Page 2119 of 3371
GI-38
CONSULT-II CHECKING SYSTEM
Revision: August 20072004 QX56
Nickel Metal Hydride Battery Replacement EAS0014S
CONSULT-II contains a nickel metal hydride battery. When replacing the battery obey the following:
WAR NIN G:
Replace the nickel metal hydride battery with Genuine CONSULT-II battery only. Use of another bat-
tery may present a risk of fire or explosion. The battery may present a fire or chemical burn hazard if
mistreated. Do not recharge, disassemble or dispose of in fire.
Keep the battery out of reach of children and discard used battery conforming to the local regulations.
Checking EquipmentEAS0014T
When ordering the below equipment, contact your NISSAN distributor.
CAUTION:
Previous CONSULT-II “I” and “Y” DLC-I and DLC-II cables should NOT be used anymore because
their DDL connector pins can be damaged during cable swapping.
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self- diagnosis depending on control unit which carries out CAN communication.
If CONSULT-II CONVERTER is not connected with CONSULT-II, the vehicle enters “FAIL SAFE
MODE” which will “LIGHT UP the HEAD LIGHT” and /or “COOLING FAN ROTATING” when CON-
SULT-II is started.
NOTE:
The CONSULT-II must be used in conjunction with a program card.
CONSULT-II does not require loading (Initialization) procedure.
Be sure the CONSULT-II is turned OFF before installing or removing a program card.
CONSULT-II Start ProcedureEAS0014U
NOTE:
Turning ignition switch off when performing CAN diagnosis could cause CAN memory to be erased.
1. Connect CONSULT-II and CONSULT-II CONVERTER to the
data link connector.
Tool name Description
NISSAN CONSULT-II (J-44200)
1. CONSULT-II unit (Tester internal soft: Resident
Version 3.4.0) and accessories.
2. Program card UED04D-1 and AEN04A-1 (for
NATS) or later, to confirm the best combination
of these software, refer to CONSULT-II Opera-
tion Manual.
3. CONSULT-II CONVERTER.
4. "CONSULT-II pigtail" cable.
SAIA0363E
PAIA0070E
Page 2120 of 3371
CONSULT-II CHECKING SYSTEM
GI-39
C
D
E
F
G
H
I
J
K
L
MB
GI
Revision: August 20072004 QX56
2. If necessary, turn on the ignition switch.
3. Touch “START (NISSAN BASED VHCL)” or System Shortcut
key (eg: ENGINE) on the screen.
CONSULT-II Data Link Connector (DLC) CircuitEAS001SM
INSPECTION PROCEDURE
If the CONSULT-II cannot diagnose the system properly, check the following items:
NOTE:
The preceding schematic is an example and may not be a true representation of the vehicle. The actual DDL1
circuits (CAN lines) from DLC pins 6 and 14 as well as the DDL2 circuit (K-line) from DLC pin 7 may be con-
nected to more than one system. A short in a DDL circuit connected to a control unit in one system may affect
CONSULT-II access to other systems.
BCIA0029E
LAIA0028E
Symptom Check item
CONSULT-II cannot access
any system.
CONSULT-II DLC power supply circuit (Terminal 8) and ground circuit (Terminal 4). For detailed cir-
cuit, refer to LAN-5, "
CAN Communication Unit" .
CONSULT-II DLC cable and CONSULT-II CONVERTER.
CONSULT-II cannot access
individual system. (Other sys-
tems can be accessed.)
CONSULT-II program card (Check the appropriate CONSULT-II program card for the system.
Refer to GI-38, "
Checking Equipment" .
Power supply and ground circuit for the control unit of the system (For detailed circuit, refer to wir-
ing diagram for each system.)
Open or short circuit between the system and CONSULT-II DLC (For detailed circuit, refer to wiring
diagram for each system.)
Open or short circuit in CAN or K communication line. Refer to LAN-3, "Precautions When Using
CONSULT-II" .
Page 2136 of 3371
GW-1
GLASSES, WINDOW SYSTEM & MIRRORS
I BODY
CONTENTS
C
D
E
F
G
H
J
K
L
M
SECTION GW
A
B
GW
Revision: August 20072004 QX56 PRECAUTIONS .......................................................... 3
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” .................................................................. 3
Handling for Adhesive and Primer ........................... 3
Trouble Diagnosis Precaution .................................. 3
PREPARATION ........................................................... 4
Special Service Tool ................................................. 4
Commercial Service Tool ......................................... 4
SQUEAK AND RATTLE TROUBLE DIAGNOSES ..... 5
Work Flow ................................................................ 5
CUSTOMER INTERVIEW ..................................... 5
DUPLICATE THE NOISE AND TEST DRIVE ....... 6
CHECK RELATED SERVICE BULLETINS ........... 6
LOCATE THE NOISE AND IDENTIFY THE
ROOT CAUSE ...................................................... 6
REPAIR THE CAUSE ........................................... 6
CONFIRM THE REPAIR ....................................... 7
Generic Squeak and Rattle Troubleshooting ........... 7
INSTRUMENT PANEL .......................................... 7
CENTER CONSOLE ............................................. 7
DOORS ................................................................. 7
TRUNK .................................................................. 8
SUNROOF/HEADLINER ....................................... 8
OVERHEAD CONSOLE (FRONT AND REAR) ..... 8
SEATS ................................................................... 8
UNDERHOOD ....................................................... 8
Diagnostic Worksheet .............................................. 9
WINDSHIELD GLASS ...............................................11
Removal and Installation .........................................11
REMOVAL ............................................................11
INSTALLATION ....................................................11
REAR WINDOW GLASS AND MOLDING ............... 13
Removal and Installation ........................................ 13
REMOVAL ........................................................... 13
INSTALLATION ................................................... 14
POWER WINDOW SYSTEM .................................... 15
Component Parts and Harness Connector Location ... 15
System Description ................................................ 15
MANUAL OPERATION ....................................... 16AUTO OPERATION ............................................. 18
POWER WINDOW SERIAL LINK ....................... 18
POWER WINDOW LOCK ................................... 18
RETAINED POWER OPERATION ...................... 18
ANTI-PINCH SYSTEM ........................................ 18
POWER WINDOW CONTROL BY THE FRONT
DOOR LOCK ASSEMBLY LH (KEY CYLINDER
SWITCH) ............................................................. 19
CAN Communication System Description .............. 19
Schematic ............................................................... 20
Wiring Diagram — WINDOW — ............................. 22
Terminal and Reference Value for Main Power Win-
dow and Door Lock/Unlock Switch ......................... 30
Terminal and Reference Value for Power Window
and Door Lock/Unlock Switch RH .......................... 30
Terminal and Reference Value for BCM ................. 32
Work Flow ............................................................... 33
CONSULT-II Function (BCM) ................................. 33
CONSULT-II INSPECTION PROCEDURE .......... 33
ACTIVE TEST ..................................................... 34
WORK SUPPORT ............................................... 34
DATA MONITOR ................................................. 34
Trouble Diagnoses Symptom Chart ....................... 36
BCM Power Supply and Ground Circuit Check ...... 38
Main Power Window and Door Lock/Unlock Switch
Power Supply and Ground Circuit Check ............... 39
Power Window and Door Lock/Unlock Switch RH
Power Supply and Ground Circuit Check ............... 40
Front Power Window Motor LH Circuit Check ........ 41
Front Power Window Motor RH Circuit Check ....... 42
Limit Switch Circuit Check Front LH ....................... 43
Limit Switch Circuit Check Front RH ...................... 44
Encoder Circuit Check Front LH ............................. 46
Encoder Circuit Check Front RH ............................ 48
Door Switch Check ................................................. 50
Front Door Lock Assembly LH (Key Cylinder Switch)
Check ..................................................................... 52
Power Window Serial Link Check Front LH and RH ... 54
Rear Power Window Control Unit LH or RH Power
Supply and Ground Circuit Check .......................... 56
Page 2137 of 3371
GW-2Revision: August 20072004 QX56 Rear Power Window Switch LH or RH Power Supply
and Ground Circuit Check ...................................... 58
Rear Power Window Motor LH Circuit Check ......... 58
Rear Power Window Motor RH Circuit Check ........ 59
Limit Switch Circuit Check Rear LH and RH ........... 60
Encoder Circuit Check Rear LH or RH ................... 62
Power Window Serial Link Check Rear LH or RH ... 64
Rear Power Vent Window Switch Circuit Check ..... 65
Rear Power Vent Window Motor LH Circuit Check ... 65
Rear Power Vent Window Motor RH Circuit Check ... 66
Rear Power Vent Window Relay (OPEN) Check .... 66
Rear Power Vent Window Relay (CLOSE) Check ... 67
FRONT DOOR GLASS AND REGULATOR ............. 69
Removal and Installation ........................................ 69
FRONT DOOR GLASS ....................................... 69
FRONT DOOR GLASS REGULATOR ................ 70
FITTING INSPECTION AND SETTING AFTER
INSTALLATION .................................................... 70
REAR DOOR GLASS AND REGULATOR ............... 72
Removal and Installation ........................................ 72
REAR DOOR GLASS .......................................... 72
REAR DOOR GLASS REGULATOR ................... 73
SIDE WINDOW GLASS ............................................ 75
Removal and Installation ........................................ 75
REMOVAL ........................................................... 75
INSTALLATION .................................................... 75
INSIDE MIRROR ....................................................... 76
Wiring Diagram — I/MIRR — ................................. 76
Removal and Installation ........................................ 77
INSIDE MIRROR ................................................. 77
REAR WINDOW DEFOGGER .................................. 78
Component Parts and Harness Connector Location ... 78
System Description ................................................. 79CAN Communication System Description ..............80
Schematic ...............................................................81
Wiring Diagram — DEF — ......................................82
Terminal and Reference Value for BCM ..................85
Terminal and Reference Value for IPDM E/R ..........85
Work Flow ...............................................................85
CONSULT-II Function (BCM) ..................................86
CONSULT-II BASIC OPERATION PROCEDURE
...86
DATA MONITOR ..................................................87
ACTIVE TEST ......................................................87
Trouble Diagnoses Symptom Chart ........................87
BCM Power Supply and Ground Circuit Check ......89
Rear Window Defogger Switch Circuit Check .........90
Rear Window Defogger Power Supply Circuit
Check ......................................................................91
Rear Window Defogger Circuit Check ....................92
Door Mirror Defogger Power Supply Circuit Check ...92
Door Mirror LH Defogger Circuit Check ..................94
Door Mirror RH Defogger Circuit Check .................95
Rear Window Defogger Signal Check ....................96
Filament Check .......................................................96
Filament Repair .......................................................97
REPAIR EQUIPMENT .........................................97
REPAIRING PROCEDURE .................................97
DOOR MIRROR .........................................................99
Wiring Diagram — MIRROR — ..............................99
Door Mirror Assembly ........................................... 100
REMOVAL .......................................................... 100
INSTALLATION .................................................. 100
Door Mirror Glass .................................................. 100
REMOVAL .......................................................... 100
INSTALLATION .................................................. 101
Page 2154 of 3371
POWER WINDOW SYSTEM
GW-19
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: August 20072004 QX56
POWER WINDOW CONTROL BY THE FRONT DOOR LOCK ASSEMBLY LH (KEY CYLINDER
SWITCH)
When ignition key switch is OFF, front power window LH and RH can be opened or closed by turning the front
door lock assembly LH (key cylinder switch) to the UNLOCK / LOCK position for more than 3 seconds.
Front power windows can be opened as the front door lock assembly LH (key cylinder switch) is kept fully
turned to the UNLOCK position.
Front power windows can be closed as the front door lock assembly LH (key cylinder switch) is kept fully
turned to the LOCK position.
While performing open/close operation for the windows, power window is stopped when the front door
lock assembly LH (key cylinder switch) is placed in the NEUTRAL position.
When the ignition switch is turned ON while the power window opening operation is performed, the power
window opening stops.
CAN Communication System DescriptionEIS002UO
Refer to LAN-5, "CAN COMMUNICATION" .
Page 2168 of 3371
POWER WINDOW SYSTEM
GW-33
C
D
E
F
G
H
J
K
L
MA
B
GW
Revision: August 20072004 QX56
Work FlowEIS002UU
1. Check the symptom and customer's requests.
2. Understand the outline of system. Refer to GW-15, "
System Description" .
3. According to the trouble diagnosis chart, repair or replace the cause of the malfunction.
Refer to GW-36, "
Trouble Diagnoses Symptom Chart" .
4. Does power window system operate normally? Yes, GO TO 5, If No, GO TO 3.
5. INSPECTION END.
CONSULT-II Function (BCM)EIS002UV
CONSULT-II can display each diagnostic item using the diagnostic test modes shown following.
CONSULT-II INSPECTION PROCEDURE
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carry out CAN communication.
1. Connect CONSULT-II and CONSULT-II CONVERTER to the
data link connector.
2. Turn ignition switch ON.
3. Touch “START (NISSAN BASED VHCL)”.
BCM diagnostic
test itemDiagnostic mode Content
Inspection by partWORK SUPPORT Changes setting of each function.
DATA MONITOR Displays BCM input/output data in real time.
ACTIVE TEST Operation of electrical loads can be checked by sending drive signal to them.
SELF-DIAG RESULTS Displays BCM self-diagnosis results.
CAN DIAG SUPPORT MNTR The results of transmit/receive diagnosis of CAN communication can be read.
ECU PART NUMBER BCM part number can be read.
CONFIGURATION Performs BCM configuration read/write functions.
BBIA0369E
BCIA0029E
Page 2215 of 3371
GW-80
REAR WINDOW DEFOGGER
Revision: August 20072004 QX56
CAN Communication System DescriptionEIS002VO
Refer to LAN-5, "CAN COMMUNICATION" .
Page 2221 of 3371
GW-86
REAR WINDOW DEFOGGER
Revision: August 20072004 QX56
CONSULT-II Function (BCM)EIS002VU
CONSULT-II can display each diagnostic item using the diagnostic test modes shown following.
CONSULT-II BASIC OPERATION PROCEDURE
CAUTION:
If CONSULT-II is used with no connection of CONSULT-II CONVERTER, malfunctions might be
detected in self-diagnosis depending on control unit which carries out CAN communication.
1. Turn ignition switch OFF.
2. Connect CONSULT-II and CONSULT-II CONVERTER to data
link connector.
3. Turn ignition switch ON.
4. Touch “START (NISSAN BASED VHCL)”.
5. Touch “BCM”.
If “BCM” is not indicated, go to GI-39, "
CONSULT-II Data Link
Connector (DLC) Circuit" .
BCM diagnostic
test itemDiagnostic mode Content
Inspection by partWORK SUPPORT Changes setting of each function.
DATA MONITOR Displays BCM input/output data in real time.
ACTIVE TEST Operation of electrical loads can be checked by sending drive signal to them.
SELF-DIAG RESULTS Displays BCM self-diagnosis results.
CAN DIAG SUPPORT MNTR The results of transmit/receive diagnosis of CAN communication can be read.
ECU PART NUMBER BCM part number can be read.
CONFIGURATION Performs BCM configuration read/write functions.
BBIA0369E
BCIA0029E
BCIA0030E
Page 2231 of 3371
GW-96
REAR WINDOW DEFOGGER
Revision: August 20072004 QX56
3. CHECK DOOR MIRROR DEFOGGER
Check continuity between door mirror RH terminals 10 and 11.
OK or NG
OK >> Repair or replace harness.
NG >> Replace door mirror RH.
Rear Window Defogger Signal CheckEIS002W6
1. CHECK AV COMMUNICATION LINE
AV communication line check is executed. Refer to AT C - 3 2 , "
CAN Communication System Description" .
OK or NG
OK >> GO TO 2.
NG >> Replace display control unit.
2. CHECK CAN COMMUNICATION LINE
CAN communication line check is executed. Refer to LAN-5, "
CAN COMMUNICATION" .
OK or NG
OK >> Check the condition of the harness and the connector.
NG >> In addition, it is necessary to check CAN communication line. Refer to LAN-5, "
CAN COMMUNI-
CATION" .
Filament CheckEIS002W7
1. When measuring voltage, wrap tin foil around the top of the neg-
ative probe.Then press the foil against the wire with your finger.
2. Attach probe circuit tester (in Volt range) to middle portion of
each filament.10 - 11 : Continuity should exist.
LIIA2305E
Is rear window defogger displayed on the display?
SEL122R
SEL263
Page 2239 of 3371
IDX-2
ALPHABETICAL INDEX
Numerics
2-4WD shift solenoid valve ................................ TF-95
4LO indicator lamp ............................................. TF-90
4WD shift indicator lamp .................................... TF-85
4WD shift switch ................................................ TF-95
4WD solenoid valve ........................................... TF-95
4WD warning lamp ............................................ TF-13
A
A/C air flow ...................................................... ATC-29
A/C compressor clutch removal and installation .. ATC-
167
A/C compressor mounting ............................. ATC-166
A/C compressor precaution ............................. ATC-11
A/C compressor special service tool ................ ATC-14
A/C control operation (auto A/C) ...................... ATC-26
A/C diagnostic work flow (auto A/C) .............. ATC-120
A/C evaporator ............................................... ATC-175
A/C HFC134a (R134a) system identification ..... ATC-7
A/C HFC134a (R134a) system precaution ........ ATC-5
A/C HFC134a (R134a) system service procedure ATC-
162
A/C HFC134a (R134a) system service tools ... ATC-14
A/C HFC134a system service equipment precaution ...
ATC-11
A/C lubricant (R134a) ...................................... ATC-22
A/C lubrication oil ............................................. ATC-22
A/C operational check ....................... ATC-56, ATC-59
A/C self-diagnoses (auto A/C) ........ ATC-53, ATC-120
A/C service data specification ........................ ATC-182
A/C trouble diagnoses (auto A/C) .................... ATC-33
A/C, A - Wiring diagram ................................... ATC-41
A/T - Wiring diagram .......................................... AT-52
A/T fluid checking ...................... AT-13, AT-58, MA-21
A/T fluid cooler cleaning .................................... AT-15
A/T fluid replacement ............................. AT-13, MA-23
A/T fluid temperature sensor ........................... AT-131
A/T IND - Wiring diagram .................................... DI-41
A/T indicator ........................................................ DI-41
A/T shift lock system ........................................ AT-236
A/T trouble diagnoses ........................................ AT-43
ABS - Wiring diagram ..................................... BRC-16
ABS (anti-lock brake system) ........................... BRC-7
Accelerator control system ............................... ACC-2
Accelerator pedal position (APP) sensor . EC-556, EC-
562, EC-576
Accelerator pedal released position learning ..... EC-44
AF1B1-Wiring diagram EC-431, EC-439, EC-447, EC-
456, EC-466, EC-475, EC-487
AF1B2-Wiring diagram EC-433, EC-441, EC-449, EC-
458, EC-468, EC-477, EC-489
AF1HB1-Wiring diagram .................................. EC-355
AF1HB2-Wiring diagram .................................. EC-357
Aiming adjustment .................................. LT-31, LT-78
Air bag .............................................................. SRS-3
Air cleaner and air duct ..................................... EM-14
Air cleaner filter replacement ............................ MA-15
Air conditioner cut control ................................. EC-30
Air flow meter - See Mass air flow sensor EC-146, EC-
154
Air fuel ratio sensor 1 .. EC-429, EC-437, EC-445, EC-
454, EC-463, EC-472, EC-484
Air fuel ratio sensor 1 heater ........................... EC-354
Air mix. door motor .......................................... ATC-67
All - mode 4WD system ..................................... TF-10
Ambient sensor ............................. ATC-125, ATC-136
Angular tightening application ............................. EM-3
APPS1 - Wiring diagram ................................. EC-558
APPS2 - Wiring diagram ................................. EC-564
APPS3 - Wiring diagram ................................. EC-578
ASC/BS - Wiring diagram ............................... EC-536
ASC/SW - Wiring diagram .............................. EC-519
ASCBOF - Wiring diagram .............................. EC-622
ASCD .............................................................. EC-647
ASCD (automatic speed control device) ........... ACS-3
ASCD brake switch ........................... EC-534, EC-621
ASCD indicator lamp ....................................... EC-628
ASCD steering switch ..................................... EC-517
ASCIND - Wiring diagram ............................... EC-629
ATP switch ......................................................... TF-96
ATP warning lamp .............................................. TF-89
AUDIO - Wiring diagram .................................... AV-10
AUT/DP - Wiring diagram .................................. SE-19
Auto air conditioner - Wiring diagram .............. ATC-41
Auto anti-dazzling inside mirror ........... GW-76, GW-77
Autolamp ............................................................ LT-47
Automatic amplifier ......................................... ATC-60
Automatic transmission number .......................... GI-48
AV and NAVI control unit ................................... AV-63
AV communication line ...................................... AV-87
B
Back door trim ..................................................... EI-31
Back sonar .......................................................... DI-59
BACK/L - Wiring diagram ................................. LT-106
Back-up lamp ................................................... LT-106
Ball joint (front) ................................................ FSU-15
Basic inspection ................................................ EC-79
Battery ................................................................. SC-4
Battery/Starting/Charging System Tester SC-6, SC-12,
SC-19
BCM (Body control module) .............................. BCS-3
Block heater ...................................................... EM-73
Blower motor ................................... ATC-83, ATC-140
Body alignment ................................................ BL-174
Body component parts ..................................... BL-161
Body construction ............................................ BL-173
Body exterior paint color .................................. BL-160
Body mounting ................................................. BL-159
Body repair ....................................................... BL-160
Body sealing .................................................... BL-170
Brake booster .................................................... BR-17
Brake fluid level ................................................. MA-27
Brake hydraulic line ........................................... BR-12
Brake inspection ............................................... MA-28
