Hill Start Assist (HSA)................. .5-96
Cold weather driving .................. .5-97
Freeing a frozen door lock .............5-97
Antifreeze ....................... .5-97
Battery ......................... .5-97Draining of engine coolant
.............5-97
Tire equipment .................... .5-97
Special winter equipment ..............5-98
Driving on snow or ice ............... .5-98

roll away There is a risk of an accident
and injury. Therefore, quickly move your
foot from the brake pedal to the accel-
erator pedal. Never leave the vehicle
when it is held by hill start assist.
Hill start assist helps you when pulling away
forwards or in reverse on an uphill gradient. It
holds the vehicle for a short time after you
have removed your foot from the brake
pedal. This gives you enough time to move
your foot from the brake pedal to the accel-
erator pedal and depress it before the vehicle
begins to roll.
Hill start assist is not active if
•You are pulling away on a level road or a
downhill gradient.
•On vehicles with automatic transmission,
the transmission is in position N.
•The electric parking brake is applied.
•VDC is malfunctioning.
FREEING A FROZEN DOOR LOCK
To prevent a door lock from freezing, apply
deicer through the key hole. If the lock be-
comes frozen, heat the key before inserting it
into the key hole, or use the INFINITI Intelli-
gent Key.
ANTIFREEZE
In the winter when it is anticipated that the
temperature will drop below 32°F (0°C),
check the antifreeze to assure proper winter
protection. For additional information, see
"Engine cooling system" in the "8. Do-it-
yourself" section.
BATTERY
If the battery is not fully charged during ex-
tremely cold weather conditions, the battery
fluid may freeze and damage the battery. To
maintain maximum efficiency, the battery
should be checked regularly. For details, see
"Battery" in the "8. Do-it-yourself" section of
this manual.
DRAINING OF ENGINE COOLANT
If the vehicle is to be left outside without
antifreeze, drain the cooling system, including
the engine block. Refill before operating the
vehicle. For details, see "Changing engine
coolant" in the "8. Do-it-yourself" section of
this manual.
TIRE EQUIPMENT
1. SUMMER tires have a tread designed to provide superior performance on dry
pavement. However, the performance of
these tires will be substantially reduced in
snowy and icy conditions. If you operate
your vehicle on snowy or icy roads,
INFINITI recommends the use of MUD &
SNOW or ALL SEASON TIRES on all four
wheels. It is recommended that you visit
an INFINITI retailer for the tire type, size,
speed rating and availability information.
2. For additional traction on icy roads, stud- ded tires may be used. However, some
U.S. states and Canadian provinces pro-
hibit their use. Check local, state and pro-
vincial laws before installing studded tires.
Skid and traction capabilities of studded
snow tires, on wet or dry surfaces, may be
poorer than that of non-studded snow tires.
3. Tire chains may be used if desired. Make sure they are the proper size for the tires
on your vehicle and are installed according
to the chain manufacturer’s instructions.
Use chain tensioners when recommended
by the tire chain manufacturer to ensure a
tight fit. Loose end links of the tire chains
must be secured or removed to prevent
the possibility of whipping action damage
to the fenders or underbody. In addition,
COLD WEATHER DRIVING
Starting and driving5-97

WARNING
•Do not continue to drive if your vehicle
overheats. Doing so could cause engine
damage or a vehicle fire.
•To avoid the danger of being scalded,
never remove the radiator or coolant
reservoir cap while the engine is hot.
When the radiator or coolant reservoir
cap is removed, pressurized hot water
will spurt out, possibly causing serious
injury.
•Do not open the hood if steam is coming
out.
If the engine of your vehicle is overheating
(indicated by the engine coolant temperature
gauge) or if you feel a lack of engine power,
detect unusual noise, etc., proceed as fol-
lows:
1. Move and park the vehicle safely off the road and away from traffic.
2. Turn on the hazard warning flasher lights.
3. Apply the parking brake.
4. Press the P (Park) button. DO NOT STOP THE ENGINE.
5. Open all windows. 6. Switch off the air conditioner system (if
equipped).
7. Set the heater or air conditioner tempera- ture control to maximum “HOT” and fan
speed control to maximum speed.
8. Exit the vehicle.
9. Visually inspect and listen for steam or coolant escaping from the radiator before
opening the hood.
WARNING
If steam or water is coming from the en-
gine, stand clear to prevent getting
burned.
10. Open the hood. For details, see "Hood" in the "3. Pre-driving checks and adjust-
ments" section.
11. Visually check if the cooling fan is run- ning.
12. Visually check the radiator and radiator hoses for leakage.
WARNING
Be careful not to allow your hands, hair,
jewelry or clothing to come into contact
with, or get caught in, engine belts or the
engine cooling fan. The engine cooling fan
can start at any time.
13. After the engine cools down, check the coolant level in the engine coolant reser-
voir with the engine running. Do not
open the radiator cap (if equipped).
14. If the level is low, remove the engine coolant reservoir cap and add coolant
slowly into the reservoir. After refilling
the reservoir to the MAX level, install the
reservoir cap.
15. Close the hood.
Have your vehicle inspected or repaired. It is
recommended you visit an INFINITI retailer.
IF YOUR VEHICLE OVERHEATS
In case of emergency6-13

8 Do-it-yourself
Maintenance precautions.................8-2
Engine compartment check locations .........8-3
2.0L Gasoline engine ................ .8-3
Engine cooling system .................. .8-3
Checking engine coolant level ............8-4
Changing engine coolant ...............8-4
Engine oil .......................... .8-5
Checking engine oil level ...............8-5
Changing engine oil ................. .8-5
Changing engine oil filter ...............8-6
Automatic Transmission Fluid (ATF) ..........8-7
Brake fluid ......................... .8-7
Window washer fluid .................. .8-8
Battery ........................... .8-9
Accessing Vehicle battery ..............8-10
Maintenance free battery ..............8-10
Models with Idle Stop/Start System .......8-11
Battery replacement ................ .8-11
Reinitialisation procedure after battery
reconnection ..................... .8-12
Jump-starting .................... .8-12
Drive belt ......................... .8-12
Spark plugs ........................ .8-13
Air cleaner filter ..................... .8-13
Wiper blades ....................... .8-13Cleaning
........................ .8-13
Replacing front window wiper blades ......8-14
Replacing rear window wiper blade .......8-16
Brakes ........................... .8-17
Self-adjusting brakes ................ .8-17
Fuses ............................ .8-17
Before replacing a fuse ...............8-17
Engine compartment ................ .8-17
Passenger compartment ..............8-18
Intelligent Key battery replacement ........
.8-20
Checking

the battery ................ .8-20
Replacing the battery ............... .8-20
Lights ........................... .8-22
Exterior and interior lights ..............8-22
Replacement procedures ..............8-24
Wheels and tires ..................... .8-27
Tire Pressure ..................... .8-27
Tire inflation pressure ............... .8-29
Tire labeling ..................... .8-29
Types of tires ..................... .8-31
Tire chains ...................... .8-32
Tire wear and damage ............... .8-33
Tire rotation ..................... .8-34
Replacing wheels and tires .............8-34
Wheel balance .................... .8-35

When performing any inspection or mainte-
nance work on your vehicle, always take care
to prevent serious accidental injury to your-
self or damage to the vehicle. The following
are general precautions which should be
closely observed.
WARNING
•Park the vehicle on a level surface, apply
the parking brake securely and block the
wheels to prevent the vehicle from mov-
ing. Press the P (Park) button.
•Be sure the ignition switch is in the OFF
position when performing any parts re-
placement or repairs.
•Do not work under the hood while the
engine is hot. Always turn off the engine
and wait until it cools down.
•If you must work with the engine run-
ning, keep your hands, clothing, hair and
tools away from moving fans, belts and
any other moving parts.
•It is advisable to secure or remove any
loose clothing and any jewelry, such as
rings, watches, etc. before working on
your vehicle.
•If you must run the engine in an enclosed
space such as a garage, be sure there is proper ventilation for exhaust gases to
escape.
•Never get under the vehicle while it is
supported by a jack.
•Keep smoking materials, flame and
sparks away from fuel and the battery.
•Never connect or disconnect either the
battery or any transistorized compo-
nent connector while the ignition switch
is in the ON position.
•On gasoline engine models with the
Multiport Fuel Injection system, the fuel
filter and fuel lines should be serviced by
an INFINITI retailer or qualified work-
shop because the fuel lines are under
high pressure even when the engine is
turned off.
•Your vehicle is equipped with an auto-
matic engine cooling fan. It may come on
at any time without warning, even if the
ignition switch is in the OFF position
and the engine is not running. To avoid
injury, always disconnect the negative
battery cable before working near the
fan.
•Always wear eye protection whenever
you work on your vehicle.
•Never leave the engine or the transmis-
sion related component harness connec-
tor disconnected while the ignition
switch is in the ON position.
•Avoid direct contact with used engine oil
and coolant. Improperly disposed engine
oil, engine coolant, and/or other vehicle
fluids can hurt the environment. Always
conform to local regulations for disposal
of vehicle fluids.
This “ 8. Do-it-yourself” section provides in-
structions regarding only those items which
are relatively easy for an owner to perform.
You should be aware that incomplete or im-
proper servicing may result in operating diffi-
culties or excessive emissions, and could af-
fect your warranty coverage. If in doubt
about any servicing, it is recommended you
have it done by an INFINITI retailer.
MAINTENANCE PRECAUTIONS
8-2Do-it-yourself

2.0L GASOLINE ENGINE
1. Engine coolant reservoir (P.8-3)
2. Engine oil dipstick (P.8-5)
3. Engine oil filler cap (P.8-5)
4. Brake fluid reservoir (P.8-7)
5. Engine air cleaner filter (P.8-13)6. Battery (P.8-9)
7. Fuse box (P.8-17)
8. Window washer fluid reservoir (P.8-8)
WARNING
The engine cooling system is filled at the
factory with a high-quality, year-round,
antifreeze coolant solution. The antifreeze
solution contains rust and corrosion inhibi-
tors, therefore additional cooling system
additives are not necessary.
•Never remove the radiator or coolant
reservoir cap when the engine is hot.
Wait until the engine and radiator cool
down. Serious burns could be caused by
high-pressure fluid escaping from the
radiator. For additional information on
precautions, refer to "If your vehicle
overheats" in the "6. In case of emer-
gency" section
•The engine coolant reservoir tank is
equipped with a pressure type cap. To
prevent engine damage, use only a
genuine INFINITI pressure cap.
CAUTION
•Never use any cooling system additives
such as radiator sealer. Additives may
clog the cooling system and cause dam-
age to the engine, transmission and/or
cooling system.
NIC2833
ENGINE COMPARTMENT CHECK
LOCATIONS ENGINE COOLING SYSTEM
Do-it-yourself8-3

•When adding or replacing coolant, be
sure to use only INFINITI Genuine En-
gine Coolant, BASF Glysantin G40 or
equivalent in its quality. The use of other
types of engine coolant may damage the
engine cooling system.
CHECKING ENGINE COOLANT
LEVEL
NOTE
The coolant level must only be checked and
corrected when the engine is cold.
1. Park the vehicle on a level surface.
Only check the coolant level if the vehicle
is on a level surface and the engine is cold. 2. Slowly turn cap
1half a turn counter-
clockwise to allow excess pressure to es-
cape.
3. Turn cap
1further counter-clockwise
and remove it.
If the coolant is at the level of marker bar
3in the filler neck when cold, there is
enough coolant in coolant expansion tank
2.
4. If necessary, top up with INFINITI Genu- ine Engine Coolant, BASF Glysantin G40
or equivalent in its quality.
5. Replace cap
1and turn it clockwise as
far as it will go.
If the cooling system frequently requires
coolant, have it checked. It is recommended
that you visit an INFINITI retailer for this
service.
CHANGING ENGINE COOLANT
An INFINITI retailer can change the engine
coolant.
Improper servicing can result in reduced
heater performance and engine overheating.
WARNING
•To avoid being scalded, never change
the coolant when the engine is hot.
•Never remove the radiator cap when the
engine is hot. Serious burns could be
caused by high pressure fluid escaping
from the radiator.
•Avoid direct skin contact with used
coolant. If skin contact is made, wash
thoroughly with soap or hand cleaner as
soon as possible.
•Keep coolant out of reach of children
and pets.
Engine coolant must be disposed of properly.
Check your local regulations.
NDI1602
8-4Do-it-yourself

Check the fluid level in the reservoir. If the
brake fluid is below the MIN line
2, the brake
warning light will illuminate. Add brake fluid
up to the MAX line
1. Use Genuine INFINITI
brake fluid DOT4+ or equivalent. Never mix
different types of fluids. For additional infor-
mation on the recommended type of brake
fluid, refer "Recommended fluids/lubricants
and capacities" in the "9. Maintenance and
Schedules" section.
If the brake fluid must be added frequently,
the brake system should be thoroughly
checked. It is recommended that you visit an
INFINITI retailer for this service. Fill the windshield-washer fluid reservoir pe-
riodically. Add fluid when the low washer
fluid warning appears on the vehicle informa-
tion display.
To fill the windshield-washer fluid reservoir,
lift the cap off the reservoir and pour the
windshield-washer fluid into the reservoir
opening.
Add a washer solvent to the washer for bet-
ter cleaning. In the winter season, add a
windshield-washer antifreeze. Follow the
manufacturer’s instructions for the mixture
ratio.
Refill the reservoir more frequently when
driving conditions require an increased
amount of windshield-washer fluid.Recommended fluid is Genuine INFINITI
Windshield Washer Concentrate Cleaner &
Antifreeze or equivalent.CAUTION
•Do not substitute engine antifreeze
coolant for window washer solution.
This may result in damage to the paint.
•Do not fill the window washer reservoir
tank with washer fluid concentrates at
full strength. Some methyl alcohol
based washer fluid concentrates may
permanently stain the grille if spilled
while filling the window washer reser-
voir tank.
•Pre-mix washer fluid concentrates with
water to the manufacturer’s recom-
mended levels before pouring the fluid
into the window washer reservoir tank.
Do not use the window washer reservoir
tank to mix the washer fluid concentrate
and water.
NDI1601
WINDOW WASHER FLUID
8-8Do-it-yourself

Parking brake*:
Check the parking brake operation regularly.
Also make sure that the vehicle is held se-
curely on a fairly steep hill when only the
parking brake is applied. If the parking brake
needs adjustment, it is recommended you
visit an INFINITI retailer for this service.
Seats:
Check seat position controls such as seat
adjusters, seatback recliner, etc. to ensure
they operate smoothly and that all latches
lock securely in every position. Check that the
head restraints move up and down smoothly
and that the locks (if so equipped) hold se-
curely in all latched positions.
Seat belts:
Check that all parts of the seat belt system
(for example, buckles, anchors, adjusters and
retractors) operate properly and smoothly,
and are installed securely. Check the belt
webbing for cuts, fraying, wear or damage.
Steering wheel:
Check for changes in the steering condition,
such as excessive free play, hard steering or
strange noises.
Warning lights and chimes:
Make sure that all warning lights and chimes
are operating properly.Windshield defroster:
Check that the air comes out of the defroster
outlets properly and in good quantity when
operating the heater or air conditioner.
Windshield wiper and washer*:
Check that the wipers and washer operate
properly and that the wipers do not streak.
Under the hood and vehicle
The maintenance items listed here should be
checked periodically (for example, each time
you check the engine oil or refuel).
Battery*:
Except for maintenance free battery, check
the fluid level in each cell. It should be be-
tween the “UPPER” and “LOWER” lines. Ve-
hicles operated in high temperatures or under
severe conditions require frequent checks of
the battery fluid level.
NOTE
Care should be taken to avoid situations
that can lead to potential battery discharge
and potential no-start conditions such as:
1. Installation or extended use of electronic
accessories that consume battery power
when the engine is not running (Phone
chargers, GPS, DVD players, etc.) 2. Vehicle is not driven regularly and/or
only driven short distances.
In these cases, the battery may need to be
charged to maintain battery health.
Brake fluid level*:
Make sure that the brake fluid level is be-
tween the “MAX” and “MIN” lines on the res-
ervoir.
Coolant level*:
Check the coolant level when the engine is
cold.
Engine drive belt(s)*:
Make sure that no belt is frayed, worn,
cracked or oily.
Engine oil level*:
Check the level after parking the vehicle on a
level spot and turning off the engine. Wait
more than 15 minutes for the oil to drain back
into the oil pan.
Exhaust system:
Make sure there are no loose supports,
cracks or holes. If the sound of the exhaust
seems unusual or there is a smell of exhaust
fumes, immediately have the exhaust system
inspected. It is recommended you visit an
9-4Maintenance and Schedules

For recommended fuel, lubricants, fluids,
grease, and refrigerant, refer to "Recom-
mended fluids/lubricants and capacities" in
the "10. Technical information" section.
EMISSION CONTROL SYSTEM
MAINTENANCE
Drive belts*:
Check engine drive belts for wear, fraying or
cracking and for proper tension. Replace any
damaged drive belts
Engine air filter*:
Replace at specified intervals. When driving
for prolonged periods in dusty conditions,
check/replace the filter more frequently.
Engine coolant*:
Replace coolant at the specified interval.
When adding or replacing coolant, be sure to
use only Genuine INFINITI Engine Coolant or
equivalent in its quality (BASF Glysantin®
G40®). (For additional information, refer to
"Engine cooling system" in the "9. Mainte-
nance and Schedules" sectionnanceand
SchedulesMaintenance and Schedules" sec-
tion nanceand SchedulesMaintenance and
Schedules" section nanceand Schedules-
Maintenance and Schedules" section nance-
and SchedulesMaintenance and Schedules"
section nanceand SchedulesMaintenanceand Schedules" section nanceand Schedules-
Maintenance and Schedules" section nance-
and SchedulesMaintenance and Schedules"
section nanceand SchedulesMaintenance
and Schedules" section nanceand Schedules-
Maintenance and Schedules" section nance-
and SchedulesMaintenance and Schedules"
section nanceand SchedulesMaintenance
and Schedules" section.)
NOTE
Mixing any other type of coolant or the use
of non-distilled water may reduce the rec-
ommended service interval of the coolant.
Engine oil and oil filter:
Replace engine oil and oil filter at the speci-
fied intervals. For recommended oil grade
and viscosity refer to "Recommended fluids/
lubricants and capacities" in the "10. Techni-
cal information" section calinformationTech-
nical information" section information"
section.
Fuel filter:
Replace the fuel filter and drain the water at
the specified intervals.
Fuel lines*:
Check the fuel hoses, piping and connections
for leaks, looseness, or deterioration. Tighten
connections or replace parts as necessary.
Spark plugs:
Replace at specified intervals. Install new
plugs of the type as originally equipped.
CHASSIS AND BODY
MAINTENANCE
Brake lines and cables:
Visually inspect for proper installation. Check
for chafing, cracks, deterioration, and signs
of leaking. Replace any deteriorated or dam-
aged parts immediately.
Brake pads, rotors, drums, & linings:
Check for wear, deterioration and fluid leaks.
Replace any deteriorated or damaged parts
immediately.
Exhaust system:
Visually inspect the exhaust pipes, muffler
and hangers for leaks, cracks, deterioration,
and damage. Tighten connections or replace
parts as necessary.
In-cabin microfilter:
Replace at specified intervals. When driving
for prolonged periods in dusty conditions, re-
place the filter more frequently.
9-6Maintenance and Schedules
