clock INFINITI QX30 2019 Quick Reference Guide

Additional information about your vehicle is also available in your Owner’s Manual, INFINITI InTouch™ Owner’s Manual and at www.InfinitiUSA.com.
Table of Contents
• A cellular telephone should not be used for any purpose while
driving so full attention may be
given to vehicle operation.
•
Alw

ays wear your seat belt.
•

Supplemen
tal air bags do not
replace proper seat belt usage. • Childr
en 12 and under
should always ride in the
rear seat properly secured in
child restraints or seat belts
according to their age
and weight.
• Do not drink and drive.For more information, refer to the “Safety — Seats,
seat belts and supplemental restraint system (section
1)”, the “Display screen, heater and air conditioner,
and audio system (section 4)” and the “Starting and
driving (section 5)” of your Owner’s Manual.
PLEASE SEE YOUR OWNER’S MANUAL FOR IMPORTANT SAFETY INFORMATION AND SYSTEM OPERATION LIMITATIONS.
Cockpit Overview ........................................................................\
.......... 1
Instrumen t Panel ........................................................................\
........... 3
Meters and Gauges
........................................................................\
...... 5
Hood Latch
........................................................................\
..................... 7
Sun Visors
........................................................................\
........................ 7
Parking Brake
........................................................................\
................. 7
Seat Adjustments
........................................................................\
.......... 8
Head Restraint Adjustment (if so equipped)
..................................9
Lane Departure Warning (LDW) (if so equipped)
.........................9
Exterior Light Operation
.................................................................. 10
Wiper and Washer Switch
............................................................... 10
USB Connection Port
........................................................................\
. 11
Clock Set/Adjustment
....................................................................... 11Fuel-filler Door
........................................................................\
.............
12
Opening the Liftgate ........................................................................\
..12
Electronic Shift Lever


........................................................................\
.12
Windows........................................................................\
........................13
Idle Stop/Start (ISS)
........................................................................\
...13
Intelligent Park Assist (IPA) (if so equipped)
...............................14
Voice Recognition........................................................................\
....... 14
Connecting your Cellular Phone or Device via Bluetooth
® ....... 15
Blue
tooth® Streaming Audio ............................................................. 15
INFINITI In
Touch™ Services (if so equipped) ................................16
Navigation System (if so equipped)
................................................ 17
Cruise Control
........................................................................\
............. 18

11
To adjust the time and the appearance of the clock on the display:
Pr
ess the MENU button
on the Infiniti controller. Then, touch the “Settings”
key on the display.
Locate and touch the “Clock” key to adjust “On-Screen Clock”, “Daylight
Savings Time”, “Clock Format (24h)” and “Time Zone”.
The time can be adjusted through “Offset Adjustment”
by adjusting the
minutes and/or hours forward or backward. The current clock time can be set
up to a difference of 12 hours and 59 minutes.
Please see your INFINITI InTouch™ Owner’s Manual for important safety information, system limitations,
and additional operating and feature information.
Clock Set/Adjustment
Your vehicle is equipped with two USB ports, located under
the control panel, to which you can connect compatible
devices (cellular phones, iPod
® devices, other compatible
audio devices, USB memory sticks, etc.).
After connecting your device through one of the USB ports,
press the MEDIA button on the control panel to select audio
playback from the device connected through the USB ports.
A second device can be connected for charging. In order
to switch to the second device for audio playback, both
devices will need to be removed and the second device
reconnected first.
Please see your INFINITI InTouch™ Owner’s Manual for important safety
information, system limitations, and additional operating and feature information.
USB Connection Port

18
Cruise Control
CONVENTIONAL CRUISE CONTROL (IF SO EQUIPPED)
Cruise control maintains a constant set speed for you. The system is operational only at
speeds above 20 mph (30 km/h).
Pull the lever toward you to recall the previous speed.
Lift the lever up to the pressure point and release the lever to increase the speed by 1 mph (1.6 km/h).
Push the le ver down to the pressure point and release the lever to decrease the speed by
1 mph (1.6 km/h).
Lift the lever upward beyond the pressure point and release the lever to increase the speed to the nearest multiple of 5 mph (8 km/h).
Push the le ver downward beyond the pressure point and release the lever to decrease the
speed to the nearest multiple of 5 mph (8 km/h).
To override the current stored speed with your current real speed, quickly move the stalk
up
or down .
To deactivate cruise control, push the lever
away from you or push the brake pedal.
INTELLIGENT CRUISE CONTROL (ICC) (IF SO EQUIPPED)
The ICC system is designed to maintain a selected distance from the vehicle in front of you
and reduce the speed to match a slower vehicle ahead.
To increase the distance to the vehicle ahead to be maintained by the ICC system, turn the
knob
clockwise. To reduce the distance, turn the knob counterclockwise.
Please see your Owner’s Manual for important safety information, system limitations, and additional operating and
feature information.
Cruise Control Stalk
