• You may feel a pulsation in the brake pedaland hear a noise or vibration from under the
hood. This is normal and indicates that the
VDC system is working properly.
• Adjust your speed and driving to the road conditions.
For additional information, see “Slip indicator
light” (P. 2-17) and ”Vehicle Dynamic Control
(VDC) OFF indicator light” (P. 2-17).
If a malfunction occurs in the system, the
andindicator lights come on in the
instrument panel. The VDC system automati-
cally turns off when these indicator lights are
on.
The lower display is used to turn off the VDC
system. When the VDC system is turned off,
the
indicator light, the RAB system
warning light, and the FEB with Pedestrian
Detection system warning light illuminate to
indicate the VDC, FEB with Pedestrian De-
tection, and RAB systems are off.
When the lower display is used to turn off the
system, the VDC system still operates to pre-
vent one drive wheel from slipping by trans-
ferring power to a non-slipping drive wheel.
The
indicator light flashes if this occurs.
All other VDC functions are off and the
indicator light will not flash. The VDC system is automatically reset to on
when the ignition switch is placed in the OFF
position then back to the ON position.
The computer has a built-in diagnostic fea-
ture that tests the system each time you start
the engine and move the vehicle forward or in
reverse at a slow speed. When the self-test
occurs, you may hear a clunk noise and/or
feel a pulsation in the brake pedal. This is
normal and is not an indication of a
malfunction.
WARNING
• The VDC system is designed to help the
driver maintain controllability but does
not prevent accidents due to abrupt
steering operation at high speeds or by
careless or dangerous driving tech-
niques. Reduce vehicle speed and be es-
pecially careful when driving and corner-
ing on slippery surfaces and always drive
carefully. •
Do not modify the vehicle's suspension.
If suspension parts such as shock ab-
sorbers, struts, springs, stabilizer bars,
bushings and wheels are not INFINITI
recommended for your vehicle or are ex-
tremely deteriorated, the VDC system
may not operate properly. This could ad-
versely affect vehicle handling perfor-
mance, and the
indicator light may
flash or both theandindicator
lights may illuminate.
• If brake related parts such as brake pads,
rotors and calipers are not INFINITI rec-
ommended or are extremely deterio-
rated, the VDC system may not operate
properly and both the
and theindicator lights may illuminate.
• If engine control related parts are not
INFINITI recommended or are extremely
deteriorated, both the
andindicator lights may illuminate.
• When driving on extremely inclined sur-
faces such as higher banked corners, the
VDC system may not operate properly
and the
indicator light may flash or
both theandindicator lights
may illuminate. Do not drive on these
types of roads.
5-142Starting and driving

•When driving on an unstable surface
such as a turntable, ferry, elevator or
ramp, the
indicator light may flash
or both theandindicator
lights may illuminate. This is not a mal-
function. Restart the engine after driv-
ing onto a stable surface.
• If wheels or tires other than the INFINITI
recommended ones are used, the VDC
system may not operate properly and
the
indicator light may flash or both
theandindicator lights may
illuminate.
• The VDC system is not a substitute for
winter tires or tire chains on a snow cov-
ered road.
BRAKE FORCE DISTRIBUTION
During braking while driving through turns,
the system optimizes the distribution of force
to each of the four wheels depending on the
radius of the turn.
WARNING
• The VDC system is designed to help the
driver maintain controllability but does
not prevent accidents due to abrupt
steering operation at high speeds or by
careless or dangerous driving tech-
niques. Reduce vehicle speed and be es-
pecially careful when driving and corner-
ing on slippery surfaces and always drive
carefully.
• Do not modify the vehicle’s suspension.
If suspension parts such as shock ab-
sorbers, struts, springs, stabilizer bars,
bushings and wheels are not INFINITI
recommended for your vehicle or are ex-
tremely deteriorated, the VDC system
may not operate properly. This could ad-
versely affect vehicle handling perfor-
mance, and the
indicator light may
flash or both theandindicator
lights may illuminate.
• If brake related parts such as brake pads,
rotors and calipers are not INFINITI rec-
ommended or are extremely deterio-
rated, the VDC system may not operate
properly and both the
and theindicator lights may illuminate. •
If engine control related parts are not
INFINITI recommended or are extremely
deteriorated, both the
andindicator lights may illuminate.
• When driving on extremely inclined sur-
faces such as higher banked corners, the
VDC system may not operate properly
and the
indicator light may flash or
both theandindicator lights
may illuminate. Do not drive on these
types of roads.
• When driving on an unstable surface
such as a turntable, ferry, elevator or
ramp, the
indicator light may flash
or both theandindicator
lights may illuminate. This is not a mal-
function. Restart the engine after driv-
ing onto a stable surface.
• If wheels or tires other than the INFINITI
recommended ones are used, the VDC
system may not operate properly and
the
indicator light may flash or both
theandindicator lights may
illuminate.
• The VDC system is not a substitute for
winter tires or tire chains on a snow cov-
ered road.
Starting and driving5-143

Push the switch on to warn other drivers
when you must stop or park under emer-
gency conditions. All turn signal lights flash.
WARNING
• If stopping for an emergency, be sure to
move the vehicle well off the road.
• Do not use the hazard warning flashers
while moving on the highway unless un-
usual circumstances force you to drive so
slowly that your vehicle might become a
hazard to other traffic.
• Turn signals do not work when the haz-
ard warning flasher lights are on. The flashers will operate with the ignition
switch placed in any position.
Some jurisdictions may prohibit the use of
the hazard warning flasher switch while
driving.
In the event of a roadside emergency, road-
side assistance service is available to you.
Please refer to your Warranty Information
Booklet (U.S.) or the Warranty & Roadside
Assistance Information Booklet (Canada) for
details.
LIC0394
HAZARD WARNING FLASHER
SWITCH
ROADSIDE ASSISTANCE PROGRAM
6-2In case of emergency

To shut off the engine in an emergency situ-
ation while driving, perform the following
procedure:
– Rapidly push the push-button ignitionswitch three consecutive times in less than
1.5 seconds, or
– Push and hold the push-button ignition switch for more than 2 seconds.TIRE PRESSURE MONITORING
SYSTEM (TPMS)
This vehicle is equipped with Tire Pressure
Monitoring System (TPMS). It monitors tire
pressure of all tires. When the low tire pres-
sure warning light is lit, and the “Tire Pressure
Low - Add Air” or “Flat Tire-Visit dealer” (if so
equipped) warning appears in the vehicle in-
formation display, one or more of your tires is
significantly under-inflated. The system also
displays pressure of all tires (except the spare
tire) on the vehicle information display screen
by sending a signal from a sensor that is
installed in each wheel. If the vehicle is being
driven with low tire pressure, the TPMS will
activate and warn you of it by the low tire
pressure warning light. This system will acti-
vate only when the vehicle is driven at speeds
above 16 mph (25 km/h). For additional in-
formation, see “Warning lights, indicator
lights and audible reminders” (P. 2-9) and
“Tire Pressure Monitoring System (TPMS)”
(P. 8-27).
WARNING
• Radio waves could adversely affect elec-
tric medical equipment. Those who use a
pacemaker should contact the electric
medical equipment manufacturer for the
possible influences before use. •
If the low tire pressure warning light illu-
minates while driving, avoid sudden
steering maneuvers or abrupt braking,
reduce vehicle speed, pull off the road to
a safe location and stop the vehicle as
soon as possible. Driving with under-
inflated tires may permanently damage
the tires and increase the likelihood of
tire failure. Serious vehicle damage could
occur and may lead to an accident and
could result in serious personal injury.
Check the tire pressure for all four tires.
Adjust the tire pressure to the recom-
mended COLD tire pressure shown on
the Tire and Loading Information label to
turn the low tire pressure warning light
OFF. If the light still illuminates while
driving after adjusting the tire pressure,
a tire may be flat or the TPMS may be
malfunctioning. If you have a flat tire,
replace it with a replacement tire as soon
as possible. If no tires are flat and all tires
are properly inflated, have the vehicle
checked. It is recommended that you
visit an INFINITI retailer for this service.
EMERGENCY ENGINE SHUT OFF FLAT TIRE
In case of emergency6-3

WARNING
Always follow the instructions below. Fail-
ure to do so could result in damage to the
charging system and cause personal injury.
1. If the booster battery is in another vehicle, position the two vehicles to bring their
batteries near each other.
Do not allow the two vehicles to touch.
2. Apply the parking brake. Engage the P (Park) position. Switch off all unnecessary
electrical systems (lights, heater, air con-
ditioner, etc.). 3. Place the ignition switch to the LOCK or
OFF position.
4. Connect the jumper cables in the se- quence illustrated (
OA,OB,OC,OD).
CAUTION
• Always connect positive (+) to positive
(+) and negative (−) to body ground (for
example, strut mounting bolt, engine lift
bracket, etc.) — not to the battery.
• Make sure the jumper cables do not
touch moving parts in the engine com-
partment and that the cable clamps do
not contact any other metal. 5. Start the engine of the booster vehicle and
let it run for a few minutes.
6. Keep the engine speed of the booster ve- hicle at about 2,000 rpm and start the
engine of the vehicle being jump started.
CAUTION
Do not keep the starter motor engaged for
more than 10 seconds. If the engine does
not start right away, place the ignition
switch in the OFF position and wait 3 to 4
seconds before trying again.
7. After starting the engine, carefully discon- nect the negative cable and then the posi-
tive cable.
LCE2223
6-6In case of emergency

Parking brake:Check the parking brake op-
eration regularly. The vehicle should be se-
curely held on a fairly steep hill with only the
parking brake applied. If the parking brake
does not securely hold the vehicle, it is recom-
mended that you visit an INFINITI retailer for
service.
Seat belts: Check that all parts of the seat
belt system (for example, buckles, anchors,
adjusters and retractors) operate properly
and smoothly, and are installed securely.
Check the belt webbing for cuts, fraying,
wear or damage.
Seats: Check seat position controls such as
seat adjusters, seatback recliner, etc., to en-
sure they operate smoothly and all latches
lock securely in every position. Check that the
head restraints/headrests move up and
down smoothly and the locks (if so equipped)
hold securely in all latched positions.
Steering wheel: Check for changes in the
steering system, such as excessive free play,
hard steering or strange noises.
Warning lights and chimes: Make sure all
warning lights and chimes are operating
properly.
Windshield defroster: Check that the air
comes out of the defroster outlets properly and in sufficient quantity when operating the
heater or air conditioner.
Windshield wiper and washer*:
Check that
the wipers and washer operate properly and
that the wipers do not streak.
Under the hood and vehicle
The maintenance items listed here should be
checked periodically (for example, each time
you check the engine oil or refuel).
Battery (for maintenance free batteries)*:
This vehicle is equipped with a sealed main-
tenance free battery. It is recommended that
you visit an INFINITI retailer for this service.
NOTE:
Care should be taken to avoid situations
that can lead to potential battery discharge
and potential no-start conditions such as:
1. Installation or extended use of electronic accessories that consume battery power
when the engine is not running (Phone
chargers, GPS, DVD players, etc.).
2. Vehicle is not driven regularly and/or only driven short distances.
In these cases, the battery may need to be
charged to maintain battery health. Brake fluid level*:
Make sure that the brake
fluid level is between the MAX and MIN lines
on the reservoir.
Engine coolant level*: Check the coolant level
when the engine is cold.
Engine drive belt*: Make sure the drive belt is
not frayed, worn, cracked or oily.
Engine oil level*: Check the level after parking
the vehicle on a level spot and turning off the
engine. Wait more than 15 minutes for the oil
to drain back into the oil pan.
Exhaust system: Make sure there are no
loose supports, cracks or holes. If the sound
of the exhaust seems unusual or there is a
smell of exhaust fumes, immediately have the
exhaust system inspected. It is recommended
that you visit an INFINITI retailer for this
service. For additional information, see “Ex-
haust gas (carbon monoxide)” (P. 5-4).
Fluid leaks: Check under the vehicle for fuel,
oil, water or other fluid leaks after the vehicle
has been parked for a while. Water dripping
from the air conditioner after use is normal. If
you should notice any leaks or if fuel fumes
are evident, check for the cause and have it
corrected immediately.
9-4Maintenance and schedules

11 Index
A
Active Engine Brake............5-145Active noise cancellation
Active sound enhancement......5-155Active Ride Control........... .5-146Active Trace Control............5-144Aiming control, headlights.........2-45Air bag (See supplemental restraint
system).................... .1-41Air bag system
Front (See supplemental front impact air
bag system)
............... .1-49Air bag warning labels............1-61Air bag warning light.........1-62, 2-12Air bag warning light,
supplemental............ .1-62, 2-12Air cleaner.................. .8-16Air cleaner housing filter..........8-16Air conditioner
Air conditioner operation........4-34Air conditioner specification label. .10-12Air conditioner system refrigerant and oil
recommendations............ .10-7Heater and air conditioner (automatic)
(if so equipped)............. .4-33Heater and air conditioner controls. .4-34Servicing air conditioner.........4-41Alarm system (See vehicle security
system).................... .2-33Anchor point locations............1-26
Antenna................... .4-41Anti-lock brake warning light. . . .2-10, 2-13Anti-lock Braking System (ABS).....5-140Antifreeze..................5-153Armrests.................... .1-5Around View® Monitor...........4-11Autolight switch.............. .2-41Automatic
Automatic power window switch. . .2-67Automatic anti-glare inside mirror.....3-34Automatic brake hold........... .5-26Automatic door locks............ .3-6
B
Battery............... .5-153, 8-12Charge warning light...........2-10Battery replacement............ .8-22INFINITI Intelligent Key.........8-22Key fob.................. .8-22Before starting the engine.........5-16Belt (See drive belt).............8-15Blind Spot Intervention® (BSI).......5-53Blind Spot Warning (BSW).........5-45Booster seats................ .1-38Brake
Anti-lock Braking System (ABS). . .5-140Brake fluid................ .8-10Brake light (See stop light)........8-25Brake system...............5-139
Brake warning light............2-10Brake wear indicators......2-18, 8-19Self-adjusting brakes...........8-19Brake Assist................ .5-141Brake fluid.................. .8-10Brake system................5-139Brakes.................... .8-19Break-in schedule..............5-131Brightness control
Instrument panel............ .2-46Bulb check/instrument panel........2-10Bulb replacement............. .8-25
C
C.M.V.S.S. certification label.......10-11Camera Aiding Sonar (parking sensor). .4-24Capacities and recommended
fuel/lubricants............... .10-2Car phone or CB radio...........4-42Cargo (See vehicle loading
information)................ .10-15Cargo area storage bin...........2-62Cargo cover................. .2-64Cargo light..................2-70Chassis control...............5-144Check tire pressure.............2-28Child restraint with top tether strap. . . .1-25Child restraints. . . .1-19, 1-20, 1-21, 1-23

Forward Emergency Braking (FEB) with
Pedestrian Detection system. . .2-13, 5-109Front air bag system (See supplemental
restraint system)................1-49Front and rear sonar system........5-147Front and rear sonar system switch. . . .2-51Front power seat adjustment.........1-3Front seats................... .1-2Front-door pocket..............2-57Fuel
Capacities and recommended
fuel/lubricants
.............. .10-2Fuel economy...............5-133Fuel gauge................. .2-7Fuel octane rating.............10-5Fuel recommendation...........10-3Fuel-filler door and cap..........3-29Loose fuel cap warning..........2-26Fuel efficient driving tips..........5-132Fuel gauge................... .2-7Fuel-filler door.................3-29Fuses..................... .8-20Fusible links..................8-21
G
Garage door opener, HomeLink® Universal
Transceiver...........2-71, 2-73, 2-74Gas cap.................... .3-29Gauge
Engine coolant temperature gauge. . . .2-6Fuel gauge................. .2-7Odometer.................. .2-5
Speedometer..............2-4, 2-5Tachometer................. .2-6Trip odometer................2-5General maintenance..............9-2Glove box................... .2-59Glove box lock.................2-59Grocery hooks.................2-63
H
Hazard warning flasher switch........6-2Head restraints.................1-7Head Up Display (HUD)...........2-52Headlight aiming control...........2-45Headlight and turn signal switch......2-40Headlight switch.............. .2-40Headlights.................. .8-24Headlights, aiming control..........2-45Heated mirrors.................3-36Heated rear seats...............2-50Heated seats................. .2-49Heater
Heater and air conditioner (automatic)
(if so equipped)
.............. .4-33Heater and air conditioner controls. . .4-34Heater operation..............4-35Heater and air conditioner (automatic). .4-33Heater and air conditioner settings. . . .4-40Hill start assist system...........5-146HomeLink® Universal
Transceiver...........2-71, 2-73, 2-74Hood..................... .3-21
Hook
Luggage hook.............. .2-63Horn...................... .2-47
I
Ignition switch
Push-button ignition switch.......5-13Immobilizer system............. .5-16Important vehicle information label. . . .10-11In-cabin microfilter..............8-17Increasing fuel economy..........5-133Indicator lights and audible reminders
(See warning/indicator lights and audible
reminders)
............... .2-9, 2-10INFINITI Drive Mode Selector.......5-29INFINITI Intelligent Key System. . . .3-2, 3-6INFINITI InTouch™ Owner's Manual. . . .4-2INFINITI Vehicle Immobilizer
System..............2-34, 3-4, 5-16Inside automatic anti-glare mirror. . . . .3-34Instrument brightness control........2-46Instrument panel.............0-6, 2-2Instrument panel dimmer switch......2-46Intelligent All-Wheel Drive (AWD). . . .5-133Intelligent Cruise Control (ICC)
(for vehicles with ProPILOT Assist). . . .5-84Intelligent Key system
Key operating range............ .3-8Key operation............... .3-9Mechanical key................3-3Remote keyless entry operation.....3-14Troubleshooting guide..........3-16
11-3

Warning signals..............3-16Interior light................. .2-69ISOFIX child restraints............1-23
J
Jump starting............. .6-5, 8-14
K
Key....................... .3-2Key fob battery replacement........8-22Keyless entry
With Intelligent Key system
(See Intelligent Key system)
.......3-14
L
LabelTire and Loading Information label. .10-12LabelsAir conditioner specification label. . .10-12C.M.V.S.S. certification label......10-11Emission control information label. . .10-11Engine serial number.......... .10-11F.M.V.S.S. certification label......10-11Tire and Loading Information label. .10-12Vehicle identification number (VIN). .10-10Vehicle identification number (VIN)
plate................... .10-10Warning labels (for SRS).........1-61Lane Departure Prevention (LDP).....5-39
Lane Departure Warning (LDW)......5-34LATCH (Lower Anchors and Tethers for
CHildren) System...............1-23LED Daytime Running Lights (DRL)
system.................... .2-45License plate
Installing the license plate........10-13Liftgate.................... .3-22Liftgate release................3-27Light
Air bag warning light........1-62, 2-12Brake light (See stop light)........8-25Bulb check/instrument panel......2-10Bulb replacement............ .8-25Charge warning light...........2-10Exterior and Interior lights........8-25Fog light switch............. .2-47Fog lights................. .8-24Headlight and turn signal switch. . . .2-40Headlights.................8-24Interior light.................2-69Light bulbs.................8-24Low tire pressure warning light.....2-13Low windshield-washer fluid warning
light..................... .2-27Personal lights...............2-70Security indicator light...........2-12Warning/indicator lights and audible
reminders.............. .2-9, 2-10Lights..................... .8-24Map lights..................2-70Lock
Child safety rear door lock.........3-6Door locks................. .3-4
Glove box lock...............2-59Liftgate release...............3-27Power door locks..............3-5Loose fuel cap warning...........2-26Low fuel warning light. . . .2-11, 2-16, 2-27Low tire pressure warning light.......2-13Low windshield-washer fluid warning
light...................... .2-27Luggage (See vehicle loading
information).................10-15Luggage hook.................2-63
M
Maintenance
General maintenance........... .9-2Inside the vehicle.............. .9-3Maintenance precautions.........8-2Outside the vehicle.............9-2Seat belt maintenance...........1-18Under the hood and vehicle........9-4Maintenance requirements..........9-2Maintenance schedules.........9-7, 9-8Malfunction indicator light..........2-15Map lights.................. .2-70Memory seat..............3-37, 3-39Meters and gauges.............. .2-4Instrument brightness control......2-46Mirror
Automatic anti-glare inside mirror. . .3-34Heated mirrors.............. .3-36Outside mirrors...............3-35Vanity mirror............... .3-34
11-4

Mirror defroster................2-39Mirrors.................... .3-34Moonroof................2-67, 7-5Moving Object Detection (MOD)......4-27
O
Octane rating (See fuel octane rating). . .10-5Odometer................... .2-5Oil
Capacities and recommended
fuel/lubricants
.............. .10-2Changing engine oil.............8-6Changing engine oil filter..........8-6Checking engine oil level..........8-6Engine oil.................. .8-6Engine oil and oil filter
recommendation..............10-6Engine oil viscosity.............10-6Outside mirrors............... .3-35Overhead sunglasses holder........2-60Overheat
If your vehicle overheats..........6-7Owner's manual order form........10-26Owner's manual/service manual order
information................. .10-26
P
Parking
Parking/parking on hills.........5-135Parking brake..........2-11, 2-13, 2-17Personal lights................ .2-70
Power
Power door locks............. .3-5Power outlet............... .2-55Power rear windows...........2-66Power steering system.....5-136, 5-137Power windows............. .2-65Rear power windows...........2-66Power outlet................. .2-55Power steering...........5-136, 5-137Precautions
Maintenance precautions.........8-2On-pavement and off-road driving
precautions................. .5-8Precautions on booster
seats.........1-21, 1-28, 1-34, 1-38Precautions on child
restraints.......1-21, 1-28, 1-34, 1-38Precautions on seat belt usage......1-11Precautions on supplemental restraint
system................... .1-41Precautions when starting and
driving.................5-4, 5-10Predictive Forward Collision Warning
(PFCW)................... .5-120ProPILOT Assist................5-73Push starting.................. .6-7
R
Radio
Car phone or CB radio..........4-42Rain sensor.................. .2-37
Readiness for inspection maintenance (I/M)
test..................... .10-24Rear Automatic Braking (RAB). .2-17, 5-104Rear bench seat adjustment..........1-4Rear Cross Traffic Alert (RCTA)......5-65Rear power windows.............2-66Rear window defroster, outside mirror
defroster, and wiper deicer switch.....2-39Rear window wiper and washer
switches................... .2-38RearView Monitor...............4-3Recommended Fluids.............10-2Recorders
Event Data.......... .10-24, 10-25Refrigerant recommendation........10-7Registering a vehicle in another
country................... .10-10Remote Engine Start.........3-18, 5-17Reporting safety defects (US only). . . .10-22Roadside assistance program.........6-2
S
Safety
Child safety rear door lock.........3-6Child seat belts. . .1-21, 1-28, 1-34, 1-38Reporting safety defects (US only). .10-22SeatMemory seat........... .3-37, 3-39Seat adjustment
Front power seat adjustment.......1-3Rear bench seats.............. .1-4
11-5
