fuse box INFINITI QX50 2020 Owner's Manual

KR20DDET engine
1. Engine coolant reservoir (P. 8-4)
2. Drive belt location (P. 8-13)
3. Air filter (P. 8-15)
4. Brake fluid reservoir (P. 8-10)
5. Battery (P. 8-11)
6. Fuse/Fusible link box (P. 8-18)
7. Windshield-washer fluid reservoir(P. 8-11)
8. Engine oil filler cap (P. 8-6)
9. Engine oil dipstick (P. 8-6)
Refer to the page number indicated in paren-
theses for operating details.
LDI3173
ENGINE COMPARTMENT CHECK
LOCATIONS
0-8Illustrated table of contents

The extended storage switch is used when
shipping the vehicle. It is located in the fuse
panel on the driver’s side of the instrument
panel. If any electrical equipment does not
operate, ensure the extended storage switch
is pushed fully in place, as shown.
To inspect the extended storage switch, en-
sure the ignition switch and headlight switch
are off, remove the fuse box cover
Ausing a
suitable tool in combination with a cloth to
avoid damaging the trim.
FRONT-DOOR POCKETS SEATBACK POCKETS
The seatback pockets may be located on the
back of the driver’s and/or passenger’s seats.
The pockets can be used to store maps.
ON position
LIC3268LIC3834LIC1328
STORAGE
2-56Instruments and controls

KR20DDET engine
1. Engine coolant reservoir
2. Drive belt location
3. Air filter
4. Brake fluid reservoir
5. Battery
6. Fuse/Fusible link box
7. Windshield-washer fluid reservoir
8. Engine oil filler cap
9. Engine oil dipstick
LDI3173
ENGINE COMPARTMENT CHECK
LOCATIONS
Do-it-yourself8-3

If the brakes do not operate properly, it is
recommended that you have the brakes
checked. It is recommended that you visit an
INFINITI retailer for this service.
Self-adjusting brakes
Your vehicle is equipped with self-adjusting
brakes.
The front and rear disc-type brakes self-
adjust every time the brake pedal is applied.
WARNING
Have your brake system checked if the
brake pedal height does not return to nor-
mal. It is recommended that you visit an
INFINITI retailer for this service.
Brake pad wear indicators
The disc brake pads on your vehicle have
audible wear indicators. When a brake pad
requires replacement, a high pitched scraping
or screeching sound will be heard when the
vehicle is in motion. The noise will be heard
whether or not the brake pedal is depressed.
Have the brakes checked as soon as possible
if the wear indicator sound is heard.Under some driving or climate conditions, oc-
casional brake squeak, squeal or other noise
may be heard. Occasional brake noise during
light to moderate stops is normal and does
not affect the function or performance of the
brake system.
Proper brake inspection intervals should be
followed.
For additional information regard-
ing brake inspections, refer to the appropri-
ate maintenance schedule information in the
"Maintenance and schedules" section of this
manual.
If any electrical equipment does not operate,
check for an open fuse.
Fuses are used in the passenger and engine
compartment. Spare fuses are provided and
can be found in the passenger compartment
fuse box.
When installing a fuse make sure the fuse is
installed in the fuse box securely.
LDI2997
BRAKES FUSES
8-18Do-it-yourself

ENGINE COMPARTMENT
WARNING
Never use a fuse of higher or lower amper-
age rating than that specified on the fuse
box cover. This could damage the electrical
system or electronic control units or cause a
fire.If any electrical equipment does not come on,
check for an open fuse.
1. Be sure the ignition switch and the head- light switch are OFF.
2. Open the engine hood.
3. Remove the fuse box cover by pushing the tabs and lifting the cover up.
4. Remove the fuse with the fuse puller. The fuse puller is located in the fuse
block in the passenger compartment.
5. If the fuse is open
A, replace it with a
new fuse
B.
6. If a new fuse also opens, have the elec- trical system checked and repaired. It is
recommended that you visit an INFINITI
retailer for this service.
Fusible links
If the electrical equipment does not operate
and fuses are in good condition, check the
fusible links. If any of these fusible links are
melted, replace with only Genuine NISSAN
parts.
LDI3174LDI3200
Do-it-yourself8-19

PASSENGER COMPARTMENT
WARNING
Never use a fuse of higher or lower amper-
age rating than that specified on the fuse
box cover. This could damage the electrical
system or electronic control units or cause a
fire.
If any electrical equipment does not operate,
check for an open fuse. NOTE:
The fuse box is located on the driver’s side of
the instrument panel.
1. Be sure the ignition switch and the head- light switch are OFF.
2. Remove the fuse box cover
Awith a
suitable tool. Use a cloth to avoid dam-
aging the trim.
3. Locate the fuse that needs to be re- placed.
4. Remove the fuse with the fuse puller
B. 5. If the fuse is open
C, replace it with an
equivalent good fuse
D.
6. Push the fuse box cover to install.
If a new fuse also opens, have the electrical
system checked and repaired. It is recom-
mended that you visit an INFINITI retailer for
this service.
NOTE:
Your vehicle may not be equipped with all
fuses listed on the fuse label.
LDI3167LDI3203
8-20Do-it-yourself

Front air bag system
(See supplemental restraint system)....1-51
Front and rear sonar system ........5-187
Front and rear sonar system switch ....2-50
Front-door pocket ...............2-56
Front power seat adjustment .........1-3
Frontseats....................1-2
Fuel Capacities and recommended
fuel/lubricants...............10-2
Fuel economy ...............5-173
Fuel-filler door and cap ..........3-30
Fuel gauge ..................2-7
Fueloctanerating.............10-5
Fuel recommendation ...........10-3
Loose fuel cap warning ..........2-26
Fuel efficient driving tips ..........5-172
Fuel-filler door .................3-30
Fuel gauge ....................2-7
Fuses ......................8-18
Fusiblelinks...................8-19
G
Garage door opener, HomeLink® Universal
Transceiver............2-76,2-78,2-79
Gascap.....................3-30
Gauge Engine coolant temperature gauge ....2-6
Fuel gauge ..................2-7
Odometer ...................2-5
Speedometer ..............2-4,2-5
Tachometer .................2-6
Trip odometer .............2-4,2-5
General maintenance ..............9-2 Glovebox....................2-58
Gloveboxlock.................2-58
Grocery hooks
.................2-62
H
Hazard warning flasher switch ........6-2
Headlight aiming control ...........2-44
Headlight and turn signal switch ......2-40
Headlights ...................8-23
Headlights, aiming control ..........2-44
Headlight switch ...............2-40
Head restraints ..................1-7
Head Up Display (HUD) ............2-51
Heated seats ..................2-48
Heater Heater and air conditioner (automatic)
(if so equipped) ...............4-35
Heater and air conditioner controls . . .4-36
Heater operation .............4-37
Heater and air conditioner (automatic) . . .4-35
Heater and air conditioner settings .....4-42
Hill start assist system ............5-186
HomeLink® Universal
Transceiver............2-76,2-78,2-79
Hood .......................3-23
Hook Luggage hook ...............2-61
Horn.......................2-46
I
Ignition switch Push-button ignition switch .......5-13Immobilizer system
..............5-17
Important vehicle information label . . . .10-11
In-cabin microfilter ..............8-15
Increasing fuel economy ..........5-173
Indicator lights and audible reminders
(See warning/indicator lights and audible
reminders) .............2-9,2-10,2-16
INFINITI Drive Mode Selector ........5-29
INFINITI Intelligent Key System .....3-2,
3-7
INFINITI
InTouch™ Owner's Manual .....4-2
INFINITI Vehicle Immobilizer
System ...............2-34,3-4,5-17
Inside automatic anti-glare mirror .....3-35
Instrument brightness control ........2-45
Instrument panel .............0-6,2-2
Instrument panel dimmer switch ......2-45
Intelligent All-Wheel Drive (AWD) .....5-173
Intelligent Cruise Control (ICC)
(for vehicles without ProPILOT Assist) . . .5-77
Intelligent Key system Key operating range ............3-8
Keyoperation ...............3-10
Mechanical key ...............3-3
Remote keyless entry operation .....3-14
Troubleshooting guide ..........3-17
Warningsignals ..............3-17
Interiorlight................... 2-74
ISOFIX child restraints ............1-24
J
Jump starting ............... 6-5, 8-12
11-3
