4. Insert the support rod3into the slot4on the underside of the hood.
5. When closing the hood, replace the sup-
port rod in its original position
5, slowly
lower the hood to about8–12in.(20–
30 cm) above the hood lock, then let it
drop. Make sure the hood is securely
latched.
WARNING
•Make sure the hood is completely closed
and latched before driving. Failure to do
so could cause the hood to fly open and
result in an accident.
•If you see steam or smoke coming from
the engine compartment, to avoid injury
do not open the hood.
OPENING FUEL-FILLER DOOR
To open the fuel-filler door, unlock it using
one of the following operations, then push
the right side of the door
1.
•Push the door handle request switch with
the Intelligent Key carried with you.
•Push the “UNLOCK”button on the
Intelligent Key.
•Push the power door lock switch to the
“UNLOCK”position.
To close the fuel-filler door, close the door
until it securely latches. To lock the fuel filler
door, lock the vehicle using the intelligent key.
FUEL-FILLER CAP
Turn the fuel-filler cap counterclockwise to
remove. To tighten, turn the cap clockwise
until a single click is heard.
Put the fuel-filler cap on the cap holder
2while refueling.
WARNING
•Gasoline is extremely flammable and
highly explosive under certain condi-
tions. You could be burned or seriously
injured if it is misused or mishandled.
Always stop the engine and do not
smoke or allow open flames or sparks
near the vehicle when refueling.
•Do not attempt to top off the fuel tank
after the fuel pump nozzle shuts off au-
tomatically. Continued refueling may
cause fuel overflow, resulting in fuel
spray and possibly a fire.
•Use only an original equipment type
fuel-filler cap as a replacement. It has a
built-in safety valve needed for proper
operation of the fuel system and emis-
sion control system. An incorrect cap
can result in a serious malfunction and
possible injury.
NDI1605NPA1482
FUEL-FILLER DOOR
3-16Pre-driving checks and adjustments

8 Do-it-yourself
Maintenance precautions.................8-2
Engine compartment check locations.........8-3
2.0L Gasoline engine.................8-3
Engine cooling system...................8-3
Checking engine coolant level............8-4
Changing engine coolant...............8-4
Engine oil...........................8-5
Checking engine oil level...............8-5
Changing engine oil..................8-5
Changing engine oil filter...............8-6
Automatic Transmission Fluid (ATF)..........8-7
Brake fluid..........................8-7
Window washer fluid...................8-8
Battery............................8-9
Accessing Vehicle battery...............8-9
Maintenance free battery..............8-10
Models with Idle Stop/Start System.......8-10
Battery replacement.................8-10
Reinitialisation procedure after battery
reconnection......................8-12
Jump-starting.....................8-12
Drive belt..........................8-12
Spark plugs.........................8-12
Air cleaner filter......................8-13
Wiper blades........................8-13Cleaning.........................8-13
Replacing front window wiper blades......8-14
Replacing rear window wiper blade.......8-16
Brakes............................8-17
Self-adjusting brakes.................8-17
Fuses.............................8-17
Before replacing a fuse...............8-17
Engine compartment.................8-18
Passenger compartment..............8-19
Intelligent Key battery replacement........
.8-20
Checking the battery.................8-21
Replacing the battery.................8-21
Lights............................8-23
Exterior and interior lights..............8-23
Replacement procedures..............8-25
Wheels and tires......................8-27
Tire Pressure......................8-27
Tire inflation pressure................8-30
Tire labeling......................8-30
Types of tires.....................8-32
Tire chains.......................8-33
Tire wear and damage................8-33
Tire rotation......................8-34
Replacing wheels and tires.............8-34
Wheel balance.....................8-36

2.0L GASOLINE ENGINE
1. Engine coolant reservoir (P. 8-3)
2. Engine oil dipstick (P. 8-5)
3. Engine oil filler cap (P. 8-5)
4. Brake fluid reservoir (P. 8-7)5. Engine air cleaner filter (P. 8-13)
6. Battery (P. 8-9)
7. Fuse box (P. 8-17)
8. Window washer fluid reservoir (P. 8-8)
WARNING
The engine cooling system is filled at the
factory with a high-quality, year-round,
antifreeze coolant solution. The antifreeze
solution contains rust and corrosion inhibi-
tors, therefore additional cooling system
additives are not necessary.
•Never remove the radiator or coolant
reservoir cap when the engine is hot.
Wait until the engine and radiator cool
down. Serious burns could be caused by
high-pressure fluid escaping from the
radiator. For additional information on
precautions, refer to "If your vehicle
overheats"
•The engine coolant reservoir tank is
equipped with a pressure type cap. To
prevent engine damage, use only a
genuine INFINITI pressure cap.
CAUTION
•Never use any cooling system additives
such as radiator sealer. Additives may
clog the cooling system and cause dam-
age to the engine, transmission and/or
cooling system.NIC2833
ENGINE COMPARTMENT CHECK
LOCATIONSENGINE COOLING SYSTEM
Do-it-yourself8-3

air conditioner after use is normal. If you
should notice any leaks or if gasoline fumes
are evident, check for the cause and have it
corrected immediately.
Radiator and hoses:
Check the front of the radiator and clean off
any dirt, insects, leaves, etc., that may have
accumulated. Make sure the hoses have no
cracks, deformation, rot or loose connec-
tions.
Underbody:
The underbody is frequently exposed to cor-
rosive substances such as those used on icy
roads or to control dust. It is very important to
remove these substances, otherwise rust will
form on the floor pan, frame, fuel lines and
around the exhaust system. At the end of
winter, the underbody should be thoroughly
flushed with plain water, being careful to
clean those areas where mud and dirt may
accumulate. For additional information, see
"Cleaning exterior".
Windshield washer fluid*:
Check that there is adequate fluid in the res-
ervoir.The following descriptions are provided to
give you a better understanding of the sched-
uled maintenance items that should be regu-
larly checked or replaced. The maintenance
schedule indicates at which mileage/time in-
tervals each item requires service.
In addition to scheduled maintenance, your
vehicle requires that some items be checked
during normal day-to-day operation. Refer to
"General maintenance" in this section.
Items marked with “*” are recommended by
INFINITI for reliable vehicle operation. You
are not required to perform maintenance on
these items in order to maintain the warran-
ties which come with your vehicle. Other
maintenance items and intervals are required.
When applicable, additional information can
be found in the “Do-it-yourself” section in
Chapter 8.
NOTE
INFINITI does not advocate the use of non-
OEM approved aftermarket flushing sys-
tems and strongly advises against perform-
ing these services on an INFINITI product.
Many of the aftermarket flushing systems
use non-OEM approved chemicals or sol-
vents, the use of which has not been vali-
dated by INFINITI.For recommended fuel, lubricants, fluids,
grease, and refrigerant, refer to "Recom-
mended fluids/lubricants and capacities".
EMISSION CONTROL SYSTEM
MAINTENANCE
Drive belts*:
Check engine drive belts for wear, fraying or
cracking and for proper tension. Replace any
damaged drive belts
Engine air filter*:
Replace at specified intervals. When driving
for prolonged periods in dusty conditions,
check/replace the filter more frequently.
Engine coolant*:
Replace coolant at the specified interval.
When adding or replacing coolant, be sure to
use only Genuine INFINITI Engine Coolant or
equivalent in its quality (BASF Glysantin®
G40®). (For additional information, refer to
"Engine cooling system".)
NOTE
Mixing any other type of coolant or the use
of non-distilled water may reduce the rec-
ommended service interval of the coolant.
EXPLANATION OF GENERAL
MAINTENANCE ITEMS
Maintenance and Schedules9-5

The following are approximate capacities. The actual refill quantities may be slightly different. When refilling, follow the procedures instructed
in the “8. Maintenance and do-it-yourself” section to determine the proper refill capacity.
Fluid type Capacity (approximate) Recommended Fluids/Lubricants
Metric Measure US measure Imperial Measure
Fuel tank 50 L
(4WD: 56 L)13.2 gal
(4WD: 14.8 gal11 gal
(4WD: 12.3 gal)
–See "Fuel recommendation" later in this section.
Engine oil (*)
Drain and refill with oil filter
change5.6 L 6 qt 5 qt The approximate capacities listed are for refilling during an engine oil change. *:
For additional information, see "Changing engine oil".
2.0L gasoline engine:
–Engine oil meeting specification MB229.5, viscosity SAE 0W-30 or equivalent–As an alternative to this recommended oil, engine oils meeting specification
MB229.5, viscosity SAE 0W-40, 5W-30 and 5W-40 may be used and meet
all specifications and requirements necessary to maintain the new vehicle
limited warranty.
For additional information, see "Engine oil and oil filter recommendations" later in
this section.
Cooling system
with Reservoir7.6 8.1 qt 6.7 qt
–Genuine INFINITI Engine Coolant or equivalent in its quality
BASF Glysantin® G40®
–Use Genuine INFINITI Engine Coolant, or equivalent in its quality, in order to
avoid possible aluminum corrosion within the engine cooling system caused by
the use of non-genuine engine coolant.Note that any repairs for incidents
with the engine cooling system while using non-genuine engine coolant may
not be covered by the warranty even if such incidents occurred during the
warranty period.
Automatic Transmission
Fluid (ATF)6.21 L 6.6 qt 5.5 qt Shell DCT-M1
Brake fluid Refill to the proper fluid level accord-
ing to the instructions in the “8. Main-
tenance and do-it-yourself” section.
–Genuine INFINITI brake fluid DOT4+ or equivalent.–Never mix different types of fluids.
Differential gear oil 0.74 L 0.8 qt 0.65 qt
–Castrol BOT 355 75W-85
Multi-purpose grease — — —
–NLGI No. 2 (Lithium soap base)
RECOMMENDED FLUIDS/
LUBRICANTS AND CAPACITIES
10-2Technical information

Fluid type Capacity (approximate) Recommended Fluids/Lubricants
Metric Measure US measure Imperial Measure
Air conditioner system
refrigerant—— —
–HFC-134a
Air conditioner system
lubricant—— —
–INFINITI A/C System Oil Type S or equivalent
FUEL RECOMMENDATION
INFINITI recommends the use of unleaded
premium gasoline with an octane rating of at
least 91 AKI (Anti-Knock Index) number (Re-
search octane number 95).
If unleaded premium gasoline is not available,
unleaded regular gasoline with an octane rat-
ing of at least 89 AKI number (Research oc-
tane number 93) may be temporarily used,
but only under the following precautions:
•Have the fuel tank filled only partially with
unleaded regular gasoline, and fill up with
unleaded premium gasoline as soon as
possible.
•Avoid full throttle driving and abrupt ac-
celeration.
Use unleaded premium gasoline for maxi-
mum vehicle performance.
CAUTION
•Using a fuel other than that specified
could adversely affect the emission con-
trol system, and may also affect war-
ranty coverage.
•Under no circumstances should a leaded
gasoline be used, because this will dam-
age the three-way catalyst.
•Do not use E-15 or E-85 fuel in your
vehicle. Your vehicle is not designed to
run on E-15 or E-85 fuel. Using E-15 or
E-85 fuel in a vehicle not specifically de-
signed for E-15 or E-85 fuel can ad-
versely affect the emission control de-
vices and systems of the vehicle.
Damage caused by such fuel is not cov-
ered by the INFINITI New Vehicle Lim-
ited Warranty.
•Do not use fuel that contains the octane
booster methylcyclopentadienyl man-
ganese tricarbonyl (MMT). Using fuel
containing MMT may adversely affect
vehicle performance and vehicle emis-
sions. Not all fuel dispensers are labeled
to indicate MMT content, so you may
have to consult your gasoline retailer for
more details. Note that Federal and
California laws prohibit the use of MMT
in reformulated gasoline.
•U.S. government regulations require
ethanol dispensing pumps to be identified
by a small, square, orange and black label
with the common abbreviation or the ap-
propriate percentage for that region.
Gasoline specifications
INFINITI recommends using gasoline that
meets the World-Wide Fuel Charter
(WWFC) specifications where it is available.
Technical information10-3

Aftermarket fuel additives
INFINITI does not recommend the use of any
aftermarket fuel additives (Example: fuel in-
jector cleaner, octane booster, intake valve
deposit removers, etc.) which are sold com-
mercially. Many of these additives intended
for gum, varnish or deposit removal may con-
tain active solvent or similar ingredients that
can be harmful to the fuel system and engine.
Octane rating tips
Using unleaded gasoline with an octane rat-
ing lower than recommended above can
cause persistent, heavy spark knock. (Spark
knock is a metallic rapping noise.) If severe,
this can lead to engine damage. If you detect
a persistent heavy spark knock even when
using gasoline of the stated octane rating, or
if you hear steady spark knock while holding
a steady speed on level roads, it is recom-
mended you have an INFINITI retailer cor-
rect the condition. Failure to correct the con-
dition is misuse of the vehicle, for which
INFINITI is not responsible.
Incorrect ignition timing will result in knock-
ing, after-run and/or overheating. This in turn
may cause excessive fuel consumption or
damage to the engine. If any of the above
symptoms are encountered, have your ve-
hicle checked. It is recommended you visit an
INFINITI retailer.However, now and then you may notice light
spark knock for a short time while accelerat-
ing or driving up hills. This is no cause for
concern, because you get the greatest fuel
benefit when there is light spark knock for a
short time under heavy engine load.
ENGINE OIL AND OIL FILTER
RECOMMENDATIONS
Selecting the correct oil
It is essential to choose the correct grade,
quality, and viscosity engine oil to ensure sat-
isfactory engine life and performance. For
additional information, refer to "Recom-
mended fluids/lubricants and capacities"
earlier in this section.
Select only engine oils that meet the MB229.5
specification and SAE viscosity standard. These
oils have the MB229.5 specification label on the
container. Oils which do not have the specified
quality label should not be used as they could
cause engine damage.
Oil additives
INFINITI does not recommend the use of oil
additives. The use of an oil additive is not
necessary when the proper oil type is used
and maintenance intervals are followed.
Oil which may contain foreign matter or has
been previously used should not be used.
Oil viscosity
The engine oil viscosity or thickness changes
with temperature. Because of this, it is impor-
tant that the engine oil viscosity be selected
based on the temperatures at which the vehicle
will be operated before the next oil change.
Choosing an oil viscosity other than that recom-
mended could cause serious engine damage.
Outside Temperature Range
Anticipated Before Next Oil Change
GASOLINE ENGINE OIL
JVT0428X
Technical information10-5

Model 2.0L Gasoline
Type Gasoline, 4-cycle
Cylinder arrangement 4-cylinder in-line
Bore x Stroke in (mm) 3.268 x 3.622
(83.0 x 92.0)
Displacement cu in (cm
3) 121.55 (1,991)
Idling speed rpm
DCT in N position 700
Ignition timing (BTDC) degrees
DCT in N position -10°CA to +35°CA BTDC at
700rpm
Spark plug Standard Platinum tipped
Spark plug gap in (mm) 0.028 (0.7)
Camshaft operation Timing chain
This spark ignition system complies with the Canadian standard ICES-002.
ENGINE SPECIFICATIONS
Technical information10-7
