 2-7/8 qt
Reservoir 0.4 L 3/8 qt 3/8 qt
Automatic Transmission Fluid (ATF) — — —

Genuine NISSAN Matic S ATF or equivalent


INFINITI recommends using Genuine NISSAN Matic S ATF (or equivalent) ONLY in INFINITI
automatic transmissions. Do not mix with other fluids. Using fluids that are not equivalent to
Genuine NISSAN Matic S ATF may damage the automatic transmission. Damage caused by the
use of fluids other than as recommended is not covered under the INFINITI’s new vehicle limited
warranty.
Differential gear
oilFront — — —

Genuine NISSAN Differential Oil Hypoid Super GL-5 80W-90 or equivalent conventional (non-
synthetic) oil
Rear — — —

Genuine NISSAN HYPOID FLUID·S1 GL-5 75W-80 or equivalent
Transfer fluid — — —

Genuine NISSAN Matic J ATF or equivalent


INFINITI recommends using Genuine NISSAN Matic J ATF (or equivalent) ONLY in INFINITI
transfers. Do not mix with other fluids. Using fluids that are not equivalent to Genuine NISSAN
Matic J ATF may damage the transfer. Damage caused by the use of fluids other than as
recommended is not covered under the INFINITI’s new vehicle limited warranty.
Brake fluid Refill to the proper oil level according to
the instructions in the “8. Do-it-yourself”
section.

Genuine NISSAN Super Heavy Duty Brake Fluid
*4or equivalent DOT 3*4: Available in mainland U.S.A. through an INFINITI retailer.
Multi-purpose grease — — —

NLGI No. 2 (Lithium soap base)
CAPACITIES AND RECOMMENDED
FLUIDS/LUBRICANTS

(GAWR). The total of the axle loads
should not exceed the gross vehicle
weight rating (GVWR). These ratings
are given on the vehicle certification
label. If weight ratings are exceeded,
move or remove items to bring all
weights below the ratings.Do not tow a trailer with your
vehicle.
FLAT TOWING
Towing your vehicle with all four wheels on
the ground is sometimes called flat towing.
This method is sometimes used when towing
a vehicle behind a recreational vehicle, such
as a motor home.
CAUTION
.Failure to follow these guidelines can
result in severe transmission damage.
.Whenever flat towing your vehicle,
always tow forward, never back-
ward.
.DO NOT tow any Automatic Trans-
mission (AT) vehicle with all four
wheels on the ground (flat towing).
Doing so WILL DAMAGE internal
transmission parts due to lack of
transmission lubrication.
.DO NOT tow any All-Wheel Drive
(AWD) vehicle with any of the wheels
on the ground. Doing so may cause
serious and expensive damage to the
powertrain.
.For emergency towing procedures
refer to “Towing recommended byINFINITI” (P.6-15).
Automatic Transmission
All-Wheel Drive (AWD) models:
Do not tow an AWD vehicle with any of the
wheels on the ground.
Two-Wheel Drive (2WD) models:
To tow a vehicle equipped with an automatic
transmission, an appropriate vehicle dolly
MUSTbe placed under the towed vehicle’s
drive wheels.Alwaysfollow the dolly man-
ufacturer’s recommendations when using
their product.
Technical and consumer information10-19
TOWING A TRAILER

11 Index
A
ABS (Anti-lock Braking System) .................. 5-130
Active Lane Control ............................................ 5-25
Active noise cancellation ................................. 5-141
Active sound enhancement ............................ 5-141
Active trace control .......................................... 5-133
Air bag system
Front-seat mounted side-impact
supplemental air bag system ..................... 1-52
Roof-mounted curtain side-impact and
rollover supplemental air bag system ...... 1-52
Air bag warning labels ....................................... 1-55
Air bag warning light .............................. 1-55, 2-14
Air cleaner housing filter ................................... 8-15
Air conditioner
Air conditioner operation ........................... 4-34
Air conditioner service ................................. 4-41
Air conditioner specification label ......... 10-13
Air conditioning system refrigerant
and oil recommendations ................ 4-41, 10-7
Automatic air conditioner ........................... 4-36
Heater and air conditioner ......................... 4-34
Servicing air conditioner .............................. 4-41
Sync mode setting ......................................... 4-39
Air deflectors ...................................................... 10-15
Alarm
How to stop alarm (see vehicle
security system) ............................................. 2-33
Alcohol, drugs and driving ................................ 5-10Android Auto .......................................................... 4-2
Antenna .................................................................. 4-42
Anti-lock Braking System (ABS) .................. 5-130
Appearance care
Exterior appearance care ............................... 7-2
Interior appearance care ................................ 7-5
Apple CarPlay
®...................................................... 4-2
Around View®Monitor ...................................... 4-11
Audible reminders ................................................ 2-20
Autolight system .................................................. 2-38
Automatic
Automatic adjusting function
(power windows) ........................................... 2-55
Automatic air conditioner ........................... 4-36
Automatic Transmission Fluid (ATF) ......... 8-9
Driving with Automatic
Transmission (AT) .......................................... 5-16
Automatic door locks ............................................ 3-5
Automatic seat positioner ................................ 3-33
Avoiding collision and rollover ............................ 5-9
B
Back-up Collision Intervention (BCI) .............. 5-62
Battery .................................................................... 8-11
Battery replacement, Intelligent Key ......... 3-2
Battery saver system .................................... 2-41
Intelligent Key ................................................. 8-19
Variable voltage control system ............... 8-13
Before starting the engine ................................ 5-14Belts (See drive belts) ......................................... 8-13
Blind Spot Intervention
®(BSI) ......................... 5-48
Blind Spot Warning (BSW) .............................. 5-40
Brake
Anti-lock Braking System (ABS) ............ 5-130
Brake fluid ......................................................... 8-9
Brake force distribution ............................. 5-132
Brake system ................................................ 5-129
Parking brake operation ............................. 5-20
Brake warning light ............................................. 2-13
Break-in schedule .............................................. 5-122
Bulb check/instrument panel ........................... 2-13
Bulb replacement ................................................. 8-22
C
Camera aiding sonar function ......................... 4-24
Capacities and
recommended fluids/lubricants ....................... 10-2
Car phone or CB radio ....................................... 4-42
Card holder ............................................................ 2-52
Catalytic converter
Three-way catalyst ......................................... 5-5
Center ventilators ................................................ 4-34
Chassis control ................................................... 5-135
Check tire pressure warning ............................. 2-24
Checking intercooler coolant level .................... 8-6
Child restraints ..................................................... 1-20
LATCH system ............................................... 1-22
Precautions on child restraints .................. 1-20

11-2
Child safety ........................................................... 1-18
Chimes
Audible reminders .......................................... 2-20
Seat belt warning light
and chime ............................................. 1-13, 2-14
Circuit breaker
Fusible link ....................................................... 8-18
Cleaning exterior and interior .................... 7-2, 7-5
Climate control
Automatic air conditioner ........................... 4-36
Clock ...................................................................... 2-31
Coat hooks ............................................................ 2-53
Cockpit ...................................................................... 2-3
Cold weather driving ........................................ 5-138
Compass .................................................................... 2-9
Console box ........................................................... 2-52
Coolant
Capacities and
recommended fluids/lubricants ................. 10-2
Changing engine coolant ............................... 8-5
Checking engine coolant level ...................... 8-4
Corrosion protection ............................................. 7-8
Courtesy light ....................................................... 2-60
Cruise control ....................................................... 5-70
Fixed speed cruise control (on
ICC system) .................................................... 5-88
Intelligent Cruise Control (ICC) ................. 5-72
Cruise indicator .................................................... 2-25
Cup holders ........................................................... 2-50
Current fuel consumption ................................. 2-29D
Daytime running light system .......................... 2-41
Defroster switch
Rear window and outside mirror
defroster switch ............................................. 2-37
Dimensions ......................................................... 10-10
Direct Adaptive Steering ................................. 5-127
Distance Control Assist (DCA) ........................ 5-92
Distance to empty ............................................... 2-29
Drive belts .............................................................. 8-13
Drive positioner (See Memory seat) .............. 3-33
Driver assist system indicator .......................... 2-25
Driving
Cold weather driving ................................. 5-138
Driving with Automatic
Transmission (AT) .......................................... 5-16
Precautions when starting and driving ..... 5-4
E
ECO drive indicator light ................................... 2-19
ECO mode ............................................................. 5-22
ECO pedal system ............................................... 5-22
Economy
Fuel .................................................................. 5-123
Elapsed time ......................................................... 2-29
Elapsed time and trip odometer ..................... 2-29
Emergency Call (SOS) button .......................... 2-48
Emergency tire puncture repair kit .................... 6-5
Emission control information label ............... 10-12
Emission control system warranty ............... 10-21Engine
Before starting the engine .......................... 5-14
Break-in schedule ........................................ 5-122
Capacities and
recommended fluids/lubricants ................. 10-2
Changing engine coolant ............................... 8-5
Changing engine oil and filter ...................... 8-7
Checking engine coolant level ...................... 8-4
Checking engine oil level ............................... 8-6
Coolant temperature gauge ......................... 2-8
Emergency engine shut off ......................... 5-13
Engine block heater ................................... 5-139
Engine compartment check locations ........ 8-3
Engine cooling system ................................... 8-3
Engine oil ........................................................... 8-6
Engine oil and filter
replacement indicator ................................... 2-27
Engine oil and oil
filter recommendation .................................. 10-6
Engine serial number ................................. 10-12
Engine specifications ................................... 10-8
Engine start operation indicator ............... 2-23
If your vehicle overheats ............................. 6-13
Intercooler cooling system ............................ 8-5
Remote engine start ..................................... 3-19
Remote engine start
operation indicator ........................................ 2-23
Starting the engine ....................................... 5-15
Engine coolant temperature gauge .................. 2-8
Entry/exit function
Memory seat ................................................... 3-33

Maintenance schedules ................................. 9-6
Outside the vehicle ......................................... 9-2
Seat belt maintenance ................................. 1-17
Standard maintenance ................................... 9-8
Under the hood and vehicle ......................... 9-4
Malfunction indicator light (MIL) ..................... 2-17
Map lights .............................................................. 2-58
Master warning light .............................. 2-14, 2-18
Mechanical key (Intelligent Key system) .......... 3-3
Memory seat ......................................................... 3-33
Memory storage
Memory seat ................................................... 3-34
Meter
Trip computer ................................................. 2-29
Meters and gauges ................................................ 2-6
Instrument brightness control ................... 2-43
Mirror
Inside mirror .................................................... 3-29
Outside mirrors .............................................. 3-31
Vanity mirror ................................................... 3-33
Monitor
Around View
®Monitor ................................ 4-11
RearView Monitor ........................................... 4-3
Moonroof ............................................................... 2-56
Moving Object Detection (MOD) ................... 4-29
N
New vehicle break-in ........................................ 5-122
O
Odometer .................................................................. 2-7
Off-road recovery .................................................. 5-9
Oil
Capacities and
recommended fluids/lubricants ................. 10-2
Changing engine oil and filter ...................... 8-7
Checking engine oil level ............................... 8-6
Engine oil ........................................................... 8-6
One touch unlock sensor (See Intelligent
Key system) .............................................................. 3-9
Operation
Indicators for operation ............................... 2-23
Outside air temperature .................................... 2-31
Outside mirrors .................................................... 3-31
Overheat, If your vehicle overheats ............... 6-13
Owner’s Manual/Service Manual
order information ............................................. 10-24
P
Panic alarm ............................................................ 3-17
Parking
Parking brake operation ............................. 5-20
Parking on hills ............................................. 5-126
Parking brake break-in ................................... 5-130
PERSONAL mode ............................................... 5-24
Phone
Car phone or CB radio ................................ 4-42
Power
Power door lock ............................................... 3-4Power outlet ................................................... 2-47
Power steering system .............................. 5-127
Power windows ............................................. 2-54
Power moonroof ................................................. 2-56
Power steering warning light ........................... 2-18
Pre-crash seat belts with
comfort function .................................................. 1-14
Precautions
Braking precautions .................................... 5-129
Child restraints ............................................... 1-20
Cruise control ................................................. 5-70
Maintenance ..................................................... 8-2
Seat belt usage ............................................... 1-11
Supplemental restraint system .................. 1-38
When starting and driving ............................ 5-4
Predictive Forward Collision
Warning (PFCW) ............................................... 5-113
Push starting ......................................................... 6-12
Push-button ignition switch .............................. 5-11
R
Radio
Car phone or CB radio ................................ 4-42
Rain-sensing auto wiper system ..................... 2-36
Rapid air pressure loss ....................................... 5-10
Readiness for inspection/maintenance
(I/M) test (US only) .......................................... 10-22
Rear seats ................................................................. 1-6
Rear window and outside mirror
defroster switch ................................................... 2-37
RearView Monitor ................................................. 4-3
11-5

11-6
Recorders
Event data .................................................... 10-23
Registering your vehicle in
another country ................................................. 10-11
Remote engine start ........................................... 3-19
Remote keyless entry system .......................... 3-15
Repairing flat tire (with emergency tire
puncture repair kit) ................................................. 6-5
Reporting safety defects ................................. 10-21
Request switch (See Intelligent
Key system) .............................................................. 3-9
Roadside assistance program ............................. 6-2
Rollover ..................................................................... 5-9
Roof
Moonroof ......................................................... 2-57
Run-flat tires .......................................................... 6-4
S
Safety
Child seat belts ............................................... 1-18
Reporting safety defects .......................... 10-21
Seat adjustment
Front power seat adjustment ....................... 1-3
Front seats ......................................................... 1-3
Seat belt(s)
Child safety ..................................................... 1-18
Infants ............................................................... 1-18
Injured persons ............................................... 1-14
Larger children ............................................... 1-19
Pre-crash seat belts with comfort
function ............................................................ 1-14Precautions on seat belt usage .................. 1-11
Pregnant women ........................................... 1-14
Seat belt cleaning ............................................. 7-7
Seat belt extenders ....................................... 1-17
Seat belt maintenance ................................. 1-17
Seat belt warning light
and chime ............................................. 1-13, 2-14
Seat belts .......................................................... 1-11
Seat belts with pretensioners .................... 1-54
Small children .................................................. 1-18
Three-point type ............................................ 1-14
Seat(s)
Driver-side memory ...................................... 3-33
Heated seats ................................................... 2-45
Seats .................................................................... 1-2
Security system
Vehicle security system ................................ 2-32
Security system (INFINITI Vehicle
Immobilizer System)
Engine start ..................................................... 2-33
Servicing air conditioner .................................... 4-41
Shift lever
Shift lock release ........................................... 5-19
Shift lock release, Transmission ...................... 5-19
Shifting
Automatic Transmission (AT) ..................... 5-16
Side ventilators .................................................... 4-34
SNOW mode ......................................................... 5-22
Sonar settings .................................................... 5-137Sonar system ...................................................... 5-136
Camera aiding sonar function
(models with Around View
®Monitor) .... 4-24
Spare tire ............................................................... 10-9
Spark plugs ............................................................ 8-14
Speedometer ............................................................ 2-7
SPORT mode ........................................................ 5-22
SPORT+ mode ...................................................... 5-22
Standard maintenance ......................................... 9-8
STANDARD mode ............................................... 5-22
Starting
Before starting the engine .......................... 5-14
Jump starting .................................................. 8-13
Precautions when starting and driving ..... 5-4
Push starting ................................................... 6-12
Starting the engine ....................................... 5-15
Status light, Front passenger air bag ............ 1-46
Steering
Direct Adaptive Steering ........................... 5-127
Heated steering wheel ................................. 2-46
Power steering system .............................. 5-127
Tilt/telescopic steering ................................ 3-27
Storage ................................................................... 2-50
Storage box ........................................................... 2-52
Sun visors ............................................................... 3-29
Sunglasses holder ................................................ 2-51
Supplemental air bag warning labels ............. 1-55
Supplemental air bag warning light ... 1-55, 2-14
Supplemental restraint system ........................ 1-38
Precautions on supplemental
restraint system ............................................. 1-38
