Black plate (298,1)
[ Edit: 2013/ 10/ 21 Model: Y51-D ]
4-130Monitor, climate, audio, phone and voice recognition systems
.When the air conditioner is in the AUTO
mode, the fan speed decreases auto-
matically for easy recognition.
. Wait until a tone sounds before speak-
ing a command.
. Speak in a natural voice without paus-
ing between words.
SAA3001
Giving voice commandY51D-V-E01-033803BF-E542-48CB-8124-C6CD19F7B4B91. Push and release the TALKswitch
located on the steering wheel.
2. A list of commands appears on the screen, and the system announces,
“Please say a command”.
3. After the tone sounds and the icon on the screen changes from
to,
speak a command.
Operating tips:
GUID-CA441E56-2FD0-4540-A74C-DB510E9F7AE0. Voice commands cannot be accepted
when the icon is
.
. The list displayed can be scrolled by
tilting the menu control switch on the steering wheel.
. If the command is not recognized, the
system announces, “Please say again”.
Repeat the command in a clear voice.
. Push the BACK button once to return to
the previous screen.
. If you want to cancel the command,
push and hold the TALK
switch for
1 second. The message “Voice can-
celed” will be announced.
. To skip the voice guidance function and
give the command immediately, press
the TALK
switch to interrupt the
system. Remember to speak after the
tone.
How to speak numbers:
GUID-CA441E56-2FD0-4540-A74C-DB510E9F7AE0INFINITI Voice Recognition requires a cer-
tain way to speak numbers when giving
voice commands. Refer to the following
examples.
General rule
Only single digits 0 (zero) to 9 can be used.
(For example, if you would like to say 500,
“five zero zero” can be used, but “five
hundred” cannot.
Condition:

Black plate (422,1)
[ Edit: 2013/ 10/ 21 Model: Y51-D ]
6-12In case of emergency
Y51D-V-E01-9ECDEC9C-D91E-43BE-8956-65EFDD4A98EF
CAUTION
.Do not continue to drive if your vehicle
overheats. Doing so could cause engine
damage or a vehicle fire.
. To avoid the danger of being scalded,
never remove the radiator cap while the
engine is still hot. When the radiator cap
is removed, pressurized hot water will
spurt out, possibly causing serious
injury.
. Do not open the hood if steam is coming
out.
If your vehicle is overheating (indicated by
an extremely high temperature gauge
reading), or if you feel a lack of engine
power, detect abnormal noise, etc., take
the following steps:
1. Move the vehicle safely off the road,
apply the parking brake and move the
shift lever to the P (Park) position.
Do not stop the engine.
2. Turn off the climate control. Open all the windows, move the heater or air
conditioner temperature control to
maximum hot and fan control to high speed.
3. If engine overheating is caused by
climbing a long hill on a hot day, run
the engine at a fast idle (approximately
1,500 rpm) until the temperature gauge
indication returns to normal.
4. Get out of the vehicle. Look and listen for steam or coolant escaping from the
radiator before opening the hood. (If
steam or coolant is escaping, turn off
the engine.) Do not open the hood
further until no steam or coolant can be
seen.
5. Open the engine hood.WARNING
If steam or water is coming from the engine,
stand clear to prevent getting burned.
6. Visually check drive belts for damage or looseness. Also check if the cooling fan
is running. The radiator hoses and
radiator should not leak water. If cool-
ant is leaking or the cooling fan does
not run, stop the engine.
WARNING
Be careful not to allow your hands, hair,
jewelry or clothing to come into contact
with, or get caught in, engine belts or the
engine cooling fan. The engine cooling fan
can start at any time.
7. After the engine cools down, check thecoolant level in the reservoir tank with
the engine running. Add coolant to the
reservoir tank if necessary. Have your
vehicle repaired at the nearest INFINITI
retailer.
IF YOUR VEHICLE OVERHEATS
Condition:

Black plate (505,1)
[ Edit: 2013/ 10/ 21 Model: Y51-D ]
Y51D-V-E01-D0235718-BCC7-46F6-99A2-4F6CF7CB5A97
Do not tow a trailer with your
vehicle.
FLAT TOWINGY51D-V-E01-4BE369F8-85AF-4E5B-BCE0-25BA91776960Towing your vehicle with all four wheels on
the ground is sometimes called flat towing.
This method is sometimes used when
towing a vehicle behind a recreational
vehicle, such as a motor home.
CAUTION
.Failure to follow these guidelines can
result in severe transmission damage.
. Whenever flat towing your vehicle, al-
ways tow forward, never backward.
. DO NOT tow any automatic transmission
vehicle with all four wheels on the
ground (flat towing). Doing so WILL
DAMAGE internal transmission parts
due to lack of transmission lubrication.
. For emergency towing procedures refer
to“Towing recommended by INFINITI”
(P.6-14).
Automatic transmissionY51D-V-E01-91431205-A8B6-4757-8B7E-FE93E672CD0DTo tow a vehicle equipped with an auto-
matic transmission, an appropriate vehicle
dolly MUST be placed under the towed
vehicle’s drive wheels. Alwaysfollow the
dolly manufacturer’s recommendations
when using their product.
Y51D-V-E01-BE355711-C850-4467-8C72-25BED609009FDOT (Department Of Transportation) Qual-
ity Grades: All passenger car tires must
conform to federal safety requirements in
addition to these grades.
Quality grades can be found where applic-
able on the tire sidewall between tread
shoulder and maximum section width. For
example:
Treadwear 200 Traction AA Temperature A
TREADWEARY51D-V-E01-06C0EFD4-1C2A-4B83-84AD-0520C1DA8585The treadwear grade is a comparative
rating based on the wear rate of the tire
when tested under controlled conditions
on a specified government test course. For
example, a tire graded 150 would wear one
and one-half (1 1/2) times as well on the
government course as a tire graded 100.
The relative performance of tires depends
upon actual conditions of their use, how-
ever, and may depart significantly from the
norm due to variations in driving habits,
service practices and differences in road
characteristics and climate.
Technical and consumer information9-19
TOWING A TRAILER UNIFORM TIRE QUALITY GRADING
Condition:

Black plate (511,1)
[ Edit: 2013/ 10/ 21 Model: Y51-D ]
10 Index
A
ABS (Anti-lock Braking System)...
....................... 5-101
Active noise control ...
........................................ 5-107
Air bag system Front-seat mounted side-impact
supplemental air bag system ...
....................... 1-48
Roof-mounted curtain side-impact
supplemental air bag system ...
....................... 1-48
Air bag warning labels ...
...................................... 1-51
Air bag warning light ...
............................... 1-51, 2-15
Air cleaner housing filter ...
................................... 8-24
Air conditioner Air conditioner specification label ...
................ 9-13
Air conditioning system refrigerant and
lubricant recommendations ...
............................ 9-7
Automatic climate control ...
............................ 4-34
In-cabin microfilter ...
....................................... 4-48
Air filter In-cabin microfilter ...
....................................... 4-48
Alarm
How to stop alarm (see vehicle
security system) ...
........................................... 2-30
Alcohol, drugs and driving ...
.................................. 5-8
Antenna ...
............................................................ 4-83
Anti-lock Braking System (ABS) ...
....................... 5-101
Appearance care Exterior appearance care ...
................................ 7-2
Interior appearance care ...
................................ 7-4
Armrest ...
............................................................... 1-4
Ashtrays (See cigarette lighter and ashtrays) ...
.... 2-46 Audible reminders
...
............................................ 2-19
Audio operation precautions ...
............................. 4-49
Audio system ...
.................................................... 4-49
Steering wheel audio controls ...
...................... 4-82
Auto closure ...
..................................................... 3-19
Autolight system ...
............................................... 2-35
Automatic Automatic climate control ...
.................. 4-37, 4-41
Automatic transmission fluid (ATF) ...
............... 8-18
Climate control ...
............................................ 4-34
Driving with automatic transmission ...
............ 5-14
Automatic door locks ...
.......................................... 3-5
Automatic drive positioner ...
................................ 3-27
Automatic seat positioner ...
................................. 3-27
Average fuel consumption and speed ...
................ 2-27
Avoiding collision and rollover ...
............................ 5-7
B
Battery ...
.............................................................. 8-20
Battery replacement, Intelligent Key ...
............... 3-2
Battery saver system ...
................................... 2-37
Intelligent Key ...
.............................................. 8-30
Variable voltage control system ...
................... 8-22
Before starting the engine ...
................................ 5-13
Belts (See drive belts) ...
....................................... 8-22
Blind Spot Intervention (BSI) ON
indicator light ...
................................................... 2-16
Bluetooth
®hands-free phone system
(models with navigation system) ...
....................... 4-85 Bluetooth
®hands-free phone system
(models without navigation system) ...
.................. 4-95
Bluetooth
®streaming audio ...
............................. 4-74
Brake Anti-lock Braking System (ABS) ...
.................. 5-101
Brake fluid ...
................................................... 8-19
Brake force distribution ...
............................. 5-103
Brake system ...
............................................... 5-98
Parking brake operation ...
............................... 5-19
Brake warning light ...
........................................... 2-11
Break-in schedule ...
............................................. 5-91
Brightness control Display ON/OFF button ...
................................ 4-10
Bulb check/instrument panel ...
............................ 2-10
Bulb replacement ...
.............................................. 8-33
C
Cabin air filter ...
................................................... 4-48
Capacities and recommended fuel/lubricants ...
...... 9-2
Car phone or CB radio ...
...................................... 4-84
Card holder ...
....................................................... 2-50
Catalytic converter
Three way catalyst ...
......................................... 5-4
CD/CF/USB memory care and cleaning ...
............. 4-81
Center multi-function control panel ...
..................... 4-4
Check tire pressure warning ...
.............................. 2-23
Child restraints ...
................................................. 1-20
LATCH system ...
.............................................. 1-21
Precautions on child restraints ...
..................... 1-20
Condition:

Black plate (512,1)
[ Edit: 2013/ 10/ 21 Model: Y51-D ]
10-2
Child safety...
...................................................... 1-18
Child safety rear door lock ...
.................................. 3-6
Chimes Audible reminders ...
....................................... 2-19
Seat belt warning light and chime ...
............... 2-15
Cigarette lighter and ashtrays ...
........................... 2-46
Circuit breaker
Fusible link ...
.................................................. 8-28
Cleaning exterior and interior ...
....................... 7-2, 7-4
Climate control
Automatic climate control ...
............................ 4-34
Clock ...
................................................................ 2-45
Coat hooks ...
....................................................... 2-51
Cockpit ...
............................................................... 2-3
Cold weather driving ...
....................................... 5-105
Compact Disc (CD) player (See audio system) ...
... 4-65
Compact spare tire ...
........................................... 8-46
Console box ...
...................................................... 2-49
Controller
Center multi-function control panel ...
................ 4-6
Controls Control panel button ...
...................................... 4-4
INFINITI Controller ...
.......................................... 4-6
Coolant Capacities and
recommended fuel/lubricants ...
........................ 9-2
Changing engine coolant ...
............................. 8-14
Checking engine coolant level ...
...................... 8-13
Corrosion protection ...
........................................... 7-7
Cruise control ...
................................................... 5-47
Fixed speed cruise control (on ICC system) ...
... 5-67 Intelligent cruise control (ICC) system
...
.......... 5-49
Cruise indicator ... ................................................ 2-23
Cup holders ...
...................................................... 2-47
Current fuel consumption ...
.................................. 2-27
D
Daytime running light system ...
........................... 2-37
Defroster switch Rear window and outside mirror
defroster switch ...
........................................... 2-34
Dimensions ...
....................................................... 9-10
Display cleaning ...
................................................. 4-8
Display controls (See center multi-function
control panel) ...
..................................................... 4-4
Distance Control Assist (DCA) system ...
................ 5-71
Distance Control Assist (DCA) system
switch indicator ...
................................................ 2-24
Distance Control Assist (DCA) system
warning light ...
.................................................... 2-12
Distance to empty ...
............................................. 2-27
Dot matrix liquid crystal display ...
....................... 2-19
Drive belts ...
........................................................ 8-22
Drive positioner ...
................................................ 3-27
Driving
Cold weather driving ...
.................................. 5-105
Driving with automatic transmission ...
............ 5-14
Precautions when starting and driving ...
........... 5-3
DVD player operation ...
........................................ 4-66
E
ECO drive indicator light ...
................................... 2-17
ECO mode ...
......................................................... 5-20
ECO pedal system ...
............................................. 5-21
Economy
Fuel ...
............................................................. 5-92
Elapsed time ...
..................................................... 2-27
Elapsed time and trip odometer ...
........................ 2-27
Emission control information label ...
.................... 9-13
Emission control system warranty ...
..................... 9-20
Engine Before starting the engine ...
........................... 5-13
Break-in schedule ...
........................................ 5-91
Capacities and
recommended fuel/lubricants ...
........................ 9-2
Changing engine coolant ...
............................. 8-14
Changing engine oil and filter ...
...................... 8-15
Checking engine coolant level ...
...................... 8-13
Checking engine oil level ...
............................. 8-15
Coolant temperature gauge ...
............................ 2-8
Emergency engine shut off ...
........................... 5-11
Engine block heater ...
................................... 5-106
Engine compartment check locations ...
............. 8-7
Engine cooling system ...
................................. 8-12
Engine oil ...
.................................................... 8-14
Engine oil and oil filter recommendation ...
........ 9-6
Engine oil replacement indicator ...
.................. 2-25
Engine oil viscosity ...
........................................ 9-7
Engine serial number ...
................................... 9-12
Engine specifications ...
..................................... 9-8
Condition:

Black plate (513,1)
[ Edit: 2013/ 10/ 21 Model: Y51-D ]
Engine start operation indicator...
................... 2-22
If your vehicle overheats ...
.............................. 6-12
Starting the engine ...
...................................... 5-13
Engine coolant temperature gauge ...
...................... 2-8
Entry/exit function Automatic drive positioner ...
........................... 3-27
Event Data Recorders (EDR) ...
............................... 9-23
Exhaust gas (carbon monoxide) ...
.......................... 5-3
F
F.M.V.S.S./C.M.V.S.S. certification label ...
............. 9-12
Filter
Air cleaner housing filter ...
.............................. 8-24
Changing engine oil and filter ...
...................... 8-15
Flashers (See hazard warning flasher switch) ...
...... 6-2
Flat tire ...
............................................................... 6-3
Flat towing ...
........................................................ 9-19
Floor mat cleaning ...
.............................................. 7-6
Floor mat positioning aid ...
.................................... 7-6
Fluid Automatic transmission fluid (ATF) ...
............... 8-18
Brake fluid ...
................................................... 8-19
Capacities and
recommended fuel/lubricants ...
........................ 9-2
Engine coolant ...
............................................. 8-12
Engine oil ...
.................................................... 8-14
Power steering fluid ...
..................................... 8-18
Window washer fluid ...
................................... 8-19
FM-AM-SAT radio with Compact Disc
(CD) player ...
........................................................ 4-62
Fog light switch ...
................................................ 2-40 Forest Air
®...
........................................................ 4-43
Forward Collision Warning (FCW) system ...
........... 5-83
Front passenger air bag and status light ...
........... 1-45
Front power seat adjustment ...
............................... 1-3
Front seat Front seat adjustment ...
.................................... 1-3
Front-seat active head restraints ...
......................... 1-9
Fuel Capacities and
recommended fuel/lubricants ...
........................ 9-2
Fuel economy ...
............................................... 5-92
Fuel economy information (display) ...
.............. 4-12
Fuel Information ...
............................................. 9-4
Fuel octane rating ...
.......................................... 9-4
Fuel-filler cap ...
............................................... 3-21
Fuel-filler door ...
............................................. 3-21
Gauge ...
............................................................ 2-9
Fuel efficient driving tips ...
................................... 5-91
Fuses ...
................................................................ 8-28
Fusible links ...
..................................................... 8-28
G
Garage door opener
HomeLink®Universal Transceiver ...
................. 2-60
Gas cap ...
............................................................ 3-21
Gauge ...
................................................................. 2-6
Engine coolant temperature gauge ...
................. 2-8
Fuel gauge ...
..................................................... 2-9
Odometer ...
....................................................... 2-7
Speedometer ...
................................................. 2-7
Tachometer ...
.................................................... 2-8 Trip computer
...
.............................................. 2-26
General maintenance ...
.......................................... 8-2
Glove box ...
......................................................... 2-49
H
Hands-free phone system
Bluetooth®(models with
navigation system) ...
....................................... 4-85
Bluetooth
®(models without
navigation system) ...
....................................... 4-95
Hazard warning flasher switch ...
............................ 6-2
Head restraints/headrests ...
................................... 1-5
Headlights Aiming control (See adaptive front lighting
system (AFS)) ...
............................................... 2-37
Bulb replacement ...
......................................... 8-33
Headlight switch ...
.......................................... 2-35
Xenon headlights ...
......................................... 2-34
Heated seats ...
.................................................... 2-41
Heated steering wheel ...
...................................... 2-40
Heater
Automatic climate control ...
............................ 4-34
Engine block heater ...
................................... 5-106
Hill start assist system ...
................................... 5-104
HomeLink
®Universal Transceiver ...
...................... 2-60
Hood release ...
.................................................... 3-17
Hook
Coat hooks ...
.................................................. 2-51
Horn ...
................................................................. 2-41
10-3
Condition:

Black plate (516,1)
[ Edit: 2013/ 10/ 21 Model: Y51-D ]
10-6
Cruise control...
.............................................. 5-47
Lane departure warning (LDW) system ...
......... 5-24
Maintenance ...
.................................................. 8-5
Seat belt usage ...
........................................... 1-10
Supplemental restraint system ...
..................... 1-38
When starting and driving ...
.............................. 5-3
Pre-crash seat belts with comfort function ...
........ 1-13
Predictive course line settings ...
.......................... 4-32
Preview function ...
............................................... 5-99
Preview function (for Intelligent cruise
control system) ...
................................................. 5-70
Preview Function warning light ...
.......................... 2-15
Push starting ...
.................................................... 6-11
Push-button ignition switch ...
....................... 5-9, 5-10
R
Radio
Car phone or CB radio ...
................................. 4-84
FM-AM-SAT radio with Compact Disc
(CD) player ...
................................................... 4-62
Rain-sensing auto wiper system ...
........................ 2-33
Rapid air pressure loss ...
....................................... 5-7
Readiness for inspection/maintenance (I/M) test
(US only) ... .......................................................... 9-22
Rear door lock Child safety rear door lock ...
............................. 3-6
Rear pocket ...
...................................................... 2-50
Rear sunshade ...
.................................................. 2-56
Rear window and outside mirror
defroster switch ...
................................................ 2-34
RearView monitor ...
.............................................. 4-26 Recorders
Event data ...
................................................... 9-23
Registering your vehicle in another country ...
...... 9-11
Remote keyless entry system ...
............................ 3-13
Reporting safety defects ...
................................... 9-21
Rise-up and build-up ...
...................................... 5-103
Roadside assistance program ...
............................. 6-2
Rollover ...
.............................................................. 5-7
Roof Moonroof ...
..................................................... 2-55
S
Safety
Child seat belts ...
........................................... 1-18
Reporting safety defects ...
.............................. 9-21
Satellite radio operation ...
................................... 4-63
Seat adjustment Front power seat adjustment ...
.......................... 1-3
Front seats ...
..................................................... 1-3
Seat belt(s) Child safety ...
................................................. 1-18
Infants ...
......................................................... 1-18
Injured persons ... ........................................... 1-13
Larger children ...
............................................. 1-19
Precautions on seat belt usage ...
.................... 1-10
Pre-crash seat belts with comfort function ...
... 1-13
Pregnant women ...
.......................................... 1-13
Seat belt cleaning ...
.......................................... 7-6
Seat belt extenders ...
...................................... 1-17
Seat belt maintenance ...
................................. 1-17
Seat belt warning light and chime ...
............... 2-15 Seat belts
...
.................................................... 1-10
Seat belts with pretensioners ...
...................... 1-50
Shoulder belt height adjustment ...
.................. 1-16
Small children ...
............................................. 1-19
Three-point type ...
.......................................... 1-13
Seat(s) Climate controlled seats ...
.............................. 2-42
Driver-side memory ...
...................................... 3-27
Heated seats ...
............................................... 2-41
Seats ...
............................................................. 1-2
Security system Vehicle security system ...
................................ 2-29
Security system (INFINITI Vehicle Immobilizer
System) Engine start ...
................................................. 2-30
Servicing air conditioner (See automatic
climate control) ...
................................................. 4-34
Servicing climate control ...
................................... 4-48
SETTING button ...
................................................. 4-16
Shift lever Shift lock release ...
......................................... 5-18
Shift lock release, Transmission ...
........................ 5-18
Shifting Automatic transmission ...
............................... 5-14
Shoulder belt height adjustment ...
....................... 1-16
SNOW mode ...
..................................................... 5-20
Sonar settings (models with
navigation system) ...
............................................ 4-24
Sonar system ...
.................................................... 5-95
Sonar system OFF switch ...
.................................. 5-97
Spare tire ...
........................................................... 9-9
Condition:
