bluetooth INFINITI QX30 2017 Owner's Manual

Phone command
1st command 2nd command 3rd command 4th command Action
Phone Favorites
<1-6>Access frequently called contacts by storing into them in the favorite list.


Redial Make a call to the last outgoing phone number.
International Call Makes an international call by allowing more than 11 digits to be spoken.
You may need to include the international call prefixes and country codes.
Add Phone Use this command to connect a compatible Bluetooth® device to the system. Follow
the on screen instructions to complete the pairing process from your handset.
Call Work <1 - 6> To call someone’s work place, say the person’s name stored in the phonebook on your
cellular phone between “Call” and “Work”.
Call Cellular <1 - 6> To call someone’s cellular phone, say the person’s name stored in the phonebook on
your cellular phone between “Call” and “Mobile”.
Call Home <1 - 6> To call someone’s home, say the person’s name stored in the phonebook on your
cellular phone between “Call” and “Home”.
Call Other <1 - 6> To call someone at a place categorized as “Other”, say the person’s name stored in the
phonebook on your cellular phone between “Call” and “Other”.
NOTE
The system can read out SMS text messages in
voice. However, it cannot always read the text
correctly.
4-112Display screen, heater and air conditioner, and audio system

1st command 2nd command 3rd command Action
Audio USB Play Song

iPod Play Song
Switches to the USB or iPod, selecting the track. You can speak the commands successively.
USB Play Song
iPod Play SongSwitches to the USB or iPod, selecting the track. You can speak the commands successively.
Play Plays the spoken audio source.
Play AM Switches to the AM band, selecting the station last played.
FM Switches to the FM band, selecting the station last played.
SXM SiriusXM Satellite Radio band, selecting the channel last played
USB Turns on the USB, selecting the last played mode.
iPod Turns on the iPod, selecting the last played mode.
CD Turns on the CD, selecting the last played mode.
Bluetooth Audio Turns on the Bluetooth Audio, selecting the last played mode.
iPod Playlist
<1 — 6> Turns on the iPod, playing the spoken playlist.
iPod Play Playlist Turns on the iPod, playing the spoken playlist.
USB All Artists Displays the USB all artists list.
USB All Albums Displays the USB all albums list.
USB All Folders Displays the USB all folders list.
iPod All Artists Displays the iPod all artists list.
iPod All Albums Displays the iPod all albums list.
iPod All Songs Displays the iPod all songs list.
4-114Display screen, heater and air conditioner, and audio system

Notes on operating audio by voice recognition:
•An audio device connected via Bluetooth®
cannot be operated with the Voice Recogni-
tion system. Source change is only available
for Bluetooth® streaming Audio.
•Song title and Artist name information will
be overwritten when another iPod
R/iPhone
Ris connected after song titles and artist
names in the previously connected iPod
R/
iPhon
Re have been installed.
•If two USB devices are connected at the same
time, voice operation will only be available for
use with one registered and selected device.When selecting “YES” in the pop-up screen that
displays after a new USB audio device is con-
nected, the USB audio device is registered in
the voice recognition system and is selected
automatically. One iPod and one USB device
can be registered in the system. If a USB audio
device is newly registered, old data is overwrit-
ten. It may take a few moments to register an
audio device. If you want to enable voice opera-
tion for music stored on a previously registered
audio device, select the device you want to use
in advance.
Voice recognition settingsin the5. Starting
and drivingsection
Even when a device has been previously
registered, simply connecting the device will
not result in it being selected automatically.
•The Voice Recognition system may not func-
tion when the song information is too long
(artist names, album titles, song titles and
playlists, etc.).
•The SXM function will not operate without a
subscription to SiriusXM Satellite Radio.
Information command
1st command 2nd command Action
Information Voice Menu Connects to the INFINITI InTouchTMServices Response Specialists. Refer to the Navigation Owner’s Manual for details.
Operator Connects to the INFINITI InTouchTMServices Response Specialists. Refer to the Navigation Owner’s Manual for details.
Where am I?* Displays the information of the current position.
Fuel Prices Displays the fuel prices.
Weather Forecast Displays the weather forecast.
Current Weather Displays the nearby weather (current weather).
Sports Scores Displays the sports scores.
Traffic Information* Turns the traffic information system on or off.
Route Information* Displays the route information.
*: Models with navigation system only.
Display screen, heater and air conditioner, and audio system4-115

SETTINGS MENU
The Infiniti InTouch system can be customised to make it easier for you to use by adjusting various settings.
Push

Bluetooth® streaming audio
Symptom Possible cause Possible solution
Registration cannot be performed. The Bluetooth® audio device is not compatible with
the in-vehicle audio system.Check the Owner’s Manual for the Bluetooth® audio
device.
The PIN code is incorrect. Check the PIN code for the Bluetooth® audio device
that is to be registered.
Check that the PIN code for the Bluetooth® audio
device is consistent with that for the in-vehicle audio
system.
Another Bluetooth® device is used in the vehicle. Turn off the other Bluetooth® device and wait until
registration is completed.
Music cannot be played. The Bluetooth® audio device is not compatible with
the in-vehicle audio system.Check the Owner’s Manual for the Bluetooth® audio
device.
The system is not in the Bluetooth® audio mode. Push

BLUETOOTH® HANDS-FREE PHONE SYSTEM
Symptom Possible cause Possible solution
A cellular phone cannot be registered. The cellular phone is not compatible with the
in-vehicle hands-free phone system.Use a cellular phone compatible with the system. Visit the
website (www.infinitiusa/bluetooth) for model
compatibility.
Registration of the cellular phone has been performed
incorrectly.Check the registration procedure, and then register the
cellular phone again.
A cellular phone cannot be connected or
becomes disconnected after registration is
complete.The Bluetooth® setting of the in-vehicle hands-free
phone system is turned off.Turn on the Bluetooth® setting of the system.
The Bluetooth® setting of the cellular phone is turned
off.Turn on the Bluetooth® setting of the cellular phone.
The remaining battery level of the cellular phone is
low.Charge the battery of the cellular phone.
The wireless Bluetooth® connection may be disrupted
depending on the location of the cellular phone.Do not place the cellular phone in an area surrounded by
metal or far away from the in-vehicle hand-free phone
system. Do not place the cellular phone close to the seats
or your body.
Registration of the cellular phone is not complete. Perform registration of the cellular phone.
A call to a particular phone number fails. If the system tries to make a call several times to the
same phone number (for example: the party does not
respond to the call, the party is out of the network
service area, or the call is abandoned before the party
responds), the system may reject a request to make a
call to the phone number.Turn the cellular phone off and then on again to reset the
connection.
4-134Display screen, heater and air conditioner, and audio system

Symptom Possible cause Possible solution
The system does not recognize the connection
of a cellular phone and cannot receive or make
a call.The cellular phone is not compatible with the
in-vehicle hands-free phone system.Use a cellular phone compatible with the system. Visit the
website (www.infinitiusa/bluetooth) for model
compatibility.
The cellular phone is not connected. Check the registration procedure, and then register the
cellular phone again.
The phone operation is limited by the functions (such
as dial lock, etc.) of the registered cellular phone.Remove any settings that are limiting use of the cellular
phone, and then perform registration again.
Registered voice tag is cut short. Speaking of the voice tag did not fit within the
5 second recording period after the beep.Speak the voice tag within 5 seconds after the beep.
The other party cannot hear your voice. The
other party can hear your voice, but it cracks or
cuts out.The cellular phone is not connected. Check the registration procedure, and then register the
cellular phone again.
The fan speed of the air conditioner is too fast. Decrease the fan speed of the air conditioner.
The ambient noise level is excessive. (For example:
heavy rain, construction sites, inside a tunnel,
oncoming vehicles, etc.)Close the windows to shut out ambient noise.
The noise generated by driving the vehicle is too
loud.Reduce the vehicle speed, and then speak a command.
The incoming or outgoing voice level is too loud. Adjust the incoming or outgoing voice level properly.
The voice is cut out or noise is heard during a
call.The wireless Bluetooth® connection may be disrupted
depending on the location of the cellular phone.Do not place the cellular phone in an area surrounded by
metal or far away from the in-vehicle hands-free phone
system. Do not place a cellular phone close to the seats or
your body.
When a cellular phone is operated to make a
call, the hands-free function is no longer
available.Some models of a cellular phone do not switch to the
hands-free mode when they are operated to make a
call.This is not a malfunction. Make a call again using the
hands-free function.
The other party’s voice cannot be heard. There
is no ring tone.The volume level is set to the minimum. Adjust the volume level.
A cellular phone is not connected. Check the registration procedure, and then register the
cellular phone again.
Display screen, heater and air conditioner, and audio system4-135

Symptom Possible cause Possible solution
Each volume level (ring tone, incoming voice or
outgoing voice) is different.Each volume level is not adjusted properly. Adjust each volume level properly.
The antenna display is different between the
navigation screen (if equipped) and the screen
on a cellular phone. Making or receiving a call
is unavailable even though the antenna display
indicates that it is possible to do so.The antenna display varies depending on the model
of cellular phone.This does not indicate a malfunction. The antenna display
and remaining battery level shown on the navigation
screen may be different from those shown on the cellular
phone screen. Use them as a reference.
A voice cannot be heard clearly when using a
cellular phone behind tall buildings.Some structures such as tall buildings, etc. may
cause irregular reflection of radio waves or completely
shut out radio waves that are used for cellular
phones.This is not a malfunction.
Noise is heard when using a cellular phone
under/near areas of elevated railroads, high
voltage electric power cables, traffic signals, or
neon billboards, etc.Electromagnetic waves that are generated from radio
devices may adversely affect the cellular phone.This is not a malfunction.
Noise is heard in the sound from the audio
system while using a cellular phone.Radio waves that are generated from a cellular phone
may adversely affect the sound from the audio
system.This is not a malfunction.
The sound skips. The cellular phone may have turned on the wireless
LAN (Wi-Fi).Turn off the wireless LAN (Wi-Fi).
Phonebook cannot be downloaded. An error occurred during the phone pairing process. Re-register the Bluetooth® pairing information after
deleting the pairing information from both the cellular
phone and the vehicle system.
4-136Display screen, heater and air conditioner, and audio system

11 Index
ABS (Anti-lock Braking System).........2-9
Warninglight .................2-9
Active sound enhancement..........5-67
Operation...................5-67
Adaptive Front lighting System........2-64
Aids .......................5-60
Forward emergency braking system....5-60
Hill Start Assist (HSA)............5-93
Intelligent Parking Assist (IPA).......5-68
Air bags.....................1-47
Front passenger air bag switch.......1-47
Overview....................0-2
Repair and replacement...........1-56
Supplemental Restraint System......1-39
Warninglight..............1-55, 2-12
Air cleaner filter.................8-13
Air conditioner.................4-43
Heater and air conditioner.........4-43
Refrigerant and lubricant..........10-6
Servicing...................4-52
Specification label.............10-12
Airfresheners...................7-4
Anti-theft alarm system.............2-57
AppGarage...................4-100
Screen....................4-100
Settings screen...............4-101
Around View Monitor..............4-25
Moving object detection (MOD)......4-38Settings....................4-33
Audible reminders................2-14
Audio.......................4-53
Operation precautions...........4-53
Settings...................4-82
Sourcebar..................4-66
System....................4-53
Automatic transmission.............8-7
Fluid(ATF)...................8-7
Operation...................5-17
Battery......................8-9
Cautionlabel .................8-9
Coldweather.................5-93
Jump-starting.................6-10
Replacement - Intelligent Key.......8-20
Saver system.................2-85
Vehicle battery................8-10
Blind Spot Warning (BSW) system......5-35
Bluetooth®...................4-86
Hands-Free Phone System.....4-86,4-134
Information..................4-98
Streamingaudio ..............4-133
Booster seats..................1-36
Precautions..................1-36
Brakes......................8-17
ABS (Anti-Lock Braking System)......5-88
Adjustment..................8-17
Fluid ......................8-7Forward emergency braking system....5-60
Parking brake................5-25
Precautions..................5-87
System....................5-87
Warninglight .................2-9
Break-inschedule................5-81
Brightness....................2-68
Instrumentpanel ..............2-68
Capacities and recommendations.......10-2
Coolant....................10-2
Fuel......................10-2
Oil.......................10-2
Refrigerant..................10-2
Cardholder...................2-78
Center multi-function control panel......4-2
Changing .....................8-5
Enginecoolant ................8-5
Engineoil ...................8-5
Engine oil filter................8-6
Tires and wheels..............8-34
Checking.....................8-4
Coolantlevel .................8-4
Engine oil level................8-5
Child restraints.................1-20
Anchorage ..................1-23
ISOFIX installation..............1-24
Precautions..................1-20

Child safety....................1-18
Rear door locks.................3-7
Cleaning......................7-3
Alloy wheels..................7-3
Chrome parts..................7-3
Exterior.....................7-2
Glass ......................7-3
Interior.....................7-4
Leatherseatcovers ..............7-6
Removingspots ................7-3
Seatbelts....................7-5
Underbody...................7-3
Washing.....................7-2
Waxing.....................7-2
Clock .......................2-75
Adjusting time.................2-75
Coat hooks....................2-79
Cockpit.......................0-6
Overview..................0-6,2-2
Cold weather...................5-93
Battery.....................5-93
Driving on snow or ice............5-94
Engine coolant................5-93
Precautions..................5-93
Special equipment..............5-94
Tire equipment................5-94
Compact Disc (CD)................4-71
Player..................4-71, 4-128
Compartment...................2-85
Connecting....................4-91
Bluetooth® device..............4-91Bluetooth® Hands-Free Phone.......4-88
Coolant......................10-2
Capacities...................10-2
Changing engine coolant...........8-5
Checking coolant level............8-4
Coldweather .................5-93
Engine cooling system.............8-3
Temperature gauge..............2-6
Corrosion protection...............7-7
Environmental factors.............7-7
Cruisecontrol ..................5-44
Canceling...................5-46
Operation...................5-45
Cupholders ...................2-78
Customer assistance..............4-124
Defroster.....................2-60
Switch.....................2-60
Dimensions....................10-9
Engine.....................10-7
Tires......................10-8
Display......................2-68
Brightness...................2-68
Vehicle information display.........2-15
Warningsandindicators...........2-29
Doors........................3-7
Lift gate.....................3-7
Lockingkey...................3-5
Locks ......................3-4
Map pocket..................2-81
Drive belts....................8-12
Driving.......................5-17Automatic Transmission...........5-17
Cold weather.................5-93
Idle Stop/Start System............5-27
Onsnoworice................5-94
Precautions...................5-4
Emergency key...................3-2
Engine.......................5-15
Before starting.................5-15
Changingenginecoolant...........8-5
Changingengineoil..............8-5
Changing oil filter...............8-6
Checking coolant level............8-4
Checking engine oil level...........8-5
Cold weather.................5-93
Compartment...............0-9,8-3
Cooling system.................8-3
Data ......................10-7
Oil........................8-5
Serial number.................10-11
Spark plugs..................8-13
Starting....................5-16
Event data recorders (EDR)..........10-20
Exhaustgas ....................5-4
Precautions...................5-4
Exterior.......................7-2
Cleaning.....................7-2
Lights.....................8-22
Overview....................0-3
Exterior rear view mirrors............3-17
Filter........................8-13
Aircleaner...................8-13
11-2Index
