LT-32
HEADLAMP (FOR USA)
Revision: August 20072004 QX56
If the vehicle front body has been repaired and/or the headlamp assembly has been replaced, check aiming.
Use the aiming chart shown in the figure.

Basic illuminating area for adjustment should be within the range shown on the aiming chart.
Adjust headlamps accordingly.
Bulb Replacement EKS007A7
HEADLAMP (OUTER SIDE), FOR LOW BEAM
1. Position fender protector aside.
2. Turn headlamp switch OFF.
3. Disconnect battery ground cable.
4. Remove ballast.
5. Disconnect the electrical connector.
6. Release bulb retaining spring and pull bulb straight out.
7. Installation is in the reverse order of removal.
HEADLAMP (INNER SIDE), FOR HIGH BEAM
1. Turn headlamp switch OFF.
2. Disconnect the electrical connector.
3. Turn the bulb counterclockwise to remove it.
4. Installation is in the reverse order of removal.
FRONT PARKING LAMP (INNER OR OUTER)
1. Turn the bulb socket counterclockwise to unlock it.
2. Pull the bulb to remove it from the socket.
3. Installation is in the reverse order of removal.
FRONT SIDE MARKER LAMP
1. Position fender protector aside.
2. Turn the bulb socket counterclockwise to unlock it.
3. Pull the bulb to remove it from the socket.
WKIA3894E

LT-64
AUTO LIGHT SYSTEM
Revision: August 20072004 QX56
Removal and Installation of Optical SensorEKS007B3
REMOVAL
1. Remove defrost grille. Refer to IP-10, "INSTRUMENT PANEL ASSEMBLY" .
2. Disconnect the connector.
3. Turn the optical sensor counterclockwise to remove it from
defroster grille.
INSTALLATION
Installation is in the reverse order of removal.
WKIA1061E

LT-78
FRONT FOG LAMP
Revision: August 20072004 QX56
Aiming AdjustmentEKS007BF
The fog lamp is a semi-sealed beam type which uses a replaceable halogen bulb. Before performing aiming
adjustment, make sure of the following.

Keep all tires inflated to correct pressure.

Place vehicle on level ground.

See that vehicle is unloaded (except for full levels of coolant,
engine oil and fuel, and spare tire, jack, and tools). Have the
driver or equivalent weight placed in driver seat.
Adjust aiming in the vertical direction by turning the adjustment
screw.
NOTE:
Access adjustment screw from underneath front bumper. Turn screw
clockwise to raise pattern and counterclockwise to lower pattern.
1. Set the distance between the screen and the center of the fog
lamp lens as shown.
2. Turn front fog lamps ON.
3. Adjust front fog lamps using adjusting screw so that the top edge
of the high intensity zone is 200 mm (7.9 in) below the height of
the fog lamp centers as shown.

When performing adjustment, if necessary, cover the headlamps
and opposite fog lamp.
SEL350X
MEL327G
MEL328GA

FRONT FOG LAMP
LT-79
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: August 20072004 QX56
Bulb Replacement EKS007BG
1. Remove the front turn/fog lamp assembly. Refer to LT-79, "Removal and Installation" .
2. Turn the bulb cover counterclockwise to remove it.
3. Unlatch retaining spring.
4. Remove bulb and disconnect the connector.
CAUTION:

Do not touch the glass of bulb directly by hand. Keep
grease and other oily substances away from it. Do not
touch bulb by hand while it is lit or right after being
turned off. Burning may result.

Do not leave bulb out of fog lamp reflector for a long time
because dust, moisture smoke, etc. may affect the perfor-
mance of fog lamp. When replacing bulb, be sure to
replace it with new one.
Installation is in the reverse order of removal.
Removal and InstallationEKS007BH
The fog lamp is a semi-sealed beam type which uses a replaceable halogen bulb.
CAUTION:

Do not leave fog lamp assembly without bulb for a long period of time. Dust, moisture, smoke, etc.
entering the fog lamp body may affect the performance. Remove the bulb from the headlamp
assembly just before replacement bulb is installed.

Grasp only the plastic base when handling the bulb. Never touch the glass envelope. Touching the
glass could significantly affect the bulb life and/or fog lamp performance.
1. Remove the front turn/fog lamp finisher.
2. Remove bolt and pull fog lamp out of front fascia.
3. Disconnect electrical connector.
Installation is in the reverse order of removal.
WKIA1886E
WKIA1887E
: 5.3 Nm (0.54 kg-m, 47 in-lb)
WKIA1888E

LT-94
TURN SIGNAL AND HAZARD WARNING LAMPS
Revision: August 20072004 QX56
Bulb Replacement (Front Turn Signal Lamp)EKS007BU
1. Remove turn/fog lamp assembly. Refer to LT- 7 9 , "Removal and Installation" .
2. Turn bulb socket counterclockwise to remove it from lamp housing.
3. Pull bulb from socket.
Installation is in the reverse order of removal.
Bulb Replacement (Rear Turn Signal Lamp)EKS007BV
Refer to LT- 1 2 2 , "Bulb Replacement (Turn Signal)" in REAR COMBINATION LAMP.
Removal and Installation of Front Turn Signal LampEKS007BW
Refer to LT- 3 3 , "Removal and Installation" .
Removal and Installation of Rear Turn Signal Lamp EKS007BX
Refer to LT- 1 2 2 , "Removal and Installation" in REAR COMBINATION LAMP.

BACK-UP LAMP
LT-107
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: August 20072004 QX56
Bulb ReplacementEKS007CB
1. Remove back door lower finisher. Refer to EI-41, "Removal and Installation" .
2. Turn bulb socket counterclockwise and remove it from the lamp housing.
3. Pull bulb from socket.
Installation is in the reverse order of removal.
Removal and InstallationEKS007CC
1. Remove license lamp finisher. Refer to EI-24, "Removal and Installation" .
2. Carefully release tabs to remove back up lamp housing from
license plate finisher.
Installation is in the reverse order of removal.
WKIA1898E

PARKING, LICENSE PLATE AND TAIL LAMPS
LT-121
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: August 20072004 QX56
Front Parking LampEKS007CP
BULB REPLACEMENT
For bulb replacement, refer to LT- 3 2 , "FRONT PARKING LAMP (INNER OR OUTER)" or LT-32, "FRONT
SIDE MARKER LAMP" .
Tail LampEKS007CQ
BULB REPLACEMENT
The tail lamp bulbs are not serviceable separately. Replace rear combination lamp. Refer to LT-122, "Removal
and Installation" .
License Plate LampEKS007TR
BULB REPLACEMENT
1. Remove back door lower finisher. Refer to EI-41, "Removal and Installation" .
2. Turn bulb socket counterclockwise to remove it.
3. Pull bulb from socket.
Installation is in the reverse order of removal.

LT-122
REAR COMBINATION LAMP
Revision: August 20072004 QX56
REAR COMBINATION LAMPPFP:26554
Bulb Replacement (Turn Signal)EKS007CR
NOTE:
The tail/stop lamp bulbs are LEDs and are not serviceable separately.
1. Remove rear combination lamp mounting bolts.
2. Pull rear combination lamp to remove from the vehicle.
3. Turn bulb socket counterclockwise and unlock it.
4. Remove bulb.
Installation is in the reverse order of removal.
Removal and InstallationEKS007CS
1. Remove rear combination lamp mounting bolts.
2. Pull rear combination lamp to remove from the vehicle.
3. Disconnect rear combination lamp connectors.
Installation is in the reverse order of removal.
WKIA1393E
Rear combination lamp
mounting bolts: 2.4 Nm (0.24 kg-m, 21 in-lb)
WKIA1393E

ILLUMINATION
LT-153
C
D
E
F
G
H
I
J
L
MA
B
LT
Revision: August 20072004 QX56

to ignition relay, located in the IPDM E/R.
With the ignition switch in the ON or START position, power is supplied

through 10A fuse (No. 59, located in the fuse and relay box)

to BCM terminal 38, and

to ignition relay in the IPDM E/R, and

through 10A fuse [No. 14, located in the fuse block (J/B)]

to combination meter terminal 24.
Ground is supplied

to BCM terminal 67 and

to combination meter terminal 17

through grounds M57, M61 and M79, and

to IPDM E/R terminals 38 and 59

through grounds E9, E15 and E24.
ILLUMINATION OPERATION BY LIGHTING SWITCH
With the lighting switch in the 1ST or 2ND position (or if the auto light system is activated), the BCM receives
input signal requesting the illumination lamps to illuminate. This input signal is communicated to the IPDM E/R
across the CAN communication lines. The CPU of the IPDM E/R controls the tail lamp relay coil, which, when
energized, directs power

through 10A fuse (No. 36, located in the IPDM E/R)

through IPDM E/R terminal 49

to illumination control switch terminal 1

to power liftgate switch terminal 3

to front room/map lamp assembly (console box illumination) terminal 7

to hazard switch terminal 3

to rear sonar system OFF switch terminal 3

to glove box lamp terminal +

to display control unit terminal 14

to 4WD shift switch terminal 7 (with 4-wheel drive)

to front air control terminal 23

to rear power vent window switch terminal 5

to DVD player terminal 12 (with DVD entertainment system)

to NAVI control unit terminal 25

to pedal adjusting switch terminal 5

to electric brake (pre-wiring) terminal 4

to heated seat switches terminal 5

to A/T device terminal 11

to VDC OFF switch terminal 3

to tow mode switch terminal 3

to headlamp aiming switch terminal 3

to clock terminal 3

to compass and thermometer terminal 4, and

through 10A fuse (No. 37, located in the IPDM E/R)

through IPDM E/R terminal 57

to AV switch terminal 3

to audio unit terminal 8

to rear air control terminal 1 and

to rear audio remote control unit terminal 6.
Illumination is controlled

through illumination control switch terminal 2

LT-154
ILLUMINATION
Revision: August 20072004 QX56

to power liftgate switch terminal 4

to front room/map lamp assembly (console box illumination) terminal 8

to AV switch terminal 4

to hazard switch terminal 4

to audio unit terminal 7

to rear sonar system OFF switch terminal 4

to 4WD switch terminal 8 (with 4-wheel drive)

to front air control terminal 24 and

to rear power vent window switch terminal 6

to DVD player terminal 10 (with DVD entertainment system)

to pedal adjusting switch terminal 6

to A/T device terminal 12

to front heated seat switches terminal 6

to VDC OFF switch terminal 4

to tow mode switch terminal 4

to headlamp aiming switch terminal 4

to clock terminal 4 and

to combination meter terminal 18.
Ground is supplied

to illumination control switch terminal 3

to glove box lamp terminal –

to display control unit terminal 3

to rear heated seat switches terminal 6

to electric brake (pre-wiring) terminal 1 and

to compass and thermometer terminal 7

through grounds M57, M61 and M79, and

to NAVI control unit terminal 30

to rear air control terminal 3 and

to rear audio remote control unit terminal 15

through grounds B117 and B132.
With power and ground supplied, illumination lamps illuminate.
EXTERIOR LAMP BATTERY SAVER CONTROL
When the combination switch (lighting switch) is in the 1ST or 2ND position (or if auto light system is acti-
vated), and the ignition switch is turned from ON or ACC to OFF, the battery saver control function is activated.
Under this condition, the illumination lamps remain illuminated for 5 minutes, then the illumination lamps are
turned off.
When the lighting switch is turned from OFF to 1ST or 2ND position (or if auto light system is activated) after
illumination lamps are turned off by the battery saver control, the illumination lamps illuminate again.
Exterior lamp battery saver control mode can be changed by the function setting of CONSULT-II.
CAN Communication System DescriptionEKS007DB
Refer to LAN-5, "CAN COMMUNICATION" .
